Alto 2000 User manual

AMERICAN-LINCOLN
TECHNOLOGY
SMART 2000
Sweeper/scrubber
Part No. 2-86-00254 2001 Printed in theAmerican-Lincoln Technology® USA
Operator's Manual
Beginning with Serial No. 690060
All directions given in this book are as seen from the operator's position at the rear of the machine.
For new books, write to:
READ THIS BOOK
Alto U.S., Inc., 1100 Haskins Road, Bowling Green, Ohio 43402
This book has important information for the use and safe operation of this machine. Failure
to read this book prior to operating or attempting any service or maintenance procedure to
your machine could result in injury to you or to other personnel; damage to the machine or to
other property could occur as well. you must have training in the operation of this machine
before using it. If you or your operator (s) cannot read English, have this manual explained
fully before attempting to operate this machine.
Si Ud. o sis operadores no pueden leer el Inglés, se hagen explicar este manual completamente
antes de tratar el manejo o servicio de esta máquina.

AMERICAN-LINCOLNTECHNOLOGY 1 - 1
SMART2000
SPECIFICATIONS .................................................................................................................................. 1-4
MACHINEDIMENSIONS ........................................................................................................................1-6
STANDARD HARDWARE &TORQUEVALUES ......................................................................................1-7
HYDRAULICTORQUE REQUIREMENTS ...............................................................................................1-8
DECIMAL- METRICCONVERSIONTABLE ...........................................................................................1-9
MACHINEPREPARATION ......................................................................................................................1-10
PREPARINGTHEMACHINEFOROPERATION...............................................................................1-10
BATTERYPOWEREDMACHINE PREPARATION ............................................................................1-11
SAFETYINSTRUCTIONS .................................................................................................................1-12
OPERATIONOFCONTROLSANDGAUGES .........................................................................................1-15
LIGHTSWITCH................................................................................................................................. 1-15
HORNBUTTON ................................................................................................................................ 1-15
KEYSWITCH ...................................................................................................................................1-15
HOURMETER.................................................................................................................................. 1-15
BATTERYCONDITIONMETER ........................................................................................................1-16
BATTERYCONDITIONLIGHT ...........................................................................................................1-16
SEATPOSITIONADJUSTMENT .......................................................................................................1-16
FILTERSHAKERSWITCH ...............................................................................................................1-17
DUSTCONTROLSWITCH................................................................................................................1-17
MAIN BROOMAND SIDE BROOMSWITCH .................................................................................... 1-17
SIDEBROOMADJUSTMENT ...........................................................................................................1-17
MAINBROOMADJUSTMENT ..........................................................................................................1-17
SCRUBDECKSWITCH ...................................................................................................................1-18
SQUEEGEESWITCH ......................................................................................................................1-18
SOLUTIONCONTROLKNOB ...........................................................................................................1-18
LOWSOLUTIONLIGHT(WARNINGLIGHT) .....................................................................................1-19
RECOVERYHIGHLIGHT(WARNINGLIGHT)...................................................................................1-19
PARKING BRAKE ............................................................................................................................1-19
TURNSIGNAL(4-WAY)OPTION ......................................................................................................1-19
HYDRAULICRESERVOIRLEVELSIGHT GAUGE...........................................................................1-19
ACCELERATORandDIRECTIONALCONTROLPEDAL ...................................................................1-20
BACK-UPALARM SWITCH..............................................................................................................1-20
FILTERPANELKNOB ......................................................................................................................1-20
MAINBROOMCOMPARTMENTDOOR ...........................................................................................1-21
HOPPERLIFTSWITCH....................................................................................................................1-21
ESPSYSTEMOPERATINGINSTRUCTIONS .........................................................................................1-22
THESCRUBBING SYSTEM- HOWITWORKS ............................................................................... 1-22
THENON-RECYCLING ORSTANDARD SCRUBBINGSYSTEM -HOW ITWORKS ........................1-22
RECOVERY OR ESP SYSTEM - HOW IT WORKS .........................................................................1-22
OPERATINGINSTRUCTIONS .................................................................................................................1-23
BEFORESTARTINGTHEENGINE...................................................................................................1-23
PRE-STARTCHECKLIST..................................................................................................................1-23
STARTINGBATTERYMACHINES ....................................................................................................1-23
POST-OPERATIONCHECKLIST.......................................................................................................1-23
SERVICECHART ...................................................................................................................................1-24
HELPFULHINTSFORCLEANINGOPERATION .....................................................................................1-26
SERVICEPRECAUTIONS ......................................................................................................................1-27
SERVICEINSTRUCTIONS ......................................................................................................................1-28
MAINBROOM .................................................................................................................................. 1-28
CHECKINGTHEMAIN BROOM SWEEPPATTERN.........................................................................1-28
ADJUSTINGTHEMAINBROOM HEIGHT ........................................................................................1-28
REPLACINGTHEMAINBROOM .....................................................................................................1-28
MAINBROOMLEVELADJUSTMENT ..............................................................................................1-28
SIDEBROOM .................................................................................................................................. 1-29
CHECKINGTHESIDE BROOM SWEEPPATTERN .........................................................................1-29
TABLE OF CONTENTS

1 - 2 AMERICAN-LINCOLNTECHNOLOGY
SMART 2000
REPLACINGTHESIDEBROOM ......................................................................................................1-29
HOPPER ..........................................................................................................................................1-30
CLEANINGTHEHOPPER................................................................................................................1-30
ADJUSTINGTHEHOPPERSWITCH................................................................................................1-30
DUSTCONTROLFILTER ..................................................................................................................1-30
CHECKINGTHEDUSTCONTROLFILTER .......................................................................................1-30
CLEANINGTHEDUSTCONTROLFILTER........................................................................................1-30
REPLACINGTHEDUSTCONTROLFILTER .....................................................................................1-31
DUSTFLAPS ...................................................................................................................................1-31
CHECKINGTHEDUSTFLAPS ........................................................................................................1-31
ADJUSTINGTHEDUSTFLAPS .......................................................................................................1-31
BRAKES ..........................................................................................................................................1-32
ADJUSTINGTHE BRAKEPEDAL ....................................................................................................1-32
ADJUSTINGTHEBRAKES ..............................................................................................................1-32
ADJUSTINGTHEFOOTTHROTTLESWITCH...................................................................................1-32
GENERALMACHINEMAINTENANCE....................................................................................................1-33
FILLINGTHEHYDRAULICRESERVOIR ..........................................................................................1-33
CLEANINGTHEHYDRAULIC SYSTEM ...........................................................................................1-33
REPLACINGTHERETURNFILTERELEMENT ................................................................................1-33
REPLACING THESCRUB BRUSH ...................................................................................................1-34
ADJUSTINGTHESCRUDDECK ......................................................................................................1-34
COVERSANDLATCHES .................................................................................................................1-34
SOLUTIONLOWWARNINGLIGHT ..................................................................................................1-34
RECOVERYHIGHWARNINGLIGHT ...............................................................................................1-34
SOLUTIONCONTROL ......................................................................................................................1-34
RECYCLINGPUMP ESP SYSTEM..................................................................................................1-35
RECYCLINGPUMPSTORAGE........................................................................................................1-35
REARSQUEEGEE ..........................................................................................................................1-35
ADJUSTINGTHEREARSQUEEGEELIFT.......................................................................................1-35
SQUEEGEECASTER WHEELS ......................................................................................................1-35
ADJUSTINGCASTERS ....................................................................................................................1-35
EMPTYINGTHERECOVERYTANK ................................................................................................1-36
PARTSLIST LEGEND............................................................................................................................ 1-37
HARDWARELEGEND ............................................................................................................................ 1-38
ORDERINGPARTS ................................................................................................................................ 1-44
ELECTRICALSCHEMATIC (BATTERY) ..................................................................................................1-45
CONNECTION-HARNESS ROUTING (BATTERY) .................................................................................1-46
HYDRAULICSCHEMATIC(BATTERY) ...................................................................................................1-47
CHAPTER2(PARTSLIST) ..................................................................................................................... 2-1
MAINBROOM ..................................................................................................................................2-2
MAIN BROOM BAFFLEAND FLAPS ............................................................................................... 2-6
SIDEBROOM (12V & 36V) .............................................................................................................. 2-8
HOPPERASSEMBLY (12V & 36V BATTERY) ................................................................................. 2-10
SCRUBDECKACTUATOR ...............................................................................................................2-12
SCRUBDECKASSEMBLY(40”) ......................................................................................................2-14
SCRUBDECKASSEMBLY(46”) ......................................................................................................2-17
SIDESQUEEGEE (40”)....................................................................................................................2-19
SIDESQUEEGEE (46”)....................................................................................................................2-20
REARSQUEEGEE (40”) .................................................................................................................. 2-22
REARSQUEEGEE (46”) .................................................................................................................. 2-24
REARSQUEEGEE LIFTSYSTEM (12VAND 36V) ..........................................................................2-26
SWINGSQUEEGEE SUPPORT ...................................................................................................... 2-28
SOLUTIONTANK ............................................................................................................................. 2-30
SOLUTIONCONTROL ......................................................................................................................2-32
RECOVERYTANK ...........................................................................................................................2-34
TABLE OF CONTENTS

AMERICAN-LINCOLNTECHNOLOGY 1 - 3
SMART2000
FORWARDAND REVERSECONTROL(BATTERY).........................................................................2-36
BRAKE ASSEMBLY .........................................................................................................................2-38
FRONTWHEELASSEMBLY............................................................................................................ 2-40
REAR WHEELASSEMBLY.............................................................................................................. 2-42
FRONTCOVERANDLATCHASSEMBLY ........................................................................................2-44
SEATASSEMBLY ............................................................................................................................2-46
ACCESSPANELS ...........................................................................................................................2-47
ROLLOUTBATTERY .......................................................................................................................2-48
DUSTCONTROL(BATTERY) ...........................................................................................................2-50
VACUUMMANIFOLD SYSTEM .......................................................................................................2-54
HYDRAULICMOTORANDPUMPASSEMBLY ................................................................................2-56
MOTORANDPUMP MOUNTINGASSEMBLY................................................................................. 2-58
HYDRAULICRESERVOIRASSEMBLY ............................................................................................2-59
HYDRAULICFILTERANDSOLENOIDASSEMBLY ..........................................................................2-60
HYDRAULICCONNECTIONDIAGRAM ............................................................................................2-62
POWERPANEL(36V) .....................................................................................................................2-64
POWERSTEERING .........................................................................................................................2-66
ELECTRICALPOWER PANEL(36V) ...............................................................................................2-68
INSTRUMENTPANEL ......................................................................................................................2-70
DECALS...........................................................................................................................................2-74
CHAPTER3(OPTIONS) ......................................................................................................................... 3-1
BACK-UPALARM (12V & 36V) ........................................................................................................ 3-2
BATTERYSTAND .............................................................................................................................3-3
ESP (12V & 36V) .............................................................................................................................3-4
FIREEXTINGUISHER .......................................................................................................................3-7
LIGHTPACKAGE .............................................................................................................................3-8
OVERHEADGUARD(OHG)............................................................................................................ 3-9
STROBELIGHTWITHOUTOHG (12& 36VDC)...............................................................................3-10
STROBELIGHT WITH OHG(12 & 36VDC)......................................................................................3-12
SEAT BELTASSEMBLY...................................................................................................................3-14
SQUEEGEEWAND .........................................................................................................................3-15
PADDRIVER(20”)............................................................................................................................ 3-16
SPRAY & VAC WAND (12V & 36V) ................................................................................................. 3-17
HYDRAULICKIT ...............................................................................................................................3-21
INDEX.....................................................................................................................................................3-22
WARRANTY ........................................................................................................................................... 3-25
TABLE OF CONTENTS

1 - 4 AMERICAN-LINCOLNTECHNOLOGY
SMART 2000
CLEANINGPATH
Scrubbing - 40 in. (101 cm)
- 46 in. (117 cm)
Sweeping - 46in.(117 cm)
EdgeCleaning - 6 in.(15 cm) Right Side 46in. 117 cm) only
TRAVELSPEED - 0-4 MPH (0 - 6.4kph)
STEERING - Rack& Pinion 90°-90° Hyd. Power Steering
- AdjustableSteering Column
TURNINGRADIUS
Left - 59 in. (150 cm)
Right - 59 in. (150 cm)
Aisle“U” Turn - 87 in. (221 cm)
DIMENSIONS
Length - 87 in. (221 cm)
Width - 46 in. (116.8 cm)
Height - 52 in. (132 cm)
Heightw/OverheadGuard - 79 in. (200.6 cm)
Wheel Base - 37.6 in. (95.5 cm)
WEIGHTStandard Machine(Battery) - 1700 lbs. (765 kg.) without battery
- 510Ah battery 1800 lbs. (810 kg)
- 720Ah battery 1990 lbs. (896 kg)
TIRES Front (Battery)Solid Urethane - Two (2)16 in (41cm) x 3.75 in (8.26 cm)
Rear (Battery)Solid Rubber - One (1)16 in (41 cm) x 4.00 in (10.16cm)
RAMPCLIMBING
Transporting - 8° (battery)
MAINBROOM
One piece plastic core disposable type. Broom position can be set to “restricted down” or
“freefloating”.
Length - 36 in (91.4 cm)
Diameter - 10 inches (25.4 cm)
OptionalBristle Type - Nylon(High density)
- Proex
- NylonEight (8) Row
SIDEBROOM
Side Broom Size - 16inches (40.6cm) Diameter
SPECIFICATIONS

AMERICAN-LINCOLNTECHNOLOGY 1 - 5
SMART2000
SPECIFICATIONS
INSTRUMENTSANDCONTROLS
Main/SideBroomSwitch Key Switch
(activatesimmediately whenlowered) Rectangular HourMeter
Headlight/Taillight Switch (option) Battery Rollout
SqueegeeSwitch RecoveryHighLight
3 Position Scrub Deck Switch DustControl Switch(with certain models)
HornButton Solution Low Light
SolutionControl CoolantTemperatureLight
HopperUp/Down Filter Shaker Switch
SCRUBBINGSYSTEM
BrushSize-46” (116.84 cm) - Three(3)16”(40.6cm) Diameter
BrushSize-40” (101.4 cm) - Two(2)20” (51cm)Diameter
BrushDrive Lift - ElectricActuator
ScrubLoad
40”scrubpath)(116.84cm) - From 90 lbs. to 140 lbs. per brush (Battery)
46”scrub path)(101.4cm) - From 90 lbs. to 140 lbs. per brush (Battery)
SQUEEGEE
Rear - Accu-Trac™46 in(116.8cm) Swing, break away,
w/notool squeegee replacement
Side - 26 in (66 cm) Easy Change
TANKS SolutionTank - 55Gallons (208 liter)Polyethylene
RecoveryTank - 55 Gallons (208liter)Polyethylene
Solution Metering - Variable to 3.0 GPM (11.4 lpm)
DrainHose - 48 in (122 cm) No Plugrequired
CleanOutPort - 5.7in(14.5cm)heavydebris
HOPPER
Capacity - 2.5cu.ft.(71liter)
DUMPANDLIFT
DumpHeight - 14 in (35.6 cm.)
SYSTEMFLUIDCAPACITIES
Hydraulic System (Battery) - 4.7 Gallons (17.79 Liters)
OPTIONALEQUIPMENT
Back-UpAlarm Headlight/Taillights
Push Pull Light Switch (Work Light) Strobe Light(Red orAmber)
ESPSystemw/o Detergent Provisions OverheadGuard
PadDrivers Arm Rest
Spray and Vac Wand Option Fire Extinguisher
LinatexSqueegee SqueegeeWand
720AmpHour Battery 510Amp Hour Battery

1 - 6 AMERICAN-LINCOLNTECHNOLOGY
SMART 2000
87”
(221 cm)
79”
(200.6 cm)
46"
(116.8 cm)
37.6"
(95.5 cm)
52"
(132 cm)
c1961/0002
MACHINE DIMENSIONS

AMERICAN-LINCOLNTECHNOLOGY 1 - 7
SMART2000
STANDARD HARDWARE & TORQUE VALUES
SAE - Grade 5 SAE - Grade 8
Screw
Size
Grade
5
Plated
Grade
8
Plated
410H
Stainless
Brass Type
F&T
&BT
Type
B, AB
*6
*8
*10
*1/4
5/16
3/8
7/16
1/2
9/16
5/8
3/4
7/8
1
14
27
39
86
15
28
44
68
98
135
239
387
579
15
28
43
108
17
31
49
76
110
153
267
-
-
-
-
-
130
22
40
63
95
138
191
338
545
818
-
-
-
151
24
44
70
108
155
216
378
-
-
18
33
47
114
19
34
55
85
-
-
-
-
-
20
35
54
132
22
39
62
95
-
-
-
-
-
5
9
13
32
6
10
16
-
-
-
-
-
-
20
37
49
120
-
-
-
-
-
-
-
-
-
23
41
64
156
-
-
-
-
-
-
-
-
-
21
34
49
120
-
-
-
-
-
-
-
-
-
C
CCC
FFF F
C = Coarse Thread
F = Fine Thread
* = Torque values for #6 through 1/4 are lb./in. All others are lb./ft.
NOTE
Decrease the torque by 20% when using thread lubricant
The torque tolerance is ± on torque values.
C2000/9905

1 - 8 AMERICAN-LINCOLNTECHNOLOGY
SMART 2000
HYDRAULIC TORQUE REQUIREMENTS
HYDRAULIC TORQUE REQUIREMENTS
Refer to the following chart for torque values on all hydraulic hoses and fittings.
Nominal O-Ring Face Seal End SAE O-Ring Boss End
SAE Thread Swivel Thread Str. Fitting
Dash Size Nut Size or Locknut
Size Inch Torque Inch Torque
LB-FT LB-FT
-3 * * 3/8-24 8-10
-4 9/16-18 10-12 7-16-20 14-16
-5 * * 1/2-20 18-20
-6 11/16-16 18-20 9/16-18 24-25
-8 13/16-16 32-35 3/4-16 50-60
-10 1-14 46-50 7/8-14 72-80
-12 1 3/16-12 65-70 1 1/16-12 125-135
-14 1 3/16-12 65-70 1 3/16-12 160-180
-16 1 7-16-12 92-100 1 5/16-12 200-220
-20 1 11/16-12 125-140 1 5/8-12 210-280
-24 2-12 150-165 1 7/8-12 270-360
* O-Ring face seal type end not defined for this tube size.
NOTE
Parts must be lightly oiled with hydraulic fluid.
C-2002

AMERICAN-LINCOLNTECHNOLOGY 1 - 9
SMART2000
DECIMAL - METRIC CONVERSION TABLE
FRACTION FRACTION
DECIMAL DECIMAL
MILLIMETER MILLIMETER
C-2001/9907

1 - 10 AMERICAN-LINCOLNTECHNOLOGY
SMART 2000
YOURSMART2000MACHINEHAS BEEN SHIPPED COMPLETE, BUTDONOTATTEMPTTOOPERATE
WITHOUTFOLLOWINGTHESEINSTRUCTIONS.
PREPARINGTHE MACHINEFOR OPERATION(ICEnginePowered)
1. Connectand tighten battery cables.
2. Fillthe tank with REGULAR GRADE gasoline. (Diesel fuel if equipped with diesel engine.)
WARNING
Never fill the tank while the engine is running. Always be sure the gasoline container and sweeper are electrically
connected before pouring gasoline. This can easily be done by providing an insulated wire (permanently attached
to container) with a battery clip on the other end.
3. Check engine crankcase oil level. Although properly lubricated at the factory, check before starting the
engine. Nospecial break in oil is used and recommended number of operating hours before the initial oil
change is the same as normal. See Maintenance.
4. Check radiator coolant level. Permanent type antifreeze is added at the factory to provide protec-
tion to approximately -35°F (37°C). To retain this protection level, always add ½ part water to ½part
antifreeze.
5. Checkoillevelin the hydraulic reservoir located at the drivers side of the machine beside theengine. The
oil fill level should be halfway on sight glass. If oil is needed, add Standard, 30 weight, non-detergent motor
oil. Afterthe first 50 operating hours, service must be performed on your engine toensurefuturehigh
performanceand trouble free operation. See Maintenance.
MACHINE PREPARATION
Figure 1

AMERICAN-LINCOLNTECHNOLOGY 1 - 11
SMART2000
MACHINE PREPARATION - BATTERY
NOTE
After the first 35 operating hours, service must be performed on your engine to ensure future high performance
and trouble free operation. See Maintenance.
BATTERYPOWEREDMACHINES
*Uncratethe machine and carefully removefromskid to prevent damage.
*TheSMART 2000 machines that are shippedwithoutbatterieshave the (+) positive drive motor lead
disconnected.
*Open the battery compartment and connect the (+) positive motor lead to the top terminal post
(the wire “P” is also attached to it). Tighten the terminal nut.
*Install the scrub brushes.
*Checkthe oil level in the hydraulic reservoir
*Installbatteriesasfollows(ifnot included):
1. Turn the key to the “OFF” position.
2. RaisetheFrontCovertotheopenposition.
3. Use a battery lifting device with a 2500 lbs. (1150 Kg) capacity hoist to lift the battery. Set up the battery
tray in the center position. Make sure the size of the battery fits into the tray prior to installation
(20.25W x 38.50 x 31.00 L).
4. Using the lifting device, lower the 36 volt battery into the battery tray directly in front of the
driver’scompartment. Orient the cables & plug them in as required.
5. Plugthe polarized connector from the battery into the 36 volt plug provided.
WARNING
Hydrogen gas is formed during the charging operation and is explosive! Only charge batteries in a well ventilated
area with the lid open. Avoid any open flame or electrical sparks. Pulling out the charger plug with the timer on
will cause an arc and must be avoided.

1 - 12 AMERICAN-LINCOLNTECHNOLOGY
SMART 2000
SAFETY INSTRUCTIONS
THEFOLLOWINGSTATEMENTSAREUSEDTHROUGHOUTTHISMANUALASINDICATEDINTHEIR
DESCRIPTIONS: DANGER
To warn of immediate hazards which will result in severe personal injury or death.
WARNING
To warn of hazards or unsafe practices which could result in severe personal injury or death.
CAUTION
To warn of hazards or unsafe practices which could result in minor personal injury.
ATTENTION
To warn of unsafe practices which could result in extensive equipment damage.
NOTE
To give important information or to warn of unsafe practices which could result in equipment damage.
WARNING
THEFOLLOWINGINFORMATION SIGNALSPOTENTIALLYDANGEROUSCONDITIONSTOTHEOPERATOROREQUIP-
MENT. READTHISMANUALCAREFULLY. KNOWWHEN THESECONDITIONSCANEXIST. THEN,TAKENECESSARY
STEPSTOTRAINMACHINEOPERATINGPERSONNEL. FORTHESAFEOPERATIONOFTHISMACHINE,READAND
UNDERSTANDALLWARNINGS,CAUTIONSANDNOTES.
WARNING
Machines can ignite flammable materials and vapors. Do not use with or near flammables such as gasoline, grain
dust, solvents, and thinners.
WARNING
Improper use of heavy machinery can cause personal injury.
WARNING
Operate only when lids, doors, and access panels are securely closed.
WARNING
Use care when reversing machine in confined area.
WARNING
When servicing the machine, disconnect the batteries first to prevent possible injury.
WARNING
When working on the machine, empty hopper, remove batteries, clear area of people and obstructions, use
additional people and proper procedures when lifting the machine.
WARNING
Always empty the hopper and disconnect the battery before doing maintenance.
WARNING
You must have training in the operation of this machine before using it. READ THE INSTRUCTION BOOK.
WARNING
Do not operate this machine unless it is completely assembled.
WARNING
Do not use this machine as a step or furniture.
WARNING
Stop and leave this machine on a level surface. When you stop the machine, put the power switch in the “OFF”
position and engage the Wheel Lock.

AMERICAN-LINCOLNTECHNOLOGY 1 - 13
SMART2000
WARNING
To prevent injury and damage to the machine, do not lift the machine or move it to an edge of a stair or loading
dock.
WARNING
Lead acid batteries generate gases which can cause an explosion. Keep sparks and flames away from batteries.
NO SMOKING. Charge batteries only in areas with good ventilation.
WARNING
Always wear eye protection and protective clothing when working near batteries. Remove all jewelry. Do not put
tools or other metal objects across the battery terminals or across the tops of batteries.
WARNING
Maintenance and repairs must be done by authorized personnel only. Tighten all fasteners. Maintain adjustments
according to the specifications given in the service manual for the machine. Keep the electrical parts of the
machine dry. For storage, keep the machine in a building.
WARNING
Make sure all labels, decals, warnings, cautions and instructions are fastened to the machine. Purchase new
labels and decals fromAmerican-Lincoln Technology.
WARNING
The operator must exhibit extreme caution when negotiating, turning, and traveling across grades or ramps. Start,
stop, change direction, travel and brake smoothly. Slow down when turning.
WARNING
Avoid uneven surfaces and loose materials. Watch for obstructions, especially overhead.
WARNING
Operate only from the designated operator’s position. Stay inside the body of the machine. Keep hands and feet
on the designated controls. Always operate in well lighted areas.
WARNING
Do not carry passengers on the machine. Set the Wheel Lock when leaving the machine. Chock (block) the
wheels if the machine is parked on a grade (ramp), or is being prepared for Maintenance.
WARNING
Never leave the operator’s compartment when the is engine running.
WARNING
Report damage or faulty operation immediately. Do not operate the machine until repairs have been completed.
Maintenance and repairs must be done by authorized
personnel only.
WARNING
To maintain the stability of this machine in normal operation, the overhead guard, counterweights, roller bumper
guards, or any similar equipment installed by the manufacturer as original equipment should never be removed. If
it becomes necessary to remove such equipment for repair or maintenance, this equipment must be reinstalled
before the machine is placed back into operation.
WARNING
Electrical hazard. Shocks can cause serious personal injury. Unplug the battery before cleaning or servicing. To
avoid possible injury or property damage, read the Operator’s Manual before servicing the machine. Maintenance
and repair must be done by authorized personnel.
WARNING
Disconnecting the battery connector with the key switch in the “I” position will cause sparks that could ignite
explosive hydrogen gas generated by the batteries. To prevent serious injury or possible property damage, turn
Key Switch to “O” position before disconnecting the battery cable from the machine for charging or service.
SAFETY INSTRUCTIONS

1 - 14 AMERICAN-LINCOLNTECHNOLOGY
SMART 2000
FORSAFETY, OBSERVETHEFOLLOWINGWARNINGS.FAILURETOCOMPLYMAYCREATEASERIOUSRISKOFINJURY
TOYOURSELFANDOTHERS.THISMACHINESHOULDNOTBE USED INHAZARDOUSLOCATIONSINCLUDINGAREAS
OFVOLATILEDUSTORVAPORCONCENTRATIONS.
Operators must be trained and qualified to operate this machine. They must also understand the operator’s
manual before starting.
Use caution when mounting or dismounting the machine particularly on wet slippery
surfaces. Do not dump the hopper over an open pit or dock. Do not dump the hopper when positioned on a grade
(ramp). The machine must be level (horizontal).
SAFETY INSTRUCTIONS

AMERICAN-LINCOLNTECHNOLOGY 1 - 15
SMART2000
OPERATION OF CONTROLS AND GAUGES
LIGHT SWITCH (See Figure 2)
The light switch is located above the horn button to the left
of the steering wheel. By pressing on the lower part of the
switch,itwill work various light options that are available for
this machine, such as:
Headlights
Taillights
HORN BUTTON (See Figure 3)
The horn button is located to the left of the steering column
below the instrument panel. The horn button is always
active.
KEY SWITCH (See Figure 4)
The keyed ignition switch is located on the instrument panel
totheright of the broom lever.
The“OFF”position (O position) will shut off the engine. The
IGN/ONposition (I position) provides powertoallmachine
systems and accessories. The “START” position (one
positionclockwiseofIposition)ismomentary and provides
powerto the startermotor.
NOTE
To reengage, the key must be returned to the “OFF” position.
HOUR METER (See Figure 5)
Thehour meter is located on the instrumentpanel below the
fuelgauge (gas version), below the batteryconditionmeter
(batteryversion). The meter is activated when the key
switch is placed in the ignition position. The meter
indicates the actual “run” time of the machine. The meter
canbe used to determine when maintenance should be
doneon the machine.
Figure2
Figure4
Figure5
Figure3

1 - 16 AMERICAN-LINCOLNTECHNOLOGY
SMART 2000
OPERATION OF CONTROLS AND GAUGES - Cont.
BATTERYCONDITION METER (See Figure 6)
The battery condition meter is located on the right side of
the instrument panel. The condition meter indicates the
levelof charge in the batteries (inspect underload). The
batteriesaresufficiently charged when the needle stays in
thegreenarea on the gauge while the machine is being
operated.
Chargethe batteries when the needle drops into the red
zonewhileoperating the machine. Do not operate the
machine if the needle stays in the red area.
BATTERYCONDITION LIGHT (See Figure 7)
The meter shows the condition of the battery, while the
machineisrunning,underload. Whenthebattery voltage
fallsbelow 31-32 volts for longer than 2-3 seconds the low
voltagelight will come on and the Brush/Water solenoids
will be shut off automatically. This is a permanent lockout
untilthepoweristurnedofftomodule. Thelowvoltage
lock out can be reset almost immediately by turning off all
powertothemodulefor3-5seconds.Inapermanentlow
battery condition, the machine can be functional only for
one minute periods an then only by turning the ignition off
andon.
SEAT POSITION ADJUSTMENT (See Figure 8)
Theseatpositionadjustment lever is located on the front
of the seat to the left. The lever is spring loaded to the
“LOCK”position.
To adjust the seat, push the lever to the “RIGHT” and
move the seat to the desired position. Then release the
leverto “LOCK” the seat into place.
Figure7
Figure8
Figure6

AMERICAN-LINCOLNTECHNOLOGY 1 - 17
SMART2000
Figure10
Figure11
Figure9
FILTER SHAKER SWITCH (See Figure 9)
The filter shaker switch is located on the top left corner of
the instrument panel . By pressing and holding in the
lower part of the switch, it will activate the filter shaker
motors for 20 to 30 seconds. Upon releasing the switch,
it will return to the off (middle) position.
TheImpeller fan will stop when the filter shaker has been
activated. Thefilter shaker will only operate with the
hopperin the “DOWN” position.
DUST CONTROL SWITCH (See Figure 9)
The Dust Control Switch located on the top left corner of
the instrument panel.To turn on the dust control system
for“NORMAL” sweeping, press in the upper portion ofthe
switch. To turn off the dust control system for sweeping in
wet conditions, return the switch to the middle position
(wetsweep bypass). This will prevent the filter from being
damagedby water pickup while sweeping.
SIDE BROOM and MAIN BROOM SWITCH (See
Figure 10)
The Side and Main Broom Switch is located to the right of
the steering column. By pressing in the upper portion of
the switch, the side and main broom are raised and
turned off. To lower and turn on both brooms, press the
lowerportionoftheswitch.
MAIN BROOMADJUSTMENT (See Figure 11)
Themain broom adjustment knob for changing thesweep
height to compensate for broom wear, is located in front
of the machine to the right of the filter. Turning the knob to
theleft(counterclockwise)willlowerthemainbroom.
SIDE BROOMADJUSTMENT (See figure 11)
Theside broom adjustment knob for changing the sweep
heighttocompensateforbroom wear, is located in front
of the machine to the right of the filter. Turning the knob to
theleft(counterclockwise) will lower the side broom.
OPERATION OF CONTROLS AND GAUGES - Cont.

1 - 18 AMERICAN-LINCOLNTECHNOLOGY
SMART 2000
SCRUB DECK SWITCH (See Figure 12)
The scrub deck switch is located on the instrument panel
to the left of the solution control knob. Pressing in the
upperportion of th switch raises the scrub deck and turns
the brush. In the middle position, the scrub deck lowers
to the normal down position. Pressing the lower portion of
the switch lowers the scrub deck to the heavy down
position.
Inthethirdposition,ScrubDeckHeavy, additional
downwardpressure is applied. This will help for extremely
dirtysurfaces.
NOTE
Lowering the scrub deck does not turn on the brushes. The
brushes turn on automatically when the machine moves in
the forward or reverse direction.
SQUEEGEE SWITCH (See Figure 13)
The squeegee blade switch is located on the console to
theleftof the steering wheel.Pressing the lower portion of
the switch will lower the squeegee and activate the
squeegeevacuum. Pressing the upper portionofthe
switchwillturnoffthesqueegeevacuumandraisethe
squeegee.
In the middle position the switch will raise the squeegee.
Inthis position the vacuum remains on to allow vacuuming
the water that is left in the squeegee recovery hose. This
preventswater from dripping onthefloor with the
squeegee“UP.”
Ifthesqueegeeisloweredandthedirectionofthe
machineis reverse (activated by the FWD/REV pedal) the
squeegeewill automatically raise.
Uponmoving in the forwardposition,thesqueegee wil
automaticallyreturntotheloweredposition.
SOLUTIONS CONTROL KNOB (See Figure 14)
The solution control knob is located to the left hand side of
thesteering wheel. Turning the knob counterclockwise will
increasethe flow of solution and water.Thefartherthe
solutioncontrol knob is turned the heavier the flow of water
and solution will be. Turning the knob counterclockwise
will decrease the flow of the water and solution. To turn
the water and solution off turn the knob all the way
counterclockwise.
NOTE
For best results, discontinue application of solution
10 feet before stopping or making a 90° or 180° turn.
Figure12
Figure13
Figure14
OPERATION OF CONTROLS AND GAUGES - Cont.

AMERICAN-LINCOLNTECHNOLOGY 1 - 19
SMART2000
A
B
Figure17
Figure16
Figure15
RECOVERY HIGH LIGHT (See Figure 15)
Therecovery high warninglightwill illuminate
approximately5minutesbeforetherecoverytankis full,
givingampletime to complete the scrubbing cycle, before
themechanicalfloatshutsoffthevacuumtotherecovery
tank.
LOW SOLUTION LIGHT (See Figure 15)
The Low Solution Warning Light is located on the
console.The Solution Warning Light will illuminate when
the solution tank is empty, marking the end of the
scrubbing cycle.
PARKING BRAKE (See Figure 16)
Neverleave operator’sseatwithout engagingtheparking
brake. The parking brake is located on the floor of the
machine left of the directional control pedal.To set the
parkingbrake, press down on the foot pedal (ItemA) and
the press down the lock (Item B). To unlock the parking
brake,push down on the upper portion of the foor pedal
andrelease.
TURN SIGNAL - 4-Way (Option)
The turn signal option is located on the steering column
andworks as automotive turn signals work, forward on
thelever for right and back on the lever for left.The4-way
flasherwill activate when the turn signal lever is pulled
out.
HYDRAULICRESERVOIR LEVEL SIGHT GAUGE (See
Figure 17)
The sight gauge is located on the left side of the machine
underthefrontcover.Thesightgaugeisusedto indicate
thelevel of fluid in the reservoir. Thefluid level must be
visible in the sight gauge when the hopper is in the down
position.
OPERATION OF CONTROLS AND GAUGES - Cont.
