Almost Heaven Saunas Grayson Operating instructions

Grayson Sauna
Installation &
Owner’s Manual
Revised February 2017

2
CHECK YOUR BOXES
Be sure to immediately check your boxes against your shipping list and bill of lading to make sure all boxes are there.
Examine for any damage and notify Almost Heaven Saunas if there needs to be a repair or replacement of damaged or
missing materials.
ELECTRICAL REQUIREMENTS
All electrical wiring must be performed by A QUALIFIED LICENSED ELECTRICIAN. Because of the heat involved in the
sauna, it is required that you use copper wire with 90ºC insulation. Do not use aluminum wire to make the connection.
Consult with an electrician so you can determine the requirements for your particular situation. All wiring must conform
to all national, state and local codes and regulations and according to the instructions provided with the heater.
LOCATING THE SAUNA
Your Grayson Indoor Sauna was specifically designed to utilize your existing floor. As such, assembly is made very sim-
ple since the entire sauna sits on pre-fabricated rails and risers rather than on an integral floor platform. Your sauna can
be assembled on any surface that is firm and flat, including concrete, ceramic, vinyl, laminate or tile. (Installation on a
carpeted surface is not recommended.)
ASSEMBLY
You should use two people for the assembly of the Grayson Sauna. The wall and roof sections are large and need two
people to lift and hold in place during assembly.
Read this entire manual through to the end before proceeding with the assembly.
BASIC TOOLS
You should have the following tools:
 Cordless drill for driving screws
 1/8” drill bit
 Stepladder or stool
 Rubber Mallet
 Claw hammer
 Screwdrivers (Phillips and Flathead)
 Framing Square
 Utility knife
 Level
Grayson Sauna Packing List
 4 Floor Risers
 4 Wall Support Rails
 Wall Section A
 Wall Section B
 Wall Section C
 Wall Section D
 Wall Section E
 Window Section F
 Door Section H
 Window Section G
 Filler strip
 3 pieces of wall trim
 4 Roof Support Rails
 2 Roof Sections4 pieces
of roof trim
 Upper Bench
 Lower Bench
 Back rest with pre-
mounted LED light
 LED power supply
 Hardware packet
 Bucket with liner
 Ladle
 Thermometer/
hygrometer
 Door knob kit
 Heater fence kit
 Harvia 6.0kw heater
 Box of sauna stones
 Assembly manual
packet

3
1. Connect the 4 FLOOR RISERS
Your existing floor will serve as the floor for your
sauna. The pre-fabricated rails and risers will be
placed on your existing floor and provide the
structural support for the sauna room.The 4 floor
risers are pre-drilled and are assembled with 2”
screws. Use a square to be sure the assembled
frame is square.
NOTE: Be sure your surface is flat before you
begin assembly.
Assemble floor riser
2. Position the WALL SUPPORT RAILS
Place the 4 wall support rails with the groove fac-
ing up on top of the assembled floor riser.
Using 2” screws, Draw the corners tight by angle
screwing the corners together.
NOTE: One side of each rail is pre-drilled. After
lining up the rails and prior to screwing them to-
gether, it is suggested that you pre-drill through
the factory-drilled pilot hole into the second rail
using a 1/8” drill bit. Drill about 1” into the sec-
ond rail. This will prevent the possibility of strip-
ping or breaking the screw.
Position wall support rails
3. Fasten WALL SUPPORT RAILS
Using 2” screws, attach the support rails to the
floor riser; be sure that the groove is facing up.
Use 4 screws for each rail.
The combined riser and rails is now called the
wall support section.
Fasten wall support rails to floor riser
Angle-screw corners to draw tight

4
5. Position WALL SECTION B
Position Wall Section B on the left rear of the sau-
na according to ILLUSTRATION 1.
NOTE: Wall Section B will overlap Wall A.
Position Wall Section B
6. Attach Wall Section B to Wall Section A
Using 2” screws, connect Wall Section B to Wall
Section A using the pre-drilled holes.
NOTE: Be sure the wall edges and top edges
align evenly.
Attach Wall Sections A and B
ILLUSTRATION 1
The 8 wall sections, A– H, will be
positioned in the grooves of the
completed wall support section as
shown.
A
BC
D
E
F
G
H
Completed
Wall
Support
4. Position WALL SECTION A
Position Wall Section A in the groove of the rail
on the left rear side of the sauna according to the
guide on ILLUSTRATION 1.
NOTE: Wall A should only go as far back in the
groove as shown so that the back wall section B
can overlap the edge of wall A.
Position Wall Section A

5
Position Wall Section C
8. Position WALL SECTION D
Position Wall Section D on the right rear side of
the sauna according to the guide on ILLUSTRA-
TION 1. Using 2” screws and pre-drilled holes,
fasten Wall Section C to Wall Section D.
NOTE: As with step 6, be sure the wall edges and
top edges align evenly.
Position Wall Section D
9. Position WALL SECTION E
Position Wall Section E on the front right side of
the sauna according to the guide on ILLUSTRA-
TION 1.
NOTE: Wall Section E will attach to Wall Section
D by way of the tongue and groove profile but will
not be fastened with screws.
Position Wall Section E
10. Position WINDOW SECTION F
Position Window Section F on the right front of
the sauna according to the guide on ILLUSTRA-
TION 1. Using 2” screws and pre-drilled holes,
fasten Window Section F to Wall Section E.
NOTE: As with step 6, be sure the wall edges and
top edges align evenly.
Position Window Section F
7. Position WALL SECTION C
Position Wall Section C on the right rear side of
the sauna according to the guide on ILLUSTRA-
TION 1.
NOTE: Wall Section C will attach to Wall Sec-
tion B by way of the tongue and groove profile but
will not be fastened with screws.

6
Install filler strip to Window Section F
12. Position WINDOW SECTION G
Position Window Section G on the left front side
of the sauna according to the guide on ILLUS-
TRATION 1.
NOTE: Window Section G will not attach to Wall
Section A.
Position Window Section G
13. Position DOOR SECTION H
Position Door Section H on the front left side of
the sauna according to the guide on ILLUSTRA-
TION 1. Using 2” screws and pre-drilled holes,
fasten Door Section H to Window Section G.
NOTE: Window Section H will not attach to the
filler strip previously attached to Window Section
F.
Position Door Section H
14. Attach WALL CONNECTOR
Find the pre-drilled wall connector. Place the
wall connector on the top of the front wall edge,
bridging Door Section H, the filler strip, and Win-
dow Section F. Screw it into place with 2”
screws.
Attach wall connector
11. Install FILLER STRIP
Screw the filler strip to Window Section F to fill
the gap between Window Sections F and Door
Section H. Trim pieces will later be installed over
this joint.
NOTE: Due to the inherent variations in lumber
dimensions, this gap may not be completely filled
by the filler piece. This will be addressed later:
provided trim pieces will cover any remaining
openings.
H

7
Completed Roof Support
16. Attach ROOF SUPPORT over walls
Position the completed Roof Support over the wall
sections. Once in place on all 4 sides, use 2”
screws to attach Roof Support to wall sections.
Use 4 evenly spaced screws per rail.
NOTE: Tap the Roof Support firmly in place
with a rubber mallet so wall sections are fully in-
serted into the groove before screwing into place.
Attach Roof Support over walls
17. Position ROOF SECTIONS
Place two Roof Sections on top of Roof Support,
nesting the tongue of one section into the groove
of the other. Measure around perimeter before fas-
tening to be sure distance from edge is equal.
NOTE: Finished side of Roof Sections are to face
the interior of the sauna with battens facing up.
Position Roof Sections
18. Fasten ROOF SECTIONS
Using 2” screws, fasten Roof Sections to Roof
Support using pre-drilled holes.
NOTE: Be sure to keep even distance from edge
of Roof Section edges and Roof Support edges
around perimeter of sauna as measured in step 17.
Fasten Roof Sections to Roof Support
15. Build ROOF SUPPORT
Assemble 4 roof support rails by angle-screwing
with 2” screws through the pre-drilled holes.
NOTE: Be sure that the rails are square and level
and that the screw head does not protrude into the
groove.

8
20. Attach UPPER BENCH
Using 2” screws, attach the Upper Bench to the
Bench Supports using the pre-drilled holes in the
Upper Bench.
NOTE: The Upper Bench is slightly wider than
the Lower Bench.
Attach Upper Bench
21. Attach LOWER BENCH
Using 2” screws, attach the Lower Bench to the
Lower Bench Supports using the pre-drilled holes
in the Lower Bench.
NOTE: The Lower Bench will overlap two wall
sections on each side of the sauna.
Attach Lower Bench
Attach Roof Trim pieces
19. Attach TRIM
Find the package of 4 Roof Trim pieces and attach
to the raw edge of the Roof Sections with finish
nails. Find the package of 2 Wall Trim pieces and
attach over the filler strip between sections F & H.
NOTE: The trim pieces are not pre-drilled. You
may install using finish nails.
22. Attach VENT COVER
Screw the Vent Cover over the vents on Wall
Section B using the pre-drilled hole.
NOTE: Tighten only enough so vent cover
will turn freely over vents.

9
23. Measure Height
for LONG BACK
REST
Measure the desired
position at which you
will later install the
Back Rest above the
Upper Bench.
(Suggested: 8-12”
above the bench and
centered on the wall.)
25. Attach LONG BACK
REST
Use 2” screws and pre-
drilled holes to attach the
Long Back Rest to Wall
Sections B and C.
24. Drill Hole for LIGHT
CORD
The LED lighting comes in-
stalled on the back of the Back
Rest. Find the cord coming
from the light switch and drill
a small hole in Wall Section C
to insert the Light Cord
through so it comes through to
the outside of the sauna.
26. Mount POWER SUPPLY
Use provided screws to position
Power Supply where it is most con-
venient for you on the outside of
Wall Section C.
Optional: Secure excess wire with
zip tie or some other fastener as de-
sired.
27. Connect to POWER SUPPLY
Plug the Cord into the Power Supply. Plug the Power Supply into
any wall outlet, and flip the switch mounted on the back of the
bench to operate the LED light.
Cord from LED light
Power
Supply

10
28. HEATER INSTALLATION
Mount the heater as shown in the manufacturer's instructions. The heater should be
mounted on Wall Section E, over the vents and 7” from the floor of the sauna. All the
necessary hardware is supplied with the heater.
Drill a hole below and behind the heater to run the wire and/or conduit according to local
electrical codes. The heater will be hard-wired according to the specific wiring require-
ments for your heater.
Do not attempt to wire the heater yourself. Contact a licensed electrician in accordance
with your local electrical codes. Heater brand may vary depending on where the sauna
was purchased. Install sauna stones in accordance with heater manufacturer instructions.
Typical wiring requirements for distances of up to 30 feet from the breaker box are as follows:
4.5kw-6.0kw heaters require 10-2 w/ground, copper wire only, and 30amp non-GFCI breaker.
8.0kw 8-2 w/ground, copper wire only, and 40amp non-GFCI breaker.
29. Your fence kit will arrive
banded with stretch wrap. It
consists of four pieces, shown
here.
30. Prop up the first pre-assembled portion and attach the two long horizontal pieces.
Make sure the countersunk holes on the wall mounting bracket face inward.
31. Attach the final piece—the
remaining pre-assembled portion.
32. Position the fence around the heater and use the pre-drilled holes to attach it to the
wall.

11
33. Attach DOOR KNOB
Take the two sections of the door knob and insert
the thread through the hole in the door. Tighten so
that handles are snug to glass.
NOTE: Hand tighten only and be sure rubber gas-
ket is between knob and glass.
Attach Door Knob on Door

12
OPERATION
After the sauna has been installed, sweep down the inside to remove any sawdust and wood shavings, and then
vacuum completely. Using a damp cloth and warm water, wipe down the entire sauna including the benches to
remove any remaining dirt, dust and debris. Rinse off the sauna stones and install them in or on the heater in
accordance with the heater manufacturer’s instructions. Improper placement of heater stones can result in low-
er than desired heat temperatures. The first time you turn the heater on, set it to the maximum setting and
operate it for about 30 minutes with the door propped open. Then close the door and allow your sauna to come
up to the desired temperature.
Since you most likely will use your sauna as both a "wet sauna" and a "dry sauna", you should install the sauna
stones that have been included with the heater, following the manufacturer’s instructions. These stones are
necessary if water will be sprinkled on the heater to create the "wet sauna", and they will produce more
consistent heating in the dry mode (without the use of water). It is common for a stone to occasionally crack
during initial heating. If excess amounts of water are used during sauna, prop door open to let the humidity es-
cape. Not much water is necessary to achieve a “wet sauna”.
The amount of ventilation in the sauna can be adjusted by means of the vent located toward the top of the sau-
na. It is important to have adequate fresh air flowing through the sauna, and this flow can be adjusted with the
movable vent cover.
TRADITIONAL STEPS IN TAKING A SAUNA BATH
STEP #1 - Set your heater so that the sauna room achieves the desired temperature, usually between 150º F and
170º F. As a novice, you should begin at the lower end of this range and work your way up to the higher
temperatures over several sauna baths.
STEP #2 - Remove all clothing (except maybe your swimsuit), eyeglasses, contact lenses, jewelry, etc. Take a
quick shower with warm water and soap, or a quick dip in your hot tub.
STEP #3 - Enter the sauna initially for about 5 to 15 minutes. Bring a towel into the sauna onto which you can
sit or lay. Leave the sauna room once you have begun to perspire freely.
STEP #4 - Now you may take a cold plunge in your swimming pool, shower or snow bank. After that, relax and
cool down for another 10 to 20 minutes.
STEP #5 - Re-enter the sauna. On this return visit you may wish to sprinkle small amounts of water onto the
stones creating bursts of steam. If the water spills through the heater and onto the floor, you are using too much,
although this will not hurt the heater or the sauna.
STEP #6 - After your final visit to the sauna, relax for at least 20 minutes. Shower with soap and warm water.
Finish your shower with cooler water to close the pores of your skin. Dress only after you have cooled down
completely.
NOTE: Whatever your sauna regimen, it is important that you keep yourself hydrated by drinking plenty
of water!
