Allied Telesis AT-MC1004 User manual

AT-MC1004
AT-MC1005/1
AT-MC1005/2
AT-MC1005/3
AT-MC1005/4
Gigabit Ethernet Media Converters
Installation Guide
PN 613-50163-00 Rev B

Copyright 2002 Allied Telesyn, Inc.
960 Stewart Drive Suite B, Sunnyvale CA USA 94085
All rights reserved. No part of this publication may be reproduced without prior written
permission from Allied Telesyn, Inc.
Ethernet is a registered trademark of Xerox Corporation. All other product names,
company names, logos or other designations mentioned herein are trademarks or
registered trademarks of their respective owners.
Allied Telesyn, Inc. reserves the right to make changes in specifications and other
information contained in this document without prior written notice. The information
provided herein is subject to change without notice. In no event shall Allied Telesyn,
Inc. be liable for any incidental, special, indirect, or consequential damages whatsoever,
including but not limited to lost profits, arising out of or related to this manual or the
information contained herein, even if Allied Telesyn, Inc. has been advised of, known, or
should have known, the possibility of such damages.

iii
Electrical Safety and Emission Compliance
Statement
Standards: This product meets the following standards.
U.S. Federal Communications Commission
Declaration Of Conformity
Manufacture Name: Allied Telesyn, Inc.
Manufacture Address: 960 Stewart Drive, Suite B
Sunnyvale, CA 94085 USA
Manufacture Telephone: [phone]
Declares that the product: Gigabit Ethernet Media
Converters
Model Numbers: AT-MC1004, AT-MC1005/1,
AT-MC1005/2, AT-MC1005/3,
AT-MC1005/4
This product complies with FCC Part 15B, Class B Limits:
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device must not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Radiated Energy
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device pursuant to Part 15 of FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with instructions, may cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on. The user is encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and the receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Changes and modifications not expressly approved by the manufacturer
or registrant of this equipment can void your authority to operate this
equipment under Federal Communications Commission rules.
Industry Canada
This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du
Règlement sur le matériel brouilleur du Canada.

iv
RFI Emission EN55022 Class B !1
Warning: In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate
measures. !2
Immunity EN55024 !3
Electrical Safety TUV-EN60950,
UL1950, CSA 950 !4
Laser EN60825 !5
Important: Appendix B contains translated safety statements for installing
this equipment. When you see the !, go to Appendix B for the translated
safety statement in your language.
Wichtig: Anhang B enthält übersetzte Sicherheitshinweise für die
Installation dieses Geräts. Wenn Sie !sehen, schlagen Sie in Anhang B
den übersetzten Sicherheitshinweis in Ihrer Sprache nach.
Vigtigt: Tillæg B indeholder oversatte sikkerhedsadvarsler, der vedrører
installation af dette udstyr. Når De ser symbolet !, skal De slå op i tillæg
B og finde de oversatte sikkerhedsadvarsler i Deres eget sprog.
Belangrijk: Appendix B bevat vertaalde veiligheidsopmerkingen voor het
installeren van deze apparatuur. Wanneer u de !ziet, raadpleeg
Appendix B voor vertaalde veiligheidsinstructies in uw taal.
Important: L'annexe B contient les instructions de sécurité relatives à
l'installation de cet équipement. Lorsque vous voyez le symbole !,
reportez-vous à l'annexe B pour consulter la traduction de ces instructions
dans votre langue.
Tärkeää: Liite B sisältää tämän laitteen asentamiseen liittyvät käännetyt
turvaohjeet. Kun näet !-symbolin, katso käännettyä turvaohjetta
liitteestä B.
Importante: l’Appendice B contiene avvisi di sicurezza tradotti per
l’installazione di questa apparecchiatura. Il simbolo !,indicadiconsultare
l’Appendice B per l’avviso di sicurezza nella propria lingua.
Viktig: TilleggBinneholderoversattsikkerhetsinformasjonforinstallering
av dette utstyret. Når du ser !, åpner du til Tillegg B for å finne den
oversatte sikkerhetsinformasjonen på ønsket språk.
Importante: O Anexo B contém advertências de segurança traduzidas para
instalar este equipamento. Quando vir o símbolo !, leia a advertência de
segurança traduzida no seu idioma no Anexo B.
Importante: El Apéndice B contiene mensajes de seguridad traducidos
para la instalación de este equipo. Cuando vea el símbolo !, vaya al
Apéndice B para ver el mensaje de seguridad traducido a su idioma.
Obs! Bilaga B innehåller översatta säkerhetsmeddelanden avseende
installationen av denna utrustning. När du ser !, skall du gå till Bilaga B
för att läsa det översatta säkerhetsmeddelandet på ditt språk.

v
Table of Contents
Electrical Safety and Emission Compliance Statement.......................iii
Welcome to Allied Telesyn ..........................................................................vii
Where to Find Web-based Guides ...................................................................vii
Document Conventions ....................................................................................vii
Contacting Allied Telesyn Technical Support................................................viii
Online Support.........................................................................................viii
Telephone Support ...................................................................................viii
E-mail Support.........................................................................................viii
Returning Products ...........................................................................................ix
FTP Server.........................................................................................................ix
For Sales or Corporate Information .................................................................ix
Tell Us What You Think ....................................................................................x
Chapter 1
Overview...........................................................................................................1
Key Features.......................................................................................................3
Fiber Optic Port...........................................................................................3
Twisted Pair Port ........................................................................................3
Status LEDs ................................................................................................4
Half- and Full-Duplex Mode.......................................................................4
External AC/DC Power Adapter.................................................................5
Network Topologies............................................................................................6
Standalone Topology...................................................................................6
Back-to-Back Topology................................................................................7
Chapter 2
Installing the Media Converter ...................................................................9
Verifying the Package Contents........................................................................9
Planning the Installation............................................................................9
Selecting a Site..........................................................................................10
Reviewing Safety Guidelines....................................................................11
Installing the Media Converter .......................................................................12
Warranty Registration.....................................................................................13

Table of Contents
vi
Chapter 3
Troubleshooting ............................................................................................15
Appendix A
Technical Specifications .............................................................................17
Physical.............................................................................................................17
Temperature .....................................................................................................17
Electrical Rating...............................................................................................17
Agency Certifications........................................................................................17
Fiber Optic Port Specifications........................................................................18
Pinout Assignments..........................................................................................19
Appendix B
Translated Safety Statements....................................................................21

vii
This guide contains instructions on how to install the AT-MC1004 and the
AT-MC1005/x Series Gigabit Ethernet Media Converters.
Where to Find Web-based Guides
The Allied Telesyn web site at www.alliedtelesyn.com provides you with an
easy way to access the most recent documentation and technical information
for all of our products. All web-based documents relating to this product and
other Allied Telesyn products, can be downloaded from the web site in PDF
format.
Document Conventions
This guide uses the following conventions:
Note
Notes provide additional information.
Caution
Cautions indicate that performing or omitting a specific action may
result in equipment damage or loss of data.
Warning
Warnings indicate that performing or omitting a specific action may
result in bodily injury.
Welcome to Allied Telesyn

viii
Contacting Allied Telesyn Technical Support
You can contact Allied Teleysn technical support online or by telephone or
e-mail.
Online Support
You can request technical support online accessing the Knowledge Base at
http://kb.alliedtelesyn.com. You can use the Knowledge Base to submit
questions to our technical support staff and review answers to previously
asked questions.
Telephone Support
For technical support by telephone, contact Allied Telesyn at one of the
following locations:
E-mail Support
Latin America, Mexico, Puerto Rico, Caribbean, and Virgin Islands
[e-mail]
Europe
[e-mail]
Americas
United States, Canada, Mexico,
Central America, South America
Tel: [phone]
Germany
Switzerland, Austria, Eastern Europe
Tel: [phone]
Asia
Singapore, Taiwan, Thailand,
Malaysia, Indonesia, Korea,
Philippines, China,
India, Hong Kong
Tel: [phone]
Italy
Spain, Portugal, Greece, Turkey, Israel
Tel: [phone]
Australia
Tel: [phone] Japan Tel: [phone]
France
Belgium, Luxembourg,
The Netherlands, Middle East, Africa
Tel: [phone]
United Kingdom
Denmark, Norway, Sweden, Finland
Tel: [phone]

AT-MC1004 and AT-MC1005/x Series Installation Guide
ix
Returning Products
Products for return or repair must first be assigned a Return Materials
Authorization (RMA) number. A product sent to Allied Telesyn without a
RMA number will be returned to the sender at the sender’s expense.
To obtain an RMA number, contact Allied Telesyn’s Technical Support at one
of the following locations:
FTP Server
If you need management software for an Allied Telesyn managed device and
you know the file name of the software, you can download the software by
connecting directly to our FTP server at ftp.alliedtelesyn.com. At login,
enter ‘anonymous’ as the user name and your e-mail address for the password.
For Sales or Corporate Information
You can contact Allied Telesyn for sales or corporate information at the
location below:
Allied Teleyn, Inc.
19800 North Creek Parkway, Suite 200
Bothell, WA 98011
Tel: [phone]
Fax: [phone]
North America
Toll-free: 1-800-762-1664
Fax: [phone]
Europe, Africa, and the Middle
East
Tel: [phone]
Fax: [phone]
Latin America, the Caribbean, and
Virgin Islands
Tel: international code + 425-481-3852
Fax: international code + 425-481-3895
Puerto Rico
Tel: [phone], ext 3852
or
1-800-424-4284, ext 3852
Mexico
Toll-free: 800-424-5012, ext 3852
Fax: international code + 425-481-3895
Asia and Southeast Asia
Tel: [phone]
Fax: [phone]
Australia
Toll-free: 1-800-000-880
Fax: [phone]
New Zealand
Toll-free: 0800-45-5782

x
Tell Us What You Think
If you have any comments or suggestions on how we might improve this or
other Allied Telesyn documents, please fill out the General Enquiry Form at
online. This form can be accessed by selecting “Contact Us” from
www.alliedtelesyn.com.

1
Chapter 1
Overview
The AT-MC1004 and AT-MC1005/x Series Gigabit Ethernet Media Converters
are designed to extend the distance of your network by converting Gigabit
Ethernet data between twisted pair cabling and either multimode or single-
mode fiber optic cabling.
The AT-MC1004 media converter features a 1000Base-SX fiber optic port and
a 1000Base-T twisted pair port. Thefiber optic port has an SC connector and a
maximum operating distance of 550 meters (1,804 feet). The twisted pair port
has an RJ-45 connector and a maximum operating distance of 100 meters (328
feet).
The AT-MC1005/x media converters feature a 1000Base-LX fiber optic port
and a 1000Base-T twisted pair port. The fiber optic port has an SC connector
and a maximum operating distance of 10 kilometers (6.2 miles) to 70
kilometers (43.4 miles), depending on the model. The twisted pair port has an
RJ-45 connector and a maximum operating distance of 100 meters (328 feet).
These units operate at 1000 Mbps and feature full-duplex operation.
The AT-MC1004 and AT-MC1005/x Series Gigabit Media Converters can be
used on a desktop or in an AT-MCR12 chassis. These units are easy to install
and do not require any software configuration or management. Figure 1
illustrates an AT-MC1004 media converter.
Figure 1 AT-MC1004 Gigabit Ethernet Media Converter
1000Base-SX 1000Base-T
REC
LNK
REC
LNK
TX MM RX
MC1004 GIGABIT ETHERNET MEDIA CONVERTER
PWR

2
Figure 2 shows an example of an AT-MC1005/x Series Media Converter.
Figure 2 AT-MC1005/x Series Gigabit Ethernet Media Converter (Model AT-MC1005/3)
Table 1 lists the cabling distances for the Gigabit Ethernet media converters.
Table 1 Maximum Cabling Distances
Port Type of Connector Maximum Operating
Distance1
1. Maximum distance may be less depending on the type of fiber optic cabling used with the port.
1000Base-T2
2. The 1000Base-T port uses 4 pair (8 wires) in a twisted pair cable.
All Models RJ-45 100 m (328 ft)
1000Base-SX
AT-MC1004 SC 550 m (1,804 ft)
1000Base-LX
AT-MC1005/1 SC 10 km (6.2 mi)
AT-MC1005/2 SC 20 km (12.4 mi)
AT-MC1005/3 SC 40 km (24.8 mi)
AT-MC1005/4 SC 70 km (43.4 mi)
1000Base-LX 1000Base-T
REC
LNK
REC
LNK
TX SM RX
MC1005/3 GIGABIT ETHERNET MEDIA CONVERTER
PWR

AT-MC1004 and AT-MC1005/x Series Installation Guide
3
Key Features
The media converters have the following key features:
❑LEDs for unit and port status
❑1000Basetwisted pairport with a maximum operating distance of 100
meters (328 feet)
❑1000Base fiber optic port with a maximum operating distance of 550
meters (1,804 feet) to 70 kilometers (43.4 miles) using single-mode or
multimode fiber optic cabling, depending on the model
❑Full-duplex operation
❑External AC/DC power adapter
❑Standard, compact size for desktop use or with an AT-MCR12
rackmount chassis
Fiber Optic Port
The 1000Base-SX port on the AT-MC1004 media converter has an SC
connector and is designed to operate with multimode fiber optic cabling. This
port has a maximum operating distance of 550 meters (1,804 feet) using 62.5/
125 micron multimode fiber optic cable.
The 1000Base-LX port on the AT-MC1005/x Series Media Converters has an
SC connector and is designed to operate with single-mode fiber optic cabling.
This port has a maximum operating distance of 10 kilometers (6.2 miles) to 70
kilometers (43.4 miles), depending on your model, using 9/125 micron single-
mode fiber optic cable.
Twisted Pair Port
The 1000Base-T port on the AT-MC1004 and AT-MC1005/x Series Gigabit
Media Converters has an RJ-45 connector and is designed to operate with
Category 5 or better shielded or unshielded twisted pair cable.
An RJ-45 twisted pair port on a 1000 Mbps Ethernet network device can have
one of two possible wiring configurations: MDI or MDI-X. The RJ-45 port on a
PC, router, or bridge is typically wired as MDI, while the twisted pair port on
a switch or hub is usually MDI-X.

4
To connect two network devices that have dissimilar wiring configurations,
such as MDI to MDI-X, you use a straight-through twisted pair cable. To
connect two network devices that have the same wiring configuration, such as
MDI to MDI, you use a crossover cable.
The AT-MC1004 and AT-MC1005/x Series Gigabit Media Converters feature
automatic MDI/MDI-X. Each port automatically determines the configuration
of the port on the device to which it is connected and then configures itself
appropriately. For example, if a port on a media converter is connected to a
port on a bridge, which is typically wired as MDI, the port on the media
converter automatically configures itself as MDI-X. This feature allows you to
use either straight-through or crossover cables when connecting devices to the
media converter. This eliminates the need for a cross-over cable.
Status LEDs
Table 2 defines the units LEDs.
Table 2 Status LEDs
Half- and Full-Duplex Mode
Duplex mode refers to the way an end-node sends and receives data on the
network. An end-node can operate in either half- or full-duplex mode,
depending on its capabilities. An end-node that is operating in half-duplex
mode can either send data or receive data, but it cannot do both at the same
time. An end-node that is operating in full-duplex mode can send and receive
data simultaneously. The best network performance is achieved when an end-
node can operate at full-duplex, since the end-node is able to send and receive
data simultaneously.
The AT-MC1004 and AT-MC1005/x Series Gigabit Ethernet Media Converters
operate in full-duplex mode only. The media converter can operate with end-
nodes capable of either full-duplex mode or that can auto-negotiate the duplex
mode. However, it is important to remember that the two end-nodes connected
to the ports on the media converter must be able to operate in full-duplex
mode.
LED Color Description
PWR Green Power is applied to the unit.
REC Green Data is being received on the ports.
LNK Green A link has been established on the ports.

AT-MC1004 and AT-MC1005/x Series Installation Guide
5
External AC/DC Power Adapter
An external AC/DC power adapter is included with the media converter for
desktop operation (see Figure 3). The power adapter supplies 12V DC to the
media converter. Allied Telesyn supplies an approved safety compliant AC
power adapter for the 120 and 240V AC versions with an unregulated output
of 12V DC at 1 A. The power required for the media converter is 12V DC,
1000 mA.
Note
The power adapter is not used if you install the media converter in an
AT-MCR12 chassis.
Figure 3 External AC/DC Power Adapter (North American version)

6
Network Topologies
The AT-MC1004 and AT-MC1005/x Series Gigabit Ethernet Media Converters
can be used in two different topologies: standalone and back-to-back. Both
types of topologies are described below.
Standalone Topology
A standalone topology uses only one media converter between the end-nodes.
Figure 4 illustrates a standalone topology that uses two AT-MC1005/1 media
converters to interconnect three remote campuses. Campus 1 has an
AT-8224XL switch with two AT-A15/LX expansion modules. The modules,
which provide a connection of up to 10 kilometers (6.2 miles), are connected to
the 1000Base-LX ports on the media converters. The 1000Base-T ports on the
media converters are connected to the AT-A14 expansion modules in the
AT-8216FXL/MT switches at Campus 2 and Campus 3.
Figure 4 Standalone Topology
100BASE-FXFAST ETHERNET SWITCH
STATUS
RESET
FAULT
RPS
PWR
100BASE-FX
A
B
RS-232
TERMINAL PORT
PORTACTIVITY
1234 5678 9101112 13141516
L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C
ACTIVITY
FULLDUP
100MLINK
HALFDUP / COL
L/A
D/C
100BASE-FXFAST ETHERNET SWITCH
STATUS
RESET
FAULT
RPS
PWR
100BASE-FX
A
B
RS-232
TERMINAL PORT
PORTACTIVITY
1234 5678 9101112 13141516
L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C
ACTIVITY
FULLDUP
100MLINK
HALFDUP / COL
L/A
D/C
STATUS
RESET
FAULT
RPS
PWR
10BASE-T/100BASE-TX
FASTETHERNET SWITCH
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
10BASE-T/ 100BASE-TX
1X3X5X7X
2X4X6X8X
9X11X13X15X
10X12X14X16X
17X19X21X23X
18X20X22X24X
A
B
RS-232
TERMINAL PORT
100MLINK / ACTIVITY 10M LINK / ACTIVITY
HALFDUP / COL
FULLDUP
PORTACTIVITY
L/A
L/A
D/C
D/C
L/A
D/C
AT-A15
1000BASE-X
LINK
ACTIVITY
FULL
HALF
AT-A15
1000BASE-X
LINK
ACTIVITY
FULL
HALF
1000Base-LX 1000Base-T
REC
LNK
REC
LNK
TX SM RX
MC1005/1 GIGABIT ETHERNET MEDIA CONVERTER
PWR
1000Base-LX 1000Base-T
REC
LNK
REC
LNK
TX SM RX
MC1005/1 GIGABIT ETHERNET MEDIA CONVERTER
PWR
AT-A14
1000BASE-X
LINK
ACTIVITY
FULL
HALF
AT-A14
1000BASE-X
LINK
ACTIVITY
FULL
HALF
Campus 1: AT-8224XL with two
AT-A15/LX Expansion Modules
10 km (6.2 mi) maximum
AT-MC1005/1
Campus 2: AT-8216FXL/MT with one
Twisted Pair
100 m (328 ft) maximum
AT-MC1005/1
100 m (328 ft) maximum
Single-mode
Fiber Optic
AT-A14 Expansion Module Campus 2: AT-8216FXL/MT with one AT-A14 Expansion Module

AT-MC1004 and AT-MC1005/x Series Installation Guide
7
Back-to-Back Topology
In some network configurations you may want to interconnect two media
converters in what is referred to as a back-to-back topology. In this topology,
the media converters not only extend the distance of your network but also
convert the fiber optic cable from twisted pair to fiber optic and back again.
Figure 5 illustrates one AT-8216FXL/MT switch with an AT-A14 expansion
module at each campus. The switches are interconnected by two AT-MC1005/3
media converters. The 1000Base-T ports on the media converters are
connected to the AT-A14 expansion modules in the switches, while the
1000Base-LX ports on the media converters are directly connected together.
Figure 5 Back-to-Back Topology
100BASE-FXFAST ETHERNET SWITCH
STATUS
RESET
FAULT
RPS
PWR
100BASE-FX
A
B
RS-232
TERMINALPORT
PORTACTIVITY
1234 5678 9101112 13141516
L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C
ACTIVITY
FULLDUP
100MLINK
HALFDUP / COL
L/A
D/C
AT-A14
1000BASE-X
LINK
ACTIVITY
FULL
HALF
100BASE-FXFAST ETHERNET SWITCH
STATUS
RESET
FAULT
RPS
PWR
100BASE-FX
A
B
RS-232
TERMINALPORT
PORTACTIVITY
1234 5678 9101112 13141516
L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C L/A D/C
ACTIVITY
FULLDUP
100MLINK
HALFDUP / COL
L/A
D/C
AT-A14
1000BASE-X
LINK
ACTIVITY
FULL
HALF
1000Base-LX 1000Base-T
REC
LNK
REC
LNK
TX SM RX
MC1005/3 GIGABIT ETHERNET MEDIA CONVERTER
PWR
1000Base-LX 1000Base-X
REC
LNK
REC
LNK
TX SM RX
MC1005/3 GIGABIT ETHERNET MEDIA CONVERTER
PWR
Campus 2: AT-8216FXL/MT with
AT-MC1005/3
Campus 1: AT-8216FXL/MT with one
100 m (328 ft) maximum
AT-A14 Expansion Module
one AT-A14 Expansion Module
40 km (24.8 mi) maximum
AT-MC1005/3
Single-mode
100 m (328 ft) maximum
Fiber Optic
Twisted Pair

9
Chapter 2
Installing the Media Converter
Verifying the Package Contents
Make sure the following items are included in your media converter package.
If any item is missing or damaged, contact your Allied Telesyn sales
representative.
❑One AT-MC1004 or AT-MC1005/x Series Gigabit Ethernet Media
Converter
❑Four protective feet (for desktop use only)
❑External AC/DC power adapter (North America, Continental Europe,
United Kingdom, or Australia)
❑This installation guide
❑Warranty card
Planning the Installation
Be sure to observe the following guidelines when planning the installation of
your media converter.
❑The end-nodes connected to the ports of the media converter must
operate in full-duplex mode. The AT-MC1004 and AT-MC1005/x
Series Gigabit Ethernet Media Converters operate only in full-duplex
mode.
❑Referto Table 3and Table 4for thetwisted pair and fiberoptic cabling
specifications.

10
Table 3 Twisted Pair Cabling Specifications
Note
The 1000Base-T ports use 4 pair (8 wires) in a twisted pair cable.
Table 4 Fiber Optic Cabling Specifications
Selecting a Site
Be sure to observe the following requirements when choosing a site for your
switch.
❑Select a site that is dust-free and moisture-free.
❑Be sure that the site will allow you to easily access the fiber optic and
twisted pair cables and the power cord.
❑Use dedicated power circuits or power conditioners to supply reliable
power to the device.
Model Cable Maximum Operating
Distance
All Models Shielded or Unshielded Twisted
Pair Category 5 or better 100 m (328 ft)
Model Cable Maximum
Operating
Distance
Maximum
Allowable Loss
Budget
AT-MC1004 50/125or62.5/125micron
multimode 550 m (1,804 ft) 8.5 dB at 850 nm
AT-MC1005/1 9/125 micron single-mode 10 km (6.2 mi) 17 dB at 1310 nm
AT-MC1005/2 9/125 micron single-mode 20 km (12.4 mi) 18.0 dB at 1550 nm
AT-MC1005/31
1. For maximum performance of Gigabit Optical Datalinks when greater than 40 km (24.8 mi) and operating within the
1550 nm optical spectrum, it is mandatory that the Single-mode Fiber (SMF) be rated as non-dispersion-shifted,
dispersion shifted, or non-zero dispersion shifted.
9/125 micron single-mode 40 km (24.8 mi) 18.0 dB at 1550 nm
AT-MC1005/419/125 micron single-mode 70 km (43.4 mi) 20.0 dB at 1550 nm
