Almost Heaven Saunas Hampton Operating instructions

Hampton Hybrid Sauna
Installation & Owner’s Manual
®
Hybrid

Read this entire manual through to the end before
proceeding with the assembly.
Thank you for your purchase of your Hampton indoor sauna!
Should you have any questions during assembly,
please feel free to call us at 888.355.3050,
or email [e-mail].
Regular business hours are 9-5 EST, M-F.
Your Hampton Indoor Sauna is specically designed to utilize your
existing oor. As such, assembly is made very simple since the entire
sauna sits on pre-fabricated rails and risers. Your sauna can be assembled
on any surface that is rm and at, including concrete, ceramic, vinyl,
laminate or tile. Installation on a carpeted surface is not recommended.
NOTE: Your Hampton sauna requires a dedicated 20 amp outlet for
proper operation. A separate hard-wired 220V, 30 amp circuit is
required for the traditional sauna heater.
Hampton Sauna
Installation & Owner’s Manual
®
HAMPTON SAUNA INSTALLATION MANUAL
page 1

HAMPTON SAUNA INSTALLATION MANUAL
page 2
Image 1 Image 2 Image 3 Image 4
Image 5 Image 6 Image 7 Image 8
Pre-Assembly Suggestions
• While you can move the completed Hampton very gently by sliding it across the oor, we suggest that you assemble
the sauna in the location where you plan to use it.
• Terms such as “left” and “right” refer to the location when facing the completed sauna from the front, or glass side.
Sauna Assembly
1.Place the oor section in the location where you will want the sauna and position the rear wall so that it is on the outside
of the oor section as shown (1). Find the left wall section and position so that it is outside the oor section and aligns
with the rear wall section (2). Screw the left wall section to the rear wall using the 3” screws as shown (3). View from inside
after left wall has been attached to rear wall. Note: The oor section does not attach to any of the walls (4).
Slide the bench support between the vertical boards at the base of the left wall section (5). Plug the wire from the rear
wall section into the wire from the bench support. This connection will power the oor heating panel located on the
bench support (6). Place the bench over the bench support (7). It will be supported by the bench support as well as
support boards located on the side and rear walls. Note: The bench support and bench are installed prior to installing
the right wall section. Find the right wall section and place to the outside of the oor section, ensuring that the bench
support ts between the vertical boards on the right wall section (8).

Screw the right wall section to the rear wall using 3” screws (9). Locate the back rest and position over the heater
panels (10). Secure the back rest to the rear wall using 2” screws. Note: Be sure the back rest is level and positioned
approximately 2” above the bench (11). Picture of assembly thus far (12).
The front glass wall will attach to the left and right wall sections via a pin and slot assembly. Note the pin on left and
right wall sections (13). Note the slots on the right and left sides of the front glass panel (14). With two people, position
the front wall section so that the pins align with the slots (15). Then lift the front wall section so that the pin will insert
into the large portion of the slot at the top, middle and bottom of each side. Then lower the wall section so that the pin
slides into the narrow part of the slots. This will secure the front wall section to the left and right wall sections. (16).
Image 9 Image 10 Image 11 Image 12
Image 13 Image 14 Image 15 Image 16
pin
slot
HAMPTON SAUNA INSTALLATION MANUAL
page 3

HAMPTON SAUNA INSTALLATION MANUAL
page 4
If necessary, use a rubber mallet to assist in lowering the front wall section to the height of the left and right wall
sections (17). Find the heater wire connections at the top of the panels and move them so they lay to the outside of
the sauna for now. This is so that they do not interfere with positioning the roof section (18). Find the roof section and
remove the thin protective dust cover that is secured with small screws (19). Place the roof section over the top of the
sauna and lower between the walls so that it rests on the supports at the top of the wall sections. Note: The power
box on the top side of the roof should be to the rear of the sauna (20).
Connect the heater wires, then lay the wire into the groove that is cut into the roof section. This will ensure that the
dust cover can be reinstalled without interfering with the wires (21). Be sure that the wires plugs are fully connected
and seated securely into the receptacles (22). The plug accompanying your Hampton sauna will be dierent than
pictured (23). Feed the power connector through the hole in the dust cover and reposition the dust cover over the
roof section (24).
Image 21 Image 22 Image 23 Image 24
Image 17 Image 18 Image 19 Image 20

HAMPTON SAUNA INSTALLATION MANUAL
page 5
Reattach the dust cover to the roof section (25). Find the door handle and disassemble (26). Reattach the door handle
to the holes located in the glass door. Note: Tighten screws until they are snug, but not overly tight (27). Find the two
door hinges and hex wrench and disassemble the hinges (28).
Reattach the hinges to the door and the glass window, tightening with the hex wrench so they are snug. Note: You
may have to loosen the screws again when the door is attached to adjust the t of the door. Once the t is completed
you may tighten the screws in the hinges (29). Attach the magnetic door latch to the top of the door frame. Note: Do
not fully tighten the door latch until you are sure that the door will properly secure to the latch (30). Slide the metal
catch over the door to align with the magnetic door latch as shown (31).
Install the traditional heater according to the instructions in the heater manual. This will include mounting the heater
to the wall of the sauna with mounting screws, with the bottom of the heater being approximately 7” from the oor
of the sauna. Be sure that the screws are at the same height (32). Lower the heater onto the mounting screws (33).
Assemble the heater fence (34). Place the heater fence in front of the traditional heater (35).
WARNING: Never operate the infrared heaters and the traditional heaters at the same time.
Operate one or the other, depending on the type of sauna you would like to enjoy.
Image 32 Image 33 Image 34 Image 35
Image 25 Image 26 Image 27 Image 28
Image 29 Image 30 Image 31

HAMPTON SAUNA INSTALLATION MANUAL
page 6
CONTROL OPERATION
Power On/O
Turn on the system by pushing and holding the Power button for 4 seconds until the green lights on the display are
lit. Turn the system o by pushing the Power button a second time for 1 second. The red light on the Power button
indicates the system is turned o. All of the sauna functions will only operate when the system is on and the panel is
green.
Infrared Heater Operation
With the display on, press the Heater button, which will immediately turn green. This indicates that the infrared heater
panels are heating.
To adjust the temperature, press the Temperature (-) or Temperature (+) to raise or lower the set temperature. The
temperature is displayed in Celsius, with the lowest temperature setting being 30°C (86°F) and the maximum
temperature setting being 70°C (158°F). Pressing the temperature buttons will raise or lower the temperature by 1°
each time the button is pressed. After 8 seconds the display will indicate the actual temperature in the sauna.
The heaters can operate to a maximum of 60 minutes, and you can adjust the heating time with the Time (-) or Time
(+) buttons. You will add 1 minute to the time each time you press the Time button. After 8 seconds the display will
show the time remaining. When there are 5 minutes left in the cycle, the timer will sound 3 times to remind you that
your session is ending. When the heaters turn o after 60 minutes you can reset the timer if you wish to keep the
heaters on for another cycle.
Bluetooth Function
To activate Bluetooth, press the Bluetooth button which will immediately turn green. Turn on the Bluetooth function
on our Bluetooth device and pair to BT Audio. You can now listen to music from your device and control the volume
Control panel operation
60
55
50
45
40
35
30
25
20
15
10
5
Temperature display
Temperature+
Time+
Bluetooth
Light control
Power on/off
Time display bar
Temperature -
Time -
Light wave
1. Power on/off
In energized state , the system is under standby , when first press “Power on/off” button, the system is
switched on,the room temperature will display on the screen, when second press this button , the
system and all loads will be turned off.if the button color shows green means on-state,and red color
means closed
2. Light wave function
Under the power on state,press “Light wave” button,start the light wave function ,green button means
turn on,and red means turn off,the light wavetemperature will memory last setting, time is 60 minuets
Light wave temperature setting:in light wave state,press “Temperature+ Temperature -”button to adjust
the temperature,the adjustment range is 30-65 degree,every press could increase only 1 degree, if no
operation exceed 8 seconds,the screen will returns to display the current actual temperature.
Light wave time setting:in light wave state,press “Time+ Time -” button to adjust time,the adjustment
range is 5-60 minutes,every press could increase only 1 minute,When the time countdown only 5 minutes,
the buzzer alarm 3 times. if no operation exceed 8 seconds,the screen will returns to display thecurrent
actual time.
Display
Temperature (+)
Time (+)
Bluetooth
Light Control
Power On/O
Temperature (-)
Time (-)
Heater

HAMPTON SAUNA INSTALLATION MANUAL
page 7
from your device. The speakers are located above the ceiling and are not visible from inside the sauna.
Lighting
To turn on the overhead light, press the Light button, which will immediately turn green on the display. The color of
the overhead light will be the same as when the unit was last turned o. The light has 9 settings which display as L1-
L9. The settings are as follows: L1=white, L2=red+blue, L3=blue, L4=blue+green, L5=green, L6=green+red, L7=red,
L8=all colors, L9=fade from color to color. To change the light setting press the Light button and hold for 5 seconds.
Then press the button and release to get to the setting you’d like. The system will exit the Light function after 8
seconds.
High Temp Limit
You should never operate the infrared and traditional heaters at the same time. The infrared system will not operate
if the temperature in the room is 80°C or above, so be sure the room cools o after using the traditional heater before
operating the infrared heaters.
Sensor Fault Detection
An EO indicator on the display panel means there is an open circuit and you should check your circuit breaker to be
sure it is not tripped. The plug on your infrared sauna requires a 20amp dedicated circuit.
An E1 indicator on the display panel means that there is some sort of short in the circuit, and you should contact your
electrician.
