Altronix AL602ADA220 User guide

NAC Power Extenders
Models Include:
AL602ADA220
AL802ADA220
AL1002ADA220
NAC Power Extenders
Application Guide
(see Installation Guide for additional information)
Rev. 042209 More than just power.TM
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________

- 2 - 02 ADA220 Application Guide
1.General Information (Use this in conjunction with respective Installation Guide):
Altronix AL602ADA220, AL802ADA220 and AL1002ADA220 are very versatile devices. They can be used with
or without specific synchronization modules provided by some manufacturers. Multiple units can be synchronized
by using either the built-in sync mode or a external synchronization module. Please note, that only notification
appliances with synchronization capabilities can be synchronized. Units can operate with either one (1) or two (2)
outputs from the FACP.
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
2. Class A and Class B Hookups:
Units can be used with the outputs configured for:
• Two (2) Class A (Fig. 2a). • Two (2) Class B and one (1) Class A NAC circuits
• Up to Four (4) Class B. (Fig. 2b).
SW1SW2
+ OUT1 --
IN1+ IN1--IN2--
IN2+ C "DRY1" NC
RET1+RET1-- RET2--
RET2+C "DRY2" NC
+ OUT2 -- + OUT3 -- + OUT4 --
UPPER TERMINALS
LOWER TERMINALS
Two (2) Class A Hookups
From
FACP
NAC1
From
FACP
NAC2
Return
to FACP
Return
to FACP
ON
1
ON
1
Fig. 2a
Fig. 2c
Fig. 2b
NAC Loop 1 starts on Output 1 and terminates
on Output 3. Switch SW1, when ON, provides
proper termination for this loop. NAC Loop 2
starts on Output 2 and terminates on Output 4,
SW2 must be turned ON for proper termination.
Please make sure that all the DIP switches for
corresponding outputs are set the same way.
For combination of two (2) Class B and one
(1) Class A circuit, only one (1) switch (SW1 or
SW2) must be turned ON, terminating Class A
circuit only.
SW1SW2
+ OUT1 --
IN1+ IN1--IN2--
IN2+ C "DRY1" NC
RET1+RET1--RET2--
RET2+ C "DRY2" NC
+ OUT2 -- + OUT3 -- + OUT4 --
UPPER TERMINALS
LOWER TERMINALS
2.2K
EOL
2.2K
EOL
One (1) Class A, two (2) Class B Hookups
ON
1
ON
1
IN1+ IN1--IN2--
IN2+ C "DRY1" NC
RET1+ RET1--RET2--
RET2+ C "DRY2" NC
UPPER TERMINALS
LOWER TERMINALS
Addressable Control
Module Trigger Output
Normally Closed Dry Contact
(Non-Supervised Class E)
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Dry Contact Input Wiring

02 ADA220 Application Guide - 3 -
3.Non-synchronizable NAC Appliances:
When using NAC appliances not designed to support synchronization feature, it is recommended to use separate
output circuits for audible notification appliances (horns) and visual notification appliances (strobes). Set DIP switches
for the visual notification appliances to follow Input 1 [IN1] and for audible notification appliances to follow Input 2
[IN2]. This will allow, when using two (2) outputs from the FACP, to support silencing of audible notification appli-
ances. When using only one (1) FACP output, set all DIP switches to follow Input 1 [IN1]. The units outputs can each
be set for the desired NAC drive signal, such as Code 3 or march time sequence (Output Programming Selection
Table, pg. 6). Non-synchronizable Audible Appliances will follow the sequence, when feature is selected.
4. Using Multiple NAC Power Extenders from an FACP:
AL602/AL802/1002ADA220 units are designed to follow (replicate) the coded sequence, generated by a manu-
facturer’s sync module. One (1) or more units can be triggered. Connect the output of the FACP module to Input 1
and Input 2 Terminate the input circuit with the EOL or FACP, connecting it to terminals marked [RET +] and [RET –],
or continue the input circuit, connecting to terminals marked [RET +] and [RET –] to [INP +] and [INP –] of the next
unit, when multiple units need to be triggered.
In case FACP does not have any synchronization capabilities and the sync mode is not used,
the notification appliance synchronization will not be provided.
FACP with Sync Output
Control
Circuit
Control Circuit
No Notification Appliances Allowed
Sync Module
NAC Power Extender:
DIP switches set to Input to Output follower mode.
POWER
IN +
POWER
IN ---
ZONE 1
POWER
IN +
POWER
IN ---
HORN
CONTROL
POWER
OUT +
POWER
OUT ---
ZONE 1
POWER
OUT +
POWER
OUT ---
ZONE 2
+ NAC 1 --- + NAC 2 ---
2.2K
EOL
2.2K
EOL
2.2K
EOL
2.2K
EOL
FACP
(Fire Alarm
Control Panel
with sync
capabilities)
Or
Memory
Reset
To FACP EOL or
next NAC power extender
For Class A configuration
return to FACP
Memory
Reset
NAC Power Extender:
DIP switches set to Input to Output follower mode.
ON
1
ON
1
ON
1
ON
1
Compatible Special
Application Devices.
See Compatibility List
Fig. 4a
CAUTION: Do not connect any notification appliances on the control circuit interconnecting
FACP outputs (sync module outputs) and inputs of NAC Power Extenders. Applications that do
not employ synchronization module or FACP with synchronization protocol will not provide NAC
sycnchronization between NAC Power Extenders.

- 4 - 02 ADA220 Application Guide
5.Synchronizing NAC Power Extender Using Built-in Sync Protocol:
AL602/AL802/1002ADA220 have built-in protocols to support Amseco, Gentex®, System Sensor®, Wheelock®
two-wire synchronizable devices, therefore an external sync module is not required (Output Programming Selection
Table, pg. 5). In these modes Input 1 is always used to activate visual notification appliances (strobes) and Input 2
is used to activate and silence audible notification appliances (strobes).
Note: Input 1 has to be activated in all the configurations.
SW1SW2
+ OUT1 --
IN1+ IN1-- IN2--
IN2+ C "DRY1" NC
RET1+RET1--RET2--
RET2+ C "DRY2" NC
+ OUT2 -- + OUT3 -- + OUT4 --
UPPER TERMINALS
LOWER TERMINALS
SW1SW2
+ OUT1 --
IN1+ IN1-- IN2--
IN2+C "DRY1" NC
RET1+RET1--RET2--
RET2+ C "DRY2" NC
+ OUT2 -- + OUT3 -- + OUT4 --
UPPER TERMINALS
LOWER TERMINALS
2.2K
EOL
2.2K
EOL
2.2K
EOL
2.2K
EOL
2.2K
EOL
2.2K
EOL
To EOL or next
NAC Power Extender
Class B configuration only
NAC Power Extender:
DIP Switches set for desired Sync Protocol (ex. Gentex®,
System Sensor®, Amseco, CooperWheelock®).
NAC Power Extender:
DIP Switches set for Input to Output Follower Mode
Control Circuit
No Notification Appliances
Allowed
FACP
(Fire Alarm
Control Panel)
FACP EOL
For Class A
Configuration
return to FACP
FACP EOL
For Class A
Configuration
return to FACP
ON
1
ON
1
ON
1
ON
1
Fig. 5a
When connecting, keep wires on different sides of the screws in order to maintain loop integrity supervision.
DO NOT LOOP CONTINUOUS WIRE AROUND THE SCREW.
IN1+ IN1-- IN2--
IN2+ C "DRY1" NC
RET1+ RET1--RET2--
RET2+ C "DRY2" NC UPPER TERMINALS
LOWER TERMINALS
EOL or
Next Device
Control Circuit
NO Notification
Appliances allowed
FACP
For Class A configuration return to FACP
Fig. 6a
6.Using a Single FACP Output:
When only one FACP output is available, you may connect both Input 1 and Input 2 to it.
Wire [RET1 +] and [RET1 –] to [INP2 +] and [INP2 –].
Both visual and audible notification appliances will be activated simultaneously (Fig. 6a).

02 ADA220 Application Guide - 5 -
Output Programming Selection Table:
Outputs must be programmed independently (OUT1 - OUT4)
Function Switch Positions Descriptions
ON OFF
Input to Output
Follower Mode 12, 3
Output follows signal it receives from the corresponding
input (i.e. FACP Sync module - maintains synchronization of
notification appliance circuit).
Temporal Code 3 Mode 31, 2 Enables Temporal Code 3 signal generation output.
This mode will accept a steady or a pulsing input.
Steady Mode 1, 2, 3 A steady output signal will be generated.
This mode will accept steady or pulsing input.
For the above modes DIP Switch 4 determines which Input controls the
corresponding output:
Switch 4 in the ON position causes output(s) to be controlled by Input 1.
Switch 4 in the OFF position causes output(s) to be controlled by Input 2.
Sync Mode Selection Table:
Function Switch Positions Descriptions
ON OFF
Amseco
Sync Mode*
1, 3,
42
This mode is designed to work with the Amseco series of horns,
strobes, and horn/strobes to provide a means of synchronizing
the Temporal-coded horns, synchronizing the flash timing of the
strobe, and allowing audible notification appliances (horns) and
visual notification appliances (strobes) to be silienced/ deactivated
at the same time.
Gentex®
Sync Mode*
Gentex is a registered
trademark of
Gentex Corporation.
1, 2,
3, 4
This mode is designed to work with the Gentex®series of horns,
strobes, and horn/strobes to provide a means of synchronizing
the Temporal-coded horns, synchronizing the flash timing of the
strobe, and allowing audible notification appliances (horns) and
visual notification appliances (strobes) to be silienced/ deactivated
at the same time.
System Sensor®
Sync Mode*
System Sensor is a
registered trademark
of Honeywell.
1, 2, 4 3
This mode is designed to work with the System Sensor®series of
horns, strobes, and horn/strobes to provide a means of synchroniz-
ing the Temporal-coded horns, synchronizing the one-second flash
timing of the strobe, and allowing audible notification appliances
(horns) and visual notification appliances (strobes) to be silienced/
deactivated at the same time.
CooperWheelock®
Sync Mode*
CooperWheelock is a
registered trademark
of Cooper Wheelock.
2, 3, 4 1
This mode is designed to work with the CooperWheelock series of
horns, strobes, and horn/strobes to provide a means of synchroniz-
ing the Temporal-coded horns, synchronizing the one-second flash
timing of the strobe, and allowing audible notification appliances
(horns) and visual notification appliances (strobes) to be silienced/
deactivated at the same time.
*Note: AL602ADA220, AL802ADA220 and AL1002ADA220 will only synchronize horns, horn/strobes and
strobes that contain synchronization capability. The same synchronization mode must be selected for all outputs.
AL800LGK9E Board
Output DIP Switches
INPUT SELECT
TEMPORAL
STROBE SYNC
IN>OUT SYNC

- 6 - 02 ADA220 Application Guide
Notes:

02 ADA220 Application Guide - 7 -
Notes:

- 8 - 02 ADA220 Application Guide
1.5”
(38.1mm)
1.5”
(38.1mm)
4.615” (117.2mm) 4.615” (117.2mm)
1.5”
(38.1mm)
1.5”
(38.1mm)
4.615” (117.2mm) 4.615” (117.2mm)
1.75”
(44.5mm)
1.75”
(44.5mm)
1.375”
(34.9mm)
1.125”
(28.6mm)
1.5”
(38.1mm)
1.5”
(38.1mm)
5.0” (127.0mm) 5.0” (127.0mm)
4.5” (114.3mm)4.5” (114.3mm) 1.25”
(31.8mm)
1.25”
(31.8mm)
0.79” (20.1mm)0.91”
(23.1mm)
0.91”
(23.1mm)
15.5” (393.7mm)
1.1” (27.9mm)
1.1” (27.9mm)
1.1” (27.9mm)
12.23” (310.6mm)
2.0”
(50.8mm)
2.0”
(50.8mm)
1.25” (31.8mm)1.25” (31.8mm)
Enclosure Dimensions (BC400):
15.5” x 12” x 4.5” (393.7mm x 304.8mm x 114.3mm)
Altronix is not responsible for any typographical errors.
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
140 58th Street, Brooklyn, New York 11220 USA | phone: [phone] | fax: [phone]
website: www.altronix.com | e-mail: [email protected] | Lifetime Warranty
02ADA220 Application Guide H10U MEMBER
