Alliance Laundry Systems 25 Pound Capacity User manual

Installation
www.comlaundry.com
Part No. 70380301R11EN
January 2012
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)
Tumble Dryers
25 Pound Capacity
30 Pound Capacity
35 Pound Capacity
55 Pound Capacity
Starting Serial No. 0602004144
Refer to Page 5 for Model Identification
T478C
T478C

70380301 (EN)
1
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation must conform with local codes or, in the absence of local codes, with:
In the U.S.A., installation must conform to the latest edition of the American National Standard Z223.1/
NFPA 54 “National Fuel Gas Code” and Standard ANSI/NFPA 70 “National Electric Code.”
In Canada, installation must comply with Standards CAN/CSA-B149.1 or Natural Gas and Propane
Installation Code and CSA C22.1, latest edition, Canadian Electric Code, Part I.
In Australia and New Zealand, installation must comply with the Gas Installations Standard AS/NZS 5601
Part 1: General Installations.
IMPORTANT: Information must be obtained from a local gas supplier on instructions to be followed if the
user smells gas. These instructions must be posted in a prominent location. Step-by-step instructions of the
above safety information must be posted in a prominent location near the tumble dryer for customer use.
• Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
• WHAT TO DO IF YOU SMELL GAS:
– Do not try to light any appliance.
– Do not touch any electrical switch; do not use any phone in your building.
– Clear the room, building or area of all occupants.
– Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s
instructions.
– If you cannot reach your gas supplier, call the fire department.
• Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
W052
FOR YOUR SAFETY, the information in this manual must be followed to minimize the risk
of fire or explosion or to prevent property damage, personal injury or death.
W033
WARNING
• Ne pas entreposer ni utiliser d’essence ou autres gaz et liquides inflammables au voisinage
de cet appareil ou de tout autre.
• QUE FAIRE EN PRÉSENCE D’UNE ODEUR DE GAZ :
– Ne pas tenter d’allumer un quelconque appareil.
– Ne toucher à aucun interrupteur électrique ; ne pas utiliser de téléphone dans le bâtiment.
– Évacuer le local, la bâtiment ou la zone de tous ses occupants.
– Téléphoner immédiatement à la compagnie de gaz depuis une maison voisine. Suivre les
instructions de la compagne de gaz.
– Si la compagnie de gaz n’est pas joignable, appeler les pompiers.
• L’installation et l’entretien doivent être effectués par un installateur agréé, un service de
réparation ou la compagnie de gaz.
W052R1FR
POUR VOTRE SÉCURITÉ, veillez à bien respecter les indications de ce manuel afin de
minimiser les risques d’incendie ou d’explosion ou d’écarter les dangers de dommages
matériels, corporel ou de mort.
W033FR
AVERTISSEMENT

2
70380301 (EN)
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
The following information applies to the state of Massachusetts, USA.
 This appliance can only be installed by a Massachusetts licensed plumber or gas fitter.
 This appliance must be installed with a 36 inch (91 cm) long flexible gas connector.
 A “T-Handle” type gas shut-off valve must be installed in the gas supply line to this appliance.
 This appliance must not be installed in a bedroom or bathroom.
• Installation of unit must be performed by a qualified installer.
• Install tumble dryer according to manufacturer’s instructions and local codes.
• DO NOT install a tumble dryer with flexible plastic venting materials. If flexible metal (foil
type) duct is installed, it must be of a specific type identified by the appliance manufacturer
as suitable for use with tumble dryer. Refer to section on connecting exhaust system.
Flexible venting materials are known to collapse, be easily crushed, and trap lint. These
conditions will obstruct tumble dryer airflow and increase the risk of fire.
W752R1
WARNING
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
W053
• L’installation de l’unité doit être effectuée par un installateur qualifié.
• Installer le séchoir selon les instructions du fabricant et les codes locaux.
• NE PAS installer un séchoir avec des matériaux de mise à l’air libre en matière plastique
flexible. Si un conduit métallique flexible (type en feuilles) est installé, il doit être d’un type
spécifique identifié par le fabricant d’appareils ménagers comme pouvant être utilisé avec le
séchoir. Se reporter à la section sur la connexion au dispositif d’échappement. Les
matériaux flexibles de mise à l’air libre sont connus pour s’effondrer, pour être facilement
écrasés et pour emprisonner les peluches. Ces conditions obstruent le débit d’air du
séchoir et augmentent le risque d’incendie.
W752FR
AVERTISSEMENT
POUR VOTRE SÉCURITÉ
Ne pas entreposer ni utiliser d’essence ou autres gaz et liquides inflammables au voisinage
de cet appareil ou de tout autre.
W053FR

© Copyright 2012, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
3
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
70380301 (EN)
Table of
Contents
Introduction......................................................................................... 5
Model Identification ............................................................................. 5
Customer Service.................................................................................. 7
Wiring Diagram.................................................................................... 7
Serial Plate Location............................................................................. 7
Safety Information.............................................................................. 8
Important Safety Instructions ............................................................... 9
Specifications and Dimensions........................................................... 11
Cabinet Dimensions.............................................................................. 12
Exhaust Outlet Locations...................................................................... 13
Gas Connection Locations.................................................................... 14
Electrical Connection Locations........................................................... 15
Steam Connection Locations................................................................ 16
Installation........................................................................................... 17
Pre-Installation Inspection.................................................................... 17
Location Requirements......................................................................... 17
Tumble Dryer Enclosure....................................................................... 18
Position and Level the Tumble Dryer................................................... 19
To Reverse the Loading Door............................................................... 20
Before Placing Tumble Dryer into Service .......................................... 23
Required for CE Models Only......................................................... 24
Installing CE Gas Drying Tumble Dryers............................................ 24
General Information......................................................................... 24
Basic Configuration ......................................................................... 27
Specific Conversion Procedures ...................................................... 28
Exhaust Requirements ....................................................................... 31
Layout................................................................................................... 31
Make-Up Air......................................................................................... 31
Venting ................................................................................................. 31
Individual Venting ........................................................................... 32
Manifold Venting............................................................................. 34
Gas Requirements............................................................................... 37
Gas Supply Pipe Sizing and Looping................................................... 39
High Altitude Burner Orifice Sizing..................................................... 41
Electrical Requirements..................................................................... 42
Grounding Instructions......................................................................... 42
For CE Models Only............................................................................. 43
Service/Ground Location...................................................................... 44
Connecting Electrical Service............................................................... 45
Configuring Your Tumble Dryer for Other Service Voltages......... 45
Conversion Instructions........................................................................ 46
Ferrite Ring Installation........................................................................ 48
Electrical Requirements for Gas and Steam Models............................ 49
Electrical Requirements for Electric Models........................................ 51

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
4
70380301 (EN)
Steam Requirements........................................................................... 55
Piping Recommendations..................................................................... 55
Installing Steam Trap and Making Condensate
Return Connections............................................................................ 56
Single Drop Timer .............................................................................. 58
Power-Up Mode.................................................................................... 58
Ready Mode.......................................................................................... 58
Start Mode ............................................................................................ 58
Run Mode ............................................................................................. 58
Setting Dry Time Dipswitches.............................................................. 58
Resetting Cycle Time to Zero............................................................... 58
Dipswitch Settings................................................................................ 59
Adjustments......................................................................................... 61
Loading Door Switch............................................................................ 61
Airflow Switch...................................................................................... 61
Door Strike............................................................................................ 62
Removing Tumble Dryer from Service............................................. 63

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
5
70380301 (EN)
Introduction
Model Identification
Information in this manual is applicable to these
models.
Gas Steam Electric
25 Pound
CHD25G2-CA025L
CHD25G2-CA025N
CHD25G2-CT025L
CHD25G2-CT025N
CHD25G2-CU025L
CHD25G2-CU025N
DR25G2-BA025L
DR25G2-BA025N
DR25G2-BT025L
DR25G2-BT025N
DR25G2-BU025L
DR25G2-BU025N
HA025L
HA025N
HT025L
HT025N
HU025L
HU025N
IPD25G2-IT025L
IPD25G2-IT025N
SA025L
SA025N
ST025L
ST025N
SU025L
SU025N
UA025L
UA025N
UT025L
UT025N
UU025L
UU025N
YT025L
YT025N
YU025L
YU025N
CHD25S2-CT025S
CHD25S2-CU025S
DR25S2-BT025S
DR25S2-BU025S
HT025S
HU025S
IPD25S2-IT025S
ST025S
SU025S
UT025S
UU025S
YT025S
YU025S
CHD25E2-CT025E
CHD25E2-CU025E
DR25E2-BT025E
DR25E2-BU025E
HT025E
HU025E
IPD25E2-IT025E
ST025E
SU025E
UT025E
UU025E
YT025E
YU025E
30 Pound
CHD30G2-CA030L
CHD30G2-CA030N
CHD30G2-CT030L
CHD30G2-CT030N
CHD30G2-CU030L
CHD30G2-CU030N
DR30G2-BA030L
DR30G2-BA030N
DR30G2-BT030D
DR30G2-BT030L
DR30G2-BT030N
DR30G2-BU030L
DR30G2-BU030N
HA030L
HA030N
HT030D
HT030L
HT030N
HU030L
HU030N
IPD30G2-IT030L
IPD30G2-IT030N
SA030L
SA030N
ST030D
ST030L
ST030N
SU030L
SU030N
UA030L
UA030N
UT030L
UT030N
UU030L
UU030N
YT030L
YT030N
YU030L
YU030N
CHD30S2-CT030S
CHD30S2-CU030S
DR30S2-BT030S
DR30S2-BU030S
HT030S
HU030S
IPD30S2-IT030S
ST030S
SU030S
UT030S
UU030S
YT030S
YU030S
CHD30E2-CT030E
CHD30E2-CU030E
DR30E2-BT030E
DR30E2-BU030E
HT030E
HU030E
IPD30E2-IT030E
ST030E
SU030E
UT030E
UU030E
YT030E
YU030E
Models continued on next page.

Introduction
70380301 (EN)
6
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Includes models with the following control suffixes :
(Continued)
Gas Steam Electric
35 Pound
AT035L
AT035N
CHD35G2-CA035L
CHD35G2-CA035N
CHD35G2-CT035L
CHD35G2-CT035N
CHD35G2-CU035L
CHD35G2-CU035N
DR35G2-BA035L
DR35G2-BA035N
DR35G2-BT035L
DR35G2-BT035N
DR35G2-BU035L
DR35G2-BU035N
HA035L
HA035N
HT035L
HT035N
HU035L
HU035N
IPD35G2-IT035L
IPD35G2-IT035N
SA035L
SA035N
ST035L
ST035N
SU035L
SU035N
UA035L
UA035N
UT035L
UT035N
UU035L
UU035N
YT035L
YT035N
YU035L
YU035N
AT035S
CHD35S2-CT035S
CHD35S2-CU035S
DR35S2-BT035S
DR35S2-BU035S
HT035S
HU035S
IPD35S2-IT035S
ST035S
SU035S
UT035S
UU035S
YT035S
YU035S
AT035E
CHD35E2-CT035E
CHD35E2-CU035E
DR35E2-BT035E
DR35E2-BU035E
HT035E
HU035E
IPD35E2-IT035E
ST035E
SU035E
UT035E
UU035E
YT035E
YU035E
55 Pound
CA055L
CA055N
CT055L
CT055N
CU055L
CU055N
DR55SG2-BA055L
DR55SG2-BA055N
DR55SG2-BT055D
DR55SG2-BT055L
DR55SG2-BT055N
DR55SG2-BU055L
DR55SG2-BU055N
HA055L
HA055N
HT055D
HT055L
HT055N
HU055L
HU055N
IPD55G2-IT055L
IPD55G2-IT055N
SA055L
SA055N
ST055D
ST055L
ST055N
SU055L
SU055N
UA055L
UA055N
UT055L
UT055N
UU055L
UU055N
Not Applicable
CT055E
CU055E
DR55SE2-BT055E
DR55SE2-BU055E
HT055E
HU055E
IPD55E2-IT055E
ST055E
SU055E
UT055E
UU055E
3O – DX4 OPL EO – LED OPL SD – single drop
3V – DX4 vended LC – network adaptable coin SX – single drop, prep for coin
3X – DX4 prep for coin LX – network adaptable, prep for coin UO – UniLinc OPL
BC – basic electronic, coin LY – network adaptable, prep for card WC – network ready coin
BL – basic electronic, central pay NC – NetMaster coin WX – network ready, prep for coin
BX – basic electronic, prep for coin NR – NetMaster card WY – network ready, prep for card
BY – basic electronic, prep for card NX – NetMaster, prep for coin ZC – NetMaster network coin
DO – DMP OPL NY – NetMaster, prep for card ZR – NetMaster network card
DV – DMP vended OM – OPL micro ZX – NetMaster network, prep for coin
DX – DMP prep for coin QT – dual digital timer ZY – NetMaster network, prep for card

Introduction
7
70380301 (EN) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Customer Service
If literature or replacement parts are required, contact
the source from which the machine was purchased or
contact Alliance Laundry Systems at [phone]
for the name and address of the nearest authorized
parts distributor.
For technical assistance, call [phone].
Wiring Diagram
The wiring diagram is located inside the junction or
contactor box.
The wiring diagram part number is in the lower
portion of the electrical data on the serial plate.
Serial Plate Location
When calling or writing for information about your
product, be sure to mention model and serial numbers.
Model and serial numbers are found on serial plate on
rear of machine, and inside the loading door hinge.
TMB2098N
1Serial Plate
1
Conversion Table
Multiply By To Obtain Multiply By To Obtain
Btu 0.252 kCal Pounds/sq. inch 0.06895 Bars
Btu 1055 Joules Pounds/sq. inch 0.070 kg/sq. cm
Inch 25.4 Millimeters Pounds (lbs.) 0.454 Kilograms
Inches W.C. 0.036 Pounds/sq. inch Boiler Horsepower 33,479 Btu/hr.
Inches W.C. 0.249 kPa Boiler Horsepower 34.5 lbs. steam/hr.
lb./inch
2
(psi) 6.895 kPa CFM 0.471 liters/second
ft
3
28.32 Liters kW 3414 Btu/hr.

70380301 (EN)
8
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
Precautionarystatements(“DANGER,”“WARNING,”
and “CAUTION”) followed by specific instructions,
are found in this manual and on machine decals. These
precautions are intended for the personal safety of the
operator, user, servicer, and those maintaining the
machine.
Additional precautionary statements (“IMPORTANT”
and “NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used
to inform the reader of specific procedures where
minor machine damage will occur if the procedure
is not followed.
NOTE: The word “NOTE” is used to communicate
installation, operation, maintenance or servicing
information that is important but not hazard
related.
NOTE: The WARNING and IMPORTANT
instructions appearingin this manual arenot meant
to cover all possible conditions and situations that
may occur. It must be understood that common
sense, caution and carefulness are factors which
CANNOT be built into this tumble dryer. These
factors MUST BE supplied by the person(s)
installing, maintaining or operating the tumble
dryer.
Always contact your dealer, distributor, service agent
or the manufacturer on any problems orconditions you
do not understand.
Indicates an imminently hazardous
situation that, if not avoided, will cause
severe personal injury or death.
DANGER
Indicates a hazardous situation that, if not
avoided, could cause severe personal
injury or death.
WARNING
Indicates a hazardous situation that, if not
avoided, may cause minor or moderate
personal injury or property damage.
CAUTION
Failure to install, maintain, and/or operate
this machine according to manufacturer’s
instructions may result in conditions which
can produce serious injury, death and/or
property damage.
W051R1
WARNING

Safety Information
9
70380301 (EN) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Save These Instructions
Important Safety Instructions
1. Read all instructions before using the tumble
dryer.
2. Refer to the Grounding Instructions for the
proper grounding of the tumble dryer.
3. Do not dry articles that have been previously
cleaned in, washed in, soaked in, or spotted with
gasoline, dry cleaning solvents, or other
flammable or explosive substances as they give
off vapors that could ignite or explode.
4. Do not allow children on or in the tumble dryer.
This appliance is not intended for use by young
children or infirm persons without supervision.
Young children should be supervised to ensure
that they do not play with the appliance.
5. Before the tumble dryer is removed from service
or discarded, remove the door to the drying
compartment and the door to the lint
compartment.
6. Do not reach into the tumble dryer if the cylinder
is revolving.
7. Do not install or store the tumble dryer where it
will be exposed to water and/or weather.
8. Do not tamper with the controls.
9. Do not repair or replace any part of the tumble
dryer, or attempt any servicing unless specifically
recommended in the user-maintenance
instructions or in published user-repair
instructions that you understand and have the
skills to carry out.
10. Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or product.
11. To reduce the risk of fire, DO NOT DRY plastics
or articles containing foam rubber or similarly
textured rubberlike materials.
12. Always clean the lint filter daily.
13. Keep area around the exhaust opening and
adjacent surrounding area free from the
accumulation of lint, dust, and dirt.
14. The interior of the tumble dryer and the exhaust
duct should be cleaned periodically by qualified
service personnel.
15. If not installed, operated and maintained in
accordance with the manufacturer’s instructions
or if there is damage to or mishandling of this
product’s components, use of this product could
expose you to substances in the fuel or from fuel
combustion which can cause death or serious
illness and which are known to the State of
California to cause cancer, birth defects or other
reproductive harm.
16. Tumble dryer will not operate with the loading
door open. DO NOT bypass the door safety
switch to permit the tumble dryer to operate with
the door open. The tumble dryer will stop
tumblingwhen the door is opened. Do notuse the
tumble dryer if it does not stop rotating when the
door is opened or starts rotating without pressing
or turning the START mechanism. Remove the
tumble dryer from use and call the service
person.
17. Tumble dryer will not operate with lint panel
open. DO NOT bypass lintpanel safety switch to
permit the tumble dryer to operate with the lint
panel open.
18. Do not put articles soiled with vegetable or
cooking oil in the tumble dryer, as these oils may
not be removed during washing. Due to the
remaining oil, the fabric may catch on fire by
itself.
19. To reduce the risk of fire, DO NOT put clothes
which have traces of any flammable substances
such as machine oil, flammable chemicals,
thinner, etc. or anything containing wax or
chemicals such as in mops and cleaning cloths, or
anything dry-cleaned at home with dry-cleaning
solvent in the tumble dryer.
20. Use the tumble dryer only for its intended
purpose, drying water-washed fabrics.
21. ALWAYS disconnect the electrical power to the
tumble dryer before servicing. Disconnect power
by shutting off appropriate breaker or fuse.
Hazardous Voltage. Can cause shock, burn
or cause death. Allow machine power to
remain off for two minutes prior to working
in and around AC inverter drive.
W359
WARNING

Safety Information
70380301 (EN)
10
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
22. Install this tumble dryer according to these
Installation Instructions. All connections for
electrical power, grounding, and gas supply must
comply with local codes and be made by licensed
personnel when required.
23. Remove laundry immediately after tumble dryer
stops.
24. Always read and follow manufacturer’s
instructions on packages of laundry and cleaning
aids. Heed all warnings or precautions. To reduce
the risk of poisoning or chemical burns, keep
them out of reach of children at all times
(preferably in a locked cabinet).
25. Do not tumble fiberglass curtains and draperies
unless the label says it can be done. If they are
dried, wipe out the cylinder with a damp cloth to
remove particles of fiberglass.
26. Always follow the fabric care instructions
supplied by the garment manufacturer.
27. Never operate the tumble dryer with any guards
and/or panels removed.
28. DO NOT operate the tumble dryer if it is
smoking, grinding, or has missing or broken
parts.
29. DO NOT bypass any safety devices.
30. Solvent vapors from dry-cleaning machines
createacids when drawn throughthe heaterof the
drying unit. These acids are corrosive to the
tumble dryer as well as to the laundry load being
dried. Be sure make-up air is free of solvent
vapors.
31. Failure to install, maintain, and/or operate this
machine according to the manufacturer’s
instructions may result in conditions which can
produce bodily injury and/or property damage.
To reduce the risk of serious injury, install
lockable door(s) to prevent public access to
rear of tumble dryers.
W055R1
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
11
70380301 (EN)
Specifications and Dimensions
Specifications 25 Pound 30 Pound 35 Pound 55 Pound
Noise level measured during
operation at operator position of
3.3 feet (1 meter) in front of machine
and 5.2 feet (1.6 meters) from floor 60 dBA 61 dBA 63 dBA 63 dBA
Net Weight (approximate):
Pounds (kg) 300
(137) 330 (150) 360 (163) 435 (197)
Standard Packaging Weight:
Pounds (kg) 332
(151) 364 (165) 394 (179) 476 (216)
Standard Packaging Shipping
Dimensions:
Inch (mm)
30 x 43 x 69
(762 x 1092 x
1753)
30 x 49 x 69
(762 x 1245 x
1753)
33 x 49 x 69
(838 x 1245 x
1753)
35.5 x 59 x 72
(902 x 1499 x
1829)
Slat Crate Packaging Weight:
Pounds (kg) 406
(184) 446 (202) 480 (218) 506 (230)
Slat Crate Shipping Dimensions:
Inch (mm)
34.5 x 46 x 87.75
(876 x 1168 x
2229)
34.5 x 52 x 87.75
(876 x 1321 x
2229)
37.5 x 52 x 87.75
(953 x 1321 x
2229)
40 x 60 x 87.25
(1016 x 1524 x
2216)
Cylinder Size:
Inch (mm) 26.5 x 24
(673 x 610) 26.5 x 30 (673 x 762) 30 x 30 (762 x 762) 33 x 35 (838 x 889)
Cylinder Capacity (dry weight):
Pounds (kg) 25
(11.3) 30 (13.6) 35 (15.9) 55 (24.9)
Drive Motor Horsepower 1/41/41/41/2
Fan Motor Horsepower 1/41/41/41/2
Maximum Airflow per
Pocket: C.F.M. (l/sec)
50 Hertz 430
(203) 430 (203) 550 (260) 600 (283)
60 Hertz 500
(236) 500
(236) 650 (307) 700 (330)
Maximum Static Back
Pressure:
Inch W.C. (mbar)
50 Hertz 0.6
(1.5) 0.6 (1.5) 0.5 (1.3) 0.5 (1.3)
60 Hertz 0.8
(2.0) 0.8 (2.0) 0.6 (1.5) 0.6 (1.5)
Gas Models
Gas Connection 1/2 in. NPT 1/2 in. NPT 1/2 in. NPT 1/2 in. NPT
Gas Burner Rating:
Btu/hr. (kW, Mj/hr.)
50 Hertz 64,000
(18.7, 67.5) 73,000 (21.4, 77) 90,000 (26.4, 95) 102,000 (29.9, 107.6)
60 Hertz 64,000
(18.7, 67.5) 73,000 (21.4, 77) 90,000 (26.4, 95) 112,000 (32.8, 118.2)
Electric Models
Heating Element Rating: 400/50/3 10 kW 21 kW 24 kW 27 kW
Standard 12 kW
Steam Models
Steam Connection 3/4 in. NPT 3/4 in. NPT 3/4 in. NPT N/A
Steam Coil Rating at 100 psig:
Boiler Horsepower (Btu/hr.)
(recommended operating
pressure 80-100 psig)
3.9
(134,700) 3.9 (134,700) 4.8 (166,000) N/A
N/A = Not Applicable

Specifications and Dimensions
70380301 (EN)
12
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Cabinet Dimensions
* Fire suppression system optional - may not be on machine.
NOTE: Facia panels available to increase height of
models to 72.25 inches (183 mm) and 76.25 inches
(1938 mm).
TMB2292N
B
A
C
H
E
F
D
G
J
I
K
L
ModelsABCDEF*
25 Pound 26.25 in.
(667 mm) 27.5 in. (669 mm) 23.35 in. (593 mm) 25.75 in. (654 mm) 40.875 in. (1038 mm) 6.53 in. (166 mm)
30 Pound 26.25 in.
(667 mm) 27.5 in. (669 mm) 28.35 in. (720 mm) 31.75 in. (806 mm) 46.875 in. (1191 mm) 6.53 in. (166 mm)
35 Pound 28 in.
(711 mm) 27.5 in. (669 mm) 28.35 in. (720 mm) 31.75 in. (806 mm) 46.875 in. (1191 mm) 6.53 in. (166 mm)
55 Pound 31.88 in.
(810 mm) 26.87 in. (682.5 mm) 33.75 in. (857.25 mm) 38.25 in. (971.5 mm) 53.62 in. (1365 mm) 6.53 in. (166 mm)
Models G H* I* J* K L
25 Pound 63.875 in.
(1622 mm) 16.48 in. (419 mm) 15.41 in. (391 mm) 1.59 in. (40 mm) 24.64 in. (626 mm) 28 in. (711 mm)
30 Pound 63.875 in.
(1622 mm) 16.48 in. (419 mm) 15.41 in. (391 mm) 1.59 in. (40 mm) 24.64 in. (626 mm) 28 in. (711 mm)
35 Pound 63.875 in.
(1622 mm) 16.48 in. (419 mm) 19.59 in. (497.5 mm) 1.59 in. (40 mm) 27.38 in. (695 mm) 31.5 in. (800 mm)
55 Pound 66.72 in.
(1694.7 mm) 17.75 in. (451 mm) 18.65 in. (474 mm) 1.59 in.
(40 mm) 30.5 in. (774.7 mm) 34.5 in. (876 mm)

Specifications and Dimensions
13
70380301 (EN) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Exhaust Outlet Locations
TMB2132N
B
A
Models Rear Exhaust
Diameter A B
25/30 Pound 6 in.
(152 mm) 3.875 in. (99 mm) 4.625 in. (117 mm)
35 Pound 8 in.
(203 mm) 4.875 in. (124 mm) 5.625 in. (143 mm)
55 Pound 8 in.
(203 mm) 4.808 in. (122 mm) 6.156 in. (156.3 mm)

Specifications and Dimensions
70380301 (EN)
14
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Gas Connection Locations
TMB2106N
11/2 in. NPT
B
C
A
1
Models Gas Connection – CE and Australian Units
ABC
25 Pound 59 in.
(1500 mm) 1.5 in. (38.1 mm) 29 in. (737 mm)
30 Pound 59 in.
(1500 mm) 1.5 in. (38.1 mm) 35 in. (889 mm)
35 Pound 59 in.
(1500 mm) 2.5 in. (64 mm) 35 in. (889 mm)
55 Pound 59 in.
(1500 mm) 2.5 in. (64 mm) 35 in. (889 mm)
Models Gas Connection – Non-CE and Non-Australian Units
ABC
25 Pound 57 in.
(1450 mm) 2.5 in. (64 mm) 35.5 in. (927 mm)
30 Pound 57 in.
(1450 mm) 2.5 in. (64 mm) 43 in. (1092 mm)
35 Pound 57 in.
(1450 mm) 4 in. (101.6 mm) 43 in. (1092 mm)
55 Pound 55.285 in.
(1404 mm) 1.621 in. (41.17 mm) 46.75 in. (1187.45 mm)

Specifications and Dimensions
15
70380301 (EN) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Electrical Connection Locations
TMB2204N
TMB2204N
BD
A
C
ELECTRIC
GAS AND STEAM
Models Electrical Service Gas and Steam Models Electric Models
ABCD
25/30 Pound 62.25 in.
(1581 mm) 2 in. (51 mm) 28 in. (711 mm) 3.25 in. (83 mm)
35 Pound 62.25 in.
(1581 mm) 3 in. (76 mm) 28 in. (711 mm) 4.25 in. (108 mm)
55 Pound 65.187 in.
(1655.75 mm) 1.765 in. (44.83 mm) 32.526 in. (826.16 mm) 6.547 in. (166.3 mm)

Specifications and Dimensions
70380301 (EN)
16
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Steam Connection Locations
NOTE: All connections use 3/4 inch NPT pipe.
TMB2108N
C
D
B
A
Models Inlet Outlet
ACBD
25/30/35 Pound 53.75 in.
(1365 mm) 6.29 in. (160 mm) 42.5 in. (1080 mm) 2.39 in. (61 mm)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
17
70380301 (EN)
Installation
Pre-Installation Inspection
Upon delivery, visually inspect the crate, carton and
parts for any visible shipping damage. If the crate,
carton, or cover is damaged or signs of possible
damage are evident, have the carrier note the condition
on the shipping papers before the shipping receipt is
signed, or advise the carrier of the condition as soon as
it is discovered.
Remove the crate and protective cover as soon as
possible and check the items listed on the packing list.
Advise the carrier of any damaged or missing articles
as soon as possible. A written claim should be filed
with the carrier immediately if articles are damaged or
missing.
IMPORTANT: Warranty is void unless tumble
dryer is installed according to instructions in this
manual. Installation should comply with minimum
specifications and requirements detailed herein,
and with applicable local gas fitting regulations,
municipalbuildingcodes, water supply regulations,
electrical wiring regulations, and any other
relevant statutory regulations. Due to varied
requirements, applicable local codes should be
thoroughly understood and all pre-installation
work arranged for accordingly.
Location Requirements
The tumble dryer must be installed on a level floor
capable of supporting weight of tumble dryer fully
loaded. Floor covering materials such as carpeting or
tile should be removed.
To assure compliance, consult local building code
requirements. The tumble dryer must not be installed
or stored in an area where it will be exposed to water
and/or weather.
IMPORTANT: DO NOT block the airflow at the
rear of the tumble dryer with laundry or other
articles. Doing so would prevent adequate air
supply to the combustion chamber of the tumble
dryer.
A typical tumble dryer enclosure is shown in Figure 1.
Note the minimum and maximum dimensions. Local
codes and ordinances must be complied with.
IMPORTANT: Install tumble dryers with sufficient
clearance for servicing and operation. Refer to
Figure 1.
IMPORTANT: Keep tumble dryer area clear and
free from combustible materials, gasoline and other
flammable vapors and liquids.
Material Required (Obtain Locally)
All Models One single Pole fused disconnect switch
or circuit breaker on 1 Phase models.
Circuit breaker on 3 Phase models.
Gas Models One gas shut-off valve for gas service
line to each tumble dryer.
Steam Models One steam shut-off valve for steam
service line to be connected upstream of
solenoid steam valve.
Steam shut-off valve for each condensate
return line.
Flexible steam hoses with a 125 psig
(pounds per square inch gauge)
(8.78 kg/sq. cm) working pressure for
connecting steam coils. Refer to
Figure 20 for sizing and connection
configurations.
Steam trap for steam coil outlet to
condensate return line.
Optional – Vacuum breaker for
condensate return line.
To reduce the risk of serious injury, install
lockable door(s) to prevent public access to
rear of tumble dryers.
W055R1
WARNING

Installation
70380301 (EN)
18
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Tumble Dryer Enclosure
Figure 1
TMB2021N
NOTE: Shaded areas indicate adjacent structure.
10.5 in. (13 mm) recommended between machines for removal or installations.
2Allow 2-4 in. (51-102 mm) opening at top of machine to aid in removal or installation. A removable trim piece
may be used to conceal the opening; zero clearance allowed for trim.
34 in. (102 mm) Maximum Header Thickness
412 in. (305 mm) Minimum Clearance
524 in. (610 mm) minimum, 36 in. (914 mm) recommended for maintenance purposes.
6Provision for make-up air: Minimum 1 square foot required per tumble dryer. Location for reference only. May be
anywhere behind tumble dryer.
70.25 in. (6 mm) recommended for removal or installation purposes, zero clearance allowed.
TMB2021N
1
7
2
To reduce the risk of severe injury, clearance of tumble dryer cabinet from combustible
construction must conform to the minimum clearances.
W056R1
WARNING
4
5
6
3
