Alliance Laundry Systems UWL035K12 Operating instructions

www.alliancelaundry.com
PHM1414C
PHM1414C
Part No. F8301401ENR4
November 2014
Washer-Extractor
Pocket Hardmount
Refer to page 7 for Model Numbers
Troubleshooting

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
© Copyright 2014, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
F8301401ENR4 1
Table of
Contents
Safety Information.............................................................................. 2
Explanation of Safety Messages........................................................... 2
General Safety Precautions................................................................... 2
Important Safety Instructions ............................................................... 3
Safety Decals ........................................................................................ 5
Operator Safety..................................................................................... 5
Introduction......................................................................................... 6
Customer Service.................................................................................. 6
Serial Plate Location............................................................................. 6
Model Identification ............................................................................. 7
Theory of Operation ........................................................................... 8
Starting the Machine............................................................................. 8
Fill......................................................................................................... 8
Supply ................................................................................................... 8
Wash ..................................................................................................... 8
Drain ..................................................................................................... 8
Extract................................................................................................... 8
Troubleshooting .................................................................................. 9
1. Machine Will Not Start Cycle........................................................ 10
2. Door Will Not Unlock at End of the Cycle.................................... 12
3. No External Supplies ..................................................................... 14
4. Excessive Vibration and/or Noise During Spin
(Drawing 1 of 2)............................................................................. 16
Excessive Vibration and/or Noise During Spin
(Drawing 2 of 2)............................................................................. 17
5. Machine Does Not Fill with Water ................................................ 18
6. No Display ..................................................................................... 20
7. No Outputs ..................................................................................... 22
8. Excessive Cycle Time.................................................................... 24
9. No Keypad Function ...................................................................... 25
10. Abnormal Operation ...................................................................... 26
11. No High Extract ............................................................................. 28
12. No Extract (F and V-speed Models) .............................................. 29
13. No Extract (2 Speed Models)......................................................... 31
14. No Basket Rotation (2 Speed Models)........................................... 33
15. No Rotation with Drive Fault......................................................... 35
16. No Rotation without Drive Fault ................................................... 36
17. EFS Error – Fixed Speed Models .................................................. 37
18. EFS Error – Variable Speed Models.............................................. 39
19. Heat Error (Machines with Auxiliary Heat Only) ......................... 41
20. Control Will Not Allow PDA to Download
a Machine Cycle it is Currently Running....................................... 43

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8301401ENR4
2
Safety Information
Explanation of Safety Messages
Throughout this manual and on machine decals, you
will find precautionary statements (“DANGER,”
“WARNING,” and “CAUTION”) followed by specific
instructions. These precautions are intended for the
personal safety of the operator, user, servicer, and
those maintaining the machine.
Additional precautionary statements (“IMPORTANT”
and “NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used
to inform the reader of specific procedures where
minor machine damage will occur if the procedure
is not followed.
NOTE: The word “NOTE” is used to communicate
installation, operation, maintenance or servicing
information that is important but not hazard
related.
General Safety Precautions
In the interest of safety, some general precautions
relating to the operation of this machine follow.
Danger indicates the presence of a hazard
that will cause severe personal injury,
death or substantial property damage if
the danger is ignored.
DANGER
Warning indicates the presence of a
hazard that can cause severe personal
injury, death or substantial property
damage if the warning is ignored.
WARNING
Caution indicates the presence of a
hazard that will or can cause minor
personal injury or property damage if the
caution is ignored.
CAUTION
• Failure to install, maintain and/or
operate this product according to the
manufacturer’s instructions may result
in conditions which can produce
serious injury, death and/or property
damage.
• Do not repair or replace any part of the
product or attempt any servicing unless
specifically recommended or published
in this Service Manual and unless you
understand and have the skills to carry
out the servicing.
• Whenever ground wires are removed
during servicing, these ground wires
must be reconnected to ensure that the
product is properly grounded and to
reduce the risk of fire, electric shock,
serious injury or death.
W006R2
WARNING
To reduce the risk of electric shock, fire,
explosion, serious injury or death:
• Disconnect electric power to the
washer-extractor before servicing.
• Never start the washer-extractor with
any guards/panels removed.
• Whenever ground wires are removed
during servicing, these ground wires
must be reconnected to ensure that the
washer-extractor is properly grounded.
W460
WARNING
Repairs that are made to your products
by unqualified persons can result in
hazards due to improper assembly or
adjustments subjecting you, or the
inexperienced person making such
repairs, to the risk of serious injury,
electrical shock, or death.
W007
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
3
F8301401ENR4
Always contact your dealer, distributor, service agent
or the manufacturer about any problems or conditions
you do not understand.
Important Safety Instructions
1. Read all instructions before using the washer.
2. Refer to the GROUNDING INSTRUCTIONS in
the INSTALLATION manual (supplied with your
washer) for the proper grounding of the washer.
3. Do not wash textiles that have been previously
cleaned in, washed in, soaked in or spotted with
gasoline, kerosene, waxes, cooking oils, dry-
cleaning solvents or other flammable or
explosive substances. They give off vapors that
could ignite or explode.
4. Do not add gasoline, dry-cleaning solvents or
other flammable or explosive substances to the
wash water. These substances give off vapors that
could ignite or explode.
5. Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been
used for two weeks or more. HYDROGEN GAS
IS EXPLOSIVE. If the hot water system has not
been used for such a period, before using a
washer, turn on all hot water faucets and let the
water flow from each for several minutes. This
will release any accumulated hydrogen gas. The
gas is flammable. Do not smoke or use an open
flame during this time.
6. Do not allow children to play on or in a washer.
Close supervision of children is necessary when
the washer is used near children.
7. Before the washer is removed from service or
discarded, remove the door to the washing
compartment.
8. Do not reach into the washer if the wash drum is
moving.
9. Do not install or store the washer where it will be
exposed to water and/or weather.
10. Do not tamper with the controls.
11. Do not repair or replace any part of the washer or
attempt any servicing unless specifically
recommended in the user-maintenance
instructions or in published user-repair
instructions that the user understands and has the
skills to carry out.
12. To reduce the risk of an electrical shock or fire,
DO NOT use an extension cord or an adapter to
connect the washer to an electrical power source.
13. Use the washer only for its intended purpose,
washing clothes.
14. Never wash machine parts or automotive parts in
the machine. This could result in serious damage
to the basket.
15. ALWAYS disconnect the washer from its
electrical supply before attempting any service.
16. Install the washer according to the
INSTALLATION INSTRUCTIONS. All
connections for water, drain, electrical power and
grounding must comply with local codes and,
when required, be made by licensed personnel.
17. To reduce the risk of fire, textiles which have
traces of any flammable substances such as
vegetable oil, cooking oil, machine oil,
flammable chemicals, thinner, etc. or anything
containing wax or chemicals such as in mops or
cleaning cloths, must not be put into the washer.
These flammable substances may cause the
fabric to ignite.
18. Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or product.
19. Keep the washer in good condition. Bumping or
dropping the washer can damage its safety
features. If this occurs, have the washer checked
by a qualified service person.
If you or an unqualified person perform
service on your product, you must
assume the responsibility for any
personal injury or property damage which
may result. The manufacturer will not be
responsible for any injury or property
damage arising from improper service
and/or service procedures.
W008
WARNING
To reduce the risk of fire, electric shock,
serious injury or death to persons when
using your washer, follow these basic
precautions:
W023
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
F8301401ENR4
4
20. If the supply cord is damaged, it must be replaced
by a special cord or assembly available from the
manufacturer or its service agent.
21. Be sure that water connections have a shut-off
valve and that fill hose connections are tight.
CLOSE the shut-off valves at the end of each
wash day.
22. The loading door MUST BE CLOSED any time
the washer is to fill, tumble or spin. DO NOT
bypass the loading door switch and permit the
washer to operate with the loading door open.
23. Always read and follow the manufacturer’s
instructions on packages of laundry and cleaning
aids. Heed all warnings and precautions. To
reduce the risk of poisoning or chemical burns,
keep them out of the reach of children at all times
(preferably in a locked cabinet).
24. Always follow the fabric care instructions
supplied by the textile manufacturer.
25. Never operate the washer with any guards and/or
panels removed.
26. DO NOT operate the washer with missing or
broken parts.
27. DO NOT bypass any safety devices.
28. Failure to install, maintain and/or operate this
washer according to the manufacturer's
instructions may result in conditions that can
produce bodily injury and/or property damage.
NOTE: The WARNING and IMPORTANT
SAFETY INSTRUCTIONS appearing in this
manual are not meant to cover all possible
conditions and situations that may occur. Common
sense, caution and care must be exercised when
installing, maintaining and operating the washer.
Any problems or conditions not understood should be
reported to the dealer, distributor, service agent or the
manufacturer.
IMPORTANT: Ensure that the recommended
clearances for inspection and maintenance are
provided. Never allow the inspection and
maintenance space to be blocked.
This machine must be installed, adjusted,
and serviced by qualified electrical
maintenance personnel familiar with the
construction and operation of this type of
machinery. They must also be familiar
with the potential hazards involved.
Failure to observe this warning may result
in personal injury and/or equipment
damage, and may void the warranty.
SW004
WARNING
Install the machine on a level floor of
sufficient strength. Failure to do so may
result in conditions which can produce
serious injury, death and/or property
damage.
W703
WARNING
Be careful around the open door,
particularly when loading from a level
below the door. Impact with door edges
can cause personal injury.
SW025
CAUTION
Never touch internal or external steam
pipes, connections, or components.
These surfaces can be extremely hot and
will cause severe burns. The steam must
be turned off and the pipe, connections,
and components allowed to cool before
the pipe can be touched.
SW014
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
5
F8301401ENR4
Safety Decals
Safety decals appear at crucial locations on the
machine. Failure to maintain legible safety decals
could result in injury to the operator or service
technician.
To provide personal safety and keep the machine in
proper working order, follow all maintenance and
safety procedures presented in this manual. If
questions regarding safety arise, contact the
manufacturer immediately.
Use manufacturer-authorized spare parts to avoid
safety hazards.
Operator Safety
To ensure the safety of machine operators, the
following maintenance checks must be performed
daily:
1. Prior to operating the machine, verify that all
warning signs are present and legible. Missing or
illegible signs must be replaced immediately.
Make certain that spares are available.
2. Check door interlock before starting operation of
the machine:
a. Attempt to start the machine with the door
open. The machine should not start with the
door open.
b. Close the door without locking it and attempt
to start the machine. The machine should not
start with the door unlocked.
c. Close and lock the door and start a cycle.
Attempt to open the door while the cycle is in
progress. The door should not open.
If the door lock and interlock are not functioning
properly, call a service technician.
3. Do not attempt to operate the machine if any of
the following conditions are present:
a. The door does not remain securely locked
during the entire cycle.
b. Excessively high water level is evident.
c. Machine is not connected to a properly
grounded circuit.
Do not bypass any safety devices in the machine.
NEVER insert hands or objects into
basket until it has completely stopped.
Doing so could result in serious injury.
SW012
WARNING
Never operate the machine with a
bypassed or disconnected balance
system. Operating the machine with
severe out-of-balance loads could result
in personal injury and serious equipment
damage.
SW039
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8301401ENR4
6
Introduction
Customer Service
Alliance Laundry Systems is not responsible for
personal injury or property damage resulting from
improper service. Review all service information
before beginning repairs.
If literature or replacement parts are required, contact
the source from whom the machine was purchased or
contact Alliance Laundry Systems at [phone]
for the name of the nearest authorized parts distributor.
For technical assistance, call either of these numbers
[phone] Ripon, Wisconsin or [phone]
Wevelgem, Belgium.
Serial Plate Location
When calling or writing about your product, be sure to
mention model and serial numbers. Model and serial
numbers are located on serial plate(s) as shown.
PHM2102S

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
7
F8301401ENR4
Model Identification
Information in this manual is applicable to these
washer-extractor models:
UWL035K12
UWL035K1L
UWL035K1M
UWL060K12
UWL060K1L
UWL060K1M
UWL080K1M
UWL100K1M
UWL125K1M
UWN035K12
UWN035K1L
UWN035K1M
UWN060K12
UWN060K1L
UWN060K1M
UWN080K1M
UWN100K1M
UWN125K1M
UWU035K12
UWU035K1L
UWU035K1M
UWU060K12
UWU060K1L
UWU060K1M
UWU080K1M
UWU100K1M
UWU125K1M

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8301401ENR4
8
Theory of Operation
Starting the Machine
The door lock will not allow a cycle to be started until
the door has been closed.
Fill
The operator selects a cycle and starts the machine.
Water enters the machine through water valves that are
controlled by the microcomputer. As water fills the
basket, a column of air is trapped in a pressure bulb
and hose. The air pressure continues to increase as the
basket fills with water. When the desired water level is
reached, the water level switch triggers the
microcomputer and the water valves turn off.
On designs 1 and 2, vacuum breaker installed in the
inlet plumbing or a shell overflow and air gap prevents
the backflow of water.
Supply
The operator can either connect external liquid
supplies to the machine or fill the supply dispenser
with liquid or dry supplies. The supply dispenser's
nozzles flush the compartments with water at the
appropriate times throughout a cycle.
Wash
The basket includes ribs that lift the laundry from the
wash water. The laundry then tumbles back into the
bath.
1 dual-speed motor drives the basket’s shaft with a V-
belt.
UW washer-extractors use two flange-type bearings
that are bolted to the frame.
Drain
UW washer-extractors use a normally open gravity-
type drain system. No pump is used. When the drain
valve opens, the perforated basket allows water to
drain from it.
In the event of a power failure, the drain valve will
open automatically and the machine will drain.
This model washer-extractor includes a single drain
valve.
Extract
A final high-speed extract step removes water from the
load, which maximizes drying efficiency.
The door lock system will not allow the door to be
opened until the cycle has finished.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 9
F8301401ENR4
Troubleshooting
To reduce the risk of electrical shock, fire, explosion, serious injury or death:
• Disconnect electrical power to the washer-extractor before servicing it.
• Close the gas shut-off valve to the washer-extractor (when applicable) before servicing it.
• Never start the washer-extractor with any guards/panels removed.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the washer-extractor is properly grounded.
W461R1
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
F8301401ENR4
10
1. Machine Will Not Start Cycle
PHM2119S
Machine Will Not Start Cycle
Is door handle
fully engaged? Fully latch door.
No
Is magnet
present on door?
Yes
Replace magnet.
No
Is
J15 plug fully
engaged?
Yes
Firmly seat plug.
No
Is there 24VDC
between H6-1 and
H6-5 on AP1 Output
Board?
Yes
Door circuit is open. Diagnose and repair circuit.
Yes
Replace AP1 Output Board.
No
A
NOTE: When the door is both closed and locked,
the LOCK LED will be lit and the START pad
will be flashing.
Is door
lock switch
activated? Adjust/tighten switch.
No
Yes
PHM2119S

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
11
F8301401ENR4
Machine Will Not Start Cycle
NOTE: Refer to the wiring diagram supplied with
your machine.
PHM2103S
PHM2103S
A

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
F8301401ENR4
12
2. Door Will Not Unlock at End of the Cycle
PHM2104
Door Will Not Unlock at End of the Cycle When Door Unlock Button is Pressed
Is
there voltage
(220 VAC) from H2-1 to
when the unlock button
is pressed?
Check solenoid for 220 V and mechanical bind.
If 220 VAC is present, replace solenoid.
If not, trace wiring and check for break.
Yes
Is the
machine still
waiting for basket
coast-down?
Unless the machine is rotating, the
control should allow the door to open.
Yes
Is there water in the
machine?
No
Troubleshoot the drain.
Yes
Troubleshoot the AP1 Output Board.
No
No
A
H2-12 on the AP1 output board
PHM2104S

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
13
F8301401ENR4
Door Will Not Unlock at End of the Cycle
NOTE: Refer to the wiring diagram supplied with
your machine.
A
PHM2105S
PHM2105S

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
F8301401ENR4
14
3. No External Supplies
PHM2106S
No External Supplies
Are the supplies
programmed? Correct programming.
No
Is the ribbon cable between H10
on AP1 Output Board and RB1
on AP4 Auxiliary Output Supply
Board connected and in good
shape?
Re-connect/replace AP4 board as necessary.
Yes
No
Ensure external supply wiring is correct. Refer to the No
External Supplies Schematic.
Yes
B
A
PHM2106S

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
15
F8301401ENR4
No External Supplies
NOTE: Refer to the wiring diagram supplied with
your machine.
PHM2105S
A
B
PHM2105S

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
F8301401ENR4
16
4. Excessive Vibration and/or Noise During Spin (Drawing 1 of 2)
Excessive Vibration and/or Noise During Spin
Is the load of proper
size? Add or remove items as needed to ensure load size is correct.
No
Does the wash load
contain the proper
mix of laundry
items?
Yes
Add or remove items as needed to ensure proper mix of
items (e.g. do not wash towels and sheets together).
No
Are the anchor bolts
and nuts properly
torqued?
Yes
Tighten all anchor bolts and nuts to correct torque
specifications. Refer to Installation Manual for
specifications.
No
Are the anchor bolts
and nuts the correct
size and grade?
Yes
Replace all anchor bolts and nuts with correct size and
grade. Refer to Installation Manual for specifications.
No
Are all panels on
machine? Replace all panels.
No
Yes
Yes
continued on
next page
CHM465S-a

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
17
F8301401ENR4
Excessive Vibration and/or Noise During Spin (Drawing 2 of 2)
PHM2108S
Is the washer-extractor
anchored to a flat, level
surface with the proper
depth of concrete?
Is the washer-
extractor grouted
properly?
Properly grout washer-extractor. Refer to
Installation Manual for specifications.
No
Yes
Remove and re-install washer-extractor correctly.
Refer to Installation Manual for specifications.
No
Are the front and rear
bearings making
excessive noise?
Yes
Replace/reset the bearings as needed.
Replace/reset the bearings as needed.
Yes
Lift up on the basket at the
front of the tub. Is there any
up and down play that would
indicate bearing wear?
No
Yes
continued from
previous page
Are motor and drive
pulleys aligned and
on tight?
No
Align/tighten pulleys as needed.
No
PHM2108S

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
F8301401ENR4
18
5. Machine Does Not Fill with Water
PHM2109S
Machine Does Not Fill With Water
Is water turned
on? Turn water on.
No
Is there a fill step
programmed?
Yes
Add/edit a fill step in programming.
No
Is the J13 plug
fully inserted? Fully insert J13 plug.
No
Is there 220V
present at H2-2 to
H2-14 and H2-2 to
H2-15 on AP1
output board?
Yes
Re-check for voltage at valves and ensure wiring and Molex
plugs are intact.
Refer to “No Outputs” flowchart.
No
A
B
No
Are fill valve
inlet screens
plugged?
Clean inlet screens and re-test.
Yes
Yes
No
Is there 220V present at
the hot and cold valves
and are any Fill LEDs (HF
or CF) lit on the AP1
Output Board?
Yes
Repair/Replace defective valves.
Yes
PHM2109S
