Allen + Roth WSWS-VWU1C User manual

welcoming • sophisticated • inspiring
Serial Number Purchase Date
1
Questions, problems, missing parts? Before returning to your retailer, call our customer service
department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Friday.
ATTACH YOUR RECEIPT HERE
ITEM #0339212, 0339213, 0810376, 2416435
MODEL #WSWS-VWU1C, WSWS-VWU1W
WSWS-VWU1G, LWVTBW
Français p. 10
Español p. 19
VENTILATED WOOD TOWER
allen + roth®is a registered trademark
of LF, LLC. All Rights Reserved.
EB15315
WARNING
UNIT MUST BE PERMANENTLY FASTENED TO THE WALL WITH PROVIDED HARDWARE;
THIS STORAGE UNIT IS NOT DESIGNED OR INTENDED FOR FREESTANDING USE.

32
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Wall Hanging Cleat 2
B Upper Left Side Panel 1
C Upper Right Side Panel 1
D Top/Bottom Fixed Shelf 2
E Adjustable Shelf 2
F Mounting Cleat 1
G Wood Support 2
H Middle Fixed Shelf 1
I Lower Left Side Panel 1
J Lower Right Side Panel 1
KInstallation Template 1
E
E
BC
G
A
F
A
A
D
H
IJ
D
K
HARDWARE CONTENTS (shown actual size)
M6 x 40 mm
Bolt
Qty. 14
Shelf Pin
Qty. 8
Large Flat
Washer
Qty. 4
Allen Wrench
(not shown to size)
Qty. 1
Touch-up Pen
(not shown to size)
(not included for Item
#0339213, 2416435)
Qty. 1
Wood Screw
Qty. 8
Wood Dowel
Qty. 8
Barrel Nut
(not shown to size)
Qty. 6
Lag Bolt
Qty. 4 + 1 extra
M6 x 60 mm
Bolt
Qty. 2
Lock Washer
Qty. 16
Small
Flat Washer
Qty. 16
AA
EE
JJ
KK LL MM NN
FF GG
HH II
BB CC
DD
Large
Cam Lock
Qty. 4
Large
Cam Bolt
Qty. 4

54
PREPARATION
SAFETY INFORMATION
WARNING
Please read and understand this entire manual before attempting to assemble, operate or install
the product.
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, do not attempt to
assemble the product.
Estimated Assembly Time: 60 minutes
Tools Required for Assembly (not included): Phillips Screwdriver, Power Drill, 3/16 in. Drill Bit, 3/8 in.
Drill Bit, 1/2 in. Socket Wrench, Level, Stud Finder, Marking Pencil, Tape Measure, Step Ladder and
Hammer.
UNIT IS INTENDED FOR USE ONLY WITH MAXIMUM WEIGHTS INDICATED.
OVERLOADING STORAGE UNIT WITH PRODUCTS HEAVIER THAN MAXIMUM
WEIGHT MAY RESULT IN INJURY. DISTRIBUTE ANY WEIGHT IN UNITS EVENLY.
• Each shelf maximum load: 30 lbs.
• Do not allow children to climb or play in or around this product.
• Use this unit for its intended purpose only. Do not use shelves as step ladder.
• To avoid damage, assemble the product on a sturdy, level and protective surface.
• Two or more persons must work together to install the unit onto the wall.
• Make sure all bolts/screws are tightly fastened before the unit is used.
• Check bolts/screws periodically and tighten them if necessary.
• Unit must be permanently fastened to the wall with provided hardware; this storage
unit is not designed or intended for freestanding use.
ASSEMBLY INSTRUCTIONS
ASSEMBLY INSTRUCTIONS
Hardware Used
Hardware Used
Hardware Used
Hardware Used
2. Insert wood dowels (GG) into mounting cleat (F).
1. Insert barrel nuts (HH), wood dowels (GG) and
large cam bolts (NN) into upper left side panel (B) and
upper right side panel (C) as shown. Then, attach upper
left side panel (B) and upper right side panel (C) to lower
left side panel (I) and lower right side panel (J). Insert
large cam locks (MM) into lower left side panel (I) and
lower right side panel (J) to secure panel assembly.
3. Insert barrel nut (HH) into mounting cleat (F). Secure
mounting cleat (F), beveled edge down, to upper right side
panel (C) and lower right side panel (J) where shown with
lock washers (CC), small at washers (DD) and M6 x 60 mm
bolts (BB). Then, attach the middle xed shelf (H) and top/
bottom xed shelves (D) to upper right side panel (C) and
lower right side panel (J) with lock washers (CC), small at
washers (DD) and M6 x 40 mm bolts (AA). Tighten all
connections with Allen wrench (KK).
4. Repeat step 3 for upper left side panel (B) and
lower left side panel (I).
2
1
3
4
M6 x 40 mm Bolt
M6 x 40 mm Bolt
Wood Dowel
Wood Dowel
M6 x 60 mm Bolt
M6 x 60 mm Bolt
Lock Washer
Lock Washer
Small Flat Washer
Small Flat Washer
Barrel Nut
Barrel Nut
Barrel Nut
Large Cam Lock
Large Cam Bolt
x 7
x 7
x 4
x 4
x 1
x 1
x 8
x 8
x 8
x 8
x 1
x 1
x 4
x 4
x 4
AA
AA
GG
GG
BB
BB
CC
CC
DD
DD
HH
HH
GG
MM
HH
GG
NN
F
J
C
I
B
F
BB
BB
CC CC
KK
KK
AA
AA
HH
HH
DD DD
DD
CC
CC
HH
MM
NN
Allen Wrench
Allen Wrench
KK
KK
x 1
x 1
D
H
C
J
D
B
I

6 7
ASSEMBLY INSTRUCTIONS
Hardware Used
Hardware Used
Hardware Used
5. Set assembly upright. Insert shelf pins (EE) level
where desired in tower, then rest adjustable shelves
(E) on top.
Note: Ensure the shelf pins (EE) are level.
6. If you intend to install the Expandable Pole (Item
#0339254, sold separately), attach wood supports (G) on
the inside of left upper side panel (B) and/or
right upper side panel (C) using wood screws (FF).
Note: The expandable pole should be installed to the
middle of wood support (G).
5
6
7
Shelf Pin x 8
EE
E
E
EE
EE
EE
Expandable pole kit
(sold separately)
FF
G
G
Wood Screw x 8
FF
7. Using a stud nder (not included), locate the edges of
the wood studs. Find the center line of each stud and draw
a vertical reference line on the wall over each one. Position
installation template (K) at desired location on wall.
Note: The bottom of the installation template (K) should
be no less than 31-1/2 in. from the oor.
Mark mounting holes with a pencil (not included) and dis-
card installation template (K). Drill 3/16 in. pilot holes at
marked locations. Then, with the beveled edge facing up,
attach the wall hanging cleats (A) with
large at washers (JJ) and lag bolts (II).
Lag Bolt
Large Flat Washer
x 4
x 4
II
JJ
Wooden Stud
40.6 in.
Minimum 31-1/2 in.
16 in.
JJ
JJ
II
II
A
A
K
ASSEMBLY INSTRUCTIONS
8. With the help of another person, carefully hang
the unit from mounting cleat (F) and preassembled
cleat on middle xed shelf (H) onto the wall hanging
cleats (A).
8
A
F
CARE AND MAINTENANCE
TROUBLESHOOTING
• Periodically check to make certain all components are properly positioned, free from damage
and rmly connected.
• Use a soft, clean cloth that will not scratch the surface when dusting.
• Never use water to clean the furniture as it may cause damage to the nish.
• Wipe clean using a damp cloth and a mild cleaner. Wipe dry with a clean cloth.
• In the event the furniture is stained or otherwise damaged during use, it is recommended you
call a professional to repair the furniture.
• Keep furniture away from direct sunlight as it may damage the nish.
• It is best to keep the furniture in a climate-controlled environment. Extreme temperature and
humidity changes can cause fading, warping, shrinking and splitting of wood.
• Touch-up pen (LL) has been provided (except in Item #0339213, 2416435) to repair any small
nicks or scratches that may occur during assembly or shipping. If Item #0339213, 2416435 is
damaged and touch-up is required, apply a quality wood polish to the damaged surface. Polish
not included with this item.
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Closet tower tilted. The wall hanging cleats are not level. Reinstall the wall hanging cleats and
ensure they are level.
Closet tower can
not hang on the
wall.
The mounting hole locations are not
correct.
Reinstall wall hanging cleats; make
sure the space between two wall
hanging cleats is 40.6 in. and the
bottom two mounting hole locations
are no less than 31-1/2 in. from the
oor.

8 9
WARRANTY
This product (exclusive of shelves) is warranted to the original purchaser. If there is a failure in this
unit due to defects in materials or workmanship, the manufacturer will repair or replace this item at
our discretion without charge. Warranty is void if product has been assembled incorrectly, misused,
abused by overloading, altered in any way or damaged due to accident. This warranty is not
transferable and does not cover chipping, aking, scratches, rust, dents, or other damages to the
surfaces of this product. Responsibility of the manufacturer is limited to repair or replacement of
this product. The manufacturer is not responsible for consequential, incidental, or other damages or
losses resulting from product failure.
This warranty is in lieu of all other expressed warranties. Some states do not allow the exclusion or
limitation of incidental or consequential damages, so the above limitation may not apply to you. This
warranty gives you specic legal rights and you may have other rights which vary from state to state.
PART DESCRIPTION PART #
A Wall Hanging Cleat *WSWS-VWU1C/W/G/LWVTBW-1-WHC
B Upper Left Side Panel *WSWS-VWU1C/W/G/LWVTBW-2-ULSP
C Upper Right Side Panel *WSWS-VWU1C/W/G/LWVTBW-3-URSP
D Top/Bottom Fixed Panel *WSWS-VWU1C/W/G/LWVTBW-4-T/BFP
E Adjustable Shelf *WSWS-VWU1C/W/G/LWVTBW-5-AS
F Mounting Cleat *WSWS-VWU1C/W/G/LWVTBW-6-MC
G Wood Support *WSWS-VWU1C/W/G/LWVTBW-7-WS
H Middle Fixed Shelf *WSWS-VWU1C/W/G/LWVTBW-8-MFS
I Lower Left Side Panel *WSWS-VWU1C/W/G/LWVTBW-9-LLSP
J Lower Right Side Panel *WSWS-VWU1C/W/G/LWVTBW-10-LRSP
KInstallation Template *WSWS-VWU1C/W/G/LWVTBW-11-IT
AA M6 x 40 mm Bolt *WSWS-VWU1C/W/G/LWVTBW-12-40B
BB M6 x 60 mm Bolt *WSWS-VWU1C/W/G/LWVTBW-13-60B
CC Lock Washer *WSWS-VWU1C/W/G/LWVTBW-14-LW
DD Small Flat Washer *WSWS-VWU1C/W/G/LWVTBW-15-SFW
EE Shelf Pin *WSWS-VWU1C/W/G/LWVTBW-16-SP
FF Wood Screw *WSWS-VWU1C/W/G/LWVTBW-17-M3.5x12WS
GG Wood Dowel *WSWS-VWU1C/W/G/LWVTBW-18-M8x30WD
HH Barrel Nut *WSWS-VWU1C/W/G/LWVTBW-19-M6BN
II Lag Bolt *WSWS-VWU1C/W/G/LWVTBW-20-2 ½ LB
JJ Large Flat Washer *WSWS-VWU1C/W/G/LWVTBW-21-LFW
KK Allen Wrench *WSWS-VWU1C/W/G/LWVTBW-22-M4AW
LL Touch-up Pen *WSWS-VWU1C/W/G/LWVTBW-23-TUP
MM Large Cam Lock *WSWS-VWU1C/W/G/LWVTBW-24-LCL
NN Large Cam Bolt *WSWS-VWU1C/W/G/LWVTBW-25-LCB
Complete Hardware *WSWS-VWU1C/W/G/LWVTBW-26-CH
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST,
Monday - Friday.
Printed in Vietnam
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST,
Monday - Friday.
E
E
B
I
C
J
G
FD
H
D
K
AA EE
JJ
KK LL MM NN
FF GG HH II
BB CC DD
A
A
Date: 2023-10-24
Rev. 0001-B
