Alliance Laundry Systems HC18 Maintenance and service guide

Part No. F232062R4
May 1999
NOTA: El manual en
español aparece después
del manual en inglés.
Installation/Maintenance
Washer-Extractor
Cabinet Hardmount
2-Speed, 3-Speed, and Variable-Speed
(See inside for complete model number list.)
Model Numbers
HC18 SC18 UC18
HC25 SC25 UC25
HC27 SîC27 UC27
HC35 SC35 UC35
HC50 SC50 UC50
HC80 SC80 UC80

Model Number Chart
HC18EC2
HC18MC2
HC18MD2
HC18MH2
HC18MN2
HC18MV2
HC18PC2
HC18SN2
HC18VC2
HC25EC2
HC25MC2
HC25MD2
HC25MH2
HC25MN2
HC25MV2
HC25PC2
HC25SN2
HC25VC2
HC27EC2
HC27MC2
HC27MD2
HC27MH2
HC27MN2
HC27MV2
HC27SN2
HC27VC2
HC35EC2
HC35MC2
HC35MD2
HC35MH2
HC35MN2
HC35MV2
HC35PC2
HC35SN2
HC35VC2
HC50EC2
HC50MC2
HC50MD2
HC50MH2
HC50MN2
HC50MV2
HC50PC2
HC50SN2
HC50VC2
HC80MC3
HC80MD3
HC80MH3
HC80MN3
HC80MV3
HC80PC3
HC80SN3
HC80VCV
HC80VNV
SC18EC2
SC18EP2
SC18MC2
SC18MC3
SC18MD2
SC18MD3
SC18MH2
SC18MH3
SC18MN2
SC18MN3
SC18MV2
SC18MV3
SC18SN2
SC18SN3
SC18VN2
SC18VNV
SC25EC2
SC25EP2
SC25MC2
SC25MD2
SC25MH2
SC25MN2
SC25MV2
SC25SN2
SC27EC2
SC27EP2
SC27MC2
SC27MD2
SC27MH2
SC27MN2
SC27MV2
SC27SN2
SC27VN2
SC27VNV
SC35EC2
SC35EP2
SC35MC2
SC35MC3
SC35MD2
SC35MD3
SC35MH2
SC35MH3
SC35MN2
SC35MN3
SC35MV2
SC35MV3
SC35SN2
SC35SN3
SC35VN2
SC35VNV
SC50EC2
SC50EP2
SC50MC2
SC50MC3
SC50MD2
SC50MD3
SC50MH2
SC50MH3
SC50MN2
SC50MN3
SC50MV2
SC50MV3
SC50SN2
SC50VN2
SC50VNV
SC80ECV
SC80EPV
SC80MC3
SC80MD3
SC80MH3
SC80MN3
SC80MV3
SC80SN3
SC80VNV
UC18MC2
UC18MC3
UC18MD2
UC18MD3
UC18MH2
UC18MH3
UC18MN2
UC18MN3
UC18MV2
UC18MV3
UC18PC2
UC18PC3
UC18PN2
UC18PN3
UC18VN2
UC18VNV
UC25MC2
UC25MD2
UC25MH2
UC25MN2
UC25MV2
UC25PC2
UC25PN2
UC27MN2
UC27PN2
UC27VN2
UC35MC2
UC35MC3
UC35MD2
UC35MD3
UC35MH2
UC35MH3
UC35MN2
UC35MN3
UC35MV2
UC35MV3
UC35PC2
UC35PC3
UC35PN2
UC35PN3
UC35VN2
UC35VNV
UC50MC2
UC50MC3
UC50MD2
UC50MD3
UC50MH2
UC50MH3
UC50MN2
UC50MN3
UC50MV2
UC50MV3
UC50PC2
UC50PC3
UC50PN2
UC50PN3
UC50VN2
UC50VNV
UC80MC3
UC80MD3
UC80MH3
UC80MN3
UC80MV3
UC80PC3
UC80PN3
UC80VNV

F232062 1
Table of Contents
Installation/Maintenance
Safety
Key to Symbols ................................................ 4
Safety Decal Location ...................................... 5
Operator Safety ................................................ 6
Safe Operating Environment ............................ 7
Environmental Conditions ............................ 7
Machine Location ......................................... 8
Input and Output Services ............................ 8
AC Inverter Drive ......................................... 9
Misuse .............................................................. 9
Installation
Machine Overview ........................................... 11
Delivery Inspection .......................................... 12
Customer Service ............................................. 12
Model Number Familiarization Guide ............. 13
General Specifications ..................................... 14
Machine Dimensions ........................................ 20
Dimensional Clearances ................................... 27
Machine Foundation ........................................ 29
Mechanical Installation .................................... 31
Expansion Bolt Installation .......................... 31
Elevated Base Frame Installation ................. 33
J-Bolt Installation ......................................... 35
Concrete Foundation Pad ............................. 39
Drain Connection ............................................. 42
Water Connection ............................................ 44
Electrical Installation ....................................... 45
Steam Requirements (Steam Heat
Option Only) .................................................... 52
Chemical Injection Supply System .................. 53
Control Function Test ...................................... 57
Maintenance
Daily ................................................................ 59
Beginning Of Day ........................................ 59
End Of Day .................................................. 60
Weekly ............................................................. 60
Monthly ........................................................... 60
Quarterly .......................................................... 64
Care Of Stainless Steel .................................... 65
Maintenance Checklists ................................... 66
Removal from Service
Decommissioning ............................................ 71

F232062
© Copyright 1999 Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.

F232062 3
Section 1
Safety
Anyone operating or servicing this machine
must follow the safety rules in this manual.
Particular attention must be paid to the
DANGER, WARNING, and CAUTION
blocks which appear throughout the manual.
The following warnings are general examples
that apply to this machine. Warnings specific
to a particular installation or maintenance
procedure will appear in the manual with the
discussion of that procedure.
Be careful around the open door,
particularly when loading from a level
below the door. Impact with door edges
can cause personal injury.
SW025
CAUTION
Dangerous voltages are present in the
electrical control box(es) and at the motor
terminals. Only qualified personnel familiar
with electrical test procedures, test
equipment, and safety precautions should
attempt adjustments and troubleshooting.
Disconnect power from the machine before
removing the control box cover, and before
attempting any service procedures.
SW005
WARNING
Death or serious injury can result if children
become trapped in the machine. Do not
allow children to play on or around this
machine. Do not leave children unattended
while the machine door is open.
SW001
DANGER
This machine must be installed, adjusted,
and serviced by qualified electrical
maintenance personnel familiar with the
construction and operation of this type of
machinery. They must also be familiar with
the potential hazards involved. Failure to
observe this warning may result in personal
injury and/or equipment damage, and may
void the warranty.
SW004
WARNING

Safety
4F232062
Key To Symbols
The lightning flash and arrowhead within the
triangle is a warning sign indicating the
presence of dangerous voltage.
The exclamation point within the triangle is a
warning sign indicating important instructions
concerning the machine and possibly
dangerous conditions.
This warning symbol indicates the presence of
potentially dangerous drive mechanisms
within the machine. Guards should always be
in place when the machine is in operation.
This warning symbol indicates the presence of
possibly dangerous chemicals. Proper
precautions should be taken when handling
corrosive or caustic materials.
This warning symbol indicates the presence of
hot surfaces that could cause serious burns.
Stainless steel and steam lines can become
extremely hot and should not be touched.
This warning symbol indicates the presence of
possibly dangerous pinch-points. Moving
mechanical parts can crush and/or sever
body parts.
Ensure that the machine is installed on a
level floor of sufficient strength and that the
recommended clearances for inspection
and maintenance are provided. Never allow
the inspection and maintenance space to
be blocked.
SW020
CAUTION
Never touch internal or external steam
pipes, connections, or components. These
surfaces can be extremely hot and will
cause severe burns. The steam must be
turned off and the pipe, connections, and
components allowed to cool before the pipe
can be touched.
SW014
WARNING

5
Safety
F232062
Safety decals appear at crucial locations on the
machine. Failure to maintain legible safety
decals could result in injury to the operator or
service technician.
Figure 1
H018IE3A
81968R1
81968R1
(Not present on EDC models)
(80-pound models only)
(MC Models Only)
(O.P.L. Only)
(O.P.L. Only)
(Typical)

Safety
6F232062
To provide personal safety and keep the
machine in proper working order, follow all
maintenance and safety procedures presented
in this manual. If questions regarding safety
arise, contact the factory immediately.
Use factory-authorized spare parts to avoid
safety hazards.
Operator Safety
To ensure the safety of machine operators,
the following maintenance checks must be
performed daily:
1. Prior to operating the machine, verify that
all warning signs are present and legible.
Missing or illegible signs must be replaced
immediately. Make certain that spares are
available.
2. Check door interlock before starting
operation of the machine:
a. Attempt to start the machine with the
door open. The machine should not
start with the door open.
b. Close the door without locking it and
attempt to start the machine. The
machine should not start with the
door unlocked.
c. Close and lock the door and start a
cycle. Attempt to open the door while
the cycle is in progress. The door
should not open.
If the door lock and interlock are
not functioning properly, call a
service technician.
3. Do not attempt to operate the machine
if any of the following conditions
are present:
a. The door does not remain securely
locked during the entire cycle.
b. Excessively high water level is evident.
c. Machine is not connected to a properly
grounded circuit.
Do not bypass any safety devices in
the machine.
NEVER insert hands or objects into basket
until it has completely stopped. Doing so
could result in serious injury.
SW012
WARNING
Never operate the machine with a bypassed
or disconnected balance system. Operating
the machine with severe out-of-balance
loads could result in personal injury and
serious equipment damage.
SW039
WARNING

7
Safety
F232062
Safe Operating Environment
Safe operation requires an appropriate
operating environment for both the operator
and the machine. If questions regarding safety
arise, contact the factory immediately.
Environmental Conditions
•Ambient Temperature.Water in the
machine will freeze at temperatures of
32°F (0°C) or below.
Temperatures above 120°F (50°C) will
result in more frequent motor overheating
and, in some cases, malfunction or
premature damage to solid state devices
that are used in some models. Special
cooling devices may be necessary.
Water pressure switches are affected by
increases and decreases in temperature.
Every 25°F (10°C) change in temperature
will have a 1% effect on the water level.
•Humidity. Relative humidity above 90%
may cause the machine’s electronics or
motors to malfunction or may trip the
ground fault interrupter. Corrosion
problems may occur on some metal
components in the machine.
If the relative humidity is below 30%, belts
and rubber hoses may eventually develop
dry rot. This condition can result in hose
leaks, which may cause safety hazards
external to the machine in conjunction
with adjacent electrical equipment.
•Ventilation. The need for make-up air
openings for such laundry room
accessories as dryers, ironers, water
heaters, etc., must be evaluated
periodically. Louvers, screens, or other
separating devices may reduce the
available air opening significantly.
•Radio Frequency Emissions.A filter is
available for machines in installations
where floor space is shared with
equipment sensitive to radio frequency
emissions.
•Elevation.If the machine is to be operated
at elevations of over 3,280 feet (1,000
meters) above sea level, pay special
attention to water levels and electronic
settings (particularly temperature) or
desired results may not be achieved.
•Chemicals. Keep stainless steel surfaces
free of chemical residues.
•Water Damage.Do not spray the machine
with water. Short circuiting and serious
damage may result. Repair immediately all
seepage due to worn or damaged
gaskets, etc.
Do not place volatile or flammable fluids
in any machine. Do not clean the machine
with volatile or flammable fluids such as
acetone, lacquer thinners, enamel reducers,
carbon tetrachloride, gasoline, benzene,
naptha, etc. Doing so could result in serious
personal injury and/or damage to
the machine.
SW002
DANGER

Safety
8F232062
Safe Operating Environment
(Continued)
Machine Location
•Foundation. The concrete floor must be of
sufficient strength and thickness to handle
the floor loads generated by the high
extract speeds of the machine.
•Service/Maintenance Space.Provide
sufficient space to allow comfortable
performance of service procedures and
routine preventive maintenance.
This is especially important in connection
with machines equipped with an AC
inverter drive.
Consult installation instructions for specific
details.
Input and Output Services
•Water Pressure. Best performance will be
realized if water is provided at a pressure
of 30 – 85 psi (2.0 – 5.7 bar). Although the
machine will function properly at lower
pressure, increased fill times will occur.
Water pressure higher than 100 psi
(6.7 bar) may result in damage to machine
plumbing. Component failure(s) and
personal injury could result.
•Steam Heat (Optional) Pressure.Best
performance will be realized if steam is
provided at a pressure of 30 – 80 psi
(2.0 – 5.4 bar). Steam pressure higher
than 125 psi (8.5 bar) may result in
damage to steam components and may
cause personal injury.
For machines equipped with optional
steam heat, install piping in accordance
with approved commercial steam
practices. Failure to install the supplied
steam filter may void the warranty.
•Compressed Air.For machines requiring
compressed air service, best performance
will be realized if air is provided at a
pressure of 80 – 100 psi (5.4 – 6.7 bar).
•Drainage System.Provide drain lines or
troughs large enough to accommodate
the total number of gallons that could
be dumped if all machines on the site
drained at the same time from the highest
attainable level. If troughs are used,
they should be covered to support light
foot traffic.
•Power. For personal safety and for proper
operation, the machine must be grounded
in accordance with state and local codes.
The ground connection must be to a
proven earth ground, not to conduit or
water pipes. Do not use fuses in place of
the circuit breaker. An easy-access cutoff
switch should also be provided.
Replace all panels that are removed to
perform service and maintenance
procedures. Do not operate the machine
with missing guards or with broken or
missing parts. Do not bypass any
safety devices.
SW019
CAUTION

9
Safety
F232062
Always disconnect power and water supplies
before a service technician performs any
service procedure. Where applicable, steam
and/or compressed air supplies should also be
disconnected before service is performed.
AC Inverter Drive
Machines equipped with the AC inverter drive
require special attention with regard to the
operating environment.
•An especially dusty or linty environment
will require more frequent cleaning of the
AC inverter drive cooling fan filter and of
the AC inverter drive itself.
•Power line fluctuations from sources such
as uninterruptible power supplies (UPS)
can adversely affect machines equipped
with the AC inverter drive. Proper
suppression devices should be utilized on
the incoming power to the machine to
avoid problems.
•A clean power supply free from voltage
spikes and surges is absolutely essential
for machines equipped with the AC
inverter drive. Nonlinear inconsistencies
(peaks and valleys) in the power supply
can cause the AC inverter drive to generate
nuisance errors.
If voltage is above 230V for 200V
installations or above 440V for 400V
installations, a buckboost transformer is
recommended. If voltage is above 240 or
480, a buckboost transformer is required.
•Sufficient space to perform service
procedures and routine preventive
maintenance is especially important for
machines equipped with the AC
inverter drive.
Misuse
Never use this machine for any purpose other
than washing fabric.
•Never wash petroleum-soaked rags in the
machine. This could result in an explosion.
•Never wash machine parts or automotive
parts in the machine. This could result in
serious damage to the basket.
•Never allow children to play on or around
this machine. Death or serious injury can
result if children become trapped in the
machine. Do not leave children unattended
while the machine door is open. These
cautions apply to animals as well.
Ensure that a ground wire from a proven
earth ground is connected to the ground lug
near the input power block on this machine.
Without proper grounding, personal injury
from electric shock could occur and machine
malfunctions may be evident.
SW008
WARNING

Safety
10 F232062
Notes

F232062 11
Section 2
Installation
This manual is designed as a guide to the
installation and maintenance of the 18-pound,
25-pound, 27-pound, 35-pound, 50-pound,
and 80-pound capacity cabinet hardmount
washer-extractors.
Machine Overview
The design of the machine emphasizes
performance reliability and long service life.
In washer-extractor sizes up through the
50-pound capacity models, the cylinder is
supported with two sealed bearings mounted in
a machined cast iron trunnion. On 80-pound
capacity models, the cylinder and shaft
assembly is supported by two flange roller
bearing assemblies. Bearing housings are
bolted to a heavy gamma frame.
The 2-speed machines use one dual-speed
motor to drive the cylinder via a V-belt drive in
wash speed and extract speed.
The 3-speed 18-pound capacity models use
one triple-speed motor to drive the cylinder
at wash speed, medium extract speed, and
high extract speed. The 3-speed 35-pound,
50-pound, and 80-pound capacity models use
one single-speed and one dual-speed motor to
drive the cylinder at wash speed, medium
extract speed, and high extract speed.
AC drive-controlled washer-extractors use one
motor to drive the cylinder. In all capacities
except the 80-pound, the motor is driven via a
flat belt drive. The 80-pound capacity machine
uses a 3V belt drive.
A door-lock system prevents opening of the
stainless steel door when a cycle is in progress.
It also prevents operation of the machine when
the door is open.
An electrically operated drain valve is used
to retain the water and wash solution in the
machine during the wash and rinse steps.
The drain valve closes when power is applied
and opens when power is removed, allowing
the machine to drain in the event of a
power failure.
The cylinder is designed with lifters or ribs
that lift the garments from the wash solution
when the cylinder rotates at slow speed and
allow the garments to tumble back into the
solution. The cylinder is perforated, allowing
the water to pass through and drain from
within during the wash process and extract.
Electrical controls for the machine are housed
in a separate enclosure located underneath the
top cover of the machine.

Installation
12 F232062
Machine Overview (Continued)
The polypropylene supply dispenser is
located under a flexible cover on the left side
of the machine, viewed from the front. The
compartments are numbered 1 – 3, starting
from the left side of the machine. A nozzle
flushes dry supplies from the compartment
with water at the appropriate time in the cycle.
Liquid supplies can be injected directly into
the dispenser compartments by a customer-
supplied external chemical supply system.
Hose barbs on the rear of the machine facilitate
connection to an external chemical supply
system. A terminal strip in the input power
junction box provides control signals.
Delivery Inspection
Upon delivery, visually inspect crate,
protective cover, and unit for any visible
shipping damage. If the crate, protective cover,
or unit are damaged or signs of possible
damage are evident, have the carrier note the
condition on the shipping papers before the
shipping receipt is signed, or advise the carrier
of the condition as soon as it is discovered.
Remove the crate and protective cover as soon
after delivery as possible. If any damage is
discovered upon removal of the crate and/or
protective cover, advise the carrier and file a
written claim immediately.
Customer Service
If literature or replacement parts are required,
contact the source from whom the machine
was purchased or contact Alliance Laundry
Systems LLC at [phone] for the name
and address of the nearest authorized
parts distributor.
For technical assistance, call any of the
following numbers:
[phone]
[phone]
Marianna, Florida
[phone]
Ripon, Wisconsin
A record of each machine, including the serial
number, is on file with the manufacturer. The
serial number decal is located at the rear of the
machine. See Figure 2. Always provide the
machine’s serial number and model number
when ordering parts or when seeking
technical assistance.

13
Installation
F232062
Figure 2
Model Number Familiarization Guide
Sample Model Number: SC35MN2CU20001
SC Machine Type C = Cabinet
35 Machine Capacity (pounds dry weight)
M
(E)
(P)
(S)
(V)
Type of Electrical Control M = Mechanical Timer
E = WX/EDC Microcomputer
P = P-Series Microcomputer†
S = S-Series Microcomputer
V = V-Series Microcomputer
N
(C)
(D)
(H)
(V)
Coin Meter Option N = No Coin Meter
C = W2000 (Computer-controlled models only)‡
D = Digital (Mechanical Timer models only)
H = Horizontal Slide (Mechanical Timer models only)
V = Vertical Drop (Mechanical Timer models only)
2
(3)
(V)
Speed 2 = 2-Speed
3=3-Speed
V = Variable-Speed
CElectrical Characteristics See Voltage Designation Chart in this section.
U2 Design Series
0001 Option Identification (varies from machine to machine)
†Models designated “PN” use the S-Series Microcomputer.
‡Models designated “MC” are prepared for use with an aftermarket coin meter.
H043I
380 – 415
15
50
35 16
500000
470
43
5
00000000000
SC35MN2CU20001

Installation
14 F232062
Cabinet Hardmount General Specifications
2-Speed Models
Specification 18 25 27 35 50
Overall Dimensions
Overall width, in (mm) 26 (660) 26 (660) 29 (737) 30-1/8 (765) 34-1/16 (865)
Overall height, in (mm) 42 (1067) 45 (1143) 45 (1143) 47-1/4 (1200) 49-3/4 (1265)
Overall depth, in (mm) 29-11/16
(754)
33-11/16
(856)
34-13/16
(884)
38-1/2 (978) 42 (1067)
Weight and Shipping Information
Net weight, lb (kg) 390 (177) 435 (198) 495 (225) 650 (295) 820 (373)
Domestic shipping weight, lb (kg) 430 (194) 475 (214) 555 (250) 710 (320) 970 (437)
Domestic shipping volume, ft3(m3)23.9 (0.669) 28.9 (0.809) 30.1 (0.852) 39.0 (1.09) 49.8 (1.39)
Export shipping weight, lb (kg) 480 (218) 525 (236) 605 (272) 760 (345) 1020 (464)
Export shipping volume, ft3(m3)47.1 (1.32) 35.9 (1.01) 37.7 (1.07) 47.1 (1.32) 68.6 (1.92)
Wash Cylinder Information
Cylinder diameter, in (mm) 21 (533) 21 (533) 24 (610) 26-1/4 (667) 30 (762)
Cylinder depth, in (mm) 13-3/4 (349) 18-3/4 (457) 16 (406) 18-3/8 (467) 20 (508)
Cylinder volume, ft3(l) 2.76 (78.1) 3.76 (106) 4.19 (117.9) 5.76 (163.1) 8.18 (232)
Perforation size, in (mm) 0.188 (4.76) 0.188 (4.76) 0.188 (4.76) 0.188 (4.76) 0.188 (4.76)
Perforation open area,% 17 17 23 17 18
Door Opening Information
Door opening size, in (mm) 12 (305) 12 (305) 14-11/32
(364)
13-15/16
(354)
16-1/4 (413)
Ht. door bottom above floor, in
(mm)
17-1/4 (438) 17-1/4 (438) 17 (432) 19 (480) 18-1/4 (465)
Power Consumption
Avg. power used per cycle, kW/hr 0.20 0.25 0.25 0.30 0.42
Nominal sound emission, dBA 60 63 63 64 66
Background noise level, dBA 48 51 51 49 49
Average HVAC load, Btu/hr 425 400 400 est. 510 700

15
Installation
F232062
Drive Train Information
Number of motors in drive train 1 1 1 1 1
Wash/reverse power, hp (kW) 0.18 (0.13) 0.25 (0.19) 0.25 (0.19) 0.40 (0.30) 0.55 (0.41)
High extract power, hp (kW) 1.0 (0.746) 1.4 (1.04) 1.4 (1.04) 1.8 (1.3) 2.7 (2.01)
Cylinder Speeds
Wash/reversespeed,rpm 5355474744
High extract speed, rpm 525 540 480 470 450
Centrifugal Force Data
Wash/reverse centrifugal force, Gs 0.85 0.90 0.75 0.82 0.825
High extract centrifugal force, Gs 82.1 86.9 80 82.3 86.3
Balance Detection
Vibration safety switch installed N/A N/A N/A N/A N/A
Direct Steam Heating (Optional)
Steam inlet connection size, in (mm) 1/2 (13) 1/2 (13) 1/2 (13) 1/2 (13) 1/2 (13)
Number of steam inlets 1 1 1 1 1
Steam req. to raise bath
temperature 10°F, lb
(10°C, kg)
LOW 1.1 (0.50) 1.4 (0.64) 1.5 (0.68) 2.1 (0.95) 2.8 (1.3)
HIGH 1.2 (0.54) 1.6 (0.73) 1.7 (0.77) 2.8 (1.3) 3.7 (1.7)
Average steam use per cycle, BHP 0.66 0.87 0.94 1.4 1.9
Electrical Heating (Optional)
Total electrical heating capacity, kW 7.8 7.8 7.8 15.6 23.4
Electrical heating elements 3 3 3 6 9
Electrical heat element size, kW 2.6 2.6 2.6 2.6 2.6
Cabinet Hardmount General Specifications
2-Speed Models (Continued)
Specification 18 25 27 35 50

Installation
16 F232062
Cabinet Hardmount General Specifications
3-Speed Models
Specification 18 35 50 80
Overall Dimensions
Overall width, in (mm) 26 (660) 30-1/8 (765) 34-1/16 (865) 41-1/2 (1054)
Overall height, in (mm) 42 (1067) 47-1/4 (1200) 49-3/4 (1265) 56 (1422)
Overall depth, in (mm) 29-11/16 (754) 38-1/2 (978) 42 (1067) 51-5/8 (1311)
Weight and Shipping Information
Net weight, lb (kg) 400 (182) 675 (307) 950 (432) 1600 (727)
Domestic shipping weight, lb (kg) 430 (195) 780 (355) 990 (450) 1650 (743)
Domestic shipping volume, ft3(m3)23.9 (0.669) 39.0 (1.09) 49.8 (1.39) 78.1 (2.19)
Export shipping weight, lb (kg) 490 (223) 785 (357) 1150 (523) 1700 (765)
Export shipping volume, ft3(m3)47.1 (1.32) 47.1 (1.32) 68.6 (1.92) ---
Wash Cylinder Information
Cylinder diameter, in (mm) 21 (533) 26-1/4 (667) 30 (762) 36 (914)
Cylinder depth, in (mm) 13-3/4 (349) 18-3/8 (467) 20 (508) 22 (559)
Cylinder volume, ft3(l) 2.76 (78.1) 5.76 (163.1) 8.18 (232) 12.4 (354)
Perforation size, in (mm) 0.188 (4.76) 0.188 (4.76) 0.188 (4.76) 0.188 (4.76)
Perforation open area,% 17 17 18 ---
Door Opening Information
Door opening size, in (mm) 12 (305) 13-15/16 (354) 16-1/4 (413) 18-1/2 (470)
Ht. door bottom above floor, in (mm) 17-1/4 (438) 19 (480) 18-1/4 (465) 21-1/2 (546)
Power Consumption
Avg. power used per cycle, kW/hr 0.18 est 0.28 est 0.38 est 0.55 est.
Nominal sound emission, dBA 61 65 67 60 / 69
Background noise level, dBA 48 49 49 47
Average HVAC load, Btu/hr 440 525 725 900

17
Installation
F232062
Drive Train Information
Number of motors in drive train 1 2 2 2
Wash/reverse power, hp (kW) 0.18 (0.13) 0.40 (0.30) 0.90 ( 0.67) 1.0 (0.75)
Medium extract power, hp (kW) 1.2 (0.895) 0.45 (0.34) 1.0 (0.75) 1.2 (0.89)
High extract power, hp (kW) 1.5 (1.12) 3.0 (2.2) 3.5 (2.6) 4.5 (3.36)
Cylinder Speeds
Wash/reverse speed, rpm 46 47 44 40
Medium extract speed, rpm 330 75 60 64
High extract speed, rpm 661 591 561 530
Centrifugal Force Data
Wash/reverse centrifugal force, Gs 0.65 0.82 0.825 0.82
Medium extract centrifugal force, Gs 32.5 2.10 1.53 2.1
High extract centrifugal force, Gs 130 130 134 143
Balance Detection
Vibration safety switch installed N/A Standard Standard Standard
Direct Steam Heating (Optional)
Steam inlet connection size, in (mm) 1/2 (13) 1/2 (13) 1/2 (13) 1/2 (13)
Number of steam inlets 1 1 1 1
Steam req. to raise bath
temperature 10°F, lb
(10°C, kg)
LOW 1.1 (0.5) 2.1 (0.95) 2.8 (1.3) 4.4 (2.0)
HIGH 1.2 (0.54) 2.8 (1.3) 3.7 (1.7) 6.3 (2.9)
Average steam use per cycle, BHP 0.66 1.4 1.9 3.1
Electrical Heating (Optional)
Total electrical heating capacity, kW 7.8 15.6 23.4 31.2
Electrical heating elements 3 6 9 12
Electrical heat element size, kW 2.6 2.6 2.6 2.6
Cabinet Hardmount General Specifications
3-Speed Models (Continued)
Specification 18355080

Installation
18 F232062
Cabinet Hardmount General Specifications
Variable-Speed Models
Specification 18 27 35 50 80
Overall Dimensions
Overall width, in (mm) 26 (660) 29 (737) 30-1/8 (765) 34-1/16 (865) 41-1/2 (1054)
Overall height, in (mm) 42 (1067) 45 (1143) 47-1/4 (1200) 49-3/4 (1265) 56 (1422)
Overall depth, in (mm) 29-11/16
(754)
34-13/16
(884)
38-1/2 (978) 42 (1067) 51-5/8 (1311)
Weight and Shipping Information
Net weight, lb (kg) 404 (182) 520 (234) 640 (288) 788 (355) 1406 (633)
Domestic shipping weight, lb (kg) 424 (191) 545 (245) 670 (301) 818 (371) 1456 (655)
Domestic shipping volume, ft3(m3)23.9 (0.669) 30.1 (0.852) 39.0 (1.09) 49.8 (1.39) 96.18 (2.69)
Export shipping weight, lb (kg) 494 (222) 610 (275) 750 (338) 988 (448) 1506 (678)
Export shipping volume, ft3(m3)47.1 (1.32) 37.7 (1.07) 47.1 (1.32) 68.6 (1.92) 109.4 (3.1)
Wash Cylinder Information
Cylinder diameter, in (mm) 21 (533) 24 (610) 26-1/4 (667) 30 (762) 36 (914)
Cylinder depth, in (mm) 13-3/4 (349) 16 (406) 18-3/8 (467) 20 (508) 22 (559)
Cylinder volume, ft3(l) 2.76 (78.1) 4.19 (117.9) 5.76 (163.1) 8.18 (232) 12.4 (354)
Perforation size, in (mm) 0.188 (4.76) 0.188 (4.76) 0.188 (4.76) 0.188 (4.76) 0.188 (4.76)
Perforation open area,% 17 23 17 18 27
Door Opening Information
Door opening size, in (mm) 12 (305) 14-11/32
(364)
13-15/16
(354)
16-1/4 (413) 18-1/2 (470)
Ht. door bottom above floor, in (mm) 17-1/4 (438) 17 (432) 19 (480) 18-1/4 (465) 21-1/2 (546)
Power Consumption
Avg. power used per cycle, kW/hr 0.11 0.14 0.20 0.37
Nominal sound emission, dBA N/A N/A N/A N/A N/A
Background noise level, dBA N/A N/A N/A N/A N/A
Average HVAC load, Btu/hr 425 425 510 510 900
Drive Train Information
Number of motors in drive train 1 1 1 1 1
Drive motor power, hp (kW) 1 (0.75) 1 (0.75) 2 (1.5) 2 (1.5) 5 (3.7)
