Alto ENCORE R Programming manual

AMERICAN-LINCOLN
TECHNOLOGY
ELECTRICAL
TROUBLESHOOTING
GUIDE
ENCORE R
SCRUBBER
Beginning with Serial No. 178575
Part No. 2-86-00207 2001 Printed in the U.S.AAmerican-Lincoln Technology®

American-Lincoln Technology 1-1
ENCORE R Troubleshooting Guide
GENERAL STATEMENT ......................................................................................................................... 1-2
DRIVE MOTOR FORWARD .................................................................................................................... 1-3
DRIVE MOTOR REVERSE ..................................................................................................................... 1-4
SQUEEGEE CIRCUIT ............................................................................................................................. 1-5
VACUUM CIRCUIT .................................................................................................................................. 1-6
HORN, HOUR, AND CONDITION METER CIRCUITS .............................................................................. 1-7
LOW BATTERY SHUT DOWN CIRCUIT .................................................................................................. 1-8
SCRUB BRUSHES CIRCUIT ................................................................................................................... 1-9
BRUSHES AND SOLUTION OFF IN NEUTRAL CIRCUIT ......................................................................... 1-10
INDEX ..................................................................................................................................................... 1-11
TABLE OF CONTENTS

1-2 American-Lincoln Technology
ENCORE R Troubleshooting Guide
ELECTRICAL SERVICE GUIDE
ENCORE R (2)
CAUTION STATEMENT
As with all electrical equipment, caution is essential when doing electrical service. Remove all watches, rings
and jewelry before proceeding. Take care when doing power checks. Take time needed to place meter leads
correctly so as not to short to nearby terminals and/or electrical connections. Do not forget to disconnect
power at the battery when doing continuity checks or damage to your test meter may result. All Electrical
service should be done by a qualified technician experienced in DC voltage and DC testing equipment.
GENERAL STATEMENT
The following guide will present each electrical circuit separately, not including options, unless they are
in electrical series with the standard machine.
1. "Power Off" means key switch is turned off.
2. "Power Disconnect" means battery unplugged from the machine.
3. All voltages are taken with the battery plugged in and the key switch on unless noted otherwise.
4. All voltage readings are taken with the meter (-) lead connected to the battery (-) or the (-) side of the
condition meter unless otherwise specified.
5. All continuity readings are taken with the key switch off and the battery disconnected.
GENERAL STATEMENT

American-Lincoln Technology 1-3
ENCORE R Troubleshooting Guide
DRIVE MOTOR FORWARD
DRIVE MOTOR FORWARD
Conditions necessary for circuit to work
1. Battery voltage 36VDC
2. Key switch on
3. CB-4&5, FU1 closed
4. Solenoids 1A & 6 closed
5. Seat switch closed
36 V BATTERY BANK
CB-5
CB-4
70 AMP
FWD. MTR. SOL.
REV. MTR. SOL.
THE SEAT SWITCH JUMPS FROM
THE REV. SOL. TO 1A AND THEN
TO THE FWD. SOL.
FU-1
10 AMP
10 AMP
10A 10
11
11
7K
7K
11
11A
7,7C,7H,
77,77C,77D
2
3
12
12
25A
25V
25W
25W
25Y
25Y 25Y
25V
1T
1
1,1A,1B
AB
AM
3
25F
25G
25A
BATT.
IGN.
ACC
FIELD
S2
6A
5B
NEW MODULE
12
11 16
1A
1A
SEAT
SW.
B+
25X
25
25
25
25X
25X
19
C
C
D
C
M
ET-103
10A
10
W/BRN.
GRN.
ORG.
BLK.
BLK./WHT
WHT
FWD.
REV.
6
5
19
39
38
18
17
17
8
16 9
1
S1
A1
A2
A1
2+ HP
DRIVE MTR.
ARM
16 PIN
1207-1141
M- B- B+ A2
T0200/0002
T200
