Allen + Roth S-DN091 User manual

5 PC WOVEN DINING SET
ITEM # 0773120
Serial Number Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Friday.
AB 17878
ATTACH YOUR RECEIPT HERE
MODEL # S-DN091
Français p.10
1

2
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A
B
C
D
Backrest
Seat Cushion
Chair Seat
Connect Bar 1
E
F
Chair Front Leg
Glass
G
H
Table Top
Table Leg
I
4
4
4
8
4
1
1
2
1
Connect Bar 2
B
AC
DEF
H
GI

3
HARDWARE CONTENTS (shown actual size)
Qty. 4 + 1 spare Qty. 74 + 8 spare Qty. 74 + 8 spare
Qty. 52 + 6 spare Qty. 8 + 1 spare Qty. 10 + 1 spare
Qty. 74 + 8 spare Qty. 2
M6 Wrench
M6 x 25 mm
Bolt
M6 x 15 mm
Bolt
M6 x 50 mm
Bolt
M6 x 35 mm
Bolt
Plastic Cap
M6
Spring Washer
M6
Washer
BBAA CC
DD FFEE
GG HH
HH

4
SAFETY INFORMATION
PREPARATION
Before beginning assembly ofproduct, make sureall parts are p egakcaphtiwstraperapmoC.tneser
contents list and hardware contents list. If any part is missing or damaged, do not attempt to
assemble the product.
Estimated Assembly Time: 30 minutes
Tools Required for Assembly (included): Wrench
Please read and understand this entire manual before attempting to assemble or install
the product.
WARNING
Keep all children and pets away from assembly area. Children and pets should be
supervised when they are in the area of the set.
When placing in the desired location, ensure that all legs are resting on the same surface.
You may adjust the leg levelers as required to ensure that the item stands in a rigid position.
Some parts may contain sharp edges.
Any assembly or maintenance of the product must be carried out by adults only.
Proper placement of your set is essential. Do not place the product underneath electrical lines.
Keep fingers away from places where they can be pinched or trapped.
CAUTION
• Examine occasionally to ensure that there are no loose parts. If loose parts are found, they must
be retightened fully before additional use.
• Clean the product with mild soap and water. Rinse thoroughly and wait until the product is dry
before reassembling it.
• Do not use bleach, acid, or other abrasive cleaners on the products or frame parts.
• Do not attempt to assemble the set if any parts are missing.
• This product is intended for outdoor use only.
• Keep the original packaging to store the set.
The recommended weight limits for the following item is listed below:
Chair: 250 lbs. (per chair)
If you overload your furniture, injuries can occur.
•

5
Hardware Used
M6 Spring Washer x 16
CC
M6 Washer x 16
DD
DD
GG
GG
EE
BB
BB
CC
CC
M6 x 15 mm Bolt x 8
EE
M6 x 50 mm Bolt x 8
GG
Plastic Cap x 16
HH
M6 Wrench x 2
ASSEMBLY INSTRUCTIONS
1. Attach chair seat (C) to backrest (A) using bolts (EE), spring washers (BB), flat washers (CC) and
bolts (DD), spring washers (BB), and flat washers (CC). Secure all bolts tightly with wrench (HH)
and cover with plastic caps (GG). Repeat these instructions for the three remaining chairs.
NOTE: The list below accounts for the hardware used for the assembly of all four chairs.
1
H
G
I
H
F
A
B
C
DE
A
C
BB

6
ASSEMBLY INSTRUCTIONS
3. Connect backrest (A) and chair front legs (E) to connect bar 1 (D) using bolts (DD), spring washers
(BB) and flat washers (CC). Secure all bolts tightly with wrench (HH) and cover with plastic caps
(GG). Repeat these instructions for the three remaining chairs.
NOTE: The list below accounts for the hardware used for the assembly of all four chairs.
2. Attach chair seat (C) to the middle of chair front leg (E) using bolt (AA), spring washer (BB) and
flat washer (CC). Attach the two sides of chair seat using bolts (DD), spring washers (BB) and flat
washers (CC) separately. Secure all bolts tightly with wrench (HH) and cover with plastic caps
(GG). Repeat these instructions for the three remaining chairs.
NOTE: The list below accounts for the hardware used for the assembly of all four chairs.
2
C
E
CC
BB
DD
GG
CC
BB
AA
GG
CC
BB
DD
GG
3
E
D
A
CC
BB
DD
GG
Hardware Used
DD
M6 x 15 mm Bolt x 8
GG
Plastic Cap x 12
HH
M6 Wrench x 2
CC
M6 Washer x 12
M6 Spring Washer x 12
BB
M6 x 25 mm Bolt x 4
AA
Hardware Used
DD
M6 x 15 mm Bolt x 32
GG
Plastic Cap x 32
HH
M6 Wrench x 2
CC
M6 Washer x 32
M6 Spring Washer x 32
BB

7
4
B
ASSEMBLY INSTRUCTIONS
4. Place the seat cushions (B) on the chairs (one each) and fasten them.
5. Turn over the table top (G) and attach the table legs (H) to the two sides of table top (G) using bolts
(FF), spring washers (BB) and flat washers (CC). Secure all bolts tightly with wrench (HH) and
cover with plastic caps (GG).
Hardware Used
FF
M6 x 35 mm Bolt x 10
GG
Plastic Cap x 10
HH
M6 Wrench x 2
CC
M6 Washer x 10
M6 Spring Washer x 10
BB
5
H
G
CC
BB
FF
GG

CARE AND MAINTENANCE
• Wash the frame with a mild solution of soap and water, rinse with clean water, and dry thoroughly.
• Cushions may also be cleaned by hand with a mild solution of soap and water. Rinse the cushion
cover thoroughly and allow to drip dry. Do not machine wash or tumble dry, as cushions may shrink.
Do not use bleach or solvents on fabrics. Never use cleaners that contain acid or abrasive materials.
• Bolts can loosen over time. Be sure to check bolts occasionally, tightening as needed.
• To improve the lifespan of this furniture, cover when not in use and store in a dry
place in the off season.
8
WARRANTY
This limited warranty is extended to the original purchaser and applies to defects in material and
workmanship of your item provided the item is maintained with care and used only for personal,
residential purposes.
The manufacturer warranty for this item, is to be free of defects in material and workmanship for
a period of 1 year. If any defect is found, please call our customer service department at
1-866-439-9800 for help. The manufacturer will not cover transportation or delivery costs or
compensate the individual or any outside party for assembling or disassembling the product.
This warranty gives you certain rights, and you may have other rights that vary from state to state.
ASSEMBLY INSTRUCTIONS
6. Attach connect bar 2 (I) to the two sides of table
legs (H) using bolts (DD), spring washers (BB)
and flat washers (CC). Finally, turn the table
right-side up and put glass (F) on table top (G).
Hardware Used
DD
M6 x 15 mm Bolt x 4
GG
Plastic Cap x 4
HH
M6 Wrench x 1
CC
M6 Washer x 4
M6 Spring Washer x 4
BB
6
CC BB DD GG
H
I

PART DESCRIPTION PART#
A P30114A17107
B
C
D
Backrest
Seat Cushion
Chair Seat
Connect Bar 1
E
F
Chair Front Leg
Glass
G
H
Table Top
Table Leg
I
P00403G02112
P30215A17107
P11445A17107
P32303A17107
P30602A14000
P31315A17107
P31421A17107
P11446A17107
Connect Bar 2
AA H06025C11
BB
CC
DD
M6 x 25 mm Bolt
M6 Spring Washer
M6 Washer
M6 x 15 mm Bolt
EE
FF
M6 x 50 mm Bolt
M6 x 35 mm Bolt
GG
HH
Plastic Cap
M6 Wrench
H13001C11
H12001C11
H06015C11
H06048C11
H06035C11
P91206A07001
H00002C12
9
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m.,
EST, Monday - Friday.
Printed in China
Production Number：xxxxxxxx
BBAA CC
DD FF
EE
GG HH
HH
A
B
C
E
DD
HH
I
G
F

TRESSÉ DE 5 PIÈCES
POUR COIN-REPAS
MODÈLE # S-DN091
10
ARTICLE # 0773120
Numéro de série
Des questions, des problèmes, des pièces manquantes? Avant de retourner l’article au
détaillant, appelez notre service à la clientèle au 1 866 439-9800, entre 8 h et 20 h (HNE),
du lundi au vendredi.
JOIGNEZ VOTRE REÇU ICI
Date d’achat
