Allen + Roth 1328WC-24-220 User manual

1328WC-24-220 24" Chocolate Finish Wall Cabinet
1328WC-24-236 24" Espresso Finish Wall Cabinet
1328WC-24-241 24" White Oak Finish Wall Cabinet
1328WC-24-242 24" Light Gray Finish Wall Cabinet
MODEL NUMBER DESCRIPTION
ATTACH YOUR RECEIPT HERE
Serial Number__________________ Purchase Date__________________
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-855-571-1044, 8 a.m. - 8 p.m., EST, Monday - Sunday.
WALL CABINET
MODEL # 1328WC-24-220; 1328WC-24-236;
1328WC-24-241; 1328WC-24-242
welcoming • sophisticated • inspiring

2
TABLE OF CONTENTS
Package Contents...........................................................................................................................3
Hardware Contents..........................................................................................................................3
Safety Information. .........................................................................................................................4
Preparation ....................................................................................................................................4
Assembly or Installation Instructions .............................................................................................4
Care and Maintenance ...................................................................................................................7
Warranty ........................................................................................................................................7
Replacement Parts List ................................................................................................................. 8

3
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Cabinet 1
B Wall Bracket 1
C Shelf 2
HARDWARE CONTENTS (NOT SHOWN ACTUAL SIZE)
AA
Shelf pin
Qty. 8
Touch-up pen
Qty. 1
BB
B
A
C
C

4
INSTALLATION INSTRUCTIONS
PREPARATION
Estimated Assembly Time: 20 minutes (24 hours for silicone caulk to dry).
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install
this product.
WARNING
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents list. If any part is missing or damaged, do not
attempt to assemble the product.
Tools Required for Assembly (not included): Phillips screwdriver, utility knife or scissors,
power drill with drill bit
Helpful Tools (not included): Measuring tape, level
1. Locate Wall Bracket (B) and set aside.
Locate and mark wall stud locations where
Cabinet (A) will be placed. Center Wall
Bracket (B) in desired level location off the
floor and mark locations where Wall Bracket
(B) meets the location of the wall studs.
CAUTION
• Some steps are more easily handled with two adults.
• Before installation, carefully use scissors or utility knife to cut and unwrap all parts. Make sure
you DO NOT discard the hardware.
• Use care when installing your new wall cabinet; take your time and follow the installation
instructions closely.
1
B

5
3. With the help of another adult, carefully
lower the Cabinet (A) down onto the Wall
Bracket (B). Be sure the Cabinet (A) is secure
to the wall before letting go.
2. Using hardware appropriate for your wall
type (not included), secure the Wall Bracket
(B) to the wall into preferably 2 wall studs. Use
hardware such as a cabinet screw or toggle bolt
depending on your wall type. Make sure the
Wall Bracket (B) is level and centered well to the
desired location of the Cabinet (A). Be careful
not to disturb any plumbing or electrical lines
that may be concealed in the wall.
!IMPORTANT SAFTEY STEP!
It is critical to have a strong secure
connection to the wall before continuing to
the next step.
INSTALLATION INSTRUCTIONS
2
B
1
2
B
A
3

6
4. Insert shelf pins (BB) at desired height, ensuring
they are level. Place shelves (C) on top of shelf
pins (BB).
Hardware Used
Shelf Pin x 8
BB
5. If you need to adjust the doors, do so in the following manner.
To adjust door up or down, loosen screws (a) on both hinges, adjust door, and retighten screws.
To adjust door left or right, turn screws (b) on both hinges, in or out.
To adjust door in or out, loosen screws (c) on both hinges, adjust door, and retighten screws.
INSTALLATION INSTRUCTIONS
C
2
C
2
4
1
BB
5
2
2
2
2
2
2
a
3
a
1
b
1
1
c
1
c
3

WARRANTY
CARE AND MAINTENANCE
• Dust the Wall cabinet regularly with a soft, non-lint producing cloth or household dusting product.
• You can clean the Wall cabinet with a gentle, non-abrasive household cleaner.
• Make sure to dry the wood immediately with a soft cloth or towel.
• Tips for using touch-up pen (AA): For scratches, stroke in direction of scratch. Rub off excess
colorant promptly with a soft cloth.
The manufacturer warrants this item against defects in materials and workmanship for a period
of one (1) year from the date of original retail purchase. This warranty applies only to the original
purchaser. This warranty does not apply to any damage on the product by accident, misuse, or
modified, improper installation or by affixing accessories not produced by the manufacturer. The
manufacturer is not accountable whatsoever for product installation during the warranty period.
There is no further expressed warranty. The manufacturer shall not be legally responsible for
incidental, consequential or special damages arising at or in connection with product use or
performance except as may otherwise be accorded by law. The manufacturer disclaims any and
all implied warranties.
7

8
REPLACEMENT PARTS LIST FOR 1328WC-24-220
C-90-107
Handle CF-96-1328-BN
AA
Hinge
BB
CC
DD
PART DESCRIPTION PART#
B
Touch-up pen
1328WC-24-220-001
C 1328WC-24-220-002
OX-0610
Shelf pin B1044
Wall Bracket
Shelf
D 1328WC-24-220-
003/004
E
Left Door
Right Door
For replacement parts, call our customer service department at 1-855-571-1044, 8 a.m. - 8
p.m., EST, Monday - Sunday.
AA CC DDBB
C
B
E
D

9
REPLACEMENT PARTS LIST FOR 1328WC-24-236
C-90-107
Handle CF-96-1328-BN
AA
Hinge
BB
CC
DD
PART DESCRIPTION PART#
B
Touch-up pen
1328WC-24-236-001
C 1328WC-24-236-002
W3504A
Shelf pin B1044
Wall Bracket
Shelf
D 1328WC-24-236-
003/004
E
Left Door
Right Door
For replacement parts, call our customer service department at 1-855-571-1044, 8 a.m. - 8
p.m., EST, Monday - Sunday.
AA CC DDBB
C
B
E
D

10
REPLACEMENT PARTS LIST FOR 1328WC-24-241
C-90-107
Handle CF-96-1328-BN
AA
Hinge
BB
CC
DD
PART DESCRIPTION PART#
B
Touch-up pen
1328WC-24-241-001
C 1328WC-24-241-002
OF-0010
Shelf pin B1044
Wall Bracket
Shelf
D 1328WC-24-241-
003/004
E
Left Door
Right Door
For replacement parts, call our customer service department at 1-855-571-1044, 8 a.m. - 8
p.m., EST, Monday - Sunday.
AA CC DDBB
C
B
E
D

11
REPLACEMENT PARTS LIST FOR 1328WC-24-242
C-90-107
Handle CF-96-1328-BN
AA
Hinge
BB
CC
DD
PART DESCRIPTION PART#
B
Touch-up pen
1328WC-24-242-001
C 1328WC-24-242-002
OF-0120R
Shelf pin B1044
Wall Bracket
Shelf
D 1328WC-24-242-
003/004
E
Left Door
Right Door
For replacement parts, call our customer service department at 1-855-571-1044, 8 a.m. - 8
p.m., EST, Monday - Sunday.
AA CC DDBB
C
B
E
D
