Alliance Laundry Systems TLW12CTLW12C Guide

Installation/Operation
www.comlaundry.com
Automatic
Washers
Metered Commercial
TLW12C
TLW12C
Part No. 202068R5
August 2011
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
202068 1
IMPORTANT: Read the complete
INSTALLATION/OPERATION INSTRUCTIONS
before using the washer.
For your safety and to reduce the risk of
fire or an explosion, do not store or use
gasoline or other flammable vapors and
liquids in the vicinity of this or any other
appliance.
W022
WARNING

© Copyright 2011, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
2202068
Table of
Contents
Safety Information.............................................................................. 3
Explanation of Safety Messages........................................................... 3
Important Safety Instructions ............................................................... 3
Installation........................................................................................... 5
Dimensions and Specifications............................................................. 5
Before You Start ................................................................................... 6
Tools ................................................................................................ 6
Installing the Washer ............................................................................ 6
Step 1: Remove the Shipping Brace and Shipping Plug.................. 6
Step 2: Wipe Out Inside of Washtub ............................................... 7
Step 3: Connect Fill Hoses............................................................... 7
Step 4: Connect Drain Hose to Drain Receptacle ............................ 9
Step 5: Position and Level the Washer ............................................ 10
Step 6: Plug In the Washer............................................................... 11
Step 7: Add Water to the Washer .................................................... 12
Step 8: Check Lid Switch ................................................................ 12
Step 9: Check Installation ................................................................ 12
Vending................................................................................................. 13
Meter Case ....................................................................................... 13
Models Prepped for Card Reader..................................................... 13
Additional Washer Security............................................................. 14
Operation............................................................................................. 15
Operation Instruction ............................................................................ 15
Step 1: Add Detergent...................................................................... 15
Step 2: Load Laundry....................................................................... 15
Step 3: Close Lid.............................................................................. 15
Step 4: Set Fabric Selector............................................................... 16
Step 5: Set Wash Temperature......................................................... 16
Step 6: Select Cycle Type/ Soil Level ............................................. 16
Step 7: Insert Money or Card........................................................... 16
Step 8: Start Washer......................................................................... 17
Indicator Lights................................................................................ 17
Maintenance ........................................................................................ 18
User-Maintenance Instructions............................................................. 18
Cold Weather Care........................................................................... 18
Care of Your Washer ....................................................................... 18
Replacing Hoses............................................................................... 18
Filter Screens ................................................................................... 18
Reinstallation of Shipping Materials ............................................... 18
Motor Overload Protector..................................................................... 18
Troubleshooting .................................................................................. 19
Contact Information........................................................................... 21
Installer Checklist............................................................... Back Cover

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 3
202068
Safety Information
Explanation of Safety Messages
Throughout this manual and on machine decals, you
will find precautionary statements (“DANGER,”
“WARNING,” and “CAUTION”) followed by specific
instructions. These precautions are intended for the
personal safety of the operator, user, servicer, and
those maintaining the machine.
Additional precautionary statements (“IMPORTANT”
and “NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used
to inform the reader of specific procedures where
minor machine damage will occur if the procedure
is not followed.
NOTE: The word “NOTE” is used to communicate
installation, operation, maintenance or servicing
information that is important but not hazard
related.
Important Safety Instructions
Save These Instructions
1. Read all instructions before using the washer.
2. Install the washer according to the
INSTALLATION INSTRUCTIONS. Refer to the
GROUNDING INSTRUCTIONS in the
INSTALLATION manual for the proper
grounding of the washer. All connections for
water, drain, electrical power and grounding must
comply with local codes and be made by licensed
personnel when required. Do not do it yourself
unless you know how!
3. Do not install or store the washer where it will be
exposed to water and/or weather.
4. Do not add the following substances or textiles
containing traces of the following substances to
the wash water: gasoline, kerosene, waxes,
cooking oils, vegetable oils, machine oils, dry-
cleaning solvents, flammable chemicals, thinners
or other flammable or explosive substances.
These substances give off vapors that could
ignite, explode or cause the fabric to catch on fire
by itself.
5. Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been
used for two weeks or more. HYDROGEN GAS
IS EXPLOSIVE. If the hot water system has not
been used for such a period, before using a
washing machine or combination washer-dryer,
turn on all hot water faucets and let the water
flow from each for several minutes. This will
release any accumulated hydrogen gas. THE
GAS IS FLAMMABLE, DO NOT SMOKE OR
USE AN OPEN FLAME DURING THIS TIME.
6. To reduce the risk of an electric shock or fire, DO
NOT use an extension cord or an adapter to
connect the washer to the electrical power
source.
Indicates an imminently hazardous
situation that, if not avoided, will cause
severe personal injury or death.
DANGER
Indicates a hazardous situation that, if not
avoided, could cause severe personal
injury or death.
WARNING
Indicates a hazardous situation that, if not
avoided, may cause minor or moderate
personal injury or property damage.
CAUTION
To reduce the risk of fire, electric shock,
serious injury or death to persons when
using your washer, follow these basic
precautions:
W023
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
202068
4
7. Do not allow children to play on or in the washer.
Close supervision of children is necessary when
the washer is used near children. This appliance
is not intended for use by persons (including
children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning the use of
the appliance by a person responsible for their
safety. This is a safety rule for all appliances.
8. Do not reach into the washer if the washtub or
agitator, if applicable, is moving.
9. Never operate the washer with any guards, panels
and/or parts removed or broken. DO NOT tamper
with the controls or bypass any safety devices.
10. Use your washer only for its intended purpose,
washing clothes. Always follow the fabric care
instructions supplied by the garment
manufacturer.
11. Always read and follow manufacturer’s
instructions on packages of laundry and cleaning
aids. To reduce the risk of poisoning or chemical
burns, keep them out of the reach of children at
all times (preferably in a locked cabinet). Heed
all warnings or precautions.
12. Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or product.
13. Lid MUST BE CLOSED any time the washer is
to agitate or spin. DO NOT bypass the lid switch
by permitting the washer to agitate or spin with
the lid open. A brake will stop the washtub
within seconds if the lid is opened during
spinning. If the washtub does not stop when the
lid is opened, remove the washer from use and
call the service person.
14. Be sure water connections have a shut-off valve
and that fill hose connections are tight. CLOSE
the shut-off valves at the end of each wash day.
15. Keep your washer in good condition. Bumping or
dropping the washer can damage safety features.
If this occurs, have your washer checked by a
qualified service person.
16. Do not repair or replace any part of the washer, or
attempt any servicing unless specifically
recommended in the user-maintenance
instructions or in published user-repair
instructions that you understand and have the
skills to carry out. ALWAYS disconnect the
washer from electrical supply before attempting
any service.
17. Disconnect the power cord by grasping the plug,
not the cord. If the supply cord is damaged, it
must be replaced by a special cord or assembly
available from the manufacturer or its service
agent.
18. Before the washer is removed from service or
discarded, remove the lid to the washing
compartment.
19. Failure to install, maintain, and/or operate this
washer according to the manufacturer’s
instructions may result in conditions which can
produce bodily injury and/or property damage.
NOTE: The WARNING and IMPORTANT
SAFETY INSTRUCTIONS appearing in this
manual are not meant to cover all possible
conditions and situations that may occur. Common
sense, caution and care must be exercised when
installing, maintaining, or operating the washer.
Always contact your dealer, distributor, service agent
or the manufacturer about any problems or conditions
you do not understand.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 5
202068
Installation
Dimensions and Specifications
1Pilot Hole TLW2097N
C
H
TLW2097N
25.625 in. (65.1 cm)
30.5 in. (74.47 cm)
Standard Capacity Meter Case
43 in. (109.2 cm)
0.44 in.
(1.12 cm) 26 in. (66.04 cm)
28.75 in. (73.02 cm)
41.25 in. (104.78 cm)
36 in. (91.44 cm)
51 in. (129.54 cm)
1
28 in. (71.1 cm)
38.19 in. (97 cm)
22.44 in. (57 cm)
High Capacity Meter Case
43.875 in. (111.44 cm)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
202068
6
Before You Start
Tools
For most installations, the basic tools you will need
are:
Figure 1
NOTE: If the washer is delivered on a cold day
(below freezing), or is stored in an unheated room
or area during the cold months, do not attempt to
operate it until the washer has had a chance to
warm up.
IMPORTANT: Install dryer before washer. This
allows room for attaching exhaust duct.
Installing the Washer
Step 1: Remove the Shipping Brace and
Shipping Plug
Remove the shipping brace from under the lid.
The shipping plug will be released from the base of the
washer when removing the cardboard base from the
washer. Refer to Figure 2.
The shipping brace and plug should be saved and must
be reinstalled whenever washer is moved or
transported to a new location. This will prevent
damage to washer components.
Do not tilt washer to front or sides when moving.
Refer to User-Maintenance section for instructions on
reinstalling shipping brace and shipping plug.
Figure 2
D074I
1Wrench
2Screwdriver
3Pliers
4Level
D074ID074I
12
4
3
TLW2098N
1Shipping Brace
2Shipping Plug
3Cardboard Base
TLW2
1
2
3

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
7
202068
Step 2: Wipe Out Inside of Washtub
Prior to first wash, use an all purpose cleaner or a
detergent and water solution and a damp cloth to
remove shipping dust from inside of washtub.
Figure 3
Step 3: Connect Fill Hoses
Water Supply Requirements
Water supply faucets must fit standard 3/4 inch
(19.1 mm) female garden hose couplings. DO NOT
USE SLIP-ON OR CLAMP-ON CONNECTIONS.
NOTE: Water supply faucets should be readily
accessible to permit turning them off when washer
is not being used.
Recommended cold water temperature is 50° to 75°
Fahrenheit (10° to 24° Celsius). Recommended
maximum hot water temperature is 125° Fahrenheit
(51° Celsius). Warm water is a mixture of hot and cold
water. Warm water temperature is dependent upon the
water temperature and the pressure of both the hot and
cold water supply lines.
Pressure must be a minimum of 20 to a maximum of
120 pounds per square inch (138 to 827 kPa) static
pressure measured at the faucet.
NOTE: Water pressure under 20 pounds per
square inch (138 kPa) will cause an extended fill
time in the washer.
Turn on the water supply faucets and flush the lines for
approximately two minutes to remove any foreign
materials that could clog the screens in the water
mixing valve. (This is especially important when
installing your washer in a newly constructed or
renovated building.)
TLW2099N
Under certain conditions, hydrogen gas
may be produced in a hot water system
that has not been used for two weeks or
more. HYDROGEN GAS IS EXPLOSIVE. If
the hot water system has not been used
for such a period and before using the
washer, turn on all hot water faucets and
let the water flow from each for several
minutes. This will release any
accumulated hydrogen gas. The gas is
flammable. Do not smoke or use an open
flame during this time.
W029
WARNING
To prevent personal injury, avoid contact
with inlet water temperatures higher than
125°Fahrenheit (51°Celsius) and hot
surfaces.
W748
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
202068
8
Connecting Hoses
Insert rubber washers and filter screens (from
accessories bag) in water fill hose couplings (two
hoses supplied with washer). Connect fill hoses to
water supply faucets. Then connect the hoses to the
hot and cold valve connections at the rear of the
washer. Refer to Figure 4. Thread hose couplings onto
valve connections finger tight. Then turn 1/4 turn with
pliers.
IMPORTANT: DO NOT cross thread or
overtighten couplings.
IMPORTANT: Hoses and other natural rubber
parts deteriorate after extended use. Hoses may
develop cracks, blisters or material wear from the
temperature and constant high pressure they are
subjected to.
All hoses should be checked on a monthly basis for
any visible signs of deterioration. Any hose showing
the signs of deterioration listed above should be
replaced immediately. All hoses should be replaced
every five years.
IMPORTANT: Turn off water supply faucets after
check-out and demonstration. Owner should turn
off water supply whenever there will be an
extended period of non-use.
NOTE: Longer fill hoses are available (as optional
equipment at extra cost) if the hoses (supplied with
the washer) are not long enough for the
installation. Order hoses as follows:
No. 20617 Fill Hose (8 feet) (2.44 m)
No. 20618 Fill Hose (10 feet) (3.05 m)
Risers
Risers (or air cushions) may have to be installed if the
pipes knock or pound when flow of water stops. The
risers are more efficient when installed as close as
possible to the water supply faucets. Refer to Figure 5.
Figure 5
TLW1988N
1Filter Screen (Screen must be facing
outward)
2Fill Hose
3Rubber Washer (Plain)
4Cold Water Connection
5Hot Water Connection
6Hose Coupling
7Faucet
Figure 4
TLW1988N
HOT
COLD
C
H
2
134
5
6
7
W005I
1Risers (Air cushions)
2Water Supply Faucets
W005I
2
1

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
9
202068
Step 4: Connect Drain Hose to Drain
Receptacle
Drain Facilities
IMPORTANT: The drain hose installation is a very
important factor in the washer installation. If care
is not taken when the drain hose is installed, a
siphoning action can be started which will cause
water to be siphoned from the washer during the
cycle.
End of drain hose should never be in water as
siphoning action can be started that will cause
water to be siphoned back into the washer.
The curved end of drain hose MUST be installed
even with or above the height of the cabinet top of
the washer to prevent siphoning. Refer to Figure 6.
The standpipe or drain receptacle must be capable of
handling a minimum of 1-1/2 inches (3.8 cm) outside
diameter drain hose. The drain hose should fit loose
within the standpipe (it should not be snug fit). Never
install the drain hose into a “sealed” drain system as
air cannot escape and will restrict the water from being
drained from the washer. A sealed drain system may
also allow water to be pumped back into the washer
during agitation. Both of these conditions may result
in flooding of the washer.
Remove the drain hose from its shipping position on
the rear of the washer by unhooking the hose from the
retainer clamp.
If necessary, follow the instructions for your type of
drain receptacle (high standpipe or low standpipe) to
properly install the drain hose.
High Standpipe Installation
NOTE: No. 562P3 Siphon Break Kit and No. 25863
Hose Coupling are not required for this type of
installation.
Figure 7
IMPORTANT: Drain receptacle must be capable of
handling a minimum of 1-1/2 inch (3.8 cm) outside
diameter drain hose.
W294I
1Drain Hose
2Standpipe
Figure 6
W294I
2
1
RECOMMENDED
STANDPIPE
HEIGHT
36 inches
MINIMUM
(91.44 cm)
W296I
1Drain Hose
2Cut Drain Hose off at This End to Fit the
Washer Installation
3Standpipe
{
W296I
3
1
MAXIMUM
STANDPIPE
HEIGHT NOT TO
EXCEED 5 feet
(1.5 m)
2

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
202068
10
Low Standpipe Installation
If the drain facility is lower than the cabinet top, a
siphon break kit, Part No. 562P3, must be installed in
the drain hose to prevent siphoning action and drain
hose MUST be cut to fit the washer installation. Refer
to Figure 8. Use one No. 25863 Hose Coupling to
splice hose. The No. 562P3 Siphon Break Kit and No.
25863 Hose Coupling are available as optional
equipment at extra cost through an authorized dealer
or parts distributor. Installation instructions are
supplied with the kit.
OPTIONAL: Raise the standpipe to the recommended
height of 36 inches (91.44 cm).
IMPORTANT: Drain receptacle must be capable of
handling a minimum of 1-1/2 inch (3.8 cm) outside
diameter drain hose.
Figure 8
Step 5: Position and Level the Washer
Position washer so it has sufficient clearance for
installation and servicing.
Place washer in position on a clean, dry, and
reasonably firm floor. Installing the washer on any
type of carpeting is not recommended.
Place rubber cups on all four leveling legs.
Place a level on the cabinet top and check if the
washer is level from side to side and front to back.
If washer is not level, tilt washer back to access the
front leveling legs. Loosen the locknuts and adjust legs
by screwing into or out of washer base.
Once adjusted, tilt the washer forward on front legs
and lower back down into position to set the rear self-
leveling legs.
Washer must not rock. After washer is at desired
height, tighten locknuts securely against bottom of
washer base. If these locknuts are not tight, washer
will not remain stationary during operation.
Improper installation or flexing of weak floor will
cause excessive vibration.
Do not slide washer across floor once the leveling legs
have been extended, as legs and base could become
damaged.
NOTE: For areas with uneven floors, a No. 566P3
Adjustable Rear Leg Extension Kit is available as
optional equipment at extra cost.
Verify that unit does not rock.
Figure 9
W295I
1Drain Hose Elbow
2562P3 Siphon Break Kit
3Standpipe
4Cut Hose in This Area and Install No. 25863
Hose Coupling
525863 Hose Coupling
W295I
{
2
1
5
4
3
TLW2100N
1Washer Base
2Locknut
3Leveling Leg
4Rubber Cup
51/2 inch (12.7 mm) Clearance Between
Washers
6Level
TLW2100N
1
3
2
54
6

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
11
202068
Step 6: Plug In the Washer
Electrical Requirements
(120 Volt, 60 Hertz with 3-Prong Grounding Plug)
NOTE: The wiring diagram is located in the
control hood.
When plugging in the washer:
•DO NOT overload circuits.
•DO NOT use an extension cord.
•DO NOT use an adapter.
•DO NOT operate other appliances on the same
circuit. Use separately fused 15 Amp circuits.
The washer is designed to be operated on a separate
branch, polarized, three-wire, effectively grounded,
120 Volt, 60 Hertz, AC (alternating current), circuit
protected by a 15 ampere fuse, equivalent fusetron or
circuit breaker.
The three-prong grounding plug on the power cord
should be plugged directly into a polarized three-slot
effectively grounded receptacle rated 110/120 Volts
AC (alternating current) 15 Amps. Refer to Figure 10
to determine correct polarity of the wall receptacle.
To reduce the risk of fire, electric shock,
serious injury or death, all wiring and
grounding MUST conform with the latest
edition of the National Electrical Code,
ANSI/NFPA No. 70, and such local
regulations as might apply. It is the
customer’s responsibility to have the
wiring, fuses and circuit breakers
installed by a qualified electrician to make
sure adequate electrical power is
available to the washer.
W518
WARNING
DRY2022N
1 L1
2Ground
3Neutral Side
4Round Grounding Prong
5Neutral
Figure 10
1
2
3
45
Standard 120 Volt, 60 Hertz
3-Wire Effectively
Grounded Circuit
0 V.A.C.
120±12
V.A.C.
120±12
V.A.C .
To reduce the risk of an electric shock or
fire, DO NOT use an extension cord or an
adapter to connect the washer to the
electric power source.
W082
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
202068
12
Grounding Instructions
The washer must be grounded. In the event of
malfunction or breakdown, grounding will reduce the
risk of electric shock by providing a path of least
resistance for electric current.
The washer is equipped with a cord having an
equipment-grounding conductor and a three-prong
grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and
grounded in accordance with all local codes and
ordinances.
•DO NOT modify the plug provided with the
washer – if it will not fit the outlet, have a proper
outlet installed by a qualified electrician.
•If the laundry room’s electrical supply does not
meet the above specifications and/or if you are
not sure the laundry room has an effective
ground, have a qualified electrician or your local
electrical utility company check it and correct
any problems.
Step 7: Add Water to the Washer
To prevent damage to pump, do not run washer before
adding at least one quart water to the tub. If the washer
is run before any water is added, the pump seal may
overheat, causing the pump to leak. Once installed, the
water retained in the drain system from the previous
cycle will provide sufficient cooling to prevent pump
seal damage.
NOTE: The agitator should not be removed except
for service. The washtub is designed to be self-
cleaning.
Figure 11
Step 8: Check Lid Switch
Washer should stop filling, agitating and spinning
when lid is opened.
Figure 12
Step 9: Check Installation
Refer to Installer Checklist on the back cover of this
manual and make sure that washer is installed
correctly.
Run washer through one complete cycle to make sure
it is operating properly.
Improper connection of the equipment-
grounding conductor can result in a risk
of electric shock. Check with a qualified
electrician or service person if you are in
doubt as to whether the washer is
properly grounded.
W327
WARNING
Any disassembly requiring the use of
tools must be performed by a suitably
qualified service person.
W299
WARNING
TLW2056N
TLW2101N
TLW2056N

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
13
202068
Vending
Meter Case
The factory mounted coin meter case does not include
the service door lock, coin drawer, coin drawer lock or
keys. These parts must be ordered (at extra cost)
according to the purchaser’s requirements direct from
the manufacturer of your choice.
NOTE: On models with standard capacity meter
case and high capacity meter case models starting
with Serial Nos. beginning 1010, you have the
option of using a screw type lock or a 1/4 turn lock
on the meter case service door. If you choose to use
a screw lock, then the special bracket (located
inside the meter case) must be used. DO NOT use
the special bracket if a 1/4 turn lock is used. High
capacity meter case models with Serial Nos.
beginning 0910 through 1010 use 1/4 turn lock only.
Coin Drawer Security (Models with Standard
Capacity Meter Case and high capacity meter case
models starting with Serial Nos. beginning 1010
Only) – For additional security, drill out the two pilot
holes on each side of the front of the meter case to 1/4
or 5/16 inch (6.4 or 7.9 mm) holes and install a bicycle
lock through these holes.
NOTE: An 8 in. (20.32 cm) coin drawer is required
for models with standard capacity meter case and
high capacity meter case models starting with
Serial Nos. beginning 1010. High capacity meter
case models with Serial Nos. beginning 0910
through 1010 require a 7.21 in. (18.31 cm) coin
drawer.
Models Prepped for Card Reader
The machine is shipped from the factory with the
Electronic Control Diagnostic Harness Assembly
unplugged. To avoid unauthorized manual
programming or vending, perform the following steps.
1. Open control panel. Refer to Figure 13.
2. Locate diagnostic harness on electronic control.
3. Plug connectors for “white/black” wire and “red/
blue” wire together.
Figure 13
FLW6R
1Control Panel
1

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
202068
14
Additional Washer Security
(Coin Models Only)
Located on the service door of the washer is a flat
Phillips head screw. During shipment, this screw is
used to attach the service door to the meter case. For
additional security, this screw can be reinstalled inside
the control hood of your washer. Refer to instructions
below for installation.
Tamper-resistant screws also can be installed for
additional security. Tamper-resistant screws, bits and
bit holder are available as optional equipment at extra
cost. Part numbers are:
•Bit (No. 8 screws) Part No. 281P4
•Bit (No. 12 screws) Part No. 282P4
•Bit Holder (3/8 drive) Part No. 24161
•Control panel tamper-resistant screw
Part No. 35528
•Front panel tamper-resistant screw
Part No. 35527
The following list is the procedure required to install
the Phillips head screw and tamper-resistant screws:
1. Remove the Phillips head screw from service
door (refer to Figure 14).
2. Remove two screws holding control panel to
control hood.
3. Tilt control panel forward and lay on a protective
pad to prevent scratching of cabinet top.
4. Insert Phillips head screw down through double
“D” hole in left rear corner of cabinet top (inside
control hood) until it engages retainer nut located
on left rear corner gusset of cabinet.
5. Finger tighten screw.
IMPORTANT: Do not use a power driver to tighten
screw. Torque of a power driver could over-tighten
screw causing damage to cabinet assembly.
6. Secure control panel to control hood using two
No. 8 tamper-resistant screws, Part No. 35528.
7. Remove two screws holding front panel to base
of washer and install two No. 12 tamper-resistant
screws, Part No. 35527.
Figure 14
To reduce the risk of electric shock, fire,
explosion, serious injury or death:
• Disconnect electric power to the washer
before servicing.
• Never start the washer with any guards/
panels removed.
• Whenever ground wires are removed
during servicing, these ground wires
must be reconnected to ensure that the
washer is properly grounded.
W003
WARNING
Any disassembly requiring the use of tools
must be performed by a suitably qualified
service person.
W299
TLW2102N
135528 No. 8 Screws
2Double “D” Hole
335527 No. 12 Screws
2
1
3

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 15
202068
Operation
Operation Instruction
IMPORTANT: Prior to first wash, use an all-
purpose cleaner, or a detergent and water solution,
and a damp cloth to remove shipping dust from
inside of washer.
IMPORTANT: Remove all sharp objects from
laundry to avoid tears and rips to items during
normal machine operation.
Step 1: Add Detergent
Pour measured amount of detergent into washtub.
Refer to package directions.
NEVER POUR UNDILUTED BLEACH DIRECTLY
ON LAUNDRY. Follow package directions when
using dry bleach.
If desired, fabric softener may be added to rinse water
when RINSE light comes on.
Figure 15
Step 2: Load Laundry
Load dry clothes loosely into washtub – DO NOT
overload!
When washing large items such as shag rugs and
bedspreads, add several small items to balance wash
load.
Figure 16
Step 3: Close Lid
Washer will not operate with lid open.
Figure 17
W395I
W392I
H338I

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operation
202068
16
Step 4: Set Fabric Selector
Push touchpad for NORMAL, PERM PRESS or
DELICATES. Light indicates selection.
Step 5: Set Wash Temperature
Push touchpad for HOT, WARM or COLD. Light
indicates selection.
Step 6: Select Cycle Type/ Soil Level
Push CYCLE SELECT or SOIL LEVEL touchpad.
Light indicates selection.
Figure 20
Step 7: Insert Money or Card
To Insert Money
Insert coin(s) in coin slot. Check pricing as seen on
digital display.
Figure 21
TLW2138N
Figure 18
TLW2139N
Figure 19
TLW2138N
TLW12R
W387I
TLW2118N
TLW1
TLW2118N

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operation
17
202068
To Insert Card
Insert card into opening.
Figure 22
Step 8: Start Washer
After vend price has been satisfied, push the START
pad. LID MUST BE CLOSED TO START WASHER.
Indicator Lights
INSERT COINS/CARD
INSERT COINS/CARD is lit to prompt the user to
insert coins or a card to satisfy the vend price. When
INSERT COINS/CARD is lit, the digits show the vend
price remaining to be satisfied.
WASH
WASH is lit at the beginning of the Wash portion of the
cycle and will remain lit until the Wash step is
complete.
RINSE
RINSE is lit at the beginning of the Rinse or Extra
Rinse portion of the cycle and will remain lit until the
Rinse step is complete.
SPIN
SPIN is lit during the Final Spin portion of the cycle.
SMALL LOAD
SMALL LOAD is lit if selected for the current cycle.
MEDIUM or LIGHT/MEDIUM
MEDIUM or LIGHT/MEDIUM is lit if selected for the
current cycle.
HEAVY
HEAVY is lit if selected for the current cycle.
START
START flashes one second on and one second off when
the full vend price has been satisfied.
DRY1927N
TLW2140N
Figure 23

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 202068
18
Maintenance
User-Maintenance Instructions
Cold Weather Care
If the washer is delivered on a cold day (below
freezing), or is stored in an unheated room or area
during the cold months, do not attempt to operate the
washer until it has had a chance to warm up.
Care of Your Washer
Use only a damp or sudsy cloth for cleaning the
control panel. Some cleaning products may harm the
finish on the control panel. Wipe the panel dry after
cleaning.
Wipe the washer cabinet as needed. If detergent,
bleach or other washing products are spilled on the
cabinet, wipe immediately. Some products will cause
permanent damage if spilled on the cabinet.
Do not use scouring pads or abrasive cleansers.
The washtub will need no particular care though it
may need rinsing or wiping after some unusual loads
have been washed. This also may be necessary if too
little detergent has been used.
Leave the lid open to allow the inside of the washer to
dry out after use. This helps prevent musty odors from
developing.
The agitator should not be removed except for service.
The washtub is designed to be self cleaning.
Replacing Hoses
Hoses and other natural rubber parts deteriorate after
extended use. Hoses may develop cracks, blisters or
material wear from the temperature and constant high
pressure they are subjected to.
All hoses should be checked on a monthly basis for
any visible signs of deterioration. Any hose showing
the signs of deterioration listed above should be
replaced immediately. All hoses should be replaced
every five years.
Filter Screens
Check the filter screens in the fill hoses for debris or
damage annually. Clean or replace them if necessary.
If the washer is filling with water slower than normal,
check the filter screens. Clean or replace them if
necessary.
Order filter screen Part No. F270300 from the nearest
authorized parts distributor.
Reinstallation of Shipping Materials
Shipping Brace
The shipping brace in the lid opening should be saved
and reinstalled whenever the washer is moved. To
reinstall the brace, open the washer lid and place the
brace over the washer agitator, placing the back of the
brace into the lid opening first.
Shipping Plug
The plastic shipping plug should be saved and
reinstalled any time the washer is moved. The plug fits
into two openings: The base opening and the shipping
plug opening on the bottom of the movable pivot
dome. The plug MUST be inserted into both openings
to prevent damage to the washer. In order to
accomplish this, the shipping plug opening must be
directly lined up with the base opening. Refer to
Figure 24.
Figure 24
Motor Overload Protector
The internal overload protector will stop the motor
automatically in the event of an overload.
The overload protector will reset itself in two or three
minutes and the motor will restart automatically.
If the overload protector stops motor again, remove
the washer from use and call the service person to
correct the problem.
TLW2103N
1Shipping Plug Opening
2Base Opening
3Shipping Plug
4Shipping Brace
TLW2103N
2
1
3
4
