Alphatech IP Bell User manual

ALPHATECH TECHNOLOGIES s.r.o.
Jeremenkova 88, Praha 4, Czech Republic
www.alphatechtechnologies.cz
Quick Setup Guide for the IP Bell door entry phone station
SIP based door entry intercom
Access control
access codes via buttons
optional integrated RFID reader module (EM Marin / HID)
External IP camera connection
optional connection of an external IP camera (integrated RFID
reader module required)

ALPHATECH TECHNOLOGIES s.r.o.
Jeremenkova 88, Praha 4, Czech Republic
www.alphatechtechnologies.cz
Opening the cover
Use a standard screwdriver or you can replace the standard supplied
screw by an Allen key screw. Open the cover.
To change the button labels, look at figures below.

ALPHATECH TECHNOLOGIES s.r.o.
Jeremenkova 88, Praha 4, Czech Republic
www.alphatechtechnologies.cz
Wiring and mouting on the wall
Remove the Cover as per above figure.
Feed the Ethernet cable through the cable hole.
Fix the door phone to the wall using a template, screws and rawlplugs.
Pay attention to the appropriate installation height as shown on the figures below.

ALPHATECH TECHNOLOGIES s.r.o.
Jeremenkova 88, Praha 4, Czech Republic
www.alphatechtechnologies.cz
In order for backlight, heating of the circuit board (to avoid condensation) and to power a
lock, a 12VDC 1A power supply is required. Refer to manual.
There are two options to control external devices e.g. Lock, Light, Bell. Either NO (Normally
Open) or NC (Normally Closed). Refer to the figure below.

ALPHATECH TECHNOLOGIES s.r.o.
Jeremenkova 88, Praha 4, Czech Republic
www.alphatechtechnologies.cz
Closing the cover
Close the front cover as shown on the figure.
Quick Setup
Set the jumper to either peer to peer (without an IP PBX or IP Telco) or
SIP server for the door phone to register against an IP PBX or IP Telco.
The DoorPhone comes with a static IP address of 192.168.1.250 with
username: admin and password: 1234
Programming the Door Phone
Change your PC IP address within
the range of 192.168.1.x
Open your browse and point to
192.168.1.250
Enter username: admin and
password: 1234
For more advanced options, please
refer to the manual.

ALPHATECH TECHNOLOGIES s.r.o.
Jeremenkova 88, Praha 4, Czech Republic
www.alphatechtechnologies.cz
Customer at front door (Door Phone)
When a customer comes to the front door, he presses one of the buttons, the unit then dials the
destination number or IP address that is preprogrammed. The staff member answering the call, can
talk to the customer at the front door and to let the staff member in the front door, the staff
member presses 55 on his handset to open the door.
Authorised staff member at the door (Door Phone)
When an authorised staff member comes to the front door, he can release the electrical lock and
open the door by dialling a secret access code via buttons of the doorphone. There can be different
access codes for day and night mode. E. g. the secret access code for the day mode is 22121. By
dialling 22121 (i. e. by pressing the first button twice, the second button once and again the first
button once), the door lock is released and the staff member can open the door. This feature can be
disabled, e.g. during the night mode.
Another option is to use an add-on, integrated RFID module (EM Marin 125kHz / HID). All staff
member cards/keyfobs can be administered manually or via PC (RS485/Ethernet coverter is required
for PC connection and administation). All events can be stored into SQL db, an external IP camera can
be connected, images from the camera can be recorded and stored, etc.
