Allen-Bradley ControlNet 1786-RPFM User manual

Publication 1786-IN011B-EN-P - October 2000
Installation Instructions
ControlNet Modular Repeater
Medium Distance Fiber Module
Cat. Nos. 1786-RPFM
Use this document as a guide when you install a ControlNet™repeater fiber module for
medium distances. This document contains:
This product is associated with a planning and installation guide, publication
CNET-IN001A-EN-P, The ControlNet Fiber Media Planning and Installation Guide.
To view it, visit www.ab.com/manuals or www.theautomationbookstore.com
Topic: Page:
Important User Information 2
EMC Directive 3
Low Voltage Directive 3
Fiber Optic Safety Statements 4
Rockwell Automation Support 4
About the Fiber Module 6
Mount the Fiber Module 7
Remove the Protective Caps 10
Choose Fiber Cable Types 11
Specifications for 1786-RPFM Fiber Optic Cable 12
Estimate Cable Lengths 12
Connect the Fiber Cable 13
Example Topology 14
Status Indicators 15
Related Publications 16
Mounting Dimensions 16
Specifications 17
Hazardous Location Approval 19
AB PLCs

2ControlNet Modular Repeater Medium Distance Fiber Module
Publication 1786-IN011B-EN-P - October 2000
You can purchase a printed manual by:
•contacting your local distributor or Rockwell Automation representative
•visiting www.theautomationbookstore.com and placing an order
•calling 800.963.9548 (USA/Canada) or 001.320.725.1574 (outside USA/Canada)
Important User Information
Because of the variety of uses for the products described in this publication, those
responsible for the application and use of this control equipment must satisfy
themselves that all necessary steps have been taken to assure that each application
and use meets all performance and safety requirements, including any applicable
laws, regulations, codes and standards.
The illustrations, charts, sample programs and layout examples shown in this guide
are intended solely for purposes of example. Since there are many variables and
requirements associated with any particular installation, Allen-Bradley does not
assume responsibility or liability (to include intellectual property liability) for actual
use based upon the examples shown in this publication.
Allen-Bradley publication SGI-1.1, Safety Guidelines for the Application, Installation
and Maintenance of Solid-State Control (available from your local Allen-Bradley
office), describes some important differences between solid-state equipment and
electromechanical devices that should be taken into consideration when applying
products such as those described in this publication.
Reproduction of the contents of this copyrighted publication, in whole or part,
without written permission of Rockwell Automation, is prohibited.
Throughout this manual we use notes to make you aware of safety considerations:
Attention statements help you to:
•identify a hazard
•avoid a hazard
•recognize the consequences
Allen-Bradley is a trademark of Rockwell Automation
ATTENTION
!
Identifies information about practices or circumstances that can
lead to personal injury or death, property damage or economic
loss
IMPORTANT
Identifies information that is critical for successful application
and understanding of the product.

ControlNet Modular Repeater Medium Distance Fiber Module 3
Publication 1786-IN011B-EN-P - October 2000
European Communities (EC) Directive Compliance
If this product has the CE mark it is approved for installation within the European
Union and EEA regions. It has been designed and tested to meet the following
directives.
EMC Directive
This product is tested to meet the Council Directive 89/336/EC Electromagnetic
Compatibility (EMC) by applying the following standards, in whole or in part,
documented in a technical construction file:
•EN 50081-2 EMC — Generic Emission Standard, Part 2 — Industrial
Environment
•EN 50082-2 EMC — Generic Immunity Standard, Part 2 — Industrial
Environment
This product is intended for use in an industrial environment.
Low Voltage Directive
This product is tested to meet Council Directive 73/23/EEC Low Voltage, by
applying the safety requirements of EN 61131-2 Programmable Controllers, Part 2 -
Equipment Requirements and Tests. For specific information required by EN
61131-2, see the appropriate sections in this publication, as well as the
Allen-Bradley publication Industrial Automation Wiring and Grounding Guidelines,
publication 1770-4.1.
This equipment is classified as open equipment and must be mounted in an
enclosure during operation to provide safety protection.
AB PLCs

4ControlNet Modular Repeater Medium Distance Fiber Module
Publication 1786-IN011B-EN-P - October 2000
Fiber Optic Safety Statements
Rockwell Automation Support
Rockwell Automation offers support services worldwide, with over 75 sales/support
offices, over 500 authorized distributors, and 260 authorized systems integrators
located throughout the United States alone, plus Rockwell Automation
representatives in every major country around the world. Contact your local
Rockwell Automation representative for:
•sales and order support
•product technical training
•warranty support
•support service agreements
ATTENTION
!
Do not look directly into the fiber ports. Light levels will cause
damage to your eyesight.
ATTENTION
!
"Hazardous areas require the use of specifically designed
products. This product is designed for Class I, Division 2
hazardous environments, and nonhazardous environments
only. Allen-Bradley provides similar products which are
intrinsically safe and are suitable for more hazardous
environments. Use the appropriate products that are designed
for the specific hazardous environments that your installation
requires.
In intrinsically safe applications, consult with your local safety
coordinator, and publication CNET-IN003A-US-P, the
ControlNet EX Media Planning and Installation Manual because
you need specific products on both ends of the fiber link."

ControlNet Modular Repeater Medium Distance Fiber Module 5
Publication 1786-IN011B-EN-P - October 2000
Obtain Pre-Sales Product Support
If you need to contact Rockwell Automation for pre-sales product support, try one
of the following methods:
•Call your local Rockwell Automation representative
•Network pre-sales support line, 1.440.646.3638 (3NET)
•Pre-Sales e-mail, [email protected]l.com
Obtain Technical Product Support
If you need to contact Rockwell Automation for technical assistance, try one of the
following methods:
Type of technical support: Access at:
Personalized Service Call your local Rockwell Automation representative
Post-sales Technical Support 1.440.646.5800
Email your questions to racleaskt[email protected]m
Internet site www.ab.com, then select Product Support
or
www.ab.com/support/products/pccards.html
Note: You can access Rockwell Automation Knowledge
Documents from this internet address.
AB PLCs

6ControlNet Modular Repeater Medium Distance Fiber Module
Publication 1786-IN011B-EN-P - October 2000
About the Fiber Module
Use this module when a medium-distance (distances of 3000m/ 9843ft) fiber link is
required between two ControlNet products. This fiber link provides ground
isolation between nodes and is less susceptible to noisy environments than
traditional copper media.
The module provides:
•two fiber channels
•activity LED indicators for each fiber channel
Figure 1 Components of the Module
IMPORTANT The distance that can be supported is dependent on the quality
of the fiber, number of splices, and connectors. The total loss of
the fiber link must be less than 13.3 dB.
Indicators
Protective caps
Channel 1 fiber port
Module locking tab Channel 2 fiber port
Right-side
backplane
connector with
protective cover
The left side of the modules (not shown here) also contains a backplane connector 42595

ControlNet Modular Repeater Medium Distance Fiber Module 7
Publication 1786-IN011B-EN-P - October 2000
Mount the Fiber Module
To mount the module on the DIN rail:
1. Position the module on a 35 x 7.5mm DIN rail (Allen- Bradley part number
199- DR1; 46277- 3; EN 50022) at a 30oangle.
2. Hook the lip on the rear of the module onto the top of the DIN rail, and
rotate the module onto the rail.
42596
42597
AB PLCs

8ControlNet Modular Repeater Medium Distance Fiber Module
Publication 1786-IN011B-EN-P - October 2000
3. Press the module down onto the DIN rail until flush.
The locking tab should snap into position and lock
the module to the DIN rail.
4. If the module does not snap into position, use a screwdriver or similar
device to move the locking tab down while pressing the module flush onto
the DIN rail. Release the locking tab to lock the module in place. If
necessary, push up on the locking tab to lock.
42598

ControlNet Modular Repeater Medium Distance Fiber Module 9
Publication 1786-IN011B-EN-P - October 2000
5. Remove the protective backplane cap as shown in “Remove the Protective
Caps” on page 10.
6. Once attached to the DIN rail, slide modules to the left to mate with the
repeater adapter or another repeater module.
7. Connect the fiber cable as shown in “Connect the Fiber Cable” on page 13.
ATTENTION
!
Be certain that the adapter and repeater modules are secured
together with DIN rail anchors. Failure to do so may result in
the loss of communications and/ or cause damage to the
modules. The total number of modules that can be attached to
the repeater adapter can not exceed four or the total power
consumption of the modules can not exceed 1.6A @ 5VDC,
whichever comes first.
IMPORTANT
If you exceed the module or power limit, you may cause
damage to the repeater adapter and modules.
IMPORTANT
If this is the right–most module, a DIN rail latch must be used
on the right side of the fiber module.
30043-M
AB PLCs

10 ControlNet Modular Repeater Medium Distance Fiber Module
Publication 1786-IN011B-EN-P - October 2000
Remove the Protective Caps
1. Remove the protective caps from the fiber ports that you are going to use.
2. Save the caps for future use.
Figure 2 Protective Caps
If you plan: Then:
not to use channel(s) keep the protective caps on the channels to protect
the unit from dust.
to place the module in storage keep the protective caps on the channels to protect
the unit from dust.
to connect another module to the right
backplane connector
remove the protective backplane cap and save cap
or future use.
not to connect to the right backplane connector leave the backplane cap on.
Protective
backplane cap
DIN rail
Protective cap
The left side of the module (not shown here) also
contains a backplane connector
42599
