Introduction
Ecosmart® Technology
The Alto-Shaam Combitherm combination
oven/steamer employs Ecosmart operating
efciencies in the design and application of
all operating and programming functions.
Ecosmart operational characteristics include
the use of a water barrier to close the oven
compartment to the outside air. While maintaining a
non-pressurized atmosphere, the primary purpose of
the Ecosmart system is to prevent the steam and heat
generated within the oven compartment from freely
escaping to the outside.
The Ecosmart design displaces the air within the cooking
compartment and achieves a higher level of steam
saturation that offers quick-steaming at temperatures
above 212°F (100°C).
This guide is provided as an operational aid with
step-by-step instructions of the basic functions of the
Combitherm oven, along with the many other additional
features of the control.
STEAM MODE
COMBINATION
MODE
CONVECTION
MODE
RETHERM MODE
PROtouch™ Control
The Combitherm PROtouch control features a simple,
graphics-based control panel that commands all the
oven functions. Access your titled recipes. Manual
cooking by time and temperature also are easily
accomplished.
Intuitive interface - The Alto-Shaam PROtouch
offers a simple interface that commands all of the
Combitherm’s cooking functions. As the name
implies, it is fully operable by touch.
Graphic controls - The highly visual graphic-based
control with logical procedures ensure that correct
steps are followed every time.
An excellent memory - Access an unlimited number
of programmed titled recipes that you’ve customized.
Each recipe can have up to 10 sequential steps.
HACCP data access -
CT PROformance™ ovens include a downloadable
HACCP function.
Absolute Humidity Control™ - provides 0-100%
humidity levels allowing more control over the ideal
cooking environment and product nish [patent
pending].
Powerful tool - The PROtouch control plays an
important part in our continuous improvement
process. New features and abilities can be loaded to
your oven as they become available. Simply call our
Service Department for assistance.
Superior baking - The ve-speed fan provides
consistent baking results. A moisture injection feature
provides perfect sheen and crust on breads and pastry
items.
Multi-shelf timers - Track cooking time of different food
items in the same oven with multi-shelf timers. Time is
tracked in minutes and seconds.
On-board diagnostics - The PROtouch control includes
on-board diagnostic functionality with results displayed
right on the touch screen.
Two power levels: reduced power to manage kitchen
power peaks, and eco power for optimal oven efciency.
PROpower™ power level option - an accelerated turbo
power for an instant boost of heat or quick heat recovery
[patent pending].
Multiple languages: soware operation in English,
French, German,Korean, Mandarin, Russian, or Spanish.

6 • MN-35949 • Rev 04 • 06/16 • Combitherm® CT PROformance™ Series • Technical Service Manual
Safety Procedures
CAUTION
Used to indicate the presence of a hazard that can or
will cause minor personal injury, property damage, or a
potential unsafe practice if the warning included with this
symbol is ignored.
CAUTION
Used to indicate the presence of a
hazardthat can or will cause minor or
moderate personal injury or property
damage if the warning included with this
symbol isignored.
DANGER
Used to indicate the presence of a
hazardthat will cause severe personal
injury, death, or substantial property
damage if the warning included with this
symbol is ignored.
WARNING
Used to indicate the presence of a
hazardthat can cause personal injury,
possible death, or major property
damageif the warning included with this
symbol is ignored.
• This appliance is intended to cook, hold or process foods
for the purpose of human consumption. No other use for
this appliance is authorized and is therefore considered
dangerous. The appliance must not be used to cook
food containing ammable materials (such as food with
alcohol). Substances with a low ash point can ignite
spontaneously and cause a re.
• This appliance is intended for use in commercial
establishments where all operators are familiar with
the purpose, limitations, and associated hazards of this
appliance. Operating instructions and warnings must
be read and understood by all operators and users. We
recommend regular training of your staff to avoid the
risk of accident or damage to the appliance. Operators
must also receive regular safety instructions.
• Any troubleshooting guides, component views, and
partslists included in this manual are for general
reference only and are intended for use by qualied and
trained technicians.
• This manual should be considered a permanent part of
this appliance. This manual and all supplied instructions,
diagrams, schematics, parts lists, notices, and labels
must remain with the appliance if the item is sold or
moved to another location.
NOTICE: Used to notify personnel of installation,
operation, or maintenance information that is
important but not hazard related.
Knowledge of proper procedures is essential to the
safe operation of electrically and/or gas energized
equipment. The following hazard signal words and
symbols may be used throughout this manual.
Used to indicate that referral to operating
instructions is a mandatory action. If
not followed the operator could suffer
personalinjury.
Used to indicate that referral to operating
instructions is recommended to understand
operation of equipment.
NOTICE: For equipment delivered for use in any
location regulated by the following
directive: 2012/95/EC WEEE
Do not dispose of electrical or electronic
equipment with other municipal waste.

MN-35949 • Rev 04 • 06/16 • Combitherm® CT PROformance™ Series • Technical Service Manual • 7
Safety Procedures
• To prevent serious injury, death or property damage,
your appliance should be inspected and serviced
at least every twelve (12) months by an authorized
service partner or trained technician.
• ONLY allow an authorized service partner or trained
technician to service or to repair your appliance.
Installation or repairs that are not performed by an
authorized service partner or trained technician, or
the use of non-factory authorized parts will void the
warranty and relieve Alto-Shaam of all liability.
• When working on this appliance, observe precautions
in the literature, on tags, on labels attached to
or shipped with the appliance and other safety
precautions that may apply.
• If the appliance is installed on casters freedom of
movement of the appliance must be restricted so
that utility connections (including gas, water, and
electricity) cannot be damaged when the appliance is
moved. If the appliance is moved, make sure that all
utility connections are properly disconnected. If the
appliance is returned to its original position, make
sure that any retention devices and utility connections
are properly connected.
• ONLY use the appliance when it is stationary. Mobile
appliance racks, mobile plate racks, transport trolleys,
andappliances on casters can tip over when being
moved over an uneven oor or threshold and cause
serious injury.
• ALWAYS apply caster brakes on mobile appliances or
accessories when these are not being moved. These
items could move or roll on uneven oors and cause
property damage or serious injury.
• Be extremely careful when moving appliances
because the food trays may contain hot uids that may
spill, causing serious injury.
• ALWAYS open the appliance door very slowly.
Escaping hot vapors or steam can cause serious injury
or death.
• If your gas appliance is installed under an exhaust
hood, the hood must be switched ON when the
appliance is in use to avoid the build up of combustion
gases. Failure to do so may result in serious injury,
death or property damage.
• NEVER place objects near the appliance exhaust
vents. Thisarea is hot and could be a potential ignition
source for a re.
• Do not allow objects to block or obstruct the area
below the appliance base. This may result in re,
damage to the equipment or serious injury.
• Do not use the attached hand-held hose to
sprayanything other than the interior of the
appliancecompartment.
• Do not use the attached hand-held hose on the
surface of a hot cooking compartment. The
suddentemperature change can damage the appliance
interior. Allow the appliance to cool to a minimum of
150°F(66°C). Failure to observe this precaution can
void the warranty.
WARNING
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision
concerning use of the appliance by person
responsible for their safety.
Children should be supervised to ensure
that they do not play with the appliance.

8 • MN-35949 • Rev 04 • 06/16 • Combitherm® CT PROformance™ Series • Technical Service Manual
Safety Procedures
CAUTION
To prevent SEVERE PERSONAL INJURY or
PROPERTY DAMAGE:
ALWAYS use hand protection when
operating this appliance to avoid burns.
Metal parts of this equipment become
extremely hot when in operation.
NOTICE: Automatic steam venting is a standard safety
feature built into all Combitherm oven models.
This feature vents all steam from the oven
compartment immediately before cooking time
expires or set probe temperature is reached.
Automatic steam venting does not function if the
oven door is opened before time expires or when
the oven has been set to continuous operation.
NOTICE: Use authorized Combitherm oven cleaner only.
Unauthorized cleaning agents may discolor or
harm interior surfaces of the oven. Read and
understand label and material safety data sheet
before using the oven cleaner.
LA-22026
CAUTION
To prevent INJURY or PROPERTY DAMAGE,
make certain the area around the appliance
is kept clear of combustible items.
DANGER
To prevent serious personal injury, death, or
property damage:
Do not steam clean, hose down or flood the
interior or exterior with water or liquid solution
of any kind. Do not
use water jet toclean. Failure
to observe this precaution will void the warranty.
WARNING
To prevent SERIOUS PERSONAL INJURY or
PROPERTY DAMAGE:
DO NOT handle pans containing liquid or
semiliquid products positioned above the
eye level of the operator. Such products
may scald and cause serious injury.
LA-22026
WARNING
To prevent SERIOUS PERSONAL INJURY,
DEATH, or PROPERTY DAMAGE:
The appliance must be cleaned thoroughly
to avoid deposits of grease and or food
residues inside the appliance that may
catch fire. If fat deposits and/or food waste
inside the appliance ignite, shut down
the appliance immediately and keep the
appliance door closed to extinguish the
fire. If further extinguishing is required,
disconnect the appliance from the main
power and use a fire extinguisher (do not
use water to extinguish a grease fire!).
Failure to clean the appliance properly
invalidates the warranty and relieves
Alto-Shaam of all liability.
WARNING
DO NOT obstruct or block exhaust flues
or attach any flue extension that may
impede proper burner operation, restrict
the exhaust fumes and cause negative
backdra or the appliance to shut down.
Failure to do so may result in serious injury
or death.

MN-35949 • Rev 04 • 06/16 • Combitherm® CT PROformance™ Series • Technical Service Manual • 9
Operation — CTP
CT PROformance™ Start-Up
Procedures
Turn on exhaust hood.
Turn on water supply.
Turn on gas supply valve (if applicable).
Turn on main electrical power to appliance.
Press Power ON icon on the
appliance control panel.
The oven will automatically ll the steam generator
equipped models with water that will heat to a stand-by
mode temperature of 188°F (77°C).
NOTE: To power off the appliance, press and hold the
power icon for 5 seconds to initiate power shut
down sequence to the oven. Oven will not shut
down during a cooking cycle. From time to time,
the control may become unresponsive. ONLY
when this happens, rmly press and hold the
power key for 10 seconds to power down the oven.
When the oven is powered
on, the PROtouch screen
illuminates. “Loading”
indicates that the soware
is booting up. The screen
will also indicate what level
of progress has been made
as the soware becomes
fully operational.
If, for any reason, the oven is turned off or loses power
during this start-up process, the operator will be
prompted to calibrate the Touch screen when the oven is
next powered up.
Return to Home Screen - Press the red arrow if the
PROtouch™ screen does not need to be calibrated.
Begin Calibration Process - Press the green check
mark if the Touch screen does need to be calibrated. The
screen will switch to a grey background. See illustration
at right. A crosshairs icon will appear. The operator
should touch the center intersection using a stylus for an
accurate calibration. This prompt and required action will
be repeated several times in different areas of the Touch
screen. When complete, the operator will be returned to
the Home screen.
NOTICE: Accumulations on the main burners can result
in ring out of normal sequence. This delayed
ignition creates an alarmingly loud sound. If
your appliance makes an especially loud noise
when starting up, shut down your appliance and
call a qualied and trained service technician.
In the event of a power failure, the oven will not
operate.
DANGER
Before starting the appliance, make certain
you do not detect the odor ofgas.
If you smell gas:
• Shut off the gas supply immediately.
• Do not attempt to light any appliance.
• Do not touch any electrical elements.
• Extinguish any open flame.
• Evacuate the area.
• Use a telephone outside the property and
immediately contact your gas supplier.
• If unable to contact your as supplier,
contact the fire department.

10 • MN-35949 • Rev 04 • 06/16 • Combitherm® CT PROformance™ Series • Technical Service Manual
Operation — CTP
Control Panel Identication
Download Recipes from
USB stick — overwrites
any existing recipes Upload all recipes
from control to a
USB stick
Add all recipes on a
USB stick to the list of
recipes on the oven
leaving all other recipes
on the oven untouched Upload HACCP
info to USB stick
*Download new
soware from a
USBstick
Upload audit trail
info to USB stick
Upload odometer
info to USB stick
Return to
previous screen
Upload/Download Screen
Upload/Download
Settings
Service Mode
(password protected)
Utility Screen
Return to
home screen
Soware Version
Return to
previous screen
Professional
Cooking Mode
Cookbook with
Saved Recipes
Utilities
CleaningSleep Mode Information
Call outs
*The PROtouch control plays an
important part in our continuous
improvement process. New features
and abilities can be loaded to your
oven as they become available.
Soware for your oven can be
accessed from the Alto-Shaam
website, under the Downloads tab.
Control Panel Identication

MN-35949 • Rev 04 • 06/16 • Combitherm® CT PROformance™ Series • Technical Service Manual • 11
Operation — CTP
Full oven update:
IB, CB, and OB
Update the CB
(control board) only
Update the OB
(option board) only
Update the IB
(interface board) only
Return to
previous screen
Soware Upload Screen
NOTICE: Aer the soware update has
been completed, the oven may
automatically initiate a shut down
and reboot sequence if required.
Press on button to power oven on.
Touch the utilities icon.
Touch the download icon.
Touch the download new soware icon.
Most soware updates will require the full oven update
as shown below. Additional options are available in the
event a special need arises. Call our Service Department
for assistance with these special circumstances.
Remove the cap of the USB port on the oven.
Insert the USB stick. If the USB stick is not recognized
by the Combitherm, a question mark will appear on
screen. Try again with another ash drive device or call
Alto-Shaam Service.
When the data has made a
successful transfer to the USB
drive, the screen will change.
Touch the green check mark
key to complete the process.
Remove the USB stick and
replace the cap on the USB port
on the oven.
Soware Updates
The PROtouch control plays an important part in our continuous improvement process. New features and abilities can
be loaded to your oven as they become available. Soware for your oven can be accessed from the Alto-Shaam website,
under the Resource Library Tab, then Soware Center. http://www.alto-shaam.com/en/soware-download-center
Use a USB stick to copy the PROtouch software from the website to the USB stick.
Soware Updates

12 • MN-35949 • Rev 04 • 06/16 • Combitherm® CT PROformance™ Series • Technical Service Manual
Operation — CTP
Control Panel Identication
Fahrenheit /Celsius
Use factory
default settings
Handle LED on
Lock recipes
Beeper volume
& alarm clips
Recipe display
names off
Screen brightness
Return to
previous screen
Settings Screen 1
Settings Screen 2
Keep last user setting
Handle LED off
Unlock recipes
Screen 1 of 2
Date/Time
Preventative
Maintenance Actions
Return to
utility screen
Calibrate product probe
Run diagnostics
Screen 2 of 2
Advance to next
setting screen
Return to previous
setting screen
When a setting has been selected, the
graphic will be vibrant in color while the
alternate choice will appear faded and
gray. In the illustration above, Fahrenheit,
factory default setting, handle LED on,
recipe display with text, and recipes are not
locked have been chosen.
Language Choices
Language choices available: English,
French, German, Korean, Mandarin,
Russian, or Spanish.
Recipe display
names on
NOTE: A password is required to lock
and unlock the recipes. Simply
call an Alto-Shaam Culinary
Chef for assistance.
Future Feature
(not yet available)
Force Boiler Flush
Time format available:
12-hour clock
24-hour clock
Different date formats
available: YYYY/MM/DD
MM/DD/YYYY
DD/MM/YYYY

MN-35949 • Rev 04 • 06/16 • Combitherm® CT PROformance™ Series • Technical Service Manual • 13
Operation — CTP
Control Panel Identication
Cleaning Timer
Water Filter
Replacement
Gasket Inspection
Boiler De-Liming
Return to
previous screen
Preventative Maintenance Screen
Ventless Hood
Filter Replacement
Utilities
Return to
home screen
Increase or decrease alarm setting
to match your preferred timelines.
Press item to edit
Aer the task has been completed,
set elapsed time to 0 to begin
countdown process again.
Return to
previous screen
Preventative Maintenance - Editing
Utilities
Return to
home screen

14 • MN-35949 • Rev 04 • 06/16 • Combitherm® CT PROformance™ Series • Technical Service Manual
Operation — CTP
Cooking Screen Identication
Cook Time is displayed as
hours : minutes : seconds
Steam
Mode
Oven Temperature
Cook Time
Probe Temperature
Preheat
Start
UtilitiesWrite
Recipe
Combi
Mode
Convection
Mode Retherm
Mode
Cool Down
Return to
previous screen
Return to
Home Page
Enter
Chosen
Cooking
Mode
Chosen
Entry
Field
Allowable
Temperature
Range
Entry Keypad
Return to
previous screen
NOTE: When a cooking mode has been selected, it will appear darker
blue. When the cooking mode is calling for heat, it will appear red.
When the cooking mode is calling for moisture, it will appear light
blue. In the illustration above, Combi Mode has been chosen and is
calling for heat. Also, the PROpower™ level has been chosen, and
the fan speed has been set at 100%.
Cooking Screen Identication

MN-35949 • Rev 04 • 06/16 • Combitherm® CT PROformance™ Series • Technical Service Manual • 15
Operation — CTP
Auxiliary Functions and Features
Power Settings
Two power levels: reduced power to manage kitchen
power peaks, and eco power for optimal oven efciency.
A third choice is optional on electric models, but
standard on gas models. PROpower™ is an accelerated
turbo power for an instant boost of heat or quick heat
recovery [
patent pending
].
NOTE: Reduced power will result in longer cooking
times and PROpower will decrease your cooking
time by several minutes.
Reduced Power
Return to previous screen to
set the remaining auxiliary
functions for full functionality
Eco Power
PROpower
Power level icon appears
during operation
Reduced Power Level
Multiple Fan Speeds
The PROtouch™ control includes five different fan
speeds. The reduced fan speed function is useful for
flow-sensitive products such as soufflés and meringues, or
any products affected by a high velocity of air movement.
NOTE: Fan speed choices are based upon the power
level you have chosen.
Chosen
Cooking
Mode
Chosen
Temperature
Return to
previous screen
Timer countdown in process,
Touch red square to stop
Time value, touch this area
to change the time value
Timer ready, touch
green arrow to begin
Touch shelf number to
enter a recipe identifier
(text or number)
Multi-Shelf Timer
The multi-shelf timer allows the operator to program
alarm times for the oven shelves. This can be one
common time for corresponding oven shelves or by
food item that is cooking. The multi-shelf timer can
be edited when in a recipe mode.
Eco Power Level
PROpower™ Power Level
Fan speed choices
Auxiliary Functions and Features

16 • MN-35949 • Rev 04 • 06/16 • Combitherm® CT PROformance™ Series • Technical Service Manual
Operation — CTP
Auxiliary Functions and Features
Preheat Feature
The oven should be preheated before most cooking
functions. When cooking full loads, use a temperature
50°F (10°C) greater than the cook temperature in order
to recover from heat loss when the door is opened
to add food to the oven. For items that use the Steam
mode, it is necessary to use a preheat temperature
lower than the cook temperature in order to create the
proper amount ofsteam.
Press the On button to power oven on.
Touch the Preheat icon.
Type in desired temperature.
Touch the green Check Mark icon to
startpreheating.
Preheat Cool Down
Return to
previous screen
Cool Down Feature
The cool-down feature provides the operator with
the ability to lower the temperature of the oven
compartment at an accelerated pace. This function
is useful when it is necessary to immediately change
from a high temperature cooking function to a lower
temperature function or to the steam program.
This function is also useful to help cool the oven
compartment in preparation for cleaning.
TIP: Always allow the oven walls to cool to a minimum
of 140°F (60°C) before spraying the compartment
with oven cleaner.
Open the oven door.
Touch the Cool Down icon.
Type in desired temperature.
Touch the green Check Mark icon to beginthe
Cool Down process.
The target oven temperature chosen will appear
just above the red Stop button.
The current oven temperature will appear at the
top of the screen.
Touch to Stop

MN-35949 • Rev 04 • 06/16 • Combitherm® CT PROformance™ Series • Technical Service Manual • 17
Operation — CTP
Auxiliary Functions and Features
Humidity Control Feature
The humidity control feature is an automatic
function designed to regulate humidity to provide
additional color to food as needed. This feature
is particularly useful for adding color to high
moisture products such as chicken and other
poultry, or for additional browning of full loads
and other moist products. In addition, this feature
may be used to add texture to fried items such
as french fries or breaded chicken. Humidity
control can be used in any cooking mode and can
be programmed into a cooking procedure.
Touch the nearest 10% increment on the le side
of the screen, and then adjust up or down using
the + or – icons.
0% humidity is the driest cooking environment
available. The percentage level chosen will
appear on the icon. In the illustration at right,
72% is shown.
Rapid Cool (available on boiler-free models only)
This function, when used with a program, rapidly
removes heat from the oven cavity. Swily move
from a high cooking temperature to a lower
temperature without overcooking your food.
Rest
This step allows you to pause the oven during a
program. The rest step is ideal for cold smoking
or automatic cleaning. Infuse your food with
smoke avor aer the actual smoking step has
stopped. When used during the cleaning process,
the oven cavity soaks for a specied time before
you move into the next step.
Door
The door function allows the user to program
a reminder—in the form of an animated door
opening and closing—that it is time to open the
door. This reminder may be programmed at the
end of a programmed segment or at the end of
the program.
Touch the check mark to
approve the value entered.
Humidity level choices
in increments of 10%
Chosen Humidity
Level % shown
Return to
previous screen
Return to
previous screen
Adjust humidity level up or
down in increments of 1%
Rapid Cool
(boiler-free models)
Rest
Door

18 • MN-35949 • Rev 04 • 06/16 • Combitherm® CT PROformance™ Series • Technical Service Manual
Operation — CTP
CT PROformance™ Factory Default Settings
Cooking Mode Oven Temperature Core Temperature Cooking Time
Steam 212°F
(100°C)
160°F
(70°C) 25 minutes
Combination Steam 350°F
(175C)
160°F
(70°C) 70 minutes
Convection 350°F
(175C)
160°F
(70°C) 30 minutes
Retherm 275°F
(135°C)
160°F
(70°C) 5 minutes

MN-35949 • Rev 04 • 06/16 • Combitherm® CT PROformance™ Series • Technical Service Manual • 19
Operation — CTP
The Steam mode provides the operator with the
ability to steam, poach, or blanch. This mode will
automaticallysteam at the boiling point of water; quick-
steam above the boiling point for faster cooking results;
or low temperature steam, below the boiling point, for
more delicate products such as pâté, mousse, seafood,
orcustard.
Press the On button to power oven on.
Touch the Professional Cooking mode icon.
Touch the Steam mode icon.
Touch the Start icon to steam at the
displayedsettings.
To Change the Displayed Settings:
Touch the area to the right of the
temperatureicon.
Type in desired temperature.
Touch the green Check Mark icon to
conrmchange.
• Automatic Steaming 212°F (100°C)
• Quick Steaming 213°F to 250°F (101°C to 120°C)
• Low Temperature Steaming 85°F to 211°F (30°C to 99°C)
To Cook by Time:
Touch the area to the right of the timeicon.
Type in desired time or set continuous time by
touching --:--.
Touch the green Check Mark icon to
conrmchange.
To Cook by Product Core Temperature:
Touch the area to the right of the probeicon.
Type in desired temperature.
Touch the green Check Mark icon to
conrmchange.
Insert probe into product.
Set available auxiliary functions as desired,
such as energy level, fan speed, multi-shelf
timer, etc.
Touch the Start icon to begin cooking in the
Steam mode.
• The cavity set-temperature will appear in the display.
• If cooking by probe, the actual internal product
temperature will appear next to the probe icon during
operation. To change the set value for core temperature,
touch the temperature next to the probe icon and make
changes as required.
When the cooking time has expired or the desired core
temperature has been reached, an alarm will sound and
handle light will ash several times indicating the end of
the operating mode.
Touch the red Stop icon to stop the buzzer or
open the oven door.
To stop cooking program at any time, touch the
red Stop icon.
CAUTION HOT
Use caution when opening the oven door when the
cooking chamber is hot to avoid possible burns.
Steam Mode

20 • MN-35949 • Rev 04 • 06/16 • Combitherm® CT PROformance™ Series • Technical Service Manual
Operation — CTP
The Combination mode will prove to be the most versatile
and widely used mode the Combitherm oven has to offer.
It will produce the best possible results on the widest
variety of products — all within the shortest period of
time. The unique control function of this mode enables
the operator to roast or bake with a combination of steam
and convection heat. In addition to shorter cooking times,
this combination of steam and heat offers less product
shrinkage and more moisture retention than obtained in a
convection oven.
Press On button to power oven on.
Touch the Professional Cooking mode icon.
Touch the Combination mode icon.
Touch the Start icon to cook at the displayed
settings.
To Change the Displayed Settings:
Touch the area to the right of the
Temperatureicon.
Type in desired temperature.
Touch the green Check Mark icon to
conrmchange.
• Cooking temperature range:
85°F to 575°F (30°C to 301°C)
To Cook by Time:
Touch the area to the right of the timeicon.
Type in desired time or set continuous time by
touching --:--.
Touch the green Check Mark icon to
conrmchange.
To Cook by Product Core Temperature:
Touch the area to the right of the Probe icon.
Type in desired temperature.
Touch the green Check Mark icon to
conrmchange.
Insert probe into product.
Set available auxiliary functions as desired,
such as energy level, fan speed, multi-shelf
timer, steam injection, etc.
Touch the Start icon to begin cooking in the
Steam mode.
• The cavity set-temperature will appear in the display.
• If cooking by probe, the actual internal product
temperature will appear next to the PROBE icon during
operation. To change the set value for core temperature,
touch the temperature next to the PROBE icon and make
changes as required.
When the cooking time has expired or the desired core
temperature has been reached, an alarm will sound and
handle light will ash several times indicating the end of
the operating mode.
Touch the red Stop icon to stop the buzzer or
open the oven door.
To stop cooking program at any time, touch the
red Stop icon.
Combination Mode
CAUTION HOT
Use caution when opening the oven door when the
cooking chamber is hot to avoid possible burns.
