Allen + Roth 42626 User manual

1
RATED FOR
DAMP
LOCATIONS
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday. You could also
contact us at [email protected].
ATTACH YOUR RECEIPT HERE
Purchase Date _________________________
ITEM # 5024112, 5134416
WALL SCONCE
MODEL # 42626, 42826
Español p. 13
SC22229
welcoming • sophisticated • inspiring
ALLEN + ROTH and logo design are
trademarks or registered trademarks of LF, LLC.
All rights reserved.

2
TABLE OF CONTENTS
Package Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Hardware Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Preparation ......................................................................3
Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Assembly Instructions for Plug-in Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Assembly Instructions for Hardwire Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1-Year Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

33
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Fixture 1
B Shade 1
C Socket Ring 1
D Switch (preassembled to Fixture [A]) 1
E Wall Plate (preassembled to Fixture [A]) 1
F Mounting Screws (preassembled to Wall Plate [E]) 3
G Power Cord (preassembled to Fixture [A]) 1
H Plug (preassembled to Power Cord [G]) 1
I Grommet (preassembled to Fixture [A]) 1
J Adjustment Knob (preassembled to Fixture [A]) 3
A
B
D
J
F
I
E
H
G
HARDWARE CONTENTS
Mounting Bracket
Qty. 1
Mounting
Bracket Screw
Qty. 2
Plug Button
Qty. 1
Anchor
Qty. 2
Anchor Screw
Qty. 2
FF AG
RR EE AH
PREPARATION
Estimated Assembly Time: 60 minutes
Tools Required for Assembly (not included):
1/4”
Helpful Tools (not included)
(not drawn to scale)
(for hardwire installation) (for plug-in installation)
C
7mm

4
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install the
product. Failure to do so could lead to electrical shock, re or other injuries that could be hazardous
or even fatal.
• Before you begin installing the light xture, disconnect the power by removing fuses or turning o󰀨
the circuit breakers.
• The net weight of the light kit is 2.64 lb.
• This xture is intended for indoor or damp locations. It is not suitable for outdoor locations.
DANGER:
• DO NOT connect this xture to an electrical system that does not provide a means for equipment
grounding. Never use a xture in a two-wire system that is not grounded. Installing a xture into
an electrical system not having a proper grounding means could cause metal parts of the xture
to carry electrical currents if any of the xture wires, wire connections or splices were to become
broken, cut or loose during the mounting or normal operation of the xture. Under this condition,
anyone coming in contact with the xture would be subject to electrical shock, which could cause
serious injury or death.
• DO NOT connect the bare or green insulation xture ground wire to the black (hot) current-carrying
wire or the white neutral house wire. Connection of the bare or green xture ground wire to the
black or white house wires may cause metal parts of the xture to carry electrical currents. Under
this condition anyone coming in contact with the xture will receive electrical shock, which could
cause serious injury or death.
• DO NOT damage or cut the wire insulation (covering) during installation of the xture. DO NOT
permit wires to contact any surface having a sharp edge. To do so may damage or cut the wire
insulation, which could cause serious injury or death from electrical shock.
WARNING:
• All electrical connections must be in agreement with local codes and ordinances, the National
Electric Code (NEC) and ANSI/NFPA 70-1999. Contact your municipal building department to learn
about your local codes, permits and/or inspections. Risk of re - most dwellings built before 1985
have supply wire rated for 140°F. Consult a qualied electrician before installation.
• To avoid personal injury, the use of gloves may be necessary while handling xture parts with sharp
edges.
• DO NOT suspend any xture by the house wires. A xture must always be mounted directly to an
outlet box. Wire connectors will not support the weight of a xture. Suspending a xture by the
house wires and wire connectors will result in the xture falling, with the possibility of personal
injury and the danger of electrical shock or re.
• To reduce the risk of re, electrical shock, or personal injury, each wire connector used with this
xture should accept only one 18-gauge wire from the light xture and one 18-gauge wire from the
outlet box. If there are three or more wires to connect or any of the wires is larger than 18 gauges,
consult an electrician for the proper size wire connectors to use.

5
ASSEMBLY INSTRUCTIONS FOR PLUG-IN INSTALLATION
1. Turn o󰀨 the circuit breakers and the wall switch to the
supply line leads.
DANGER: Failure to disconnect the power
supply prior to installation may result in serious injury
or death.
2. This xture has two options for installation. To install
the xture using the plug-in method, continue to the
next step.
To install the xture without the plug, skip to
ASSEMBLY INSTRUCTIONS FOR HARDWIRE
INSTALLATION, page 8. Note: Hardwire installation
requires an outlet box at the installation location.
3. Determine the desired location of the xture assembly
(A) making sure you have access to an electrical
outlet and there are no electrical lines or plumbing
where you intend to attach the mounting hardware.
Mark the anchor (AG) locations on wall and drill each
hole 7 mm in diameter. Insert the anchors (AG) and
tap into the wall until secure. Using a screwdriver,
set two screws (AH) into the anchors (AG) leaving
enough exposed to set into the keyhole slots on the
preassembled wall plate (E).
Hardware Used
AG Anchor x 2
Anchor Screw x 2
1
3
AG
AH
2
Plug-in Hardwire
AH
