Allen + Roth 41997 User manual

1
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-866-439-9800, 8 a.m. - 6 p.m., EST, Monday - Thursday,
8 a.m. - 5 p.m., EST, Friday.
ATTACH YOUR RECEIPT HERE
Purchase Date _________________________
ITEM #0808356
WALL LANTERN
MODEL #41997
Français p. 11
Español p. 21
PH19278
allen + roth®is a registered trademark of LF, LLC.
All rights reserved.
®
welcoming • sophisticated • inspiring
USC

2
TABLE OF CONTENTS
Package Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Hardware Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Assembly Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operating Instructions ..............................................................9
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

3
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Mounting Bracket (preassembled to Fixture [D]) 1
B Mounting Bracket Screw (preassembled to Mounting Bracket [A]) 2
C Screw Cap (preassembled to Mounting Screw [B]) 2
D Fixture 1
E Finial 1
F Finial Cap 1
D
A
B
C
EF
HARDWARE CONTENTS
Wire Connector
Qty. 3
Mounting Screw
Qty. 2
AA RR
PREPARATION
Estimated Assembly Time: 60 minutes
Tools Required for Assembly (not included): Helpful Tools (not included)

4
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install the
product. Failure to do so could lead to electrical shock, re or other injuries that could be hazardous
or even fatal.
• Before you begin installing the light, disconnect the power by removing fuses or turning o󰀨 the
circuit breakers.
• Make sure that all electrical connections comply with local codes, ordinances, the National
Electrical Code, and ANSI/NFPA 70-199. Hire a qualied electrician or consult a do-it-yourself
wiring handbook if you are unfamiliar with installing electrical wiring.
• The net weight of the light is 5.1 lbs.
LISTED FOR WET LOCATION
DANGER:
• DO NOT connect this xture to an electrical system that does not provide a means for equipment
grounding. Never use a xture in a two-wire system that is not grounded. Installing a xture into
an electrical system not having a proper grounding means could cause metal parts of the xture
to carry electrical currents if any of the xture wires, wire connections or splices were to become
broken, cut or loose during the mounting or normal operation of the xture. Under this condition,
anyone coming in contact with the xture would be subject to electrical shock, which could cause
serious injury or death.
• DO NOT connect the bare or green insulation xture ground wire to the black (hot) current-carrying
wire or the white neutral house wire. Connection of the bare or green xture ground wire to the
black or white house wires may cause metal parts of the xture to carry electrical currents. Under
this condition anyone coming in contact with the xture will receive electrical shock, which could
cause serious injury or death.
• DO NOT damage or cut the wire insulation (covering) during installation of the xture. DO NOT
permit wires to contact any surface having a sharp edge. To do so may damage or cut the wire
insulation, which could cause serious injury or death from electrical shock.
WARNING:
• All electrical connections must be in agreement with local codes and ordinances, the National
Electric Code (NEC) and ANSI/NFPA 70-1999. Contact your municipal building department to learn
about your local codes, permits and/or inspections. Risk of re - most dwellings built before 1985
have supply wire rated for 140°F. Consult a qualied electrician before installation.
• To avoid personal injury, the use of gloves may be necessary while handling xture parts with sharp
edges.
• DO NOT suspend any xture by the house wires. A xture must always be mounted directly to a
an outlet box. Wire connectors will not support the weight of a xture. Suspending a xture by the
house wires and wire connectors will result in the xture falling, with the possibility of personal
injury and the danger of electrical shock or re.
• To reduce the risk of re, electrical shock, or personal injury, each wire connector used with this
xture should accept only one 18-gauge wire from the light xture and one 18-gauge wire from the
outlet box. If there are three or more wires to connect or any of the wires is larger than 18 gauges,
consult an electrician for the proper size wire connectors to use.

5
ASSEMBLY INSTRUCTIONS
1. Turn o󰀨 the circuit breakers and the wall switch to the
supply line leads.
DANGER: Failure to disconnect the power
supply prior to installation may result in serious injury
or death.
2. Loosen and remove the screw caps (C) from the
mounting bracket screws (B) to remove the mounting
bracket (A) from xture (D).
3. Attach the mounting bracket (A) to the outlet box (not
included) using the mounting screws (RR). Note:
Mounting screws should be parallel to the horizon.
Then, loosen ground screw and wrap the ground wire
from outlet box around the screw and retighten the
ground screw to secure.
Hardware Used
RR Mounting
Screw x 2
1
2
3
BC
D
A
RR
Ground
Screw
Ground
Wire

6
6
A
Bare/Green (ground)
Bare
Black(hot) Black
White
White (neutral)
4
ASSEMBLY INSTRUCTIONS
WARNING: To reduce the risk of re, electrical shock or personal injury, wire connectors
provided with this xture are designed to accept only one 12-gauge house wire and two lead wires
from the fan. If your house wire is larger than 12-gauge and/or there is more than one house wire to
connect to the two xture lead wires, consult an electrician for the proper size wire connectors to use.
CAUTION: Be sure the outlet box is properly grounded or that a Ground (Green or Bare) wire is present.
4. Connect household supply and xture wires according
to the diagram and these steps:
• Connect the bare wire from the xture to the Bare/
Green (ground) supply wire.
• Connect the White wire from the xture to the White
(neutral) supply wire.
• Connect the Black wires from the xture to the Black
(hot) supply wire.
• Secure all wiring connections together with wire
connectors (AA).
Note: The Black wire is hot power for the xture.
The White wire is neutral for the xture. The Bare
wire is the ground wire xture. If household supply
wires are di󰀨erent colors than referred to above, it is
recommended a professional electrician determines the
proper wiring.
Hardware Used
AA Wire Connector x 3
5. Wrap electrical tape (not included) around each
individual wire connector down to the wire.
6. Turn the spliced/taped wires and gently push the wires
and wire connectors into the outlet box.
WARNING: Ensure no bare wire or wire strands
are visible after making connections. Place the Green
and White wire connections on the opposite side of the
outlet box from the Black wire connections.
AA
AA
5

7
ASSEMBLY INSTRUCTIONS
7. Hang xture on the two mounting bracket screws (B)
and secure with screw caps (C).
8. Lift the nial cap (F) over the threaded rod at the
bottom of the nial (E). Attach to the hole in the top of
the xture (D) by turning the nial (E) in a clockwise
direction.
9. Insert the E26-base bulb (not included) into the socket
of the xture (A).
7
8
9
Bulb
B C
E
F

8
ASSEMBLY INSTRUCTIONS
10.Use weather-proof caulk or sealant (sold separately)
around top and sides of mounting plate to prevent
water from collecting behind the xture.
11. Restore the power to the circuit breakers and the wall
switch to the supply line leads.
10
11
Mounting
Plate

9
OPERATING INSTRUCTIONS
1. Remove the nial (E) and nial cap (F) to access
controls for motion activation.
When power is rst applied the light will initialize for 45
seconds and then will be in Test Mode. The Test Mode
will last for 5 minutes. The motion sensor adjustment
dials consist of two knobs to adjust Sensitivity and delay
Timer. During the Test Mode adjust the sensitivity to
the desired distance. After 5 minutes in Test Mode the
sensor will enter Auto Mode. Once in Auto Mode the
delay Timer can be set.
At night, you may manually override the Auto Mode on
the sensor to force the light to stay on until dawn. To
toggle the operation between Manual and Auto Modes:
• Toggle the wall switch o󰀨 for 2 seconds and then on
again.
• The sensor is more sensitive to motions across its
detection path rather than the motions directly towards
it. Walking with normal speed across the detection area
to set the desired detection distance properly.
• During initial setup, the light will come on for 5
seconds every time motion is detected.
• The sensitivity was set at the maximum 40 ft. at the
factory. By turning the knob counterclockwise, the
detection distance can be decreased down to 5 ft.
• The detection range covers approximately 120
degrees.
• Clean the sensor lens with soft cloth every 1 to 2
months to maintain sensitivity.
TEST MODE AUTO MODE
Mode Activation When power is turned on, Test Mode
will start after 45 seconds.
When power is turned on, Auto
Mode will start after 5 minutes.
Works (Day/Night) Day and Night Night Only
Activated by
(Sensitivity knob) Motion Motion
Detection Range
(mounted at 6.5 ft. high) 5-40 ft. 5-40 ft.
Shut o󰀨 delay
(Timer knob) 5 seconds 5 seconds - 3 minutes
1
Sensitivity
40 5ft 180 5 sec
Timer
D

10
TROUBLESHOOTING
TWO-YEAR LIMITED WARRANTY
The manufacturer warrants all of its lighting xtures against defects in materials and workmanship
for two (2) years from the date of purchase. If within this period the product is found to be defective,
take a copy of the bill of sale as a proof of purchase and the product in its original carton to the place
of purchase. The manufacturer will, at its option, repair, replace or refund the purchase price to the
consumer. All costs of installation and removal of the xture is the responsibility of the consumer. This
warranty does not cover xtures becoming defective due to misuse, accidental damage or improper
handling and/or installation and specically excludes liability for direct, incidental or consequential
damages. As some states do not allow exclusions of limitations on an implied warranty, the above
exclusion and limitation may not apply. This warranty gives you specic rights and you may also have
other rights which may vary from state to state.
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Fixture does not light.
1. Fixture may be wired
incorrectly.
2. Worn or broken bulb.
3. Fixture is set to Auto
Mode.
1. Check wiring.
2. Replace bulb.
3. Cover sensor to simulate
darkness.
Fixture stays on
continuously.
1. Fixture is not set to Auto
Mode.
2. There is motion in
detection area.
3. Shut-o󰀨 settings are
incorrect.
1. Reset xture by turning the
power o󰀨 and on.
2. Make sure there is no motion
in the detection area.
3. Turn TIMER knob
counterclockwise to shut-o󰀨
delay time.
Fixture light blinks on and o󰀨.
1. Fixture is overheated.
2. Sensitivity is set too high.
1. Make sure the light is not near
a heat source.
2. Reduce the sensitivity to
avoid undesired triggering
by passing cars or refecting
objects.
Printed in China
9420 PB · 081619
