Allied Telesis PC4KVM User manual

www.alliedtelesis.com/corega
• Easy installation with no user configuration required
• Silent operation
• Supports Microsoft Intelimouse
• Colour coded ports (Keyboard, Video, Mouse)
• Compatible with all operating systems
• Auto-scan -keeps an eye on multiple computers at the same time
• Small and lightweight for convenient positioning
• LED lights to show on-line computer
• No power supply required -power drawn from existing computers
• Hot Plug-able
• Keyboard settings stored between computers
• Manual or keyboard computer selection
• ”Easy-grip” cable fixings
4 PORT KEYBOARD/ VIDEO/MOUSE SWITCH
CONNECT 4 COMPUTERS TO A SINGLE MONITOR,
MOUSE AND KEYBOARD
PC4KVM
corega PC4KVM is a 4 port KVM Switch , it can automatic switching
among computers within 5 sec, and has Hotkey Combination Function
Supporting. It also has power on detection function- Automatically
switching to the first power on port.

www.alliedtelesis.com/corega
PC4KVM
Ordering Information
PC4KVM 4 PORT KEYBOARD/ VIDEO/MOUSE SWITCH EU
4 PORT KEYBOARD/ VIDEO/MOUSE SWITCH
CONNECT 4 COMPUTERS TO A SINGLE MONITOR, MOUSE AND KEYBOARD
• Interface Ports
-To ‘computer‘:
4 x Keyboard PS/2 style (6-pin mini-DIN
male)
4 x Video VGA/SVGA/Multisync(HDB-15
male)
4 x Mouse PS/2 style (6-pin mini-DIN male)
-To ‘console’:
1 x Keyboard PS/2 (6-pin mini-DIN female)
1 x Video VGA/SVGA/Multisync(HDB-15
female)
1 x Mouse PS/2 style (6-pin mini-DIN
female)
• LED Indicators lights
4 x CPU -indicates monitored computer
• Operating System Compatibility
MS-DOS 6.2, Windows 3.1, Windows 95/98,
Windows NT 3.5 upward, Windows 2000,
Windows ME, Windows XP, FreeBSD, Linux
• Shock and Vibration
Shock: 100g at 10ms (estimated)
Vibration: 0.5g, 10-500Hz, 3 axis (estimated)
Seismic: 10g, 5-200Hz, 15s (estimated)
• Video Support
VGA, SVGA or Multisync(up to 2048x 1536)
• Dimensions
200mm (W) x 80mm (D) x 25mm (H)
• Weight
KVM weight 510g (cable excluded)
Shipping Package Weight 1.1Kg
• Temperature
Operating Temperature: 5 to 40°C (Please
leave 50mm clearance on all sides to provide
airflow)
Storage Temperature:-20 to 60°C
• Humidity
Operating:0-80% humidity, non-condensing
Storage:0-80% humidity, non-condensing
• Operating Altitude
-50 to 3,000 Metres
• Power Consumption
DC 5V, 80mA,4W
• Port Selection
Push Button for manual
Hot Key
Auto-scan -5 second interval
• MTBF
100,000 hours (estimated)
• Agency Approvals
CE Class B
• Packing Content
1 x KVM switch
4 x KVM cables (Computer)
1 x KVM cable (Console)
1 x installation guide
Technical Specifications
