AT-CM2K0S Converteon Line Card Installation Guide
Overview
The AT-CM2K0S line card is a Gigabit copper-to-fiber media line card. You can install this
line card in any Converteon Series chassis. The line card features one small form factor
pluggable (SFP) transceiver slot and one copper twisted pair port. The line card is hot-
swappable into and out of a Converteon chassis.
Related Documents
For details on the features and functions of a Converteon chassis, refer to the relevant
documents on our web site, www.alliedtelesis.com.
Verifying Package Contents
Ensure that the following items are included in your package:
One AT-CM2K0S line card
This installation guide
If any item is missing or damaged, contact your Allied Telesis sales representative for
assistance.
AT-CM2K0S Line Card Components
An AT-CM2K0S line card has the components shown below.
Port Descriptions
SFP Port
The SFP slot supports qualified SFP transceivers with a fixed operating speed of 1000
Mbps. Another AT-CM2K0S line card must be installed with an identical SFP module in a
remote chassis to de-multiplex the signals. Please refer to the AT-CM2K0S Product
Information/Related Products page on the www.alliedtelesis.com web site for the list of
qualified SFP modules.
Twisted Pair Port
The 10/100/1000Base-TX compliant twisted pair port has an RJ-45 connector and a
maximum operating distance of 100 meters (328 feet). Category 5 (5E), 100 Ohm
shielded or unshielded twisted pair cabling is required. The pinouts for this port are
shown in “Twisted Pair Port Pinouts.”
LEDs
An AT-CM2K0S line card has four system LEDs, two LEDs for the SFP port, and five LEDs
for the twisted pair port, as described in “LED Descriptions.”
DIP Switches
One set of DIP switches allows you to set the operating mode, as described in “DIP Switch
Settings.”
Installing an AT-CM2K0S Line Card
Note
Before you install an AT-CM2K0S line card, refer to the appropriate Converteon
chassis installation guide for electrical safety and emissions information.
Note
You can install a Converteon line card in any Converteon chassis line card slot.
To install an AT-CM2K0S line card, perform the following procedure:
1. Remove the AT-CM2K0S line card from its shipping package and store the package
in a safe place. You must use the original package if you need to return the unit to
Allied Telesis.
2. Configure the line card’s DIP switches as required. Refer to “DIP Switches” for more
information.
3. Select any line card slot in the chassis where you want to install the AT-CM2K0S line
card, and remove the blank slot cover if one is installed.
4. Align the back edge of the line card with the to and bottom alignment guides located
inside the slot.
5. Slide the line card into the slot until the front of the card is flush with the front of the
chassis.
Note
Avoid touching the line card components.
6. Secure the AT-CM2K0S line card to the chassis by using a Phillips screwdriver to
tighten the captive screw on the faceplate.
Note
Always tighten the captive screw to secure the line card to the chassis.
7. Repeat this procedure to install additional AT-CM2K0S line cards.
LED Descriptions
Status LEDs
The line card has four status LEDs as described in the following table. For more information
about Smart MissingLink, MissingLink, and OAM, refer to the relevant management
software user’s guide.
SFP Port LEDs
The SFP port has two LEDs, as described in the following table. For more information
about Smart MissingLink, refer to the relevant management software user’s guide.
Twisted Pair Port LEDs
The twisted pair port has five LEDs, as described in the following table. For more
information about Smart MissingLink, refer to the relevant management software user’s
guide.
*613-000332 Rev D*
536
AT-C M 2K0S
LKAT
LK
ATFD1000M
RDY
SFP
T
X
SMLMLOAM100M
10/100/1000
SW1
ON
1 2 3 4
536
AT-C M 2K0S
LKAT
LK
ATFD1000M
RDY
SFP
T
X
SMLMLOAM100M
10/100/1000
SW1
ON
1 2 3 4
SFP Port LEDs
SFP Port
Twisted Pair Port LEDs
Line Card Status LEDs
10/100/1000-TX Twisted Pair Port
DIP Switches
Warning: Remove all metal jewelry, such as rings and watches, before installing
or removing a line card from a powered-on chassis.
Caution: Be sure to observe all standard electrostatic (ESD) precautions, such as
wearing an antistatic wrist strap, to avoid damaging the device. A line card can be
damaged by static electricity
LED State Description
RDY Green The line card has passed diagnostics.
Off The line card has not passed diagnostics.
SML Green The Smart MissingLink mode is enabled.
Off The Smart MissingLink mode is disabled.
ML Green The MissingLink mode is enabled.
Off The MissingLink mode is disabled.
OAM Green The OAM mode is enabled (visible or bypass). You use the DIP
switches to set the OAM mode, as described in “DIP Switch
Settings.”
Off The OAM mode is disabled.
LED State Description
LK Green A link has been established on the port.
Blinking
Green
While in Smart MissingLink mode, a valid connection is established
on the port while a link on the other port is lost.
Off No link has been established on the port.
AT Blinking
Green
TX/RX activity has been detected on the port.
Off There is no TX/RX activity on the port.
LED State Description
LK Green A link has been established on the port.
Blinking
Green
While in Smart MissingLink mode, a valid connection is established
on the port while a link on the other port is lost.
Off No link has been established on the port.
AT Blinking
Green
TX/RX activity has been detected on the port.
Off There is no TX/RX activity on the port.
FD Green The port is operating in full-duplex mode.
Off The port is operating in half-duplex mode.
1000M Green The port is operating at 1000 Mbps.
Off The port is not operating at 1000 Mbps.*
100M Green The port is operating at 100 Mbps.

456
* When the 1000M and 100M LEDs are both off, the port is operating at 10 Mbps.
DIP Switch Settings
The DIP switches as described in the following table allow you to set the operating mode
of the line card. For information about the operating modes as well as Smart MissingLink,
MissingLink, and OAM, refer to the relevant management software user’s guide.
“X” means that the DIP switch position can be ON or OFF.
Twisted Pair Port Pinouts
The pinouts for the RJ-45 twisted pair port are shown in the following illustration.
The following table lists the RJ-45 pin signals when a twisted pair port is operating in the
MDI or MDI-X mode.
Warranty Information
The AT-CM2K0S line card has a limited warranty of five years. Go to
www.alliedtelesis.com/warranty for the specific terms and conditions of the warranty and
for warranty registration.
Specifications
Physical, Environmental, and Electrical Ratings
Dimensions (H x W x L) (2.2 cm x 7.3 cm x 13.0 cm)
.78 in. x 2.89 in. x 5.1 in.
Operating Temperature 0° C to 40° C (32° F to 104° F)
Storage Temperature -25° C to 70° C (-13° F to 158° F)
Operating Relative Humidity 5% to 90% (non-condensing)
Storage Relative Humidity 5% to 95% (non-condensing)
Operating Altitude Range Up to 3,048 m (10,000 ft.)
Predicted MTBF (Telcordia SR332) 880,000 hours
Power Consumption 6.5 Watts maximum
Electrical Safety and Emissions Statements
This product meets the following standards when installed in compliant host equipment.
Emissions FCC Class A, EN55022 Class A, VCCI Class A, C-TICK, CE
Warning: In a domestic environment this product may cause radio interference in which
case the user may be required to take adequate measures.
Immunity EN55024
Electrical Safety UL60950 (cULus), EN60950 (TUV), CSA22.2 No. 950
Copyright © 2008 Allied Telesis, Inc. All rights reserved.
Off The port is not operating at 100 Mbps.*
Operating Mode DIP 1 DIP 2 DIP 3 DIP 4
Link Test (default) OFF OFF OFF X
Smart MissingLink (SML) OFF ON ON X
MissingLink (ML) OFF OFF ON X
OAM Bypass ON OFF OFF X
OAM Visible ON ON OFF X
MDI Mode MDI-X Mode
Pin Signal Pin Signal
1 TX+ 1 RX+
2 TX- 2 RX-
3 RX+ 3 TX+
6 RX- 6 TX-
LED State Description
8
8
11
