Alliance Laundry Systems TLW12C_SVG Guide

Installation/Operation
Topload Washers
Metered and Nonmetered
TLW12C_SVG
Original Instructions
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)
www.alliancelaundry.com Part No. 202630R2
September 2016

WARNING
Failure to install, maintain, and/or operate this ma-
chine according to the manufacturer's instructions
may result in conditions which can produce bodily
injury and/or property damage.
W030
WARNING
For your safety and to reduce the risk of fire or an
explosion, do not store or use gasoline or other
flammable vapors and liquids in the vicinity of this or
any other appliance.
W022
NOTE: The WARNING and IMPORTANT instructions ap-
pearing in this manual are not meant to cover all possi-
ble conditions and situations that may occur. It must
be understood that common sense, caution, and care-
fulness are factors which cannot be built into these
washers. These factors MUST BE supplied by the per-
son(s) installing, maintaining, or operating the washer.
Always contact the distributor, service agent, or the manufacturer
about any problems or conditions you do not understand.
Read all instructions before using washer.
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
3 Part No. 202630R2

Table of Contents
Safety Information..................................................................................6
Explanation of Safety Messages....................................................................... 6
Important Safety Instructions........................................................................... 6
Dimensions.............................................................................................8
Installation........................................................................................... 10
Before You Start........................................................................................... 10
Tools........................................................................................................10
Order of Installation Steps..........................................................................10
Remove the Shipping Brace and Shipping Plug............................................... 10
Wipe Out Inside of Wash Tub.........................................................................11
Connect Fill Hoses........................................................................................ 11
Water Supply Requirements....................................................................... 12
Connecting Hoses......................................................................................12
Risers.......................................................................................................12
Connect Drain Hose to Drain Receptacle.........................................................13
Drain Facilities..........................................................................................13
High Standpipe Installation........................................................................ 13
Low Standpipe Installation.........................................................................14
Position and Level the Washer........................................................................14
Plug In the Washer........................................................................................ 15
Electrical Requirements............................................................................. 15
Earth/Ground Instructions.......................................................................... 16
Add Water to the Washer............................................................................... 16
Check Lid Switch......................................................................................... 16
Check Installation......................................................................................... 16
Vending....................................................................................................... 17
Meter Case............................................................................................... 17
Slide Extension Assembly..........................................................................17
Models Prepped for Card Reader and Non-Metered Models.......................... 18
Additional Security....................................................................................18
Operation............................................................................................. 20
Operation Instructions for Coin Slide Operated and Nonmetered Washers.......... 20
Add Detergent...........................................................................................20
Load Laundry........................................................................................... 20
Close Lid..................................................................................................20
Set Wash Temperature and Fabric/Cycle Selector......................................... 20
Start Washer..............................................................................................21
Indicator Lights.........................................................................................22
© Copyright 2016, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed
written consent of the publisher.
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
4 Part No. 202630R2

Control Modes.......................................................................................... 22
Rapid Advance..........................................................................................23
Setting Dipswitch...................................................................................... 23
Operation Instructions for MDC Washers........................................................ 23
Add Detergent...........................................................................................23
Load Laundry........................................................................................... 23
Close Lid..................................................................................................24
Set Fabric Selector and Wash Temperature...................................................24
Insert Coins or Card...................................................................................24
Start Washer..............................................................................................24
Indicator Lights.........................................................................................25
Maintenance.........................................................................................26
User-Maintenance Instructions....................................................................... 26
Cold Weather Care.................................................................................... 26
Care of Your Washer..................................................................................26
Replacing Hoses........................................................................................26
Filter Screens............................................................................................ 26
Reinstallation of Shipping Materials............................................................... 26
Shipping Brace..........................................................................................26
Shipping Plug........................................................................................... 26
Motor Overload Protector.............................................................................. 26
Troubleshooting....................................................................................28
Contact Information............................................................................. 30
Installer Checklist.................................................................................31
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
5 Part No. 202630R2

Safety Information
Explanation of Safety Messages
Precautionary statements (“DANGER,” “WARNING,” and
“CAUTION”), followed by specific instructions, are found in this
manual and on machine decals. These precautions are intended
for the personal safety of the operator, user, servicer, and those
maintaining the machine.
DANGER
Indicates an imminently hazardous situation that, if
not avoided, will cause severe personal injury or
death.
WARNING
Indicates a hazardous situation that, if not avoided,
could cause severe personal injury or death.
CAUTION
Indicates a hazardous situation that, if not avoided,
may cause minor or moderate personal injury or
property damage.
Additional precautionary statements (“IMPORTANT” and
“NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used to in-
form the reader of specific procedures where minor
machine damage will occur if the procedure is not fol-
lowed.
NOTE: The word “NOTE” is used to communicate in-
stallation, operation, maintenance or servicing informa-
tion that is important but not hazard related.
Important Safety Instructions
Save These Instructions
WARNING
To reduce the risk of fire, electric shock, serious in-
jury or death to persons when using your washer,
follow these basic precautions:
W023
• Read all instructions before using the washer.
• Install the washer according to the INSTALLATION IN-
STRUCTIONS. Refer to the EARTH/GROUND INSTRUC-
TIONS in the INSTALLATION manual for the proper earth/
ground connection of the washer. All connections for water,
drain, electrical power and earth/ground must comply with lo-
cal codes and be made by licensed personnel when required.
Do not do it yourself.
• Do not install or store the washer where it will be exposed to
water and/or weather.
• Do not add the following substances or textiles containing
traces of the following substances to the wash water: gasoline,
kerosene, waxes, cooking oils, vegetable oils, machine oils,
dry-cleaning solvents, flammable chemicals, thinners or other
flammable or explosive substances. These substances give off
vapors that could ignite, explode or cause the fabric to catch
on fire by itself.
• Under certain conditions, hydrogen gas may be produced in a
hot water system that has not been used for two weeks or
more. HYDROGEN GAS IS EXPLOSIVE. If the hot water
system has not been used for such a period, before using a
washing machine or combination washer-dryer, turn on all hot
water faucets and let the water flow from each for several mi-
nutes. This will release any accumulated hydrogen gas. THE
GAS IS FLAMMABLE, DO NOT SMOKE OR USE AN
OPEN FLAME DURING THIS TIME.
• To reduce the risk of an electric shock or fire, DO NOT use an
extension cord or an adapter to connect the washer to the elec-
trical power source.
• Do not allow children to play on or in the washer. Close su-
pervision of children is necessary when the washer is used
near children. This appliance is not intended for use by per-
sons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, un-
less they have been given supervision or instruction concern-
ing the use of the appliance by a person responsible for their
safety. This is a safety rule for all appliances.
• Cleaning and user maintenance shall not be made by children
without supervision.
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
6 Part No. 202630R2

• Children less than three years should be kept away unless
continuously supervised.
• Do not reach into the washer if the washtub or agitator, if ap-
plicable, is moving.
• Never operate the washer with any guards, panels and/or parts
removed or broken. DO NOT tamper with the controls or by-
pass any safety devices.
• Use your washer only for its intended purpose, washing
clothes. Always follow the fabric care instructions supplied
by the garment manufacturer.
• Always read and follow manufacturer’s instructions on pack-
ages of laundry and cleaning aids. To reduce the risk of poi-
soning or chemical burns, keep them out of the reach of chil-
dren at all times (preferably in a locked cabinet). Heed all
warnings or precautions.
• Do not use fabric softeners or products to eliminate static un-
less recommended by the manufacturer of the fabric softener
or product.
• Lid MUST BE CLOSED any time the washer is to agitate or
spin. DO NOT bypass the lid switch to permit the washer to
agitate or spin with the lid open. A brake will stop the wash-
tub within seconds if the lid is opened during spinning. If the
washtub does not stop when the lid is opened, remove the
washer from use and call the service person.
• Be sure water connections have a shut-off valve and that fill
hose connections are tight. CLOSE the shut-off valves at the
end of each wash day.
• Keep your washer in good condition. Bumping or dropping
the washer can damage safety features. If this occurs, have
your washer checked by a qualified service person.
• Do not repair or replace any part of the washer, or attempt any
servicing unless specifically recommended in the user-mainte-
nance instructions or in published user-repair instructions that
you understand and have the skills to carry out. ALWAYS dis-
connect the washer from electrical supply before attempting
any service.
• Disconnect the power cord by grasping the plug, not the cord.
If the supply cord is damaged, it must be replaced by the man-
ufacturer, its service agent or similarly qualified persons in or-
der to avoid a hazard.
• Before the washer is removed from service or discarded, re-
move the lid or door to the washing compartment.
• Failure to install, maintain, and/or operate this washer accord-
ing to the manufacturer’s instructions may result in conditions
which can produce bodily injury and/or property damage.
NOTE: The WARNING and IMPORTANT SAFETY IN-
STRUCTIONS appearing in this manual are not meant
to cover all possible conditions and situations that may
occur. Observe and be aware of other labels and pre-
cautions that are located on the machine. They are in-
tended to provide instruction for safe use of the ma-
chine. Common sense, caution and care must be exer-
cised when installing, maintaining, or operating the
washer.
Always contact your dealer, distributor, service agent or the man-
ufacturer about any problems or conditions you do not under-
stand.
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
7 Part No. 202630R2

Dimensions
Metered Models
C
H
TLW2051N_SVG
M
L
K
J
I
HG
F
ED
C
B
A
1
1. Pilot Hole
A - Electronic Control Models 570 mm [22.44 in.]
B - Coin Slide Models 548 mm [21.56 in.]
C 1295 mm [51 in.]
D 1092 mm [43 in.]
E - Electronic Control Models 970 mm [38.19 in.]
E - Coin Slide Models 1026 mm [40.38 in.]
F 711 mm [28 in.]
G 660 mm [26 in.]
H 11 mm [0.44 in.]
I 914 mm [36 in.]
J 1048 mm [41.25 in.]
K 730 mm [28.75 in.]
L 651 mm [25.63 in.]
M 775 mm [30.5 in.]
Dimensions
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
8 Part No. 202630R2

Nonmetered Models
C
H
TLW2050N_SVG
K
J
I
H
G
FE
D
C
B
A
A 548 mm [21.56 in.]
B 1295 mm [51 in.]
C 1026 mm [40.38 in.]
D 711 mm [28 in.]
E 660 mm [26 in.]
F 11 mm [0.44 in.]
G 914 mm [36 in.]
H 1048 mm [41.25 in.]
I 730 mm [28.75 in.]
J 651 mm [25.63 in.]
K 775 mm [30.5 in.]
Dimensions
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
9 Part No. 202630R2

Installation
Before You Start
Tools
For most installations, the basic tools you will need are:
TLW2215N_SVG
12
3
4
5
6
NOTE: A cloth rag and all-purpose cleaner are also
needed.
1. Safety Glasses
2. Gloves
3. Wrench
4. Screwdriver
5. Pliers
6. Level
Figure 1
NOTE: If the washer is delivered on a cold day (below
freezing), or is stored in an unheated room or area dur-
ing the cold months, do not attempt to operate it until
the washer has had a chance to warm up.
NOTE: Install dryer before washer. This allows room for
attaching exhaust duct.
NOTE: This appliance is suitable for use in countries
having a warm, damp climate.
Order of Installation Steps
The proper order of steps must be followed to ensure correct in-
stallation. Refer to the list below when installing your unit.
1. Remove the shipping brace and shipping plug.
2. Wipe out inside of the washer.
3. Connect the fill hoses.
4. Connect the drain hose to the drain receptacle.
5. Position and level the washer.
6. Plug in the washer.
7. Add water to the washer.
8. Check the lid switch.
9. Check installation.
Remove the Shipping Brace and
Shipping Plug
1. Remove the shipping brace from under the lid.
2. The shipping plug will be released from the base of the wash-
er when removing the cardboard base from the washer. Refer
to Figure 2 .
The shipping brace and plug should be saved and must be rein-
stalled whenever washer is moved or transported to a new loca-
tion. This will prevent damage to washer components.
Do not tilt washer to front or sides when moving.
Refer to User-Maintenance section for instructions on reinstalling
shipping brace and shipping plug.
Installation
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
10 Part No. 202630R2
