alpro EB501-22 User manual

Electric Mini Bolt
EB501-22 - Instructions
412
M
47
02
OF DOOR
DOOR
PREPARTION
OF DOOR
22.4
11.2 8
85.4
71
8
50
8
8
22.4 11.2
7
7150.4
136
4.1 x 2
M4 x 0.7 x 2
50 REF
7 91.5 44.5 7
150
2.5
118 1616
30
12
12
4
Technical Information
Power to Lock/Fail open monitored
Stainless steel bolt - diameter 12mm
- throw 12mm
Voltage required 12vDC
Activating current 0.7A
Holding current 100 mA
Fully protected against transients and
reverse polarity
he Autolock ime Delay can be set for
0, 3, 6 or 9 seconds.
Monitoring - Door position switch (DSS)
GENERAL INSTALLATION
INSTRUCTIONS
Ensure you have the following:-
- Strike plate
- Electric bolt
All rebate strips and/or frame stops
should be fitted before starting.
A 2 amp Power Supply should be
provided to ensure there is a Full 1
amp for the bolt. his should allow
for a basic Access System and a
back up battery to be connected to
the same source.
ARNING - THE CONNECTION
OF AN INCORRECT VOLTAGE
MAY RESULT IN DAMAGE NOT
COVERED BY THE PRODUCT
ARRANTY.
he selection of appropriate power
supply cable is very important to
ensure lock receives sufficient power
to operate.
1
2
4
3
First Choice for Locking Solutions
012 0 2676262 01202 680101 [e-mail] www.alpro.co.uk
T F E
alpro®
EB501-22 Instructions:EB501-22 Instructions 1/8/07 17:52 Page 1

Electric Mini Bolt
EB501-22 - Instructions
Connect flying leads (+) Red (-)
Black. Note - other leads for
connection of LED via plug in lead
*NOT FOR PO ER INPUT*.
his product has been designed for
use in weather protected areas and
under normal circumstances does
not require any maintenance. DO
NOT OIL OR LUBRICATE.
his product must be used in
conjuction with a quality floor spring
or door closer to ensure positive
realignment on closing.
arranty
his product is guaranteed for a period
of 3 years against defects in
manufacture, workmanship or materials
provided that all electrical and
mechanical installation requirements are
adhered to as per this instruction sheet.
All third party and consequential claims
are expressly excluded from this
warranty.
6
7
5
NORMALLY OPEN
COM RATED:0.5A
VOLTAGE:12VDC
CURRENT:START 0.7A
STANDARD 100mA
p
s
POWER DC12V IN
WHITE
WHITE
A
RED
BLACK
wy
0 SEC 3 SEC 9 SEC
6 SEC
ON
12
ON
12
NO
2
1
19.5
41
7
4.1-2
991.5 44.5 9
11
4.1-2
150
85
22
2. 5
2.5 22
7
22
12
R6.75*2
R2*4
R2*4
7
15
10
26
12
20
1.5
R2*4
1.5
M4P0.7*2
Autolock Tim D lay S ttings
S tting Switch
0120 2676262
0 1 2 0 2 6 8 0 1 0 1
alpro@i cltd.co.uk
www.alpro.co.uk
T
F
E
W
I
IE EC CL Li im mi it te ed dHarw ll Road Nuffi ld Estat Pool Dors t BH17 0BD Gr at Britain
R gist r d in England 1925537
© July 2007 IEC. All rights r s rv d.
All dim nsions ar nominal and subj ct to tol ranc s
EB501-22 Instructions:EB501-22 Instructions 1/8/07 17:52 Page 2
