Technical Data
PowerFlex 527 AC Drive Specifications
Original Instructions
Topic Page
Product Overview 2
Catalog Number Explanation 7
Technical Specifications 8
Environmental Specifications 11
Certifications 12
Dimensions and Weights 13
Design Considerations 15
Fuses and Circuit Breaker Ratings 26
Accessories and Dimensions 31
Safe Torque-Off Function 40
Additional Resources 41

2Rockwell Automation Publication 520-TD002A-EN-E - May 2015
PowerFlex 527 AC Drive Specifications
Product Overview
PowerFlex® 527 AC drives are designed to be used with an Allen-Bradley® Logix Programmable Automation Controller
(PAC). Ideal for machines that can benefit from the same drive configuration experience for both servo and AC drives, the
PowerFlex 527 drive features a built-in dual port for EtherNet/IP™ and safety over the network. The PowerFlex 527 drive
provides maximum flexibility and performance ranging up to 30 HP and 22 kW.
Designed to connect and operate only with the ControlLogix® 1756-L7x, GuardLogix® 1756-L7xS, and CompactLogix™
5370 controllers and Studio 5000 Logix Designer™ application. The PowerFlex 527 is programmed with the embedded
motion instructions within Studio 5000, these are the same instructions that are used for Allen-Bradley Kinetix® servo
drives. This streamlined approach provides a common user experience and just one software package to learn and use. The
commonality and use of consolidated integration tools helps save valuable engineering time.
Maximize your system performance and productivity by taking advantage of the following key features offered in a
PowerFlex 527 drive.
PowerFlex 527 AC Drives Feature
Design
•Designed to be used exclusively with Allen-Bradley Logix controllers.
•Designed for machine applications – such as pumps, fans, and in-feed and out-feed conveyors – that need speed
control for induction motors.
•Logix integration helps deliver a high level of motor coordination.
•Built-in dual-port EtherNet/IP supports multiple network topologies and Device Level Ring functionality.
•Built-in hardwired Safe Torque-off. SIL 3 / PLe Cat 3.
•Integrated Safety – controller-based safety delivered via EtherNet/IP. SIL 3 / PLe Cat 3.
•Reduce your spare parts with a standard control module that can be used across the entire power range.
•Support for an incremental encoder accessory card without affecting footprint.
Packaging and Mounting
•Installation can be quick and easy using the DIN rail mounting feature on A, B, and C frame drives. Panel mounting
is also available, providing added flexibility.
•Zero Stacking™ is allowed for ambient temperatures up to 45 °C, saving valuable panel space.
•Integral filtering is available on all 200V and 400V ratings, providing a cost-effective means of meeting EN61800-3
Category C2 and C3 EMC requirements. External filters provide compliance to EN61800-3 Category C1, C2, and
C3 EMC requirements for all PowerFlex 520-Series ratings.
•An optional IP 30, NEMA/UL Type 1 conduit box is easily adapted to the standard IP 20 (NEMA Type Open)
product, providing increased environmental ratings.
Optimized Performance
•Removable MOV to ground provides trouble-free operation when used on ungrounded distribution systems.
•A relay pre-charge limits inrush current.
•Integral brake transistor, available on all ratings, provides dynamic braking capability with simple low cost brake
resistors.

Rockwell Automation Publication 520-TD002A-EN-E - May 2015 3
PowerFlex 527 AC Drive Specifications
•A jumper to switch between 24V DC sink or source control for control wiring flexibility.
•Dual Overload Rating available for drives above 15 HP/11 kW. Normal duty: 110% overload for 60 seconds or
150% for 3 seconds. Heavy duty: 150% overload for 60 seconds or 180% overload (200% programmable) for
3 seconds provides robust overload protection.
•Adjustable PWM frequency up to 8 kHz ensures quiet operation.
PowerFlex 527 AC Drive Advanced Features
Control Performance
• Frequency Control with the following options:
•Volts per Hertz (V/Hz)
•Sensorless Vector Control (SVC)
•Sensorless Vector Control (SVC) Economizer
• Position Loop, including:
•Closed Loop Position Vector Control (with optional encoder card)
• Velocity Loop, including:
•Closed Loop Velocity Vector Control (with optional encoder card)
I/O Wiring
•Two (2) Analog Inputs (one current and one voltage)
are independently isolated from the rest of the drive
I/O.
•Four (4) Digital Inputs provide application versatility.
•One (1) Analog Output is jumper selectable between
either 0-10V or 0-20 mA. This scalable, 10-bit output
is suitable for metering or as a speed reference for
another drive.
•Two (2) Opto Outputs and two (2) Relay Outputs
(one form A and one form B) can be used to indicate
various drive, motor or logic conditions.
Communications
•Built-in dual port for EtherNet/IP allows easy
configuration, control, and collection of drive data over
the network. It also supports Device Level Ring (DLR)
topologies, providing fault-tolerant connectivity for
optimum drive availability.
•Online EDS file creation with RSNetWorx™ providing
ease of set-up on a network.
PowerFlex 527 Control I/O Wiring Block Diagram
R1
11 12 13 14 15 16 17
R2 R5 R6 01 02 03 04 05 06 07 C1 C2
04
05
06
07
01
02
03
11
12
13
14
15
16
17
Digital Common
Digital In 1
Digital In 2
Digital In 3
Digital In 4
R1
R2
S1
S2
S+
Relay 1 N.O.
Relay 1 Common
+24V DC
+10V DC
±10V Input
Analog Common
4-20mA Input
Analog Output
Opto Output 1
Opto Output 2
Ethernet
Comm Common
Opto Common
+24V
+10V
Safety 1
Safety 2
Safety +24V
Typical
SNK wiring
Typical
SRC wiring
Pot must be
1...10 k ohm
2 W min.
0-10V
0/4-20 mA
SNK
Digital In
Analog Out
J2
J1
SRC
ACO
AVO
SRC
SNK
R5
R6
Relay 2 Common
Relay 2 N.C.
C1
C2
Common
24V
(1)

4Rockwell Automation Publication 520-TD002A-EN-E - May 2015
PowerFlex 527 AC Drive Specifications
Common DC Bus Installations
Common DC Bus offers additional inherent breaking capabilities by utilizing all the drives/loads on the bus for energy
absorption offering higher efficiency and cost savings. The PowerFlex 527 drive has been optimized for use in Common
DC Bus or Shared DC Bus installations.
•Direct DC Bus connection to power terminal blocks.
Improved Ride Through
Operation Down to 1/2 Line Voltage
The PowerFlex 527 drive allows for the selection of 1/2 DC Bus operation, for use in critical applications where continued
drive output is desired even in the event of brown out or low voltage conditions. The PowerFlex 527 drive also supports
enhanced inertia ride through for additional low voltage mitigation.
•Selectable 1/2 line voltage operation.
•Increased power loss ride through.
Basic Position Control
Closed loop position control using Logix motion instructions such as MAM (Motion Axis Move). For more information
on Logix motion instructions, see the Logix5000 Motion Controllers Instructions Reference Manual, publication
MOTION-RM002.
Closed Loop Feedback
Encoder Option Card
The PowerFlex 527 drive allows for configurable closed loop control with an optional encoder card for either speed or
position feedback for improved speed regulation or basic position control.
•Improved speed regulation
•Basic position control
Feedback Details
Line Driver Type Incremental Encoder Option Card
•Quadrature (dual channel)
•5V/12V DC supply, 10 mA min per channel
•Single Ended or Differential (A, B, and Z
Channel)
•Duty Cycle of 50%, +10%
•Input Frequency up to 250 kHz
I/O Connection Example I/O Connection Example
Encoder
Power –
Internal Drive
Power
Internal (drive)
12V DC, 250 mA
Encoder
Power –
External
Power
Source
Encoder
Signal –
Single-Ended,
Dual Channel
Encoder
Signal –
Differential,
Dual Channel
Common
+12V DC
(250 mA)
A
A-
B
B-
Z
Z-
Cm
+V
to SHLD
+
Common
External
Power
Supply
to
SHLD
Marker Z
A
B
Marker
Z NOT
to SHLD
to Power Supply
Common
A
A-
B
B-
Z
Z-
Cm
+V
to SHLD
A NOT
B
A
B NOT
Marker
Z NOT
Marker Z
A
A-
B
B-
Z
Z-
Cm
+V
Encoder Wiring Examples

Rockwell Automation Publication 520-TD002A-EN-E - May 2015 5
PowerFlex 527 AC Drive Specifications
Safety Inside using Safe Torque-Off Function
Safe Torque-off is a standard feature that can be applied through either hardwired safety or Integrated Safety via an
EtherNet/IP network. Safe Torque-Off allows you to restart your application faster after a safety-related situation.
•Safe Torque-Off functionality removes rotational power without powering down the drive.
•Built-in safety reduces wiring and saves on installation space.
•Meets ISO 13849-1 standards and provides safety ratings up to and including SIL 3/PLe.
Communications and Software
Versatile Programming and Network Solutions
•A network can be configured using
PowerFlex 527 drives for flexible configuration
capabilities.
•Built-in dual port for EtherNet/IP
EtherNet/IP is an established, broadly adopted
network that helps simplify and enhance machine
design and operation. Dual-port EtherNet/IP
connectivity supports linear and ring topologies as well
as device level ring (DLR) functionality.
The application of the CIP Safety protocol enables the
simultaneous transmission of safety and standard
control data and diagnostics information through
EtherNet/IP.
PC Programming Software
Studio 5000 Logix Designer
•PowerFlex 527 drives are designed to be used exclusively with Allen Bradley Logix controllers.
•Drives are programmed using the motion instructions in Studio 5000 Logix Designer(1).
•PowerFlex 527 drives feature drive configuration that is stored in the Logix controller, supporting fast, automatic
device replacement.
(1) Studio 5000 Logix Designer (formerly RSLogix 5000) version 24 or greater is required.
Linear Topology
Star Topology
Ring Topology Only Rockwell Automation supports
rings at the device level (DLR)

6Rockwell Automation Publication 520-TD002A-EN-E - May 2015
PowerFlex 527 AC Drive Specifications
PowerFlex 527 Drive Family
Frame A Frame B Frame C Frame D Frame E

Rockwell Automation Publication 520-TD002A-EN-E - May 2015 7
PowerFlex 527 AC Drive Specifications
Catalog Number Explanation
Code Type
25C PowerFlex 527
(1) Normal and Heavy Duty ratings are available for drives above 15 HP / 11 kW.
1-3 4 5 6-8 9 10 11 12 13 14
25C – B 2P3 N 1 1 4 – –
Drive Dash Voltage Rating Rating Enclosure Reserved Emission Class Reserved Dash Dash
Output Current @ 3 Phase, 380...480V Input
Code Amps Fram
e
ND HD
HP kW HP kW
1P4 1.4 A 0.5 0.4 0.5 0.4
2P3 2.3 A 1.0 0.75 1.0 0.75
4P0 4.0 A 2.0 1.5 2.0 1.5
6P0 6.0 A 3.0 2.2 3.0 2.2
010 10.5 B 5.0 4.0 5.0 4.0
013 13.0 C 7.5 5.5 7.5 5.5
017 17.0 C 10.0 7.5 10.0 7.5
024 24.0 D 15.0 11.0 15.0 11.0
030(1) 30.0 D20.0 15.0 15.0 11.0
037(1) 37.0 E25.0 18.5 20.0 15.0
043(1) 43.0 E30.0 22.0 25.0 18.5
Output Current @ 3 Phase, 525...600V Input
Code Amps Fram
e
ND HD
HP kW HP kW
0P9 0.9 A 0.5 0.4 0.5 0.4
1P7 1.7 A 1.0 0.75 1.0 0.75
3P0 3.0 A 2.0 1.5 2.0 1.5
4P2 4.2 A 3.0 2.2 3.0 2.2
6P6 6.6 B 5.0 4.0 5.0 4.0
9P9 9.9 C 7.5 5.5 7.5 5.5
012 12.0 C 10.0 7.5 10.0 7.5
019 19.0 D 15.0 11.0 15.0 11.0
022(1) 22.0 D20.0 15.0 15.0 11.0
027(1) 27.0 E25.0 18.5 20.0 15.0
032(1) 32.0 E30.0 22.0 25.0 18.5
Code Voltage Phase
V 120V AC 1
A 240V AC 1
B 240V AC 3
D 480V AC 3
E 600V AC 3
Code Enclosure
N IP20 NEMA / Open
Code Interface Module
1Standard
Code EMC Filter
0 No Filter
1Filter
Code Braking
4Standard
Output Current @ 1 Phase, 100...120V Input
Code Amps Frame ND HD
HP kW HP kW
2P5 2.5 A 0.5 0.4 0.5 0.4
4P8 4.8 B 1.0 0.75 1.0 0.75
6P0 6.0 B 1.5 1.1 1.5 1.1
Output Current @ 1 Phase, 200...240V Input
Code Amps Frame ND HD
HP kW HP kW
2P5 2.5 A 0.5 0.4 0.5 0.4
4P8 4.8 A 1.0 0.75 1.0 0.75
8P0 8.0 B 2.0 1.5 2.0 1.5
011 11.0 B 3.0 2.2 3.0 2.2
Output Current @ 3Phase, 200...240V Input
Code Amps Frame ND HD
HP kW HP kW
2P5 2.5 A 0.5 0.4 0.5 0.4
5P0 5.0 A 1.0 0.75 1.0 0.75
8P0 8.0 A 2.0 1.5 2.0 1.5
011 11.0 A 3.0 2.2 3.0 2.2
017 17.5 B 5.0 4.0 5.0 4.0
024 24.0 C 7.5 5.5 7.5 5.5
032 32.2 D 10.0 7.5 10.0 7.5
048(1) 48.3 E15.0 11.0 15.0 11.0
062(1) 62.1 E20.0 15.0 15.0 11.0

8Rockwell Automation Publication 520-TD002A-EN-E - May 2015
PowerFlex 527 AC Drive Specifications
Technical Specifications
Protection
Electrical
Specifications PowerFlex 527
Bus Overvoltage Trip
100...120V AC Input:
200...240V AC Input:
380...480V AC Input:
525...600V AC Input:
405V DC bus (equivalent to 150V AC incoming line)
405V DC bus (equivalent to 290V AC incoming line)
810V DC bus (equivalent to 575V AC incoming line)
1005V DC bus (equivalent to 711V AC incoming line)
Bus Undervoltage Trip
100...120V AC Input:
200...240V AC Input:
380...480V AC Input:
525...600V AC Input
190V DC bus (equivalent to 75V AC incoming line)
190V DC bus (equivalent to 150V AC incoming line)
390V DC bus (equivalent to 275V AC incoming line)
487V DC bus (equivalent to 344V AC incoming line)
Power Ride-Thru: 100 ms
Logic Control Ride-Thru: 0.5 s minimum, 2 s typical
Electronic Motor Overload Protection: Provides class 10 motor overload protection according to NEC article 430 and motor over-temperature protection according to NEC
article 430.126 (A) (2). UL 508C File 29572.
Overcurrent: 200% hardware limit, 300% instantaneous fault
Ground Fault Trip: Phase-to-ground on drive output
Short Circuit Trip: Phase-to-phase on drive output
Specifications PowerFlex 527
Voltage Tolerance: -15% / +10%
Frequency Tolerance: 47...63 Hz
Input Phases: Three-phase input provides full rating. Single-phase input provides 35% rating on three-phase drives.
Displacement Power Factor: 0.98 across entire speed range
Maximum Short Circuit Rating: 100,000 Amps Symmetrical
Actual Short Circuit Rating: Determined by AIC Rating of installed fuse/circuit breaker
Transistor Type: Isolated Gate Bipolar Transistor (IGBT)
Internal DC Bus Choke
200...240V AC Input:
380...480V AC Input:
525...600V AC Input:
Only for Frame E drive ratings
11 kW (15 HP)
15...18.5 kW (20...25 HP) – Heavy Duty
15...18.5 kW (20...25 HP) – Heavy Duty

Rockwell Automation Publication 520-TD002A-EN-E - May 2015 9
PowerFlex 527 AC Drive Specifications
Control
Control Inputs
Specifications PowerFlex 527
Method •Frequency Control:
–Volts per Hertz (V/Hz)
–Sensorless Vector Control (SVC)
–Sensorless Vector Control (SVC) Economizer
•Position Loop:
–Closed Loop Position Vector Control (with optional encoder card)
•Velocity Loop:
–Closed Loop Velocity Vector Control (with optional encoder card)
Carrier Frequency 2...8 kHz, Drive rating based on 4 kHz
Frequency Accuracy
Digital Input:
Analog Input:
Analog Output:
Within ±0.05% of set output frequency
Within 0.5% of maximum output frequency, 10-Bit resolution
±2% of full scale, 10-Bit resolution
Performance
V/Hz (Volts per Hertz):
SVC (Sensorless Vector):
SVC Economizer:
±1% of base speed across a 60:1 speed range
±0.5% of base speed across a 100:1 speed range
±0.5% of base speed across a 100:1 speed range
Performance with Encoder
Closed Loop Velocity Vector Control: ±0.1% of base speed across a 100:1 speed range
Output Voltage Range: 0V to rated motor voltage
Output Frequency Range: 0...500 Hz (programmable)
Efficiency: 97.5% (typical)
Stop Modes: Multiple programmable stop modes including – Disable & Coast, Current Decel & Disable, and Ramp Decel & Hold
Accel/Decel: “REAL” tag programmable with Studio 5000 motion instructions.
For more information see the Logix5000 Motion Controllers Instructions Reference Manual, publication MOTION-RM002.
Intermittent Overload
Normal Duty:
Heavy Duty:
110% Overload capability for up to 60 s, 150% for up to 3 s
Applies for power rating above 15 kW (20 HP) only. Based on 480V drive rating.
150% Overload capability for up to 60 s, 180% for up to 3 s (200% programmable)
Specifications PowerFlex 527
Digital Bandwidth: 10 Rad/s for open and closed loop
Quantity: (4) Programmable
Current: 6 mA
Type
Source Mode (SRC):
Sink Mode (SNK):
18...24V = ON, 0...6V = OFF
0...6V = ON, 18...24V = OFF
Analog Quantity: (2) Isolated, ±10V and 4-20 mA
Specification
Resolution:
±10V DC Analog:
4-20 mA Analog:
External Pot:
10-bit
100k ohm input impedance
250 ohm input impedance
1...10k ohm, 2 W minimum

10 Rockwell Automation Publication 520-TD002A-EN-E - May 2015
PowerFlex 527 AC Drive Specifications
Control Outputs
Encoder
Safety
(per
channel)
Input Current: <10 mA
Input ON Voltage, max: 18...26.4V DC
Input OFF Voltage, max: 5V DC
Input ON Current: 10 mA
Input OFF Current: 500 µA
Pulse Rejection Width: 700 µs
External Power Supply: SELV/PELV
Input Type: Optically isolated and reverse voltage protected
Specifications PowerFlex 527
Relay Quantity: (2) 1 Programmable Form A and 1 Programmable Form B
Specification
Resistive Rating:
Inductive Rating:
3.0 A @ 30V DC, 3.0 A @ 125V, 3.0 A @ 240V AC
0.5 A @ 30V DC, 0.5 A @ 125V, 0.5 A @ 240V AC
Opto Quantity: (2) Programmable
Specification: 30V DC, 50 mA Non-inductive
Analog Quantity: (1) Non-Isolated 0-10V or 4-20 mA
Specification
Resolution:
0-10V DC Analog:
4-20 mA Analog:
10-bit
1 k ohm minimum
525 ohm maximum
Specifications PowerFlex 527
Type: Incremental, dual channel
Supply: 5V, 12V, 250 mA
Quadrature: 90°, ±27°@ 25 °C
Duty Cycle: 50%, +10%
Requirements: Encoders must be line driver type, quadrature (dual channel), 3.5...26V DC output, single-ended or differential andcapable of supplying
a minimum of 10 mA per channel.
Allowable input is DC up to a maximum frequency of 250 kHz. The encoder I/O automatically scales to allow 5V, 12V and 24V DC nominal
voltages.
Specifications PowerFlex 527

Rockwell Automation Publication 520-TD002A-EN-E - May 2015 11
PowerFlex 527 AC Drive Specifications
Environmental Specifications
Specifications PowerFlex 527
Altitude
Without derating:
With derating:
See Current Derating Curves on page 17 for derating guidelines.
1000 m (3300 ft) max.
Up to 4000 m (13,200 ft) max., with the exception of 600V drives at 2000 m (6600 ft) max.
Surrounding Air Temperature, max.
Without derating:
With derating:
See Current Derating Curves on page 17 for derating guidelines.
-20...50 °C (-4...122 °F)
-20...60 °C (-4...140 °F) or -20...70 °C (-4...158 °F) with optional Control Module Fan kit.
Storage Temperature
Frame A...D:
Frame E:
-40...85 °C (-40...185 °F)
-40...70 °C (-40...158 °F)
Atmosphere:
Relative Humidity: 0...95% noncondensing
Shock:
Vibration:
Complies with IEC 60068-2-27
Complies with IEC 60068-2-6:2007
Conformal Coating: Complies with:
IEC 60721-3-3 to level 3C2 (chemical and gases only)
Surrounding Environment Pollution Degree
Pollution Degree 1 & 2: All enclosures acceptable.
Sound Pressure Level (A-weighted)
Frame A & B:
Frame C:
Frame D:
Frame E:
Measurements are taken 1 m from the drive.
Maximum 53 dBA
Maximum 57 dBA
Maximum 64 dBA
Maximum 68 dBA
IMPORTANT
Drive must not be installed in an area where the ambient atmosphere contains volatile or corrosive gas, vapors
or dust. If the drive is not goingto be installed for a period of time, it must be stored in an area where it will not
be exposed to a corrosive atmosphere.
Frame
Size
Operating and Nonoperating Nonoperating (Transportation)
Force (Shock/Vibration) Mounting Type Force (Shock/Vibration) Mounting Type
A 15 g / 2 g DIN rail or screw 30 g/ 2.5 g Screw only
B 15 g / 2 g DIN rail or screw 30 g/ 2.5 g Screw only
C 15 g / 2 g DIN rail or screw 30 g/ 2.5 g Screw only
D 15 g / 2 g Screw only 30 g/ 2.5 g Screw only
E 15 g / 1.5 g Screw only 30 g/ 2.5 g Screw only

12 Rockwell Automation Publication 520-TD002A-EN-E - May 2015
PowerFlex 527 AC Drive Specifications
Certifications
Certification PowerFlex 527
c-UL-us Listed to UL508C and CAN/CSA-C22.2 No. 14-05.
RCM Australian Communications and Media Authority
In conformity with the following:
Radiocommunications Act: 1992
Radiocommunications Standard: 2008
Radiocommunications Labelling Notice: 2008
Standards applied:
EN 61800-3:2004+A1:2012
CE In conformity with the following European Directives:
Low Voltage Directive 2006/95/EC: 61800-5-1
EMC Directive 2004/108/EC: EN 61800-3
Machine Directive 2006/42/EC: EN 60261
TUV TÜV Rheinland
Standards applied:
EN ISO 13849-1:2008+AC:2009
EN 61800-5-2:2007
EN 62061:2005+A1:2013
EN 60204-1:2006+A1:2009
IEC 61508 Part 1-7:2010
Certified to ISO 13849-1 SIL3/PLe with embedded Safe Torque-Off function
Certified to ISO 61800-5-2 and EN 62061 SIL3/PLe with Network Torque-0ff function
Meets Functional Safety (FS) when used with embedded Safe Torque-Off function
KCC Korean Registration of Broadcasting and Communications Equipment
Compliant with the following standards:
Article 58-2 of Radio Waves Act, Clause 3
EAC Customs Union:
Low Voltage TR CU 004/2011
EMC TR CU 020/2011
AC 156 Tested by Trentec to be compliant with AC156 Acceptance Criteria for Seismic Qualification Testing of Nonstructural Componentsand
2003 International Building Code for worst-case seismic level for USA excluding site class F
EPRI Electric Power Research Institute
Certified compliant with the following standards:
SEMI F47
IEC 61000-4-34
ODVA ODVA conformance tested to EtherNet/IP specifications
Lloyd’s Register Llyod’s Register Type Approval Certificate 15/80016(E1)
IEEE P1668 Product meets the requirements of IEEE P1668
RoHS Compliant with the European “Restriction of Hazardous Substances” Directive
The drive is also designed to meet the appropriate portions of the following specifications:
NFPA 70 - US National Electrical Code
NEMA ICS 7.1 - Safety standards for Construction and Guide for Selection, Installation and Operation of Adjustable Speed Drive Systems.
N223
0035
Functional
Safety
Type
Approved
www.tuv.com
ID 0600000000

Rockwell Automation Publication 520-TD002A-EN-E - May 2015 13
PowerFlex 527 AC Drive Specifications
Dimensions and Weights
Frame/Rating Cross-Reference
Catalog Number Description
PowerFlex 527 Drive Ratings
25C - V 2P5 N 1 0 4
Drive Voltage Rating Rating Enclosure HIM Emission Class Version
Catalog No.
Output Ratings
Input Voltage Range Total Watts Loss Frame Size
Normal Duty Heavy Duty
Output Current (A)HP kW HP kW
100...120V AC (-15%, +10%) – 1-Phase Input, 0...230V 3-Phase Output
25C-V2P5N104 0.5 0.4 0.5 0.4 2.5 85...132 27.0 A
25C-V4P8N104 1.0 0.75 1.0 0.75 4.8 85...132 53.0 B
25C-V6P0N104 1.5 1.1 1.5 1.1 6.0 85...132 67.0 B
200...240V AC (-15%, +10%) – 1-Phase Input, 0...230V 3-Phase Output
25C-A2P5N104 0.5 0.4 0.5 0.4 2.5 170...264 29.0 A
25C-A4P8N104 1.0 0.75 1.0 0.75 4.8 170...264 50.0 A
25C-A8P0N104 2.0 1.5 2.0 1.5 8.0 170...264 81.0 B
25C-A011N104 3.0 2.2 3.0 2.2 11.0 170...264 111.0 B
200...240V AC (-15%, +10%) – 1-Phase Input with EMC Filter, 0...230V 3-Phase Output
25C-A2P5N114 0.5 0.4 0.5 0.4 2.5 170...264 29.0 A
25C-A4P8N114 1.0 0.75 1.0 0.75 4.8 170...264 53.0 A
25C-A8P0N114 2.0 1.5 2.0 1.5 8.0 170...264 84.0 B
25C-A011N114 3.0 2.2 3.0 2.2 11.0 170...264 116.0 B
200...240V AC (-15%, +10%) – 3-Phase Input, 0...230V 3-Phase Output
25C-B2P5N104 0.5 0.4 0.5 0.4 2.5 170...264 29.0 A
25C-B5P0N104 1.0 0.75 1.0 0.75 5.0 170...264 50.0 A
25C-B8P0N104 2.0 1.5 2.0 1.5 8.0 170...264 79.0 A
25C-B011N104 3.0 2.2 3.0 2.2 11.0 170...264 107.0 A
25C-B017N104 5.0 4.0 5.0 4.0 17.5 170...264 148.0 B
25C-B024N104 7.5 5.5 7.5 5.5 24.0 170...264 259.0 C
25C-B032N104 10.0 7.5 10.0 7.5 32.2 170...264 323.0 D
25C-B048N104 15.0 11.0 10.0 7.5 48.3 170...264 584.0 E
25C-B062N104 20.0 15.0 15.0 11.0 62.1 170...264 708.0 E
380...480V AC (-15%, +10%) – 3-Phase Input, 0...460V 3-Phase Output(1)
25C-D1P4N104 0.5 0.4 0.5 0.4 1.4 323...528 27.0 A
25C-D2P3N104 1.0 0.75 1.0 0.75 2.3 323...528 37.0 A
25C-D4P0N104 2.0 1.5 2.0 1.5 4.0 323...528 80.0 A
25C-D6P0N104 3.0 2.2 3.0 2.2 6.0 323...528 86.0 A
25C-D010N104 5.0 4.0 5.0 4.0 10.5 323...528 129.0 B
25C-D013N104 7.5 5.5 7.5 5.5 13.0 323...528 170.0 C
25C-D017N104 10.0 7.5 10.0 7.5 17.0 323...528 221.0 C
25C-D024N104 15.0 11.0 15.0 11.0 24.0 323...528 303.0 D
25C-D030N104 20.0 15.0 15.0 11.0 30.0 323...528 387.0 D
25C-D037N114(2) 25.0 18.5 20.0 15.0 37.0 323...528 602.0 E
25C-D043N114(2) 30.0 22.0 25.0 18.5 43.0 323...528 697.0 E

14 Rockwell Automation Publication 520-TD002A-EN-E - May 2015
PowerFlex 527 AC Drive Specifications
(1) A non-filtered drive is not available for 380...480V AC 25 HP (18.5 kW) and 30 HP (22.0 kW) ratings. Filtered drives are available, however you must verify that the application will support a filtered drive.
(2) Catalogs 25C-037N114 and 25C-043N114 come with an EMC filter.
Catalog No.
Output Ratings
Input Voltage Range Total Watts Loss Frame Size
Normal Duty Heavy Duty
Output Current (A)HP kW HP kW
380...480V AC (-15%, +10%) – 3-Phase Input with EMC Filter, 0...460V 3-Phase Output
25C-D1P4N114 0.5 0.4 0.5 0.4 1.4 323...528 27.0 A
25C-D2P3N114 1.0 0.75 1.0 0.75 2.3 323...528 37.0 A
25C-D4P0N114 2.0 1.5 2.0 1.5 4.0 323...528 81.0 A
25C-D6P0N114 3.0 2.2 3.0 2.2 6.0 323...528 88.0 A
25C-D010N114 5.0 4.0 5.0 4.0 10.5 323...528 133.0 B
25C-D013N114 7.5 5.5 7.5 5.5 13.0 323...528 175.0 C
25C-D017N114 10.0 7.5 10.0 7.5 17.0 323...528 230.0 C
25C-D024N114 15.0 11.0 15.0 11.0 24.0 323...528 313.0 D
25C-D030N114 20.0 15.0 15.0 11.0 30.0 323...528 402.0 D
25C-D037N114 25.0 18.5 20.0 15.0 37.0 323...528 602.0 E
25C-D043N114 30.0 22.0 25.0 18.5 43.0 323...528 697.0 E
525...600V AC (-15%, +10%) – 3-Phase Input, 0...575V 3-Phase Output
25C-E0P9N104 0.5 0.4 0.5 0.4 0.9 446...660 22.0 A
25C-E1P7N104 1.0 0.75 1.0 0.75 1.7 446...660 32.0 A
25C-E3P0N104 2.0 1.5 2.0 1.5 3.0 446...660 50.0 A
25C-E4P2N104 3.0 2.2 3.0 2.2 4.2 446...660 65.0 A
25C-E6P6N104 5.0 4.0 5.0 4.0 6.6 446...660 95.0 B
25C-E9P9N104 7.5 5.5 7.5 5.5 9.9 446...660 138.0 C
25C-E012N104 10.0 7.5 10.0 7.5 12.0 446...660 164.0 C
25C-E019N104 15.0 11.0 15.0 11.0 19.0 446...660 290.0 D
25C-E022N104 20.0 15.0 15.0 11.0 22.0 446...660 336.0 D
25C-E027N104 25.0 18.5 20.0 15.0 27.0 446...660 466.0 E
25C-E032N104 30.0 22.0 25.0 18.5 32.0 446...660 562.0 E

Rockwell Automation Publication 520-TD002A-EN-E - May 2015 15
PowerFlex 527 AC Drive Specifications
Drive Dimensions and Weight
Dimensions are in mm and (in.). Weights are in kg and (lb).
Design Considerations
Mounting Considerations
•Mount the drive upright on a flat, vertical and level surface.
•Protect the cooling fan by avoiding dust or metallic particles.
•Do not expose to a corrosive atmosphere.
•Protect from moisture and direct sunlight.
Frame Size A B C D E Weight
A 72.0 (2.83) 152.0 (5.98) 172.0 (6.77) 57.5 (2.26) 140.0 (5.51) 1.1 (2.4)
B 87.0 (3.43) 180.0 (7.09) 172.0 (6.77) 72.5 (2.85) 168.0 (6.61) 1.6 (3.5)
C 109.0 (4.29) 220.0 (8.66) 184.0 (7.24) 90.5 (3.56) 207.0 (8.15) 2.3 (5.0)
D 130.0 (5.12) 260.0 (10.24) 212.0 (8.35) 116.0 (4.57) 247.0 (9.72) 3.9 (8.6)
E 185.0 (7.28) 300.0 (11.81) 279.0 (10.98) 160.0 (6.30) 280.0 (11.02) 12.9 (28.4)
Frame Screw Size Screw Torque
A M5 (#10...24) 1.56...1.96 Nm (14...17 lb-in.)
B M5 (#10...24) 1.56...1.96 Nm (14...17 lb-in.)
C M5 (#10...24) 1.56...1.96 Nm (14...17 lb-in.)
D M5 (#10...24) 2.45...2.94 Nm (22...26 lb-in.)
E M8 (5/16 in.) 6.0...7.4 Nm (53...65 lb-in.)
AC
B
E
D

16 Rockwell Automation Publication 520-TD002A-EN-E - May 2015
PowerFlex 527 AC Drive Specifications
Minimum Mounting Clearances
See Dimensions and Weights on page 13 for mounting dimensions.
(1) For Frame E with Control Module Fan Kit only, clearance of 95 mm (3.7 in.) is required.
(2) For Frame E with Control Module Fan Kit only, clearance of 12 mm (0.5 in.) is required.
Ambient Operating Temperatures
See Accessories and Dimensions on page 31 for option kits.
(1) IP 30/NEMA1/UL Type 1 ratingrequires installationof the PowerFlex 520-Series IP30/NEMA 1/UL Type 1 option kit, catalog number 25-JBAx.
(2) For catalogs 25C-D1P4N104 and 25C-E0P9N104, the temperature listed under the Max. (Derate) column is reduced by 5 °C (9 °F) for all mounting methods.
(3) For catalogs 25C-D1P4N104 and 25C-E0P9N104, the temperature listed under the Max. with Control Module Fan Kit (Derate) column is reduced by 10 °C (18 °F) for vertical and vertical with zero stacking
mounting methods only.
(4) Catalogs 25C-D1P4N104 and 25C-E0P9N104 cannot be mounted using either of the horizontal mounting methods.
(5) Requires installation of the PowerFlex 520-Series Control Module Fan Kit, catalog number 25-FANx-70C.
Mounting Enclosure Rating(1)
Ambient Temperature
Minimum Maximum (No Derate) Maximum (Derate)(2) Maximum with Control Module
Fan Kit (Derate)(3)(5)
Vertical IP 20/Open Type
-20 °C (-4 °F)
50 °C (122 °F) – 70 °C (158 °F)
IP 30/NEMA 1/UL Type 1 45 °C (113 °F) 55 °C (131 °F) –
Vertical, Zero Stacking IP 20/Open Type 45 °C (113 °F) – 65 °C (149 °F)
Horizontal
with Control Module Fan Kit(4)(5) IP 20/Open Type 50 °C (122 °F) – 70 °C (158 °F)
Horizontal, Zero Stacking
with Control Module Fan Kit(4)(5) IP 20/Open Type 45 °C (113 °F) – 65 °C (149 °F)
Vertical, Zero Stacking
No clearance between drives.
Horizontal, Zero Stacking with Control Module Fan Kit
No clearance between drives.
Vertical Vertical, Zero Stacking with
Control Module Fan Kit
No clearance between drives.
Vertical with Control Module Fan Kit
Horizontal with Control Module Fan Kit
25 mm
(1.0 in.)
25 mm
(1.0 in.) (2)
(2)
25 mm
(1.0 in.)
50 mm
(2.0 in.)
50 mm
(2.0 in.)(1) 50 mm (2.0 in.)(1)
50 mm
(2.0 in.)(1)
50 mm
(2.0 in.)
50 mm
(2.0 in.) 50 mm
(2.0 in.)
50 mm
(2.0 in.) 50 mm
(2.0 in.)
50 mm
(2.0 in.)
50 mm
(2.0 in.)
50 mm
(2.0 in.)
50 mm
(2.0 in.)
50 mm
(2.0 in.) 50 mm
(2.0 in.)
50 mm
(2.0 in.)(1)

Rockwell Automation Publication 520-TD002A-EN-E - May 2015 17
PowerFlex 527 AC Drive Specifications
Current Derating Curves
Vertical Mounting
Horizontal Mounting/Floor
Derating Guidelines for High Altitude
The drive can be used without derating at a maximum altitude of 1000 m (3300 ft).
If the drive is used above 1000 m (3300 ft):
•Derate the maximum ambient temperature by 5 °C (41 °F) for every additional 1000 m (3300 ft), subject to limits
listed in the Altitude Limit (Based on Voltage) table below.
Or
•Derate the output current by 10% for every additional 1000 m (3300 ft), subject to limits listed in the Altitude Limit
(Based on Voltage) table below.
Altitude Limit (Based on Voltage)
Drive Rating Center Ground (Wye Neutral)
Corner Ground, Impedance
Ground, or Ungrounded
100...120V 1-Phase 6000 m 6000 m
200...240V 1-Phase 2000 m 2000 m
200...240V 3-Phase 6000 m 2000 m
380...480V 3-Phase 4000 m 2000 m
525...600V 3-Phase 2000 m 2000 m
Single Drive Zero Stacking
Ambient Temperature (°C)
40
100
90
110
120
80
70
60
50
45403530 60 65 70 75 80 5550
Percentage of Rated Current (%)
with Control
Module Fan Kit
IP 20/Open Type
Ambient Temperature (°C)
40
100
90
110
120
80
70
60
50
45403530 60 65 70 75 80 5550
Percentage of Rated Current (%)
IP 30/NEMA 1 with Control
Module Fan Kit
IP 20/Open Type
Single Drive Zero Stacking
Ambient Temperature (°C)
40
100
90
120
110
80
70
60
50
30 35 70 75 80 60 6550 5540 45
Percentage of Rated Current (%)
with Control
Module Fan Kit
IP 20/Open Type
Ambient Temperature (°C)
40
100
90
120
110
80
70
60
50
30 35 70 75 80 60 6550 5540 45
Percentage of Rated Current (%)
with Control
Module Fan Kit
IP 20/Open Type

18 Rockwell Automation Publication 520-TD002A-EN-E - May 2015
PowerFlex 527 AC Drive Specifications
High Altitude
Debris Protection
Take precautions to prevent debris from falling through the vents of the drive housing during installation.
Storage
•Store within an ambient temperature range of -40...85 °C(1).
•Store within a relative humidity range of 0...95%, noncondensing.
•Do not expose to a corrosive atmosphere.
(1) The maximum ambient temperature for storing a Frame E drive is 70 °C.
AC Supply Source Considerations
Ungrounded Distribution Systems
Disconnecting MOVs
To prevent drive damage, the MOVs connected to ground shall be disconnected if the drive is installed on an ungrounded
distribution system (IT mains) where the line-to-ground voltages on any phase could exceed 125% of the nominal line-to-
line voltage. To disconnect these devices, remove the jumper shown in the diagrams below.
1. Turn the screw counterclockwise to loosen.
2. Pull the jumper completely out of the drive chassis.
3. Tighten the screw to keep it in place.
ATTENTION: PowerFlex 520-Series drives contain protective MOVs that are referenced to ground. These devices must be
disconnected if the drive is installed on an ungrounded or resistive grounded distribution system.
ATTENTION: Removing MOVs in drives with an embedded filter will also disconnect the filter capacitor from earth ground.
Altitude (m)
Percentage of Rated Current (%)
40
90
100
110
120
80
70
60
50
04000 300020001000
Altitude (m)
Ambient Temperature (°C)
20
50
60
40
30
04000 300020001000

Rockwell Automation Publication 520-TD002A-EN-E - May 2015 19
PowerFlex 527 AC Drive Specifications
Jumper Location (Typical)
Phase to Ground MOV Removal
Input Power Conditioning
The drive is suitable for direct connection to input power within the rated voltage of the drive (see Input Power Conditions
on page 19). Listed in the Input Power Conditions table below are certain input power conditions which may cause
component damage or reduction in product life. If any of these conditions exist, install one of the devices listed under the
heading Corrective Action on the line side of the drive.
Input Power Conditions
(1) For drives applied on an open delta with a middle phase grounded neutral system, the phase opposite the phase that is tapped in the middle to the neutral or earth is referred to as the “stinger leg,” “high
leg,” “red leg,” etc. This leg should be identified throughout the system with red or orange tape on the wire at each connection point. The stinger leg should be connected to the center Phase B on the
reactor. See Bulletin 1321-3R Series Line Reactors on page 35 for specific line reactor part numbers.
(2) See Accessories and Dimensions on page 31 for accessory ordering information.
IMPORTANT
Tighten screw after jumper removal.
IMPORTANT
Only one device per branch circuit is required. It should be mounted closest to the branch and sized to handle the total current of
the branch circuit.
Input Power Condition Corrective Action
Low Line Impedance (less than 1% line reactance) •Install Line Reactor(2)
•or Isolation Transformer
Greater than 120 kVA supply transformer
Line has power factor correction capacitors •Install Line Reactor(2)
•or Isolation Transformer
Line has frequent power interruptions
Line has intermittent noise spikes in excess of 6000V (lightning)
Phase to ground voltage exceeds 125%of normal line to line voltage •Remove MOV jumper to ground.
•or Install Isolation Transformer with grounded secondary if necessary.
Ungrounded distribution system
240V open delta configuration (stinger leg)(1) •Install Line Reactor(2)
Power Module
R/L1
S/L2
T/L3
1234
Three-Phase
AC Input
Jumper

20 Rockwell Automation Publication 520-TD002A-EN-E - May 2015
PowerFlex 527 AC Drive Specifications
General Grounding Requirements
The drive Safety Ground - (PE) must be connected to system ground. Ground impedance must conform to the
requirements of national and local industrial safety regulations and/or electrical codes. The integrity of all ground
connections should be periodically checked.
Typical Grounding
Ground Fault Monitoring
If a system ground fault monitor (RCD) is to be used, only Type B (adjustable) devices should be used to avoid nuisance
tripping.
Safety Ground - (PE)
This is the safety ground for the drive that is required by code. One of these points must be connected to adjacent building
steel (girder, joist), a floor ground rod or bus bar. Grounding points must comply with national and local industrial safety
regulations and/or electrical codes.
Motor Ground
The motor ground must be connected to one of the ground terminals on the drive.
Shield Termination - SHLD
Either of the safety ground terminals located on the power terminal block provides a grounding point for the motor cable
shield. The motor cable shield connected to one of these terminals (drive end) should also be connected to the motor
frame (motor end). Use a shield terminating or EMI clamp to connect the shield to the safety ground terminal. The
earthing plate or conduit box option may be used with a cable clamp for a grounding point for the cable shield.
When shielded cable is used for control and signal wiring, the shield should be grounded at the source end only, not at the
drive end.
SHLD
U/T1
V/T2
W/T3
R/L1
S/L2
T/L3
Esc
Sel
