Allen-Bradley ControlLogix System 1756-L1 User manual

ControlLogix™
System
1756-L1, -L1Mx, -L55Mxx, -L63
User Manual
Allen-Bradley HMIs

Important User Information
Because of the variety of uses for the products described in this
publication, those responsible for the application and use of these
products must satisfy themselves that all necessary steps have been
taken to assure that each application and use meets all performance
and safety requirements, including any applicable laws, regulations,
codes and standards. In no event will Rockwell Automation be
responsible or liable for indirect or consequential damage resulting
from the use or application of these products.
Any illustrations, charts, sample programs, and layout examples
shown in this publication are intended solely for purposes of
example. Since there are many variables and requirements associated
with any particular installation, Rockwell Automation does not assume
responsibility or liability (to include intellectual property liability) for
actual use based upon the examples shown in this publication.
Allen-Bradley publication SGI-1.1, Safety Guidelines for the
Application, Installation and Maintenance of Solid-State Control
(available from your local Rockwell Automation office), describes
some important differences between solid-state equipment and
electromechanical devices that should be taken into consideration
when applying products such as those described in this publication.
Reproduction of the contents of this copyrighted publication, in whole
or part, without written permission of Rockwell Automation, is
prohibited.
Throughout this publication, notes may be used to make you aware of
safety considerations. The following annotations and their
accompanying statements help you to identify a potential hazard,
avoid a potential hazard, and recognize the consequences of a
potential hazard:
WARNING
!
Identifies information about practices or
circumstances that can cause an explosion in a
hazardous environment, which may lead to personal
injury or death, property damage, or economic loss.
ATTENTION
!
Identifies information about practices or
circumstances that can lead to personal injury or
death, property damage, or economic loss.
IMPORTANT Identifies information that is critical for successful
application and understanding of the product.

1Publication 1756-UM001E-EN-P - August 2002
Summary of Changes
Introduction
This release of this document contains new and updated information.
To find new and updated information, look for change bars, as shown
next to this paragraph.
Updated Information
The document contains the following changes:
Deleted Information
The following information was removed from this manual:
•Estimate Execution Time
•Estimate Memory Use
You can find this information in Logix5000 Controllers Execution Time
and Memory Use Reference Manual, publication 1756-RM087.
This change: Starts on page:
Addition of information on the battery life of the 1756-BA1 battery
when you use it in a ControlLogix5563 controller
25-3
Addition of information a 1756-BATM ControlLogix battery module,
including how to:
•estimate battery life
•replace the battery.
26-1
Allen-Bradley HMIs

Publication 1756-UM001E-EN-P - August 2002
Summary of Changes 2
Notes:

1Publication 1756-UM001E-EN-P - August 2002
Preface
Purpose of this Manual
This manual guides the development of projects for ControlLogix
controllers. It provides step-by-step procedures on how to establish
communications:
•over the following networks
–EtherNet/IP
–ControlNet™
–remote I/O
–DH+™
–DH-485
–serial
•with the following devices
–controllers
–I/O
–workstations
–PanelView™terminals
This manual works together with the Logix5000 Controllers Common
Procedures, publication 1756-PM001, which covers the following
tasks:
•Manage project files
•Organize your logic
•Organize tags
•Program routines
•Test a project
•Handle faults
Who Should Use this
Manual
This manual is intended for those individuals who program
applications that use ControlLogix controllers, such as:
•software engineers
•control engineers
•application engineers
•instrumentation technicians
Allen-Bradley HMIs

Publication 1756-UM001E-EN-P - August 2002
Preface 2
When to Use this Manual
Use this manual:
•when you are ready to integrate your application with the I/0
devices, controllers, and networks in your system.
•after you perform these actions:
–develop the basic code for your application
–perform isolated tests of your application
How to Use this Manual
This manual is divided into the basic tasks that you perform while
programming a ControlLogix controller.
•Each chapter covers a task.
•The tasks are organized in the sequence that you will typically
perform them.
As you use this manual, you will see some terms that are formatted
differently from the rest of the text:
Text that is: Identifies: For example: Means:
Italic the actual name of an item that you
see on your screen or in an example
Right-click User-Defined … Right-click on the item that is named
User-Defined.
courier information that you must supply
based on your application (a
variable)
Right-click
name_of_program …
You must identify the specific program in
your application. Typically, it is a name or
variable that you have defined.

iPublication 1756-UM001E-EN-P - August 2002
Table of Contents
Chapter 1
Configure an EtherNet/IP Module
When to Use This Procedure . . . . . . . . . . . . . . . . . . . . . . . 1-1
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
RSLogix 5000 Software . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
RSLinx Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
BOOTP Server Software . . . . . . . . . . . . . . . . . . . . . . . . 1-5
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 1-6
Configure a Module Using RSLogix 5000 Software . . . . . . . 1-7
Connect the Hardware . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Connect to the Module. . . . . . . . . . . . . . . . . . . . . . . . . 1-8
Configure the Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
Check the Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
Configure a Module Using RSLinx Software . . . . . . . . . . . . 1-13
Connect the Hardware . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
Configure the Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
Check the Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-15
Configure a Module Using BOOTP . . . . . . . . . . . . . . . . . . 1-16
Install BOOTPServer Software . . . . . . . . . . . . . . . . . . . 1-16
Connect the Hardware . . . . . . . . . . . . . . . . . . . . . . . . . 1-16
Enter the Default Network Settings . . . . . . . . . . . . . . . . 1-17
Configure the Module . . . . . . . . . . . . . . . . . . . . . . . . . 1-18
Disable BOOTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-19
Save the Relation List . . . . . . . . . . . . . . . . . . . . . . . . . . 1-19
Renew the IP Address of a 1794-AENx Module. . . . . . . . . . 1-20
Install BOOTPServer Software . . . . . . . . . . . . . . . . . . . 1-20
Set Up the Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . 1-20
Enter the New Configuration . . . . . . . . . . . . . . . . . . . . 1-21
Send the Configuration. . . . . . . . . . . . . . . . . . . . . . . . . 1-22
Disable BOOTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-22
Save the Relation List . . . . . . . . . . . . . . . . . . . . . . . . . . 1-23
Test the Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-24
Connect Directly to a Controller. . . . . . . . . . . . . . . . . . . . . 1-24
Connect a Serial Cable . . . . . . . . . . . . . . . . . . . . . . . . . 1-24
Configure a Serial Driver . . . . . . . . . . . . . . . . . . . . . . . 1-26
Chapter 2
Download and Go Online over an
EtherNet/IP Network
When to Use This Procedure . . . . . . . . . . . . . . . . . . . . . . . 2-1
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 2-1
Configure an Ethernet Driver. . . . . . . . . . . . . . . . . . . . . . . 2-2
Select a Path . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Allen-Bradley HMIs

Publication 1756-UM001E-EN-P - August 2002
Table of Contents ii
Chapter 3
Communicate with 1756 I/O over
an EtherNet/IP Network
When to Use This Procedure . . . . . . . . . . . . . . . . . . . . . . . 3-1
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 3-2
Add the Local 1756-ENBx or -ENET Module. . . . . . . . . . . . 3-3
Add the Remote 1756-ENBx or -ENET Module . . . . . . . . . . 3-5
Add I/O Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Create Aliases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
Validate Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
Chapter 4
Communicate with 1794 I/O Over
an
EtherNet/IP Network
When to Use This Procedure . . . . . . . . . . . . . . . . . . . . . . . 4-1
Before You Use This Procedure. . . . . . . . . . . . . . . . . . . . . 4-2
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 4-2
Add the local 1756-ENBx or -ENET module . . . . . . . . . . . . 4-3
Add the Remote 1794-AENx Module . . . . . . . . . . . . . . . . . 4-5
Add I/O Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Address I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
Validate Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
Chapter 5
Communicate with Another
Controller over an EtherNet/IP
Network
When to Use This Procedure . . . . . . . . . . . . . . . . . . . . . . . 5-1
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Select a Communication Method . . . . . . . . . . . . . . . . . . . . 5-2
Produce a Tag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Add the Local 1756-ENBx or -ENET Module. . . . . . . . . . . . 5-4
Add the Remote 1756-ENBx or -ENET Module . . . . . . . . . . 5-6
Add the Other Controller. . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
Consume a Tag. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
Validate Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
Does Another Controller Require the Data? . . . . . . . . . . . . 5-13
Add the Local 1756-ENBx or -ENET Module. . . . . . . . . . . . 5-14
Enter a Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16
Configure the Message . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-18
Stagger the Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-22
Access ControlLogix Data . . . . . . . . . . . . . . . . . . . . . . . . . 5-23

Publication 1756-UM001E-EN-P - August 2002
Table of Contents iii
Chapter 6
Communicate with a PanelView
™
Terminal Over a EtherNet/IP
Network
When to Use This Procedure . . . . . . . . . . . . . . . . . . . . . . . 6-1
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 6-2
Add the Local 1756-ENBx or -ENET Module. . . . . . . . . . . . 6-3
Add the PanelView Terminal . . . . . . . . . . . . . . . . . . . . . . . 6-5
Organize Your Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Configure the PanelView Terminal. . . . . . . . . . . . . . . . . . . 6-10
Create PanelView Tags . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12
Validate Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
Chapter 7
Communicate with an RSView
Project over an EtherNet/IP
Network
When to Use This Procedure . . . . . . . . . . . . . . . . . . . . . . . 7-1
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 7-1
Configure an Ethernet Driver. . . . . . . . . . . . . . . . . . . . . . . 7-2
Select a Communication Method . . . . . . . . . . . . . . . . . . . . 7-3
Create a Polled Topic . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Create a Polled Node . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
Import Logix5000 Tags . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
Create an .L5K File. . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
Install the Logix 5000 Tag Import Utility . . . . . . . . . . . . 7-8
Use the Utility to Create a .CSV File . . . . . . . . . . . . . . . 7-8
Import the .CSV File. . . . . . . . . . . . . . . . . . . . . . . . . . . 7-10
Create a Polled Tag. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-12
Create a Unsolicited Topic. . . . . . . . . . . . . . . . . . . . . . . . . 7-14
Add the 1756-ENBx or -ENET Module . . . . . . . . . . . . . . . . 7-16
Enter a Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-18
Configure the Message . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-20
Create an Unsolicited Node . . . . . . . . . . . . . . . . . . . . . . . . 7-22
Create an Unsolicited Tag . . . . . . . . . . . . . . . . . . . . . . . . . 7-23
Validate an RSView32 Tag . . . . . . . . . . . . . . . . . . . . . . . . . 7-24
Chapter 8
Communicate with 1756 I/O over a
ControlNet™Network
When to Use This Procedure . . . . . . . . . . . . . . . . . . . . . . . 8-1
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 8-1
Add the Local 1756-CNB Module . . . . . . . . . . . . . . . . . . . . 8-2
Add the Remote 1756-CNB Module . . . . . . . . . . . . . . . . . . 8-4
Add I/O Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-6
Create Aliases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10
Schedule the ControlNet Network . . . . . . . . . . . . . . . . . . . 8-13
Validate Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-14
Allen-Bradley HMIs

Publication 1756-UM001E-EN-P - August 2002
Table of Contents iv
Chapter 9
Communicate with 1771 I/O Over a
ControlNet
™
Network
When to Use This Procedure . . . . . . . . . . . . . . . . . . . . . . . 9-1
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 9-1
Add the Local 1756-CNB Module . . . . . . . . . . . . . . . . . . . . 9-3
Add the 1771-ACN Module . . . . . . . . . . . . . . . . . . . . . . . . 9-5
Read or Write Data To or From a Block Transfer Module . . 9-7
Read Data From a Block Transfer Module. . . . . . . . . . . 9-8
Write Configuration or Output Data To a Block Transfer
Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10
Configure the Messages . . . . . . . . . . . . . . . . . . . . . . . . 9-11
Read or Write Data To or From Multiple Block Transfer Modules
9-12
Create a User-Defined Data Type . . . . . . . . . . . . . . . . . 9-13
Create the Array for the Input Data. . . . . . . . . . . . . . . . 9-14
Send a Block Transfer Read Message . . . . . . . . . . . . . . 9-15
Enter the BTR Properties for Each Module . . . . . . . . . . 9-17
Convert the INTs to DINTs. . . . . . . . . . . . . . . . . . . . . . 9-18
Step to the Next BT Module . . . . . . . . . . . . . . . . . . . . . 9-19
Write Data to Multiple Block Transfer Modules . . . . . . . 9-20
Address I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-22
Schedule the ControlNet Network . . . . . . . . . . . . . . . . . . . 9-24
Validate Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-25
Stagger the Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-27
Chapter 10
Communicate with 1794 I/O Over a
ControlNet
™
Network
When to Use This Procedure . . . . . . . . . . . . . . . . . . . . . . . 10-1
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 10-1
Add the local 1756-CNB module . . . . . . . . . . . . . . . . . . . . 10-2
Add the Remote 1794-ACN Module . . . . . . . . . . . . . . . . . . 10-4
Add I/O Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-6
Create Aliases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-10
Schedule the ControlNet Network . . . . . . . . . . . . . . . . . . 10-13
Validate Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-14
Chapter 11
Communicate with Another
Controller over a ControlNet
™
Network
When to Use This Procedure . . . . . . . . . . . . . . . . . . . . . . . 11-1
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 11-2
Step 1: Add the 1756-CNB Module. . . . . . . . . . . . . . . . . . . 11-3
Step 2: Add the Remote 1756-CNB Module. . . . . . . . . . . . . 11-5
Step 3: Add the 1788-CNC Module. . . . . . . . . . . . . . . . . . . 11-8
Step 4: Add the Other Controller . . . . . . . . . . . . . . . . . . . 11-10
Step 5: Enter a Message. . . . . . . . . . . . . . . . . . . . . . . . . . 11-12
Step 6: Configure the Message . . . . . . . . . . . . . . . . . . . . . 11-14
Step 7: Stagger the Messages . . . . . . . . . . . . . . . . . . . . . . 11-16
Step 8: Access ControlLogix Data. . . . . . . . . . . . . . . . . . . 11-16

Publication 1756-UM001E-EN-P - August 2002
Table of Contents v
Chapter 12
Route PLC-5
®
Messages Between
ControlNet
™
Networks
When to Use This Procedure . . . . . . . . . . . . . . . . . . . . . . . 12-1
Route a ControlNet Message . . . . . . . . . . . . . . . . . . . . . . . 12-2
Chapter 13
Communicate with a PanelView
™
Terminal Over a ControlNet
™
Network
When to Use This Procedure . . . . . . . . . . . . . . . . . . . . . . . 13-1
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 13-2
Add the Local 1756-CNB Module . . . . . . . . . . . . . . . . . . . . 13-2
Add the PanelView Terminal . . . . . . . . . . . . . . . . . . . . . . . 13-5
Organize Your Scheduled Data . . . . . . . . . . . . . . . . . . . . . 13-8
Organize Your Unscheduled Data . . . . . . . . . . . . . . . . . . 13-10
Configure the PanelView Terminal. . . . . . . . . . . . . . . . . . 13-12
Create PanelView Tags . . . . . . . . . . . . . . . . . . . . . . . . . . 13-14
Schedule the ControlNet Network . . . . . . . . . . . . . . . . . . 13-16
Validate Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-17
Chapter 14
Communicate with an RSView
Project over a ControlNet
™
Network
When to Use This Procedure . . . . . . . . . . . . . . . . . . . . . . . 14-1
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 14-1
Configure a ControlNet Driver . . . . . . . . . . . . . . . . . . . . . . 14-2
Select a Communication Method . . . . . . . . . . . . . . . . . . . . 14-3
Create a Polled Topic . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-4
Create a Polled Node . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-6
Import Logix5000 Tags . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-7
Create an .L5K File. . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-7
Install the Logix 5000 Tag Import Utility . . . . . . . . . . . . 14-8
Use the Utility to Create a .CSV File . . . . . . . . . . . . . . . 14-8
Import the .CSV File. . . . . . . . . . . . . . . . . . . . . . . . . . 14-10
Create a Polled Tag. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-12
Create a Unsolicited Topic. . . . . . . . . . . . . . . . . . . . . . . . 14-14
Add the 1756-CNB Module . . . . . . . . . . . . . . . . . . . . . . . 14-16
Enter a Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-18
Configure the Message . . . . . . . . . . . . . . . . . . . . . . . . . . 14-20
Create an Unsolicited Node . . . . . . . . . . . . . . . . . . . . . . . 14-22
Create an Unsolicited Tag . . . . . . . . . . . . . . . . . . . . . . . . 14-23
Validate an RSView32 Tag . . . . . . . . . . . . . . . . . . . . . . . . 14-24
Chapter 15
Monitor Connections
When To Use This Procedure . . . . . . . . . . . . . . . . . . . . . . 15-1
Monitor a Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-2
Allen-Bradley HMIs

Publication 1756-UM001E-EN-P - August 2002
Table of Contents vi
Chapter 16
Communicate with a DeviceNet
Device
When to Use This Procedure . . . . . . . . . . . . . . . . . . . . . . . 16-1
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 16-1
Step 1: Add the 1756-DNB Module . . . . . . . . . . . . . . . . . . 16-1
Step 2: Create Aliases . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-4
Step 3: Set the Scanner to Run Mode . . . . . . . . . . . . . . . . . 16-6
Chapter 17
Communicate with Another
Controller Over a DH+
™
Network
When to Use This Procedure . . . . . . . . . . . . . . . . . . . . . . . 17-1
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 17-2
Configure Routing Tables . . . . . . . . . . . . . . . . . . . . . . . . . 17-3
Configure a 1756-DHRIO Channel . . . . . . . . . . . . . . . . . . . 17-8
Add a 1756-DHRIO Module. . . . . . . . . . . . . . . . . . . . . . . 17-11
Enter a Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-14
Configure the Message . . . . . . . . . . . . . . . . . . . . . . . . . . 17-16
Stagger the Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-20
Access ControlLogix Data . . . . . . . . . . . . . . . . . . . . . . . . 17-20
Chapter 18
Route PLC-5
®
or SLC 500
™
Messages From a DH+
™
Network
When to Use This Procedure . . . . . . . . . . . . . . . . . . . . . . . 18-1
Configure Routing Tables . . . . . . . . . . . . . . . . . . . . . . . . . 18-2
Configure a PLC-5 or SLC 500 Message . . . . . . . . . . . . . . . 18-6
Chapter 19
Communicate with Another
Controller over a DH-485 Network
When to Use this Procedure . . . . . . . . . . . . . . . . . . . . . . . 19-1
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 19-2
Step 1: Connect the Controller to an AIC+ . . . . . . . . . . . . . 19-3
Step 2: Configure the Serial Port . . . . . . . . . . . . . . . . . . . . 19-4
Step 3: Enter a Message. . . . . . . . . . . . . . . . . . . . . . . . . . . 19-6
Step 4: Configure the Message . . . . . . . . . . . . . . . . . . . . . . 19-8
Step 5: Check the LED. . . . . . . . . . . . . . . . . . . . . . . . . . . 19-10
Step 6: Stagger the Messages . . . . . . . . . . . . . . . . . . . . . . 19-10
Chapter 20
Communicate Over a Remote I/O
Network
When to Use This Procedure . . . . . . . . . . . . . . . . . . . . . . . 20-1
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 20-2
Add a 1756-DHRIO Module. . . . . . . . . . . . . . . . . . . . . . . . 20-3
Add a Remote I/O Adapter . . . . . . . . . . . . . . . . . . . . . . . . 20-6
Add a Block Transfer Module . . . . . . . . . . . . . . . . . . . . . . 20-9
Read or Write Data To or From a Block Transfer Module . 20-10
Read Data From a Block Transfer Module. . . . . . . . . . 20-11
Write Configuration or Output Data To a Block Transfer
Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-13
Configure the Messages . . . . . . . . . . . . . . . . . . . . . . . 20-14

Publication 1756-UM001E-EN-P - August 2002
Table of Contents vii
Read or Write Data To or From Multiple Block Transfer Modules
20-15
Create a User-Defined Data Type . . . . . . . . . . . . . . . . 20-17
Create the Data Array. . . . . . . . . . . . . . . . . . . . . . . . . 20-18
Send the Message to a BT Module . . . . . . . . . . . . . . . 20-19
Enter the Message Properties for Each Module . . . . . . 20-21
Convert the INTs to DINTs. . . . . . . . . . . . . . . . . . . . . 20-22
Step to the Next BT Module . . . . . . . . . . . . . . . . . . . . 20-23
Write Data to Multiple Block Transfer Modules . . . . . . 20-24
Address I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-26
Validate Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-28
Stagger the Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-30
Chapter 21
Download and Go Online over a
Serial Cable
When to Use this Procedure . . . . . . . . . . . . . . . . . . . . . . . 21-1
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 21-1
Step 1: Connect a Serial Cable . . . . . . . . . . . . . . . . . . . . . . 21-2
Step 2: Configure a Serial Driver . . . . . . . . . . . . . . . . . . . . 21-3
Step 3: Select a Path . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21-4
Chapter 22
Configure DF1 Master and Slave
Communications
When to Use this Procedure . . . . . . . . . . . . . . . . . . . . . . . 22-1
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 22-2
Step 1: Connect and Configure the Modems. . . . . . . . . . . . 22-2
Step 2: Select a Polling Mode. . . . . . . . . . . . . . . . . . . . . . . 22-3
Step 3: Configure the Master Controller for Standard Polling . . .
22-3
Step 4: Configure the Master Controller for Message-Based
Polling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-8
Step 5: Configure a Slave Controller. . . . . . . . . . . . . . . . . 22-10
Step 6: Enter a Message. . . . . . . . . . . . . . . . . . . . . . . . . . 22-12
Step 7: Configure the Message . . . . . . . . . . . . . . . . . . . . . 22-14
Step 8: Stagger the Messages . . . . . . . . . . . . . . . . . . . . . . 22-17
Chapter 23
Configure Dial-Up
Communications
When to Use this Procedure . . . . . . . . . . . . . . . . . . . . . . . 23-1
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 23-1
Step 1: Connect and Configure the Modems. . . . . . . . . . . . 23-2
Step 2: Configure the Serial Port of the Controller. . . . . . . . 23-3
Step 3: Dial the Other Controller . . . . . . . . . . . . . . . . . . . . 23-5
Step 4: Send the Message . . . . . . . . . . . . . . . . . . . . . . . . . 23-6
Step 5: Configure the Message . . . . . . . . . . . . . . . . . . . . . . 23-8
Step 6: Hang-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23-11
Step 7: Stagger the Messages . . . . . . . . . . . . . . . . . . . . . . 23-12
Allen-Bradley HMIs

Publication 1756-UM001E-EN-P - August 2002
Table of Contents viii
Chapter 24
Program Motion Control
When to Use This Procedure . . . . . . . . . . . . . . . . . . . . . . . 24-1
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 24-2
Select a CST Master Device . . . . . . . . . . . . . . . . . . . . . . . . 24-2
Define the Controller as the CST Master . . . . . . . . . . . . 24-3
Define a 1756-SYNCH Module as the CST Master . . . . . 24-3
Add the Motion Module . . . . . . . . . . . . . . . . . . . . . . . . . . 24-4
1756-M08SE - Add the SERCOS Drive. . . . . . . . . . . . . . . . . 24-7
Create a Motion Group . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-9
Assign the Properties of the Motion Group. . . . . . . . . . . . 24-10
Configure the Axis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-12
Display the Properties for the Axis . . . . . . . . . . . . . . . 24-12
Select an Axis Configuration. . . . . . . . . . . . . . . . . . . . 24-12
Assign Units for Measurements . . . . . . . . . . . . . . . . . . 24-13
Assign a Conversion Constant. . . . . . . . . . . . . . . . . . . 24-13
1756-M02AE - Select the Configuration of the Servo Drive . .
24-14
1756-M08SE - Select the Catalog Number of the Amplifier . .
24-15
1756-M08SE - Select the Motor and Feedback . . . . . . . 24-16
Run Hookup Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-17
Download Your Project and Go Online . . . . . . . . . . . 24-17
Display the Properties for the Axis . . . . . . . . . . . . . . . 24-18
Complete the Hookup Tests . . . . . . . . . . . . . . . . . . . . 24-18
Develop Logic for Motion Control . . . . . . . . . . . . . . . . . . 24-19
Handle Motion Faults. . . . . . . . . . . . . . . . . . . . . . . . . 24-20
Chapter 25
Maintain the 1756-BA1 Battery
When to Use This Procedure . . . . . . . . . . . . . . . . . . . . . . . 25-1
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 25-1
Estimate Battery Life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-1
Store Replacement Batteries. . . . . . . . . . . . . . . . . . . . . . . . 25-4
Replace a Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-4
Chapter 26
Maintain a 1756-BATM Battery
Module
When to Use This Procedure . . . . . . . . . . . . . . . . . . . . . . . 26-1
How to Use This Procedure. . . . . . . . . . . . . . . . . . . . . . . . 26-1
Estimate Battery Life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-2
Replace a Battery Assembly. . . . . . . . . . . . . . . . . . . . . . . . 26-4
Remove the Existing Battery Assembly . . . . . . . . . . . . . 26-4
Install a New Battery Assembly. . . . . . . . . . . . . . . . . . . 26-5
Check the BAT LED . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-6

Publication 1756-UM001E-EN-P - August 2002
Table of Contents ix
Appendix A
Map a PLC/SLC Address
When To Use This Procedure . . . . . . . . . . . . . . . . . . . . . . A-1
Map an Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Appendix B
Estimate Execution Time
Appendix C
Estimate Memory Use
Appendix D
Determine When Data Is Updated
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-1
Appendix E
Reconfigure an I/O module
Allen-Bradley HMIs

Publication 1756-UM001E-EN-P - August 2002
Table of Contents x

1Publication 1756-UM001E-EN-P - August 2002
Chapter 1
Configure an EtherNet/IP Module
When to Use This
Procedure
Use this procedure to configure any of the following modules:
You can configure a module either:
•before you install the module
–Configure the module in a temporary location, such as a
chassis that is on a test bench.
–After you configure the module, install it in your system.
•after you install the module in your system
42872
switch
1756-ENBx or -ENET
module
1794-AENx module
Allen-Bradley HMIs

Publication 1756-UM001E-EN-P - August 2002
1-2 Configure an EtherNet/IP Module
Before You Begin
The configuration of an EtherNet/IP module includes:
•IP address (required)
•subnet mask (recommended)
•gateway address (optional)
•domain name (optional)
•DNS server addresses (optional)
You use software to configure an EtherNet/IP module. (The modules
do not have hardware switches to assign an address.) To configure a
module, use one of these software:
•RSLogix 5000 Software
•RSLinx Software
•BOOTP Server Software
To determine which software lets you configure your module, use the
following table:
To configure this module: Use one of these software:
RSLogix 5000 RSLinx BOOTP server
1756-ENBx ✔✔✔
1756-ENET ✔✔✔
1794-AENx ✔

Publication 1756-UM001E-EN-P - August 2002
Configure an EtherNet/IP Module 1-3
RSLogix 5000 Software
RSLogix 5000 software lets you configure a 1756-ENBx or -ENET
module via another module that is in the chassis.
Use RSLogix 5000 software to assign:
•IP address (required)
•subnet mask (recommended)
•gateway address (optional)
•domain name (optional)
•DNS server addresses (optional)
When you configure a module with RSLogix 5000 software, you enter
an IP address or host name in two locations:
P/S L
5
5
x
x
E
N
B
P/S D
H
R
I
O
C
N
B
E
N
B
E
N
B
1756-CP3 or 1747-CP3 serial cable
network
module to configure
ControlLogix
chassis
ControlLogix
chassis
RSLogix 5000 software
another communication modulecontroller
On this tab: You:
General (first screen of the
Module Properties wizard)
Identify the module on the EtherNet/IP network with which
you want to connect
Port Configuration Assign configuration information to the module, such as its
IP address. This information is stored in the module and
identifies the module on the EtherNet/IP network.
Allen-Bradley HMIs

Publication 1756-UM001E-EN-P - August 2002
1-4 Configure an EtherNet/IP Module
RSLinx Software
RSLinx software lets you configure a 1756-ENBx or -ENET module via
another module in the chassis.
Use RSLinx software to assign:
•IP address (required)
•subnet mask (recommended)
•gateway address (optional)
•domain name (optional)
•DNS server addresses (optional)
P/S L
5
5
x
x
E
N
B
P/S D
H
R
I
O
C
N
B
E
N
B
E
N
B
1756-CP3 or 1747-CP3 serial cable
network
module to configure
ControlLogix
chassis
ControlLogix
chassis
RSLinx software
another communication modulecontroller
