Alliance Laundry Systems PHM1401C Owner's manual

Programming
www.comlaundry.com
Washer-Extractor
Pocket Hardmount
UniLinc Control
Refer to Page 10 for Model Identification
PHM1401C
PHM1401C
Part No. F8138801R3
September 2009
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
© Copyright 2009, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
F8138801 1
Table of
Contents
Safety Information.............................................................................. 4
Explanation of Safety Messages........................................................... 4
Important Safety Instructions ............................................................... 4
Safety Decals........................................................................................ 6
Operator Safety..................................................................................... 7
Safe Operating Environment ................................................................ 7
Environmental Conditions ............................................................... 7
Machine Location ............................................................................ 8
Input and Output Services................................................................ 8
AC Inverter Drive ............................................................................ 9
Introduction......................................................................................... 10
Model Identification ............................................................................. 10
Nameplate Location.............................................................................. 11
Replacement Parts ................................................................................ 11
Customer Service.................................................................................. 11
Preliminary Information.................................................................... 13
About the Control................................................................................. 13
Power Failure Recovery................................................................... 13
Communications .............................................................................. 13
Audit Information ........................................................................... 13
IR Communications Menu............................................................... 14
IR Communications Error Menu ..................................................... 14
Restore to Factory Defaults ............................................................ 14
Entering Program Mode................................................................... 15
UniLinc Identification........................................................................ 16
Operational Keypad.............................................................................. 16
Operation Modes .................................................................................. 17
General Modes of Operation............................................................ 17
Power-up Mode................................................................................ 17
Idle Mode......................................................................................... 17
Run Mode......................................................................................... 17
Stop Mode........................................................................................ 17
Error Mode....................................................................................... 17
Delayed Start Countdown Mode...................................................... 17
Communication Mode ..................................................................... 17
Entering Diagnostic Mode From Idle Mode.................................... 17
Machine Cycle Definition and Operation......................................... 18
Machine Cycle Operation..................................................................... 18
Rotation Sensor Equipped Machines.................................................... 18
Delayed Start Feature ........................................................................... 18
Jog Feature UW150 Only..................................................................... 18
Cycle Menu........................................................................................... 18
To Start a Cycle ............................................................................... 19
Run Menu ............................................................................................. 20
Contrast/Backlight Menu...................................................................... 22
Close Door Menu.................................................................................. 22
Lubricate Bearings Menu ..................................................................... 23

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
2F8138801
Run Diagnostic Menu........................................................................... 23
Speed, Temp and Water Level Menu................................................... 24
Cycle Aborted Retry Menu................................................................... 24
Cycle Aborted Fatal Menu.................................................................... 25
Cycle Stopped Menu............................................................................. 25
Delayed Start Menu.............................................................................. 25
Delayed Start Countdown Menu .......................................................... 26
Delayed Start Final Countdown Menu................................................. 26
Menu Navigation................................................................................. 27
The UniLinc.......................................................................................... 27
Menu Navigation on a Single Screen ................................................... 27
Menu Navigation with Parameters ....................................................... 27
Screen to Screen Navigation using the Arrow Keypads....................... 27
Navigation............................................................................................. 27
Display Screen Maps............................................................................ 28
System Menu Map Tree................................................................... 28
Run Menu Map Tree........................................................................ 29
Service Menu Map Tree................................................................... 29
Programming UniLinc ....................................................................... 30
System Menu........................................................................................ 30
Save Changes Menu ............................................................................. 30
Program Menu.................................................................................... 31
Program Menu...................................................................................... 31
Modify Cycle........................................................................................ 31
Available Characters........................................................................ 32
Cycle, Segment and Step Programming Flow Diagram....................... 33
Step Menu Navigation ..................................................................... 33
Reuse Fill Step Menu....................................................................... 34
Fill Step Menu.................................................................................. 34
Heater Option................................................................................... 35
Supply A and B Step Menu ............................................................ 35
Agitate Step Menu ........................................................................... 36
Cool Down Step Menu..................................................................... 36
Drain Step Menu ............................................................................. 37
Spray Rinse Extract Step Menu....................................................... 37
Extract Step Menu............................................................................ 38
End of Segment Audio Signal Step Menu....................................... 38
Global Setup........................................................................................ 39
Global Setup Menu............................................................................... 39
Language Menu.................................................................................... 39
Date/Time Menu................................................................................... 39
Water Level Menu................................................................................ 40
Temperature Menu................................................................................ 40
Audio Menu.......................................................................................... 41
Balance Retry Menu............................................................................. 41
Water Management Menu .................................................................... 42
Alarms Program Menu ......................................................................... 44

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
F8138801 3
Rapid Advance Menu........................................................................... 44
Shakeout Menu..................................................................................... 45
Banners Menu....................................................................................... 45
Factory Defaults Menu......................................................................... 45
Water Level Confirmation Menu.......................................................... 46
Water Temperature Confirmation Menu.............................................. 46
Alarms Confirmation Menu.................................................................. 46
Audio Confirmation Menu ................................................................... 47
Reset All Factory Defaults Confirmation Menu................................... 47
Factory Defaults Second Confirmation Menu...................................... 47
Diagnostic ............................................................................................ 48
Diagnostic Menu................................................................................... 48
Test Menu............................................................................................. 48
Test Cycle ........................................................................................ 49
Factory Valve Purge Menu................................................................... 51
Test Balance Weight Menu .................................................................. 51
Inputs Outputs Menu ............................................................................ 52
Water Leak Detection Diagnostic......................................................... 54
Alarms................................................................................................... 55
Machine Identification ....................................................................... 56
Machine Errors ..................................................................................... 56
Door Lock Error .............................................................................. 56
Door Open Error ............................................................................. 56
Drain Alarm Error ........................................................................... 56
Drive Balance Switch Error............................................................. 56
Drive Fault Error.............................................................................. 57
Fill Alarm Error ............................................................................... 57
Frame Balance Switch Error............................................................ 57
Open Temperature Sensor Error ..................................................... 57
Rotation Sensor Error ...................................................................... 57
Shorted Temperature Sensor Error ................................................. 57
SPI Error .......................................................................................... 57
Unbalance Error............................................................................... 58
Heat Alarm Error ............................................................................. 58
Water Level Sensor Error ................................................................ 58
PDA Communications Error............................................................ 58
Water Leak Detection Error............................................................. 58
Slow Drain Detected During A Machine Cycle Error..................... 59
Laundry Management........................................................................ 60
Total Number of Machine Cycle Counters........................................... 61
Total Number of Operating Minutes Counters..................................... 61
Last 10 Machine Cycles Rapid Advanced or Stopped ......................... 61
Maintenance........................................................................................ 62
Service Schedule Menu ........................................................................ 62
Daily Menu (Service)....................................................................... 62
Weekly Menu (Service)................................................................... 62
Monthly Menu (Service).................................................................. 63
Quarterly Menu (Service) ................................................................ 63
Cycle Charts........................................................................................ 64

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
4F8138801
Safety Information
Explanation of Safety Messages
Precautionarystatements(“DANGER,” “WARNING,”
and “CAUTION”), followed by specific instructions,
are found in this manual and on machine decals. These
precautions are intended for the personal safety of the
operator, user, servicer, and those maintaining the
machine.
Additional precautionary statements (“IMPORTANT”
and “NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used
to inform the reader of specific procedures where
minor machine damage will occur if the procedure
is not followed.
NOTE: The word “NOTE” is used to communicate
installation, operation, maintenance or servicing
information that is important but not hazard
related.
Important Safety Instructions
1. Read all instructions before using the washer.
2. Refer to the GROUNDING INSTRUCTIONS in
the INSTALLATION manual for the proper
grounding of the washer.
3. Do not wash textiles that have been previously
cleaned in, washed in, soaked in, or spotted with
gasoline, kerosene, waxes, cooking oils, dry-
cleaning solvents, or other flammable or
explosive substances as they give off vapors that
could ignite or explode.
4. Do not add gasoline, dry-cleaning solvents, or
other flammable or explosive substances to the
wash water. These substances give off vapors that
could ignite or explode.
5. Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been
used for two weeks or more. HYDROGEN GAS
IS EXPLOSIVE. If the hot water system has not
been used for such a period, before using a
washing machine or combination washer-dryer,
turn on all hot water faucets and let the water
flow from each for several minutes. This will
release any accumulated hydrogen gas. The gas
is flammable, do not smoke or use an open flame
during this time.
6. Do not allow children to play on or in the washer.
Close supervision of children is necessary when
the washer is used near children. This is a safety
rule for all appliances.
7. Before the washer is removed from service or
discarded, remove the door to the washing
compartment.
8. Do not reach into the washer if the wash drum is
moving.
DANGER indicates the presence of a
hazard that will cause severe personal
injury, death, or substantial property
damage if the danger is ignored.
DANGER
WARNING indicates the presence of a
hazard that can cause severe personal
injury, death, or substantial property
damage if the warning is ignored.
WARNING
CAUTION indicates the presence of a
hazard that will or can cause minor
personal injury or property damage if the
caution is ignored.
CAUTION
To reduce the risk of fire, electric shock,
serious injury or death to persons when
using your washer, follow these basic
precautions: W023
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
5
F8138801
9. Do not install or store the washer where it will be
exposed to water and/or weather.
10. Do not tamper with the controls.
11. Do not repair or replace any part of the washer, or
attempt any servicing unless specifically
recommended in the user-maintenance
instructions or in published user-repair
instructions that the user understands and has the
skills to carry out.
12. To reduce the risk of an electric shock or fire, DO
NOT use an extension cord or an adapter to
connect the washer to the electrical power
source.
13. Use washer only for its intended purpose,
washing textiles.
14. Never wash machine parts or automotive parts in
the machine. This could result in serious damage
to the basket.
15. ALWAYS disconnect the washer from electrical
supply before attempting any service. Disconnect
the power cord by grasping the plug, not the cord.
16. Install the washer according to the
INSTALLATION INSTRUCTIONS. All
connections for water, drain, electrical power and
grounding must comply with local codes and be
made by licensed personnel when required.
17. To reduce the risk of fire, textiles which have
traces of any flammable substances such as
vegetable oil, cooking oil, machine oil,
flammable chemicals, thinner, etc., or anything
containing wax or chemicals such as in mops and
cleaning cloths, must not be put into the washer.
These flammable substances may cause the
fabric to catch on fire by itself.
18. Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or product.
19. Keep washer in good condition. Bumping or
dropping the washer can damage safety features.
If this occurs, have washer checked by a
qualified service person.
20. Replace worn power cords and/or loose plugs.
21. Be sure water connections have a shut-off valve
and that fill hose connections are tight. CLOSE
the shut-off valves at the end of each wash day.
22. Loading door MUST BE CLOSED any time the
washer is to fill, tumble or spin. DO NOT bypass
the loading door switch by permitting the washer
to operate with the loading door open.
23. Always read and follow manufacturer’s
instructions on packages of laundry and cleaning
aids. Heed all warnings or precautions. To reduce
the risk of poisoning or chemical burns, keep
them out of the reach of children at all times
(preferably in a locked cabinet).
24. Always follow the fabric care instructions
supplied by the textile manufacturer.
25. Never operate the washer with any guards and/or
panels removed.
26. DO NOT operate the washer with missing or
broken parts.
27. DO NOT bypass any safety devices.
28. Failure to install, maintain, and/or operate this
washer according to the manufacturer’s
instructions may result in conditions which can
produce bodily injury and/or property damage.
NOTE: The WARNINGS and IMPORTANT
SAFETY INSTRUCTIONS appearing in this
manual are not meant to cover all possible
conditions and situations that may occur. Common
sense, caution and care must be exercised when
installing, maintaining, or operating the washer.
Any problems or conditions not understood should be
reported to the dealer, distributor, service agent or the
manufacturer.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
F8138801
6
Safety Decals
Safety decals appear at crucial locations on the
machine. Failure to maintain legible safety decals
could result in injury to the operator or service
technician.
To provide personal safety and keep the machine in
proper working order, follow all maintenance and
safety procedures presented in this manual. If
questions regarding safety arise, contact the
manufacturer immediately.
This machine must be installed, adjusted,
and serviced by qualified electrical
maintenance personnel familiar with the
construction and operation of this type of
machinery. They must also be familiar
with the potential hazards involved.
Failure to observe this warning may result
in personal injury and/or equipment
damage, and may void the warranty. SW004
WARNING
Ensure that the machine is installed on a
level floor of sufficient strength and that
the recommended clearances for
inspection and maintenance are provided.
Never allow the inspection and
maintenance space to be blocked. SW020
CAUTION
Be careful around the open door,
particularly when loading from a level
below the door. Impact with door edges
can cause personal injury. SW025
CAUTION
Never touch internal or external steam
pipes, connections, or components.
These surfaces can be extremely hot and
will cause severe burns. The steam must
be turned off and the pipe, connections,
and components allowed to cool before
the pipe can be touched. SW014
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
7
F8138801
Operator Safety
To ensure the safety of machine operators, the
following maintenance checks must be performed
daily:
1. Prior to operating the machine, verify that all
warning signs are present and legible. Missing or
illegible signs must be replaced immediately.
Make certain that spares are available.
2. Check door interlock before starting operation of
the machine:
a. Attempt to start the machine with the door
open. The machine should not start with the
door open.
b. Close the door without locking it and attempt
to start the machine. The machine should not
start with the door unlocked.
c. Close and lock the door and start a cycle.
Attempt to open the door while the cycle is in
progress. The door should not open.
If the door lock and interlock are not functioning
properly, call a service technician.
3. Do not attempt to operate the machine if any of
the following conditions are present:
a. The door does not remain securely locked
during the entire cycle.
b. Excessively high water level is evident.
c. Machine is not connected to a properly
grounded circuit.
Do not bypass any safety devices in the machine.
Safe Operating Environment
Safe operation requires an appropriate operating
environment for both the operator and the machine. If
questions regarding safety arise, contact the
manufacturer immediately.
Environmental Conditions
•Ambient Temperature. Water in the machine will
freeze at temperatures of 32°F (0°C) or below.
Temperatures above 120°F (50°C) will result in
more frequent motor overheating and, in some
cases, malfunction or premature damage to solid
state devices that are used in some models.
Special cooling devices may be necessary.
Water pressure switches are affected by increases
and decreases in temperature. Every 25°F (10°C)
change in temperature will have a 1% effect on
the water level.
•Humidity. Relative humidity above 90% may
cause the machine’s electronics or motors to
malfunction or may trip the ground fault
interrupter. Corrosion problems may occur on
some metal components in the machine.
If the relative humidity is below 30%, belts and
rubber hoses may eventually develop dry rot.
This condition can result in hose leaks, which
may cause safety hazards external to the machine
in conjunction with adjacent electrical
equipment.
•Ventilation. The need for make-up air openings
for such laundry room accessories as dryers,
ironers, water heaters, etc., must be evaluated
periodically. Louvers, screens, or other
separating devices may reduce the available air
opening significantly.
•Radio Frequency Emissions. A filter is available
for machines in installations where floor space is
shared with equipment sensitive to radio
frequency emissions.
•Elevation. If the machine is to be operated at
elevations of over 3280 feet (1000 m) above sea
level, pay special attention to water levels and
electronic settings (particularly temperature) or
desired results may not be achieved.
•Chemicals. Keep stainless steel surfaces free of
chemical residues.
NEVER insert hands or objects into
basket until it has completely stopped.
Doing so could result in serious injury.
SW012
WARNING
Never operate the machine with a
bypassed or disconnected balance
system. Operating the machine with
severe out-of-balance loads could result
in personal injury and serious equipment
damage. SW039
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
F8138801
8
•Water Damage. Do not spray the machine with
water. Short circuiting and serious damage may
result. Repair immediately all seepage due to
worn or damaged gaskets, etc.
Machine Location
•Foundation. The concrete floor must be of
sufficient strength and thickness to handle the
floor loads generated by the high extract speeds
of the machine. Refer to Installation manual.
•Service/Maintenance Space. Provide sufficient
space to allow comfortable performance of
service procedures and routine preventive
maintenance.
Consult installation instructions for specific details.
Input and Output Services
•Water Pressure. Best performance will be
realized if water is provided at a pressure of
30 – 80 psi (2.0 – 5.4 bar). Although the machine
will function properly at lower pressure,
increased fill times will occur. Water pressure
higher than 100 psi (6.7 bar) may result in
damage to machine plumbing. Component
failure(s) and personal injury could result.
•Steam Heat (Optional) Pressure. Best
performance will be realized if steam is provided
at a pressure of 30 – 80 psi (2.0 – 5.4 bar). Steam
pressure higher than 125 psi (8.5 bar) may result
in damage to steam components and may cause
personal injury.
For machines equipped with optional steam heat,
install piping in accordance with approved
commercial steam practices. Failure to install the
supplied steam filter may void the warranty.
•Drainage System. Provide drain lines or troughs
large enough to accommodate the total number of
gallons that could be dumped if all machines on
the site drained at the same time from the highest
attainable level. If troughs are used, they should
be covered to support light foot traffic.
•Power. For personal safety and for proper
operation, the machine must be grounded in
accordance with state and local codes. The
ground connection must be to a proven earth
ground, not to conduit or water pipes. Do not use
fuses in place of the circuit breaker. An easy-
access cutoff switch should also be provided.
Always disconnect power and water supplies before a
service technician performs any service procedure.
Where applicable, steam and/or compressed air
supplies should also be disconnected before service is
performed.
Do not place volatile or flammable fluids
in any machine. Do not clean the machine
with volatile or flammable fluids such as
acetone, lacquer thinners, enamel
reducers, carbon tetrachloride, gasoline,
benzene, naptha, etc. Doing so could
result in serious personal injury and/or
damage to the machine. SW002
DANGER
Replace all panels that are removed to
perform service and maintenance
procedures. Do not operate the machine
with missing guards or with broken or
missing parts. Do not bypass any safety
devices. SW019
CAUTION
Ensure that a ground wire from a proven
earth ground is connected to the ground
lug near the input power block on this
machine. Without proper grounding,
personal injury from electric shock could
occur and machine malfunctions may be
evident. SW008
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
9
F8138801
AC Inverter Drive
Machines equipped with the AC inverter drive require
special attention with regard to the operating
environment.
•An especially dusty or linty environment will
require more frequent cleaning of the AC inverter
drive cooling fan filter and of the AC inverter
drive itself.
•Power line fluctuations from sources such as
uninterruptible power supplies (UPS) can
adversely affect machines equipped with the AC
inverter drive. Proper suppression devices should
be utilized on the incoming power to the machine
to avoid problems.
•A clean power supply free from voltage spikes
and surges is absolutely essential for machines
equipped with the AC inverter drive. Nonlinear
inconsistencies (peaks and valleys) in the power
supply can cause the AC inverter drive to
generate nuisance errors.
•Sufficient space to perform service procedures
and routine preventive maintenance is especially
important for machines equipped with the AC
inverter drive.
This manual is designed as a guide to operating and
maintaining the Pocket Hardmount washer-extractor
equipped with the AC inverter drive.
NOTE: All information, illustrations, and
specifications contained in this manual are based
on the latest product information available at the
time of printing. We reserve the right to make
changes at any time without notice.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
10 F8138801
Introduction
Model Identification
Information in this manual is applicable to these
models:
UW35TV UWL060T3M UWN060T3M UWU060T3M
UW60TV UWL060T3V UWN060T3V UWU060T3V
UW80TV UWL080T3V UWN080T3V UWU080T3V
UW100TV UWL100T3V UWN100T3V UWU100T3V
UW125TV UWL125T3V UWN125T3V UWU125T3V
UW150TV UWL150T3V UWN150T3V UWU150T3V
UWL035T3V UWN035T3V UWU035T3V
UWL060T3L UWN060T3L UWU060T3L

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
11
F8138801
Nameplate Location
The nameplate is located on the back of the machine
and is programmed in the UniLinc Control. To access
Machine ID through the control:
1. Press and hold , then , then
keypads at the same time.
2. Press the keypad until Diagnostic is
highlighted.
3. Press the keypad.
4. Press the keypad until Machine ID is
highlighted.
5. Press the keypad.
Always provide the machine’s serial number and
model number when ordering parts or when seeking
technical assistance. Refer to Figure 1.
Figure 1
Replacement Parts
If literature or replacement parts are required, contact
the source from which the washer-extractor was
purchased or contact Alliance Laundry Systems LLC
at [phone] for the name of the nearest
authorized parts distributor. A parts manual may be
ordered by returning the reply card provided with each
washer-extractor.
Customer Service
For technical assistance, contact your local distributor
or call:
[phone]
Ripon, Wisconsin
A record of each washer-extractor is on file with the
manufacturer. Always provide the machine’s serial
number and model number when ordering parts or
when seeking technical assistance. Refer to Figure 1.
PHM1400C
1In UniLinc Control
2At back of machine
PHM1400C
2
1
EXAMPLE OF MACHINE NAMEPLATE LOCATION

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
F8138801
12
Figure 2
Model Number Familiarization Guide - Models through May 3rd, 2009
Sample Model Number: UW060TVQU10001
UW Model Number Prefix
060 Washer-Extractor Capacity (60 pounds dry weight of laundry)
TType of Electrical Control T = UniLinc Computer
VWasher-Extractor Speed Capabilities V = 8 Speeds
QElectrical Characteristics
U1 Design Series
0001 Option Identification (varies from machine to machine)
Model Number Familiarization Guide - Models starting May 4th, 2009
Sample Model Number: UWN060T3VXU1001
UW Model Number Prefix
NMarket Approvals
060 Washer-Extractor Capacity (60 pounds dry weight of laundry)
TType of Electrical Control T = UniLinc Computer
3Spray/Dispenser Feature
VWasher-Extractor Speed Capabilities V = 8 Speeds
XElectrical Characteristics
U1 Design Series
0Heat Feature
01 Option Identification (varies from machine to machine)
PHM1284R
PHM1284R
UWN060T3VXU1001
00000000000
200 – 240
319
HzHz PhasePhase
Supply Water:Supply Water: BARBAR
Number of wires :Number of wires : FLA :FLA : ampsamps
30
Circuit Breaker Size :Circuit Breaker Size : ampsamps
50-60 3
Serial No.Serial No.
Model No.Model No.
VoltageVoltage
60
30 - 85 psi, 2 - 5.7
Max. Load :Max. Load :
Schematic :Schematic :
KGKG
27
LBLB
EXAMPLE OF NAMEPLATE

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 13
F8138801
Preliminary Information
About the Control
The UniLinc control on the washer-extractor is an
advanced, graphical, programmable computer that lets
the owner control most machine features by
interacting with the control.
UniLinc allows the owner to program custom cycles,
run diagnostic cycles and retrieve audit, error and
bearing information.
Washer-extractors shipped from the factory have
default cycles and wash temperature settings built in.
The owner can change the default cycle, or any cycle.
IMPORTANT: It is extremely important that the
washer-extractor has a positive ground and that all
mechanical and electrical connections are made
before applying power to or operating the washer-
extractor.
Power Failure Recovery
If a cycle is in progress when the power fails, and if
the power outage lasts three or more seconds, the cycle
is lost and cannot be resumed when power recovers. If
the power outage lasts less than three seconds, the
control will resume the cycle when the power
recovers.
Communications
The control has the ability to communicate with a
PDA or a laptop with an IrDA device running the
UniLinc software. Devices such as PDAs and laptops
that are IrDA capable (able to transmit information to
machine) that have been tested and approved for use
with the UniLinc software can be used as a tool for
managing the machine.
Audit Information
The control collects and stores audit information,
which can be accessed with a PDA. Refer to the
following list for available audit information with a
PDA. Refer to UniLinc PC and PDA Application
User Instructions.
•Total Number of Individual Cycle Counters
•Last 25 Machine Cycles
•Service History
•Machine Errors Audit Data
•Communication Audit Data
•Re-Programming Audit Data
•Power Failures Audit Data
•Average Fill Time Audit Data
•Average Drain Time Audit Data
•Power Failure Audit Data
The PDA can receive audit and program data from the
control, and send programming data and diagnostic
commands to the control. Refer to UniLinc PC and
PDA Application User Instructions for additional
information on using a PDA.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Preliminary Information
F8138801
14
IR Communications Menu
The IR Communications Menu displays while the
control is communicating with a PDA. The control
will jump back to the previous page when the
communication is complete.
IR Communications Error Menu
The IR Communications Error Menu displays after the
control had an error communicating with a PDA. The
control will return to previous page after 3 seconds.
Restore to Factory Defaults
When the user selects Restore All Cycles And Global
Settings To Factory-Defaults, the control resets all of
the default values. The control also resets Machine
Cycles #1 through #41. The control will also reset the
following to factory-defaults:
Default Washer-Extractor Settings
Language = English
Maximum Balance Retries = 3
Water Reuse = Disabled
Rapid Advance = Enabled
Water Recirculation = Disabled
External Dispenser Pause = Disabled
Shakeout = 40 seconds
Banner # 1 = Blank
Banner # 2 = Blank
Daylight Saving = Enabled
Water Levels
High = 27
Medium = 15
Low = 3
Water Temperature
Hot = 140 F
Warm = 100 F
Cold = 35 F
Cooldown = 110 F
Temperature Controlled Fill = Disabled
Audio Signal External Signal = Disabled
Keypad Signal (beep) = Enabled
End of Cycle / Segment Sound = Enabled Low, 5
second duration
Alarms
Fill = 5 minutes
Drain = 2 minutes
Heat = 1 hour 30 minutes
PHM1003R
Figure 3
PHM1004N
Figure 4
Invalid Data

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Preliminary Information
15
F8138801
*Manual Programming = Enabled
*If manual programming is disabled, programming
changes to UniLinc can only be made with an external
communication device. Refer to UniLinc PC and
PDA Applications User Instructions.
Refer to Factory Defaults, Menu section for
information on Restoring Factory Defaults.
Entering Program Mode
1. Press and hold , then , then to
enter the System Menu. Select Program to enter
programming options.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
16 F8138801
UniLinc Identification
Operational Keypad
The control includes seven keypads. These functions
are available to the operator and are intended to
control and manage operation of the washer-extractor.
Refer to Figure 5 and Table 1.
PHM1401C
Figure 5
Keypad Description
LCD/UP ARROW Press to move the cursor on display to edit programming values. Also, press
while in Cycle Menu or Run Menu to change to the Contrast Adjust/Backlight
Menu. Also, press with and to enter System Menu.
UNLOCK/DOWN ARROW Press to move the cursor on display, edit programming values, or unlock door.
The door can only be unlocked while the machine is idle.
LEFT ARROW Press to move cursor on display.
BACK Press to move back to the previous display menu. Also, press with and
to enter System Menu. Also, back from the Cycle Menu to enter the
Service Schedule Menu.
RIGHT ARROW Press to move cursor on display. Press while running a cycle to get to Run
Diagnostic Menu. Press and hold with to enter Delayed Start Menu.
STOP/ON/OFF Press to stop and abort a machine cycle during Run Mode. Also press with
and to enter System Menu. Press with to enter Delayed Start
Menu.
START/ENTER Press to start or rapid advance a machine cycle during Run Mode. Also, press to
save edited programming values when used in programming menus.
Table 1

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
UniLinc Identification
17
F8138801
Operation Modes
General Modes of Operation
In each mode of operation, the user may press keypads
or communicate with the control to change the
displayed menu.
Power-up Mode
The control enters this mode at power-up. After the
control completes operation in the Power-up Mode it
will enter Idle Mode. The display is blank during
Power-up Mode.
Idle Mode
Control is ready for operation in Idle Mode. Control
can display different menus depending on user input
(keypad press, opening or closing the loading door, or
PDA communication). If there is no user input for one
minute, control will turn off the LCD backlight.
Control will light when there is user input. If there is
no user input for 10 minutes, display will go blank.
If control is in Idle Mode, Cycle Menu is displayed,
loading door closed, and the keypad is pressed,
control will enter Run Mode.
Run Mode
Control enters Run Mode during a cycle. Display
shows machine cycle time remaining, the colon
flashing one second on/one second off indicating that
the cycle time is counting down, and the display will
indicate the current cycle step. Loading door is closed
and locked during Run Mode. Press keypad to
end cycle and enter Stop Mode. Press keypad to
Rapid Advance to the next cycle step (if the Rapid
Advance feature is enabled. The Rapid Advance
feature is enabled by default.) Control enters Error
Mode if loading door unlocks or opens.
Stop Mode
If keypad is pressed before cycle ends, control
enters Stop Mode and performs the following steps:
•Displays a hourglass.
•Turns off all outputs.
•Verifies water is drained.
•Verifies motor is stopped by either rotation
sensor or time.
•The control will display the unlock door screen.
The user must unlock and open the door to return
to the Cycle Menu.
Error Mode
This mode will be entered to display all alarms and
machine errors.
Delayed Start Countdown Mode
Delayed Start Countdown Menu is entered after
delayed start is activated. The display will show the
hours and minutes remaining until the machine will
automatically start.
The Delayed Start Final Countdown Menu is entered
during the last sixty seconds before the control is
automatically started. The keypad will start the
selected cycle immediately. Press to return to the
Cycle Menu.
Communication Mode
This mode is entered whenever the control is
communicating with a PDA. Refer to UniLinc PC and
PDA Applications User Instructions.
Entering Diagnostic Mode From Idle Mode
When entered from the Idle Mode, the control will be
running a test selected by the user via keypad presses
or communication with a device. The diagnostic tests
available from the Idle Mode are the Test Cycle, Test
Balance Weight, and Inputs Outputs Menus.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
18 F8138801
Machine Cycle Definition and Operation
There are 41 machine cycles which can be selected
and run. Machine cycles can be modified or made
“unavailable” by manually editing them in Modify
Cycle Menu or by using the PDA to download a
modified machine cycle into the control. Machine
cycles cannot be deleted, but can be made
“unavailable” so that they are not visible from the
Cycle Menu. New machine cycles cannot be created,
but existing machine cycles that have been edited to be
“unavailable” may be re-edited to be available again.
Machine Cycle Operation
When a cycle is run, the control runs the cycle
segment by segment and step by step in a sequence.
The first segment can be programmed to “Off”,
“Prewash”, “Wash” or “Rinse”. If the segment is
programmed to “Off”, control skips to the next
segment. If the segment is not programmed to “Off”,
the first segment step (Reuse Fill step) is examined to
see if it is programmed on. If the segment step is
programmed on, it is executed and the next step
follows until the segment is complete. Any segment
steps programmed to “Off” are skipped.
At the start of a machine cycle, the control displays a
Total Remaining Cycle time. This time is taken from
the audit data for this cycle where there is stored an
average time elapsed for the last three of these cycles
that had been completed. The Total Remaining Cycle
Time begins to count down as soon as the cycle is
started. Since there will be differences between the
average elapsed cycle time and the actual elapsed
cycle time, the Total Remaining Cycle Time displayed
is corrected at the start of the cycle’s final enabled step
that has programmed time duration.
Rotation Sensor Equipped
Machines
On machines equipped with rotation sensors and a
rotation sensor error has not occurred, the control
monitors the rotation sensor. The control will never
send a new motor output which would reverse the
motor direction or force the motor to run at a lower
speed if the rotation sensor input indicates that the
machine basket is rotating. The control will wait for
the rotation to stop before sending the motor
command.
Delayed Start Feature
The user can select a machine cycle to run at a later
time. Refer to Delayed Start Menu Section.
Jog Feature UW150 Only
The user can use Jog Feature from the Cycle Menu in
Idle Mode, while the machine door is open. When the
control detects that the jog buttons are pressed, the
control will wake up and start a five second sound,
turn the beeper on and off for five seconds and then the
motor will turn in reverse direction at a reduced speed.
Cycle Menu
The Cycle Menu is the first menu displayed by the
control at power-up. The Cycle Menu allows the user
to select one of the 41 machine cycles. Machine cycles
that are turned off will not be displayed in the Cycle
Menu. As a default, the last run cycle will be displayed
in the center, highlighted position. The factory default
cycle will be Cycle01.
PHM702N
Figure 6
WARNING
To avoid personal injury, do NOT reach
into the basket while it is rotating. Keep
all personnel at a safe distance from the
machine while using the basket Jog
Feature. W641
For Technical Service
Distributor ABC
1-800-555-5555
Cycle41:
Supply Set
Up
Cycle02:
Towels White
Cycle01:
Towels
White
Bleach
Cycle Menu
