Alliance Laundry Systems SA025L Owner's manual

Programming
Tumbler
Refer to Page 4 for Model Numbers
DRY576R
Part No. 70417701R3
July 2009
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
70417701 1
NOTE: The WARNING and IMPORTANT
instructions appearing in this manual are not meant
to cover all possible conditions and situations that
may occur. It must be understood that common
sense, caution, and carefulness are factors which
cannot be built into these tumblers. These factors
MUST BE supplied by the person(s) installing,
maintaining, or operating the tumbler.
Always contact the distributor, service agent, or the
manufacturer about any problems or conditions you do
not understand.
Failure to install, maintain, and/or operate
this machine according to the
manufacturer's instructions may result in
conditions which can produce bodily
injury and/or property damage.
W030
WARNING

© Copyright 2009, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
270417701
Table of
Contents
Model Identification ........................................................................... 4
Preliminary Information.................................................................... 5
About the Control ................................................................................. 5
Glossary of Terms................................................................................. 5
Power Failure Recovery ....................................................................... 5
Communications ................................................................................... 5
Control Identification......................................................................... 6
SELECT CYCLE Pads......................................................................... 6
START Pad........................................................................................... 6
Display Identification ......................................................................... 7
Light Emitting Diodes (LEDs) ............................................................. 7
Tumbler Operation............................................................................. 8
Start Up................................................................................................. 8
Ready Mode.......................................................................................... 8
Partial Vend Mode................................................................................ 8
Additional Vend Mode ......................................................................... 8
Start Mode ............................................................................................ 8
Entering Coins ...................................................................................... 8
Entering Cards ...................................................................................... 9
Changing Active Cycles ....................................................................... 9
Opening the Tumbler Door................................................................... 9
Signals................................................................................................... 9
Extended Tumble Mode ....................................................................... 10
Special Features .................................................................................. 11
Programming Control ........................................................................... 11
Collecting Audit Information ............................................................... 11
Testing Machine and Control Functions............................................... 11
Rapid Advance Feature......................................................................... 11
Clearing the Vend Feature .................................................................... 11
Communications Mode......................................................................... 11
Coin Drop ............................................................................................. 11
Start Pulse Operation ............................................................................ 12
Service Door and Coin Vault Openings ............................................... 12
Special Vend......................................................................................... 12
OPL Mode ............................................................................................ 12
Drop-Off Mode..................................................................................... 12
Low Power/Auto-Shutdown Option ..................................................... 12
Opening Service Door......................................................................... 13
Stacked Tumbler................................................................................... 13
Stand Alone Tumbler............................................................................ 13
Entering the Manual Mode................................................................ 14
How to Enter the Manual Mode ........................................................... 14
Programming Control ........................................................................ 16
What Can Be Programmed? ................................................................. 16

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
70417701 3
Programmable Options Available......................................................... 16
1. Heat Vend Price “AtSH” ............................................................ 24
2. Coin #1 Value “dEn1” ................................................................ 25
3. Coin #2 Value “dEn2” ................................................................ 26
4. Start Pulse Value “PLSE” ........................................................... 27
5. Start Pulse Mode “PLSn” ............................................................ 28
6. Available Type “AtyP” ............................................................... 29
7. Default Cycle “dCYC” ............................................................... 30
8. OPL Mode Enable/Disable “oPL” .............................................. 31
9. Audio Signal “Aud” .................................................................... 32
10. Card Reader Display Control “CArd” ........................................ 34
11. Error Code Programming “Err-” ................................................. 35
12. Top-Off Data “toP-” ................................................................... 36
13. Cycle Time “CyC-” ..................................................................... 37
14. Cooldown Time “Cdt-” ............................................................... 38
15. Temperature “tEP-” .................................................................... 39
16. Temperature (Fahrenheit/Celsius) “t FC” ................................... 40
17. Auto Ignite Retry (Enable/Disable) “AIg” ................................. 40
18. No Heat Vend Price “AtSn” ....................................................... 41
19. Set Real Time Clock “rtC-” ........................................................ 42
20. Special Vend A Data “SPA-” ..................................................... 43
21. Special Vend B Days Enable “SPb-” .......................................... 57
22. Special Vend C Days Enable “SPC-” ......................................... 57
23. Special Vend D Days Enable “SPd-” .......................................... 58
24. Drop Off Mode (On/Off) “droP” ................................................ 59
25. Low Power/Auto Shutdown A Days Enable “LPSA” ................ 59
26. Low Power/Auto Shutdown B Days Enable “LPSb” ................. 60
27. Low Power/Auto Shutdown C Days Enable “LPSC” ................. 60
28. Low Power/Auto Shutdown D Days Enable “LPSd” ................. 61
29. Power Fail Reset “PFr” ............................................................... 61
30. IR Access (On/Off) “IrA” ........................................................... 63
31. Manual Rapid Advance (On/Off) “rAEn” .................................. 63
32. Manual Diagnostics (On/Off) “dAEn” ....................................... 64
33. Production Test Cycle (On/Off) “PtEn” ..................................... 64
Collecting Audit Information ............................................................ 65
Manual Reset....................................................................................... 66
Testing Machine and Electronic Control Functions........................ 67
Diagnostic Test Descriptions................................................................ 69
Production Test Cycle........................................................................... 74
Error Codes......................................................................................... 75
Rapid Advance Feature...................................................................... 77
Clear Vend Feature ............................................................................ 78
Power Fail Recovery........................................................................... 79
Power Fail Reset Disabled.................................................................... 79
Power Fail Reset Enabled..................................................................... 79
Communications Mode ...................................................................... 80
Infra-red Communications.................................................................... 80
Card Reader Communications (Card Models Only) ............................ 80
Network Communications.................................................................... 80

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70417701
4
Model Identification
Information in this manual is applicable to these tumbler models:
Includes models with the following control suffixes:
LC – network adaptable coin
LX – network adaptable, prep for coin
LY – network adaptable, prep for card
WC –network ready coin
WX –network ready, prep for coin
WY –network ready, prep for card
Gas Steam/Thermal Oil Electric
25 Pound SA025L
SA025N
ST025L
ST025N
ST025S ST025E
30 Pound
SA030L
SA030N
ST030D
ST030L
ST030N
ST030S ST030E
30 Pound
Stacked
SAT30L
SAT30N
STT30D
STT30L
STT30N
STT30S STT30E
35 Pound SA035L
SA035N
ST035L
ST035N
ST035S ST035E
45 Pound
Stacked
SAT45L
SAT45N
STT45D
STT45L
STT45N
Not Applicable Not Applicable
50 Pound
SA050L
SA050N
ST050D
ST050L
ST050N
ST050S
ST050T
ST050E
55 Pound
SA055L
SA055N
ST055D
ST055L
ST055N
Not Applicable
ST055E
75 Pound
SA075L
SA075N
ST075D
ST075L
ST075N
ST075S
ST075T
ST075E

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 5
70417701
Preliminary Information
About the Control
This control is an advanced, programmable computer
that lets the owner control machine features by
pressing a sequence of SELECT CYCLE pads. Refer
to Figure 1.
The control allows the owner to program custom
cycles, set vend prices, retrieve audit information, run
diagnostic tests, program special vend features and
other programmable features. Refer to Programming
Control for a list of features. Tumblers shipped from
the factory have a default cycle (MED TEMP) built in.
However, the owner can change the default cycle, or
any cycle, as needs permit.
IMPORTANT: In the event of a power failure, the
control will not have to be reprogrammed. It is
designed with a memory system that will remember
how it was programmed (for up to 10 years) until
the electrical power is restored.
IMPORTANT: It is extremely important that the
tumbler has a positive ground and that all mechanical
and electrical connections to the control are made
before applying power to or operating the tumbler.
Glossary of Terms
The following are a few terms and abbreviations to
learn. These are referred to throughout the instructions.
Display – This term refers to the window area of the
control that displays words and values.
LED (Light Emitting Diode) – This term refers to the
lights next to the keypads and status words of
the control.
Power Failure Recovery
If a cycle is in progress and the power fails, the cycle
status is saved in memory. When the power recovers,
the tumbler will resume into the previously active
cycle (if so programmed by the owner), by pressing
the START pad. If the power failure occurs while the
control is in a fatal error mode, it will return to Ready
Mode upon recovery.
The owner may program a special feature called
POWER FAIL RESET which sets a maximum power
failure duration. To program this feature, refer to
Programming Control, option 29.
If the length of the power failure is greater than the
POWER FAIL RESET time, the control will end the
cycle and the display will revert back to the Ready
Mode rather than resume the previously active cycle. If
the length of the power failure is less than the POWER
FAIL RESET time and the power failure is greater
than 2 seconds, or the POWER FAIL RESET is turned
off, the tumbler will enter START mode.
Communications
The control may be programmed manually, by
infra-red with an external device or by the network. A
limited number of features can be programmed by a
card reader.
Infra-red Communications (Optional)
An external device, such as a PDA, allows the owner
to program and retrieve information from the control
without touching the keypad. An external device
greatly expands the programming options available to
the owner. However, the external device is not required
to program and operate the tumbler. The operation of
an external device and the advanced features available
are covered separately in the instructions included
with the external device software. Contact Alliance
Laundry Systems for a list of approved PDAs and
other external devices.
Serial Card Reader Communications
(Card Models Only)
The control will accept communication with a serial
card reader in order to perform vending transactions
when a card is inserted to pay for cycles. The card
reader can also allow the owner to program and collect
audit information.
For detailed information on serial card reader
communications, refer to instructions included with
card reader.
Network Communications
The control will also accept communication with a
network interface board which allows the control to be
linked to a personal computer. This network link
allows an owner to program, collect data and run
diagnostics on any machine.
For detailed information on network communications,
refer to the network instructions.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70417701
6
Control Identification
SELECT CYCLE Pads
(Refer to Figure 1)
SELECT CYCLE pads are used to select the specific
tumbler cycle and temperature. These pads include
HIGH TEMP, MED TEMP, LOW TEMP,
DELICATES and NO HEAT. The selection of one of
these cycles will light up the corresponding LED. The
factory default cycle is MED TEMP.
START Pad
(Refer to Figure 1)
The START pad is used to start the tumbler after the
full vend price has been satisfied and the tumbler door is
closed.
Both the START pad and the SELECT CYCLE pads are
used in various combinations for programming cycles,
retrieving audit information, running diagnostic tests,
and other operations. During an active cycle (card reader
equipped machines only), the START pad may be
pressed (with a card inserted) to add time to a cycle.
Figure 1
DRY576R
1Display
27-Segment Digits
3START Pad
4SELECT CYCLE Pads
5LED Light
6LED Status Lights
DRY576R
6
1
2
3
Electronic Control
5
4

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 7
70417701
Display Identification
Light Emitting Diodes (LEDs)
(Refer to Figure 1)
LIGHT EMITTING DIODES (LEDs) are used to
indicate the chosen temperature and cycle status. See
below for information on each LED.
INSERT COINS/CARD LED
The INSERT COINS/CARD LED is lit to prompt the
user to insert coins or a card to satisfy the vend price
for the chosen cycle. The LED is lit during the
“Ready” mode. During Partial and Additional Vend,
the LED flashes one second on and one second off.
The INSERT COINS/CARD LED will shut off when
the vend price has been satisfied.
START LED
The START pad LED flashes whenever the dryer is
not in a cycle, the full vend price has been satisfied,
and the tumbler door is closed. When the START pad
is pressed, the cycle will begin or resume. The START
LED will shut off when the START pad is pressed.
The START LED will also flash any time a card is
inserted to add time to the current cycle.
DRYING LED
The DRYING LED is lit to indicate that one of the
heated cycles (HIGH TEMP, MED TEMP, LOW
TEMP, DELICATES) is currently in operation. The
DRYING LED goes off at the end of a heated cycle, if
the heated cycle is changed to a NO HEAT cycle, or
when the COOL DOWN cycle begins.
COOL DOWN LED
The COOL DOWN LED is lit whenever the COOL
DOWN portion of a heated cycle is active. It is also lit
when the NO HEAT cycle is in operation. The COOL
DOWN LED will shut off when a cycle ends or more
time is added, pushing the cycle back into the heated
portion of a cycle.
Four 7-Segment Digits
The 7-SEGMENT DIGITS are used to display the
time remaining in a cycle, vend price, error messages
and descriptive codes. During diagnostic testing or
manual programming of the control, these digits will
display descriptive codes and values (as described in
Entering the Manual Mode).

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70417701
8
Tumbler Operation
Start Up
When power is applied to the tumbler, the control
becomes active and will display its software version as
“SXX” (“XX” is the version number) for one second
and then the subversion as “XX” (if subversion isn’t
zero) for one second. If the control was not powered
down during a running cycle, it will enter the Ready
Mode.
Ready Mode
In Ready Mode, the default cycle LED is lit, and the
full vend price is displayed.
The user may select a different cycle, if desired. If the
vend price is not satisfied within 4.25 minutes, the
tumbler control will return to the Ready Mode. The
display will continue to show the remaining vend
needed to start a cycle.
Partial Vend Mode
The control enters this mode when part of the vend price
has been entered, but not enough vend is entered to
satisfy the vend price. The control will display the
remaining vend price needed to start the cycle and the
INSERT COINS/CARD LED is lit.
Additional Vend Mode
The control enters this mode if the cycle is changed to
a cycle that requires more money. If the vend price is
not satisfied within 60 seconds, the control will go
back to the first selection and the cycle will continue.
Start Mode
Vends may be satisfied by a coin drop, start pulses, or
by a third party card reader. If a coin drop is used, the
remaining vend price will decrease with each coin
entry. If start pulses are used, the remaining vend price
will decrease with each received pulse. Once the vend
is satisfied, the START LED will begin to flash and
signal will sound for ten seconds. If a third party card
reader is used, the START LED will begin to flash
when a valid cash card is entered into the reader.
When the START keypad is pressed, the tumbler will
start. The START LED will stop flashing and either
the DRYING LED or the COOL DOWN LED will be
lit. The display will change to show the remaining
cycle time on the display. The DRYING LED will be
lit during the heat portion of a heat cycle. The COOL
DOWN LED will be lit during the cool down portion
of a heat cycle and during an entire no heat cycle.
When a cycle is complete, the display will show “00”
until the door is opened, a key is pressed, a coin or
card is entered, or a start pulse is received. When any
of the above happens, the display will revert back to
the Ready Mode.
Entering Coins
Coins are entered to satisfy the programmed vend
price for a selected cycle. Coins may be entered before
selecting a cycle or during an active cycle. When coins
are entered during an active cycle, the time remaining
is increased by the amount programmed by the owner
(refer to Programming Control).
The owner may choose to add additional time for each
coin entered. If coins are entered for an active cycle
currently in the COOL DOWN Mode, coins entered
may push the cycle back into the DRYING Mode. The
maximum time for any cycle is 99 minutes.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Tumbler Operation
9
70417701
Entering Cards
A card is entered to satisfy the programmed vend price
for a selected cycle. The card may be entered before
selecting a cycle or during an active cycle. When the
card is entered during an active cycle and the START
keypad is pressed, the time remaining is increased by
the amount programmed by the owner. Refer to
Programming Control section.
The owner may choose to add additional time by
deducting a vend from the card or may require an
additional full vend price be deducted from the card. If
vend is deducted during an active heated cycle that is
currently in the COOL DOWN Mode, the additional
time added may put the cycle back into the DRYING
Mode. The maximum time for any cycle is 99 minutes.
Additional time cannot be added if it exceeds the
99 minute limit on a drying cycle.
Changing Active Cycles
In OPL machines, the active cycle may be changed at
any time during tumbler operation. In vend machines,
the active cycle may be changed in the first five
minutes for more expensive cycles. Cycles that are the
same price or less expensive can be chosen anytime.
The last five minutes of cycle can be changed with no
change to vend or time remaining.
Opening the Tumbler Door
Opening the tumbler door in a running cycle will
automatically stop the cycle. When the tumbler door is
opened, the DRYING LED or COOL DOWN LED is
turned off.
NOTE: When the door is opened during an active
cycle, the time will continue to count down and the
display will toggle every five seconds between
showing “door” and the remaining cycle time.
Once the tumbler door is closed, the START pad LED
flashes at one second intervals until the START pad is
pushed. Pressing the START pad will start or resume
the active cycle.
Signals
There are seven instances when a signal may sound
during tumbler operation. The owner may program the
signal to be turned on or off (refer to Programming
Control, option 9). These seven instances are listed
below:
1. End of Cycle Signal
By default, this signal is turned off. If turned on,
the signal will sound for three seconds at the end
of a cycle.
2. Keypad Depression Signal
The signal will sound for a quarter of a second
each time a keypad is pressed.
3. Coin Input/Start Pulse Input/Card Insertion
Signal
The signal will sound for a quarter of a second
each time a coin or start pulse is received or a
card is entered.
4. Remove Card Signal
This signal will sound one second on and one
second off while the control prompts for card
removal.
5. Start Pad Flashing Signal
This signal will sound one second on and one
second off when the START LED is flashing, for
the first ten seconds after vend has been satisfied.
6. Extended Tumble Mode Signal
This signal cannot be disabled. While in extended
tumble mode, the signal will sound one second
on and one second off for five seconds and then
continuously for five seconds before starting the
extended tumble.
7. Airflow Switch Errors Signal
This signal cannot be disabled. This signal
sounds if an EAF, EAF1 or EAF2 error is sensed
and will sound for 15 seconds or until error is
cleared.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Tumbler Operation
70417701
10
Extended Tumble Mode
The control enters Extended Tumble Mode twenty
minutes after a cycle has ended. The signal will sound
one second on and one second off for five seconds and
then continuously for five seconds before starting the
extended tumble, which lasts two minutes, every hour,
for up to 18 hours. Extended Tumble Mode ends with
any user interaction.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 11
70417701
Special Features
Programming Control
The control allows the tumbler owner to program the
control with the use of the keypad. Cycle and vend
information may be programmed, audit information
may be viewed and diagnostic tests may be run by
pressing keypad combinations.
For details on programming cycle and vend information,
refer to Programming Control.
Collecting Audit Information
The control will store audit information in its memory
that can be retrieved by pressing various keypad
combinations. The control will record coins entered,
total machine cycles, top-offs, and total start pulses.
For more information on the audit features, refer to
Collecting Audit Information.
NOTE: Additional audit information is retrievable
with an external device, a card reader or a
network. Refer to the appropriate instruction
manual.
Testing Machine and Control
Functions
Special programmable diagnostic features built into
the control allow the owner to run specific diagnostic
tests. By opening and closing the service door, with
coin vault closed, and then pressing various sequences
of keypads, the owner may retrieve and perform the
following tests:
• Control Software Version Number
• Service Door Opening Test
• Coin Vault Opening Test
• Coin Drop #1 Input Test
• Coin Drop #2 Input Test
• Start Pulse Test
• Tumbler-on Temperature Test
• Thermistor Temperature Test
• Configuration Display Tests
• Coin Header Present Status
• Airflow Switch Test
• Fan Motor Test
For detailed information on running diagnostic tests,
refer to Testing Machine and Electronic Control
Functions.
Rapid Advance Feature
This feature allows the user to quickly advance
through an active tumbler cycle or advance into a cycle
from the Ready Mode. This feature is useful when
tests must be performed immediately on a tumbler
currently in an active cycle. In this case, the user can
quickly advance through the cycle to the Ready Mode.
At this point, the user can perform the required tests
and then return the tumbler to the active cycle.
For detailed information on using the Rapid Advance
feature, refer to Rapid Advance Feature.
Clearing the Vend Feature
This feature allows the user to return the control back
to the Ready Mode if coins have been entered but the
full vend price has not yet been satisfied, while in
Partial Vend Mode.
For more information on using the Clear Vend feature,
refer to Clear Vend Feature.
Communications Mode
This feature allows the tumbler control to
communicate with an external device, a card reader or
a network. This allows the tumbler control to be
programmed and have its data read without using the
keypad.
For more detailed information on using the
Communications Mode feature, refer to
Communications Mode.
Coin Drop
The control will accept pulses from a single or dual
coin drop to satisfy vend price. Each coin drop will
have the ability to satisfy the vend.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Special Features
70417701
12
Start Pulse Operation
The control will accept pulses from optional payment
systems. The machine can be programmed to receive a
single start pulse or multiple start pulses, or the Start
Pulse Option can be turned off. The Start Pulse Mode
allows the machine to go from the “Ready” mode to
the “START” mode after single or multiple pulses are
received.
Service Door and Coin Vault
Openings
The control will capture the times and dates of the
openings of the Coin Vault and the Service Door. The
information is saved in memory. An open service door
combined with various keypad presses allows the
control to enter manual modes of operation if the
Break-In Alarm is not on. These modes include Manual
Programming, Audit Collection, Diagnostics, Rapid
Advance, and reset to factory defaults.
Special Vend
This feature allows the owner to program the control
to allow programmable vend prices for specific hours
and dates.
For details on programming Special Vend, refer to
Programming Control.
OPL Mode
This feature allows the user to start a cycle without
satisfying the vend price.
Press the START keypad to add time to the cycle.
Press the LOW TEMP and DELICATES keypads to
end the cycle.
For details on enabling OPL Mode, refer to
Programming Control.
Drop-Off Mode
This feature allows the owner to limit machine use to
an attendant without requiring vend. Starting the
machine will require the correct sequence of four
keypad presses as programmed by an external device
or a network.
Press the START keypad to add time to the cycle.
Press the LOW TEMP and DELICATES keypads to
end the cycle.
For details on enabling Drop-Off Mode, refer to
Programming Control.
Low Power/Auto-Shutdown Option
This feature allows the owner to program the control
to shut down or enter a low power consumption mode
based on programmable times and dates if either of
these options are enabled.
For details on programming the Low Power/Auto-
Shutdown option, refer to Programming Control.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 13
70417701
Opening Service Door
Stacked Tumbler
To open the service door, unlock it. Push down and in
on bottom of control so that the top of the control tilts
forward.
Stand Alone Tumbler
Unlock access panel over control and remove.
TMB1296R TMB1297R
1Control
Figure 2
Stacked Tumbler
25
C
123
SELECT
TEMP
INSERT
COIN
PUSH
START
123
SELECT
TEMP
INSERT
COIN
PUSH
START
TMB1296
R
25
C
1
SELECT
TEMP
PUSH
STAR
T
25
C
or
INSERT
CARD
INSERT
COINS
TMB1297R
Stand-Alone Tumbler
1

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70417701
14
Entering the Manual Mode
For programming, testing, and retrieving information
from the control, it is often necessary to enter the
Manual Mode by following the seven simple steps
below.
For an overview of entering the Manual Mode, refer to
the flowchart on the following page.
How to Enter the Manual Mode
1. If accessing Diagnostic Tests, be sure the tumbler
is in the Ready Mode before continuing to Step 2.
If the tumbler is in an active cycle, rapid advance
through the cycle. Refer to Rapid Advance
Feature. If coins or a card has been entered, refer
to Clear Vend Feature.
2. Open the service door. Refer to Opening the
Service Door.
NOTE: The coin vault switch must be closed to
enter the Manual Mode.
3. While pressing and holding the HIGH TEMP
keypad with one hand, press the MED TEMP
keypad with the other hand.
4. The display will show “rAPd”.
5. Press the LOW TEMP (∧) or the
DELICATES (∨) keypad to scroll through the
options until the desired option appears in the
display.
6. Press the START (enter) keypad to enter the
displayed mode.
7. To exit, press the MED TEMP (<) keypad. The
control will revert back to Ready Mode.
Manual Programming can only be turned on or off
with an external device or a network. Refer to the
appropriate instruction manual. Manual Rapid Advance
and Diagnostics can be turned on and off using an
external device by manual programming (refer to
options 30 and 31 of Programming Control), or with
the network.
By default, Manual Programming is turned “on”.
The manual features available in each group are as
follows (the menu displayed on the display in this
mode is in parentheses).
Rapid Advance (rAPd)
Manual Programming (Prog)
Manual Read Audit (AUdt)
Manual Reset (rSEt)
Diagnostic Tests (diAg)
If a manual parameter is turned off or unavailable (ex:
trying to enter diagnostics while a cycle is running),
the display will change from the selected feature to
“oFF”, an audio signal will sound for one second and
the features in the parameter cannot be entered. The
display will then return to the selected feature.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Entering the Manual Mode
15
70417701
Manual Mode : Enter by opening
and closing service door. Then
press HIGH TEMP and MED
TEMP keypads pads at same time.
“rAPd”
Rapid Advance
“Prog”
Manual
Programming
“AUdt”
Manual Read
Audit
“rSEt”
Manual Reset
“dIAg”
Diagnostic
Tes ts
Press the LOW TEMP or
the DELICATES keypad
to scroll through the
Manual Mode options.
Press the START keypad to
begin Rapid Advance cycle and
to advance through cycle steps.
Press the START keypad to
enter Manual Programming.
Refer to Manual
Programming flowchart.
“CyC”
Total machine cycles
“Coi1”
Total coins #1
“PLSE”
Total start pulses
“Coi2”
Total coins #2
Press the
LOW TEMP
or the
DELICATES
keypad to
scroll through
the Audit
options.
Press the
START keypad.
Press the
START keypad
to reset control.
Press the START keypad to
enter Diagnostic Tests. Refer to
Diagnostic Tests flowchart.
TMB1298R
Press the START (enter)
keypad to read audit.
Press the START (enter)
keypad to read audit.
Press the START (enter)
keypad to read audit.
Press the START (enter)
keypad to read audit.
“C1to”
Total coin 1 top-offs
“Pto”
Total start pulse/card
reader top-offs
“C2to”
Total coin 2 top-offs
Press the START (enter)
keypad to read audit.
Press the START (enter)
keypad to read audit.
Press the START (enter)
keypad to read audit.
To enter a programming
option, press the START
keypad. To exit, press
the MED TEMP keypad.
TMB1298R

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70417701
16
Programming Control
What Can Be Programmed?
This feature allows the owner to program cycle
parameters, standard vend pricing, special vends, and
other features by using the keypads. The control must
have the Manual Programming Mode enabled, which is
the factory default. This mode can only be turned OFF
and ON by using an external device or a network.
Refer to this section when programming the control.
This section offers a detailed description of all available
programmable options.
Each description includes instructions on when and
why the option might be used and, more importantly,
how to program the option.
For an overview of the programming organization,
refer to the flowcharts on the following pages.
For more advanced users, a quick reference list of the
options available through the programming mode is
located on this page.
NOTE: The codes in the Option column of the
Programmable Options List are what will show in
the display when that option is selected.
Programmable Options Available
Option
Number
Option
Display Description Default Value Value Range
1“AtSH” Heat Vend Price 25 0-65535
2“dEn1” Coin #1 Value 25 1-65535
3“dEn2” Coin #2 Value 100 1-65535
4“PLSE” Start Pulse Value 25 1-65535
5“PLSn” Start Pulse Mode 128 128 (on – single pulse), 192 (on –
multiple pulses) or oFF
6“AtyP” Available Type 0 0 (Ready Mode), 1 (Ready Mode,
Partial Vend Mode), 2 (Ready Mode,
End of Cycle Mode) or 3 (Ready
Mode, End of Cycle Mode, Partial
Vend Mo de)
7“dCyC” Default Cycle 4 1 (High Temp), 2 (Low Temp), 3 (No
Heat), 4 (Med Temp), or 5 (Delicates)
8“oPL” OPL Mode oFF on/oFF
9“Aud” Audio 29 0-31
10 “CArd” Card Reader Display Control oFF on/oFF
11 “Err-”Errors ——
a“CEr-” Coin Error Parameters — —
1“CEr1” Coin Error on on/oFF
2“CEr2” Coin Error Penalty oFF on/oFF
3“CEr3” Coin Drops Header Present Error on on/oFF
12 “toP-” Top-Off Data ——
a“toP1” Top-Off on on/oFF
b“toP2” Coin 1 Top-Off Time Minutes 5 1-99
c“toP3” Coin 1 Top-Off Time Seconds 0 0-59
d“toP4” Coin 2 Top-Off Time Minutes 20 1-99
e“toP5” Coin 2 Top-Off Time Seconds 0 0-59
13 “CyC-”CycleTime ——
a“CyC1” Heat Cycle Time Minutes 5 1-99
b“CyC2” Heat Cycle Time Seconds 0 0-59
c“CyC3” No Heat Cycle Time Minutes 5 1-99

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Programming Control
17
70417701
d“CyC4” No Heat Cycle Time Seconds 0 0-59
14 “Cdt-” Cooldown Time ——
a“Cdt1” High Temp Cooldown Time 1 1-15
b“Cdt2” Medium Temp Cooldown Time 1 1-15
c“Cdt3” Low Temp Cooldown Time 1 1-15
d“Cdt4” Delicates Temp Cooldown Time 1 1-15
15 “tEP-” Temperature ——
a“tEP1” High Temperature 190°F/88°C 100°-190°F/38°-88°C
b“tEP2” Medium Temperature 180°F/82°C 100°-190°F/38°-88°C
c“tEP3” Low Temperature 160°F/72°C 100°-190°F/38°-88°C
d“tEP4” Delicates Temperature 130°F/54°C 100°-190°F/38°-88°C
16 “t FC” Temperature
(Fahrenheit/Celsius)
0 0 (Fahrenheit) / 1 (Celsius)
17 “AIg” Auto Ignite Retry 3 0-5
18 “AtSn” No Heat Vend Price 25 0-65535
19 “rtC-”RealTimeClock ——
a“rtC1” Minutes — 0-59
b“rtC2” Hours — 0-23
c“rtC3”Day — 1-7
d“rtC4”Date — 1-31
e“rtC5” Month — 1-12
f“rtC6” Year — 0-99
g“rtC7” Daylight Savings on on/oFF
20 “SPA-” Special Vend A Data ——
a“SA01” Days Enable oFF on/oFF
b“SA02”StartHour 0 0-23
c“SA03” Start Minute 0 0-59
d“SA04” Length in Hours 0 0-24
e“SA05” Start Month 0 0/1-12
f“SA06” Start Date 0 0/1-31
g“SA07” Start Year 0 0-99
h“
SA08” End Month 0 0/1-12
i“SA09” End Date 0 0/1-31
j“SA10” End Year 0 0-99
k“SA11” Heat Price 0 0-65535
l“SA12” No Heat Price 0 0-65535
m“SA13” Heat Time Minutes 1 1-99
n“SA14” No Heat Time Minutes 1 1-99
o“SA15” Coin #1 Top-Off Time Minutes 1 1-99
p“SA16” Coin #2 Top-Off Time Minutes 1 1-99
21 “SPb-” Special Vend B Days Enable oFF on/oFF
22 “SPC-” Special Vend C Days Enable oFF on/oFF
23 “SPd-” Special Vend D Days Enable oFF on/oFF
24 “droP” Drop Off Mode oFF on/oFF
Option
Number
Option
Display Description Default Value Value Range

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Programming Control
70417701
18
25 “LPSA” Low Power/Auto Shutdown A
Days Enable
oFF on/oFF
26 “LPSb” Low Power/Auto Shutdown B
Days Enable
oFF on/oFF
27 “LPSC” Low Power/Auto Shutdown C
Days Enable
oFF on/oFF
28 “LPSd” Low Power/Auto Shutdown D
Days Enable
oFF on/oFF
29 “PFr” Power Fail Reset oFF on (133 [5 minutes] - 255
[127 minutes])/oFF
30 “IrA” IR Access on on/oFF
31 “rAEn” Manual Rapid Advance on on/oFF
32 “dAEn” Manual Diagnostics on on/oFF
33 “PtEn” Production Test Cycle on on/oFF
Option
Number
Option
Display Description Default Value Value Range
