Alliance Laundry Systems 802753R4 User manual

for your
frontload
washer
www.comlaundry.com
Inside . . .
Safety Information . . . 3
Operation. . . . . . . . . . . . . 6
Clothing Care . . . . . . . 18
Maintenance . . . . . . . . 27
Troubleshooting. . . . . 30
Para bajar una copia de estas instrucciones en
español, visite www.comlaundry.com.
Part No. 802753R4
February 2011

-2-
802753
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
For your safety and to reduce the risk of fire or an explosion, do not store or use
gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
W022
WARNING

-3-
802753
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Safety Information
Explanation of Safety
Messages
Throughout this manual and on machine decals, you
will find precautionary statements (“DANGER,”
“WARNING,” and “CAUTION”) followed by specific
instructions. These precautions are intended for
the personal safety of the operator, user, servicer,
and those maintaining the machine.
Additional precautionary statements
(“IMPORTANT” and “NOTE”) are followed by specific
instructions.
IMPORTANT: The word “IMPORTANT” is used to
inform the reader of specific procedures where
minor machine damage will occur if the procedure
is not followed.
NOTE: The word “NOTE” is used to communicate
installation, operation, maintenance or servicing
information that is important but not hazard
related.
Important Safety Instructions
Save These Instructions
1. Read all instructions before using the washer.
2. Refer to the Grounding (Earthing) Information in
the Installation Instructions for the proper
grounding (earthing) of the washer.
3. Do not wash articles that have been previously
cleaned in, washed in, soaked in, or spotted
with gasoline, dry-cleaning solvents, or other
flammable or explosive substances as they
give off vapors that could ignite or explode.
4. Do not add gasoline, dry-cleaning solvents, or
other flammable or explosive substances to
the wash water. These substances give off
vapors that could ignite or explode.
Indicates an imminently hazardous
situation that, if not avoided, will
cause severe personal injury or death.
DANGER
Indicates a hazardous situation that, if
not avoided, could cause severe
personal injury or death.
WARNING
Indicates a hazardous situation that, if
not avoided, may cause minor or
moderate personal injury or property
damage.
CAUTION
To reduce the risk of fire, electric shock,
serious injury or death to persons when
using your washer, follow these basic
precautions:
W023
WARNING
© Copyright 2011, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or
transmitted in any form or by any means without the expressed written consent
of the publisher.

-4-
802753
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
5. Under certain conditions, hydrogen gas may
be produced in a hot water system that has
not been used for two weeks or more.
HYDROGEN GAS IS EXPLOSIVE. If the hot
water system has not been used for such a
period, before using a washing machine or
combination washer-dryer, turn on all hot
water faucets and let the water flow from
each for several minutes. This will release any
accumulated hydrogen gas. THE GAS IS
FLAMMABLE. DO NOT SMOKE OR USE AN
OPEN FLAME DURING THIS TIME.
6. Do not allow children to play on or in the
washer. Close supervision of children is
necessary when the washer is used near
children. This is a safety rule for all appliances.
This appliance is not intended for use by young
children or infirm persons without supervision.
Young children should be supervised to ensure
that they do not play with the appliance.
7. Before the washer is removed from service or
discarded, remove the door to the washing
compartment.
8. Do not reach into the washer if the wash drum
is moving.
9. Do not install or store the washer where it will
be exposed to water and/or weather.
10. Do not tamper with the controls.
11. Do not repair or replace any part of the
washer, or attempt any servicing unless
specifically recommended in the user-
maintenance instructions or in published user-
repair instructions that you understand and
have the skills to carry out.
12. To reduce the risk of an electric shock or fire,
DO NOT use an extension cord or an adapter
to connect the washer to the electrical power
source.
13. Use your washer only for its intended purpose,
washing clothes.
14. ALWAYS disconnect the washer from
electrical supply before attempting any
service. Disconnect the power cord by
grasping the plug, not the cord.
15. Install the washer according to the
Installation Instructions. All connections for
water, drain, electrical power and grounding
(earthing) must comply with local codes and
be made by licensed personnel when required.
Do not do it yourself unless you know how!
16. To reduce the risk of fire, clothes which have
traces of any flammable substances such as
vegetable oil, cooking oil, machine oil, flammable
chemicals, thinner, etc. or anything containing
wax or chemicals such as in mops and cleaning
cloths, must not be put into the washer. These
flammable substances may cause the fabric
to catch on fire by itself.
17. Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or
product.
18. Keep your washer in good condition. Bumping
or dropping the washer can damage safety
features. If this occurs, have your washer
checked by a qualified service person.
19. Replace worn power cords and/or loose plugs.
20. Be sure water connections have a shut-off
valve and that fill hose connections are tight.
CLOSE the shut-off valves at the end of each
wash day.
21. Loading door MUST BE CLOSED any time the
washer is to fill, tumble or spin. DO NOT by-
pass the loading door by permitting the
washer to operate with the loading door open.
22. Check washer for water leaks after each use. If
water is found, turn off the water supply and
call for service immediately. Don’t use washer
until it is repaired by an authorized service
agent.
23. If the washer’s volume or type of sound
changes from what is normally heard, call an
authorized service agent immediately to
prevent possible damage to other
components.
24. Never start a cycle and leave the property
without first checking to make sure the wash
cycle is complete.

-5-
802753
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
25. Always read and follow manufacturer’s
instructions on packages of laundry and
cleaning aids. Heed all warnings or
precautions. To reduce the risk of poisoning or
chemical burns, keep them out of the reach of
children at all times (preferably in a locked
cabinet).
26. Always follow the fabric care instructions
supplied by the garment manufacturer.
27. Never operate the washer with any guards
and/or panels removed.
28. DO NOT operate the washer with missing or
broken parts.
29. DO NOT by-pass any safety devices.
30. Failure to install, maintain, and/or operate this
machine according to the manufacturer's
instructions may result in conditions which
can produce bodily injury and/or property
damage.
31. Replace washer fill hoses every five years.
32. If unit is a stacked washer and dryer, do not
operate washer and dryer if the units have
been separated.
NOTE: The WARNING and Important Safety
Instructions appearing in this manual are not
meant to cover all possible conditions and
situations that may occur. Observe and be aware
of other labels and precautions that are located
on the machine. They are intended to provide
instructions for safe use of the machine. Common
sense, caution and care must be exercised when
installing, maintaining, or operating the washer.
Always contact your dealer, distributor or service
agent about any problems or conditions you do not
understand.

-6-
802753
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Operation
Before Washing
Prepare Wash Load
Empty Pockets and Cuffs
Make sure all pockets are empty and turn them
inside out. One bobby pin, metal or plastic toy, nail
or sharp object in a load can catch laundry, cause
tears and plug the pump. Facial tissue left in a
pocket will produce extreme “lint”. A crayon or
lipstick in a wash load may cause stains that
cannot be removed. Roll down cuffs and shake out
grass, sand and gravel.
Mend Rips and Tears
Little holes can become bigger in the washer. Mend
holes and tears before placing garments in the
washer.
Close Zipper and Fasten Hooks
These can catch on garments in a wash load and
tear them. Tie belts and sashes so they won’t wind
around clothes.
Put Small Items in Bag
Small items such as baby socks may get stuck
around the door. Put them inside a mesh garment
bag.
Check For Colorfastness
Squeeze a portion of garment in warm or hot sudsy
water. If the color bleeds or runs, wash the item
separately in cold water.
Sorting Items
Different items use different wash cycles and
temperatures. Always follow the manufacturer’s
care label. Proper sorting is easy if you follow a few
guidelines:
1. Sort by Color:
Separate items into loads of
whites, darks, lights and non-
colorfast.
2. Sort by Fabric and Construction:
Separate items into loads of
cottons/linens, permanent press,
synthetics/blends/poly knits, and
delicates.
3. Sort by Temperature:
Separate items into loads
that can be washed in cold,
warm or hot water.
4. Sort by Type and Amount of Soil:
Heavily soiled clothes will need extra
treatment. Lightly soiled clothes can become
dingy if washed with heavily soiled items.
5. Sort Lint “Shedders” From Lint “Receivers”:
Some fabrics attract lint and should not be
washed with lint-shedding loads. Lint
shedders are cottons, terry towels, chenille
bedspreads, rugs and clothes that have been
heavily bleached.
Lint receivers are synthetics, permanent or
durable press, knits (including socks),
corduroy, and other smooth fabrics.
Pretreat
Pretreat shirt collars and cuffs with a pretreat
product or liquid detergent when placing them in
the washer. Before washing, treat special stains
individually. Refer to Stain Removal section for
procedures on treating specific stains.
Whites
TLW1991
TLW1991N
TLW1990N
TLW1990N
Cottons
TLW1991
TLW1991N
Cold
TLW1991N
TLW1991N

-7-
802753
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Loading the Washer
Load Articles
•Load items by the amount of space they take up,
not by their weight. Mix large and small items in a
load to get the best washing results.
•Load items loosely into the wash drum. The bulk of
the clothes rather than the weight will determine
load size.
Bulky Items
•Use the HANDWASH/DELICATE cycle for bulky
items such as blankets and comforters. The cycle
includes gentle agitation to clean items delicately
and thoroughly. The extra rinse cycle may be
selected to ensure complete removal of soap
residue. A final spin extracts the moisture at a low
speed to maintain the load’s balance and minimize
wear to the articles.
Load Sizes
•Load sizes vary. Small and large items should be
washed together to create a balanced load. If
washing a large item, two bath towels should be
added to even the load.
•Smaller loads can create an unbalanced condition
and cause premature wear on the washer. Do not
hesitate to fill the entire inner drum of the washer.
The load will compress a great deal when wet. This
allows room for proper tumbling.
Water Level
•The washer will automatically adjust the water
level to the type and size of the load during any fill.
Wash Temperature
Boosted Hot Water (on select models only)
The Boosted Hot Wash will boost the water
temperature in the tub to 140°F (60°C) and is
useful for improved cleaning of some loads. The red
HEATING light will light up when heating. The cycle
will not advance until 140°F (60°C) has been
reached.
The time needed to reach this temperature may
add an additional 30 to 60 minutes to the cycle
time. Hot water is the most effective for cleaning
but it is not recommended for all fabric types (read
labels).
NOTE: The Boosted Hot Wash can be turned off by
changing the cycle selector knob to OFF and
restarting a cycle with a different water
temperature setting.
Hot Water
The Hot Wash temperature is determined by the
actual temperature of the hot water supplied to
the washer. For models with Boosted Hot Wash,
the heater element will not be on. Hot water is the
most effective for cleaning, but it is not
recommended for all fabric types (read labels).
Warm Water
The Warm Wash is useful for providing a thorough
cleaning on lightly soiled clothing without damaging
fabric or adding to color fading.
The Warm Rinse (select models only) is useful in
preventing wrinkles on certain fabrics. Check labels
for fabric manufacturer’s recommendations.
Do not wash or dry items soiled with
vegetable or cooking oils. Some oils may
remain after washing and may cause the
fabric to catch on fire by itself.
W527
WARNING

-8-
802753
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Cold Water
The Cold Wash is ideal for delicate items. Although
its cleaning abilities are not as great with hot or
warm water, it is useful for colors that bleed easily
and for sensitive fabrics.
The Cold Rinse is optional in every cycle and is the
most beneficial for fabrics. Cold rinses reduce
wrinkling and color fading. In addition, cold rinses
will save money and energy.
NOTE: In wash temperatures colder than 60
o
F
(16
o
C), detergents do not dissolve well. This may
cause ineffective cleaning, or lint and residue to
form.
NOTE: Always follow manufacturer’s care labels.
Wash Temperature Guide
Energy
You can save energy when washing by following a few
guidelines:
1. Heating water accounts for the greatest
energy expense when washing. Save on heating
water by using warm or cold washes as well as
cold rinses.
2. Wash full loads, but do not overload.
Water Temperature Use Comments
BOOSTED HOT
(select models only)
(approximately 140°F [60°C])
• Sturdy whites and colorfast items
• Work clothes
• Heavily soiled items
• Diapers
• Best cleaning for heavily soiled
items
• Best for sanitizing
HOT
(approximately 120°F [49°C]
or as determined by outside hot
water supply)
• Sturdy whites and colorfast items
• Work clothes
• Soiled items
• Diapers
• Best cleaning for soiled items
• Good for sanitizing
WARM
(approximately 100º F [38°C])
• Rinsing of some items
• Light and moderately soiled items
• Non-colorfast or dark colors
• Permanent press
• Silks, woolens, nylon, acrylic
• Reduces wrinkling in permanent
press fabrics
• Less fading
• Reduces shrinking in knits
COLD
(approximately 60º F [16°C])
• Rinsing of most items
• Non-colorfast fabrics
• Extra delicate clothing
• Saves energy
• Reduces color fading
• Reduces wrinkling
• Reduces shrinking
120
o
F
(49
o
C)
100
o
F
(38
o
C)
60
o
F
(16
o
C)
HOT
WARM
COLD
TLW1994N

-9-
802753
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Operating Your Washer
a.
NOTE: Always follow manufacturer’s care labels.
Determine Proper Cycle
NOTE: The cycle times might be longer if a
Boosted Hot Wash, if available, is selected.
Regular Cycle
Use for sturdy items, like play or work clothes,
towels, T-shirts, etc. This cycle includes a wash
tumble and two rinses with an optional third rinse.
The final spin starts with a medium spin and
finishes with a high spin.
Permanent Press Cycle
Use for permanent press items and synthetics.
This cycle includes a wash tumble and two rinses
with an optional third rinse. The final spin starts
with a medium spin and finishes with a high spin.
Delicate Cycle
Wash delicate items usually washed by hand on this
cycle. The cycle includes a wash tumble and two
rinses with an optional third rinse. The final spin
extracts moisture at a low spin.
Rinse & Spin Cycle
Use to quickly rinse items. The rinse is followed by a
high spin.
Spin Only Cycle
Use to extract water from wet items. This cycle
uses the high spin.
OFF
Use to stop a cycle or change cycles.
Extra Rinse
This optional setting is useful for detergent
sensitive skin. By pressing the “EXTRA RINSE”
button to “ON,” the REGULAR, PERMANENT
PRESS and DELICATE cycles will each provide an
additional rinse.
WARNING
To reduce the risk of fire, electric shock,
serious injury or death to persons, read
the Safety Information section before
operating your washer.
W522

-10-
802753
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
To Wash Clothes
IMPORTANT: Before using your new washer, make
sure the washer cord is plugged into an
appropriate electrical outlet that has the proper
grounding (earthing) and polarity. Refer to the
washer nameplate and Installation Instructions for
proper voltage and Hertz the washer is designed
to operate on. Refer to Contact Information
section for nameplate location. Make sure the
washer hoses are connected to the hot and cold
water faucets, and that the faucets are turned
on. Be sure the drain hose is not kinked and is
inserted into a drain. Refer to the INSTALLATION
INSTRUCTIONS for details of proper washer
installation.
IMPORTANT: Prior to first wash, use an all
purpose cleaner, or a detergent and water
solution, and a damp cloth to remove shipping
dust from inside of wash drum.
1. Get the clothes ready for washing. Empty
pockets and cuffs. Sort items into separate
loads. Pretreat stains and heavily soiled areas.
IMPORTANT: Remove all sharp objects from
laundry to avoid tears and rips to items
during normal machine operation.
2. Measure and add low sudsing, high efficiency
(HE) detergent, fabric softener and bleach to
the dispenser drawer. Refer to section on
Using Your Dispenser Drawer. Follow
instructions on detergent package for
amount to use.
NOTE: High efficiency (HE)
detergents are designed
especially for frontload washers
to reduce oversudsing and
maximize cleaning results. Look
for the HE logo or “high efficiency” on the
detergent’s label.
IMPORTANT: If using non-HE detergent, avoid
oversudsing by using only 1/2 of the detergent
manufacturer's recommended amount.
3. Load clothes into wash drum. Refer to section
on Load Sizes.
NOTE: Small items such as baby socks may get
caught around the door. Place these articles
inside a mesh garment bag.
TLW1991N
TLW1991N
FLW2169N
FLW2170N
FLW2170N

-11-
802753
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
When washing bulky items such as blankets and
comforters, use the HANDWASH/DELICATE cycle.
The cycle includes gentle agitation to clean items
delicately and thoroughly. The extra rinse cycle may
be selected to ensure complete removal of soap
residue. A final spin extracts the moisture at a low
speed to maintain the load’s balance and minimize
wear to the articles.
4. Close the loading door tightly. The washer will
not operate with the loading door open.
5. Set WASH/RINSE temperatures.
There are three, four or five WASH/RINSE
temperatures available – Boosted Hot Wash/Cold
Rinse (select models only), Hot Wash/Cold Rinse,
Warm Wash/Warm Rinse (select models only),
Warm Wash/Cold Rinse, Cold Wash/Cold Rinse.
Refer to the Water Temperature section for the
temperature that works best for your garments.
6. Select EXTRA RINSE if desired.
The extra rinse control is useful for detergent
sensitive skin. By pressing the EXTRA RINSE to ON,
the REGULAR, PERMANENT PRESS, and
DELICATE cycles will each provide an additional
rinse. If the rinse is desired, press the switch to ON.
When the extra rinse is not wanted, OFF should be
selected.
7. Select the cycle according to the type of
fabric being washed. Use the indicator dot on
the cycle selector knob as a guide.
8. Press and hold the START button for two
seconds to start the washer. The DOOR light
will come on after a short delay, water fill will
begin, and wash drum will begin tumbling.
NOTE: Washer door MUST be closed tightly to
start washer.
FLW2171N
FLW2174N
To reduce the risk of serious injury, do
not bypass the loading door switch by
permitting the washer to tumble or spin
with the loading door open.
W095
WARNING
FLW2175N
WARNING
Window may be hot in the Boosted Hot
and Hot wash cycles.
W325

-12-
802753
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
If items need to be added or removed after a cycle
has started, turn the cycle selector knob to the
OFF position. Wait until the DOOR light goes off
(approximately 45 seconds after cycle has been
stopped), open door, add or remove items, and
start the cycle again.
There is no agitator on this washer. Instead, the
clothing gently tumbles through the water. The
wash action consists of a period of tumbling in one
direction, a brief pause, and then a reverse tumble
in the opposite direction. The pauses are part of
the tumble action and add to the unique cleaning
capabilities of the washer. They are part of the
cycle.
NOTE: There will be extended pauses when
Boosted Hot Wash, if available, is selected
because the water is being heated.
To Change Cycles
If the selected cycle is not the correct cycle for the
fabric being washed, you may change the cycle
selection at any time until the first wash fill is
complete. Once the washer has filled for the first
part of the cycle (the wash portion), the current
cycle must be aborted and a new cycle must be
started.
To change the cycle before the first fill is
complete:
Change the cycle selected on the cycle selector
knob.
To change the cycle after the first fill is complete
and before the first wash is complete:
1. Abort the current cycle by changing the cycle
selector knob to the OFF position.
2. Set the WASH/RINSE temperature selector.
3. Set cycle selector knob.
4. Turn on extra rinse, if desired.
5. Press and hold the START button for two
seconds.
To change the cycle after the first wash is
complete:
NOTE: This should only be done if the speed of the
final extract is incorrect for the fabric being
washed. For example, if washing delicate items on
the REGULAR cycle, the high speed extract may
damage the fabric. Or, if washing towels or jeans
on the DELICATE cycle, the lower speed extract
would increase drying time.
1. Abort the current cycle by changing the cycle
selector switch to the OFF position.
2. Restart the cycle from the beginning. Refer to
the To Wash Clothes section.
To Pump Out Water After Aborting Cycle
Run a SPIN ONLY cycle. This cycle will perform a high
speed extract operation that will pump all of the
water out of the washer.
Manual Soaking
To soak a clothes load, start a wash in the desired
cycle. After fill is complete and wash drum has
started tumbling, turn the cycle selector knob to
OFF. When the clothes have soaked the desired
length of time, turn the cycle selector knob to the
cycle and press the start button to restart the
cycle.

-13-
802753
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
DOOR Light
When the washer is started, the DOOR light will
come on after a short delay. The light will turn off
approximately 45 seconds after the cycle is
complete.
WASH Light
This light comes on during the wash part of each
cycle.
RINSE Light
This light comes on for the rinse portion of each
cycle.
FINAL SPIN Light
This light comes on while the wash load is in the final
spin of the cycle.
HEATING Light (Red Light – on select
models only)
This light comes on during the Boosted Hot setting
only. While the washer is heating, the HEATING light
will turn on.
Out of Balance Load
If at the end of the cycle, the load is dripping wet,
the washer has limited the spin speed. This is to
prevent damage to the unit if there is a severely
unbalanced load.
If this condition occurs, redistribute the load
manually and run a RINSE & SPIN cycle.
If the condition persists, consider steps discussed
in the Before Washing section.

-14-
802753
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Available Washing Cycles
The cycles of your washer include several different
settings. Refer to the table below for what can be
expected during the cycles that you select.
Regular Cycle
Activity Water Temperatures
Wash
Fill & Tumble Boosted Hot (select models),
Hot, Warm or Cold
Spin
Pulse Spin
Rinse
Fill & Tumble Cold
Spin
Pulse Spin
Extra Rinse (Optional)
Fill & Tumble Cold
Spin
Pulse Spin
Final Rinse
Fill & Tumble Warm (select models) or Cold
Spin
Pulse Spin
Spin
Medium Spin (650 rpm)
Final Spin
High Spin (1000 rpm)
Fluff
Tumble
Permanent Press Cycle
Activity Water Temperatures
Wash
Fill & Tumble Boosted Hot (select models),
Hot, Warm or Cold
Spin
Pulse Spin
Rinse
Fill & Tumble Cold
Spin
Pulse Spin
Extra Rinse (Optional)
Fill & Tumble Cold
Spin
Pulse Spin
Final Rinse
Fill & Tumble Warm (select models) or Cold
Spin
Pulse Spin
Spin
Medium Spin (650 rpm)
Final Spin
High Spin (1000 rpm)
Fluff
Tumble

-15-
802753
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Common Washer Sounds
Delicate Cycle
Activity Water Temperatures
Wash
Fill & Tumble Boosted Hot (select models),
Hot, Warm or Cold
Spin
Pulse Spin
Rinse
Fill & Tumble Cold
Spin
Pulse Spin
Extra Rinse (Optional)
Fill & Tumble Cold
Spin
Pulse Spin
Final Rinse
Fill & Tumble Warm (select models) or Cold
Spin
Pulse Spin
Final Spin
Low Spin (500 rpm)
Fluff
Tumble
Rinse & Spin Cycle
Activity Water Temperatures
Rinse
Fill & Tumble Warm (select models) or Cold
Spin
Pulse Spin
Spin
Medium Spin (650 rpm)
Final Spin
High Spin (1000 rpm)
Fluff
Tumble
NOTE: The Rinse setting will give a cold rinse when the optional Extra Rinse is selected.
Sounds Cause
Accelerating
This sound is heard during the spin portion of every cycle.
Tapping
These sharp sounds may come from metal fasteners, zippers, belt buckles or coins hitting
the wash drum or door glass.
Thumping
Washer may be out of balance. Washer is designed to balance the load. If the washer is
severely unbalanced, turn cycle selector knob to OFF and redistribute the load.
Rumbling
Washer may not be level. Stop washer and adjust leveling legs. Refer to INSTALLATION
INSTRUCTIONS for details.

-16-
802753
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Using Your Dispenser Drawer
Detergent Compartment
The detergent compartment is located on the right
side of the dispenser drawer. Refer to
compartment 1 of illustration.
Use low sudsing, high efficiency (HE) powdered or
liquid detergents that are recommended for use
with frontload washers. Powdered bleach can also
be used in the dispenser along with the detergent.
NOTE: High efficiency (HE)
detergents are designed
especially for frontload washers
to reduce oversudsing and
maximize cleaning results. Look
for the HE logo or “high efficiency” on the
detergent’s label.
NOTE: If using non-HE detergent, avoid
oversudsing by using only 1/2 of the detergent
manufacturer's recommended amount.
When adding detergent, use only the recommended
amount. Adding too much detergent or using
regular sudsing detergent could result in an
oversudsing condition, which would require
additional rinsing with cold water. Use care when
adding detergent so as not to spill into the other
compartments. Detergent mixed with fabric
softener can make the softener gummy.
NOTE: The normal level of suds should be below
center of the door.
Liquid Bleach Compartment
The bleach compartment is located in the left front
corner of the dispenser drawer. Refer to
compartment 2 of illustration. It has been
designed to prevent the dispensing of undiluted
bleach onto the clothes load.
Use liquid bleach in the dispenser. Powdered bleach
must not be used in this compartment. Powdered
bleach can be used in the detergent compartment
only and can be added along with the detergent.
DO NOT use more than the maximum level
indicated for the bleach compartment. Adding
more than the maximum amount could result in
early dispensing of the product and possible
damage to fabrics.
Carefully pour recommended amount of bleach into
the compartment before starting wash load.
Be careful not to spill undiluted bleach. It is a
strong chemical and can damage some fabrics if it
is not properly diluted. Follow bleach
manufacturer’s label for proper use.
Carefully close dispenser door. Do not allow bleach
to spill into other compartments.
1Detergent
2Bleach
3Fabric Softener
3
21
FLW2172N

-17-
802753
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Fabric Softener Compartment
The fabric softener compartment is located in the
left rear corner of the dispenser drawer. Refer to
compartment 3 of illustration.
Use no more than the maximum level indicated for
the fabric softener compartment. Adding more
than the maximum amount could result in early
dispensing of the product and possible staining of
fabrics.
Add fabric softener to compartment before
beginning wash load. The fabric softener will be
dispensed during the last rinse cycle.
Carefully close dispenser door. Do not allow
softener to spill into other compartments.
To Clean the Dispenser
Pour hot water into the dispenser drawer, making
sure it flushes through each compartment. Use a
small brush to thoroughly clean out any residue.
It is not necessary to remove the dispenser drawer
for normal maintenance. If the dispenser drawer
needs to be removed for any reason, use dispenser
drawer removal tool, Part No. 318P4, to avoid
damage to the drawer.

-18-
802753
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Clothing Care
Clothing Care Labels
The symbols below appear on many clothing care
labels. Following the instructions on each label will
help ensure the best laundry results.
WASH
BLEACH
IRON
TLW2010N
Machine Wash Cycle
Normal
TLW2011N
Permanent
Press/Wrinkle
Resistant
TLW2013N
Hand wash
Warning
Signs
TLW2015N
Hot
TLW2016N
TLW2017N
Cold
TLW2018
Do not wring
TLW2014N
Do not wash
Water Temperature
TLW2012N
Gentle/
Delicate
Warm
TLW2019N
TLW2020N
TLW2021N
Bleach Symbols
Any bleach
(when needed)
Warning
Signs
Only
non-chlorine
bleach
(when needed)
Do not bleach
TLW2027N
TLW2024N
TLW2026N
TLW2025N
Iron - Dry or Steam
Low
Warning
Signs
TLW2022N
Iron
TLW2023N
High Medium
No steam
Do not iron
DRY
DRYCLEAN
DRY2033N
DRY2034N
DRY2035N
DRY2036N
DRY2037N
DRY2038N
DRY2039N
DRY2040N
DRY2041N
DRY2042N
DRY2045N
DRY2046N
Tumble Dry Cycle Warning
Signs
Dry
Do not
tumble dry
Normal Permanent
Press/Wrinkle
Resistant
Gentle/
Delicate
High Medium Low No heat/Air Do not dry
(used with
Do not
wash)
DRY2043N
Line dry/
Hang to dry In the shade
Special Instructions
DRY2044N
Drip dry Dry flat
Heat Setting
DRY2048N
Dryclean Warning
Signs
DRY2047N
Dryclean Do not Dryclean

-19-
802753
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Washing Special Items
NOTE: Always Follow Manufacturer’s Care Label
Instructions.
Bedding • Warm wash and warm rinse (if available).
• Use DELICATE cycle.
• Pretreat heavily soiled areas before washing.
• When washing an electric blanket, protect the plug by stitching the edge of the
blanket over the plug. Only dry in dryer if manufacturer says it can be done.
Diapers • Rinse out diapers immediately in cold water and soak in a diaper pail with a small
amount of detergent or enzyme presoak. Soak before washing.
• Limit wash load to two dozen cloth diapers.
• Use an all-purpose, low-sudsing detergent.
Draperies, Curtains, Slip Covers
• Shake to remove dust. Remove hooks and close zippers.
• Sun-damaged draperies and curtains will not withstand washing.
• Use warm water.
• Wash curtains frequently. They can be weakened from soil, fumes, dust, and the
sun.
• Fiberglass curtains need gentle care. Read care label to see if washable. Some
fiberglass curtains should be hand washed.
Pillows
(Feather and Down)
• Do not wash pillows unless they can be dried in dryer. They may mildew if not dried
completely.
• Use warm wash, cold rinse and low-sudsing detergent.
Rugs
• Shake before washing. Do not use hot water on rubber-backed rugs.
• Wash two or three rugs to balance the washer.
Slips and Nightgowns • Wash often using all-purpose detergent, warm or hot water and cold rinse on the
PERMANENT PRESS cycle.
• To keep nylons and polyesters white, wash only with whites and use chlorine
bleach occasionally.
• Use fabric softener to remove static electricity.
Shoes
• Most shoes made of cloth and rubber can be washed.
• Use the REGULAR cycle and warm water.
• Wash with towels to balance the load.
Small Items • Wash small items such as baby socks in a mesh garment bag.
Cotton Knits
• Unless the label indicates it is preshrunk, cotton knits will probably shrink to
some degree.
• Wash water should be hot or warm, suitable for color and soil.
• Rinse water should be cold.
Rayon Knits • Rayon stretches and shrinks easily. Treat as a delicate fabric and wash gently.
Synthetic Fiber Knits
• These items will generally keep their shape.
• Make sure trimmings (including belts) are machine washable, seams are not
puckered, and zippers and trimmings are well fastened.
Knits of Manufactured Fibers • Use PERMANENT PRESS cycle.
• Wash water should be warm, or suitable for color and soil.
• Rinse water should be cold.
• Do not wash with lint-shedding fabrics.
continued

-20-
802753
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
NOTE: We do not recommend starching in this washer.
Sweaters of Manufactured Fibers • Follow directions for comparable knits.
• Button sweaters and turn inside out.
• Stretch to shape after washing.
• Avoid pulling when wet.
Wool Items • Unless labeled “machine washable,” wash by hand.
Permanent Press
• Wash often. Permanent press clothes tend to look clean even when they should
be washed.
• Do not wash with lint-shedding loads.
• Pretreat grease stains and oily areas.
• Use the PERMANENT PRESS cycle, hot or warm water, cold rinse and
recommended amount of low-sudsing detergent.
• Use fabric softener in the dispenser drawer. This will reduce the static electricity
which attracts lint and makes garments cling.
