Amana W10773360A User manual

W10773360A
W10773369A-SP
240-Volt Electric
Compact Dryer
Use and Care Guide
Table of Contents
DRYER SAFETY ......................................................................... 2
INSTALLATION INSTRUCTIONS............................................... 4
USING YOUR DRYER .............................................................. 16
DRYER CARE ........................................................................... 18
TROUBLESHOOTING.............................................................. 19
WARRANTY.............................................................................. 22
ASSISTANCE OR SERVICE..................................BACK COVER
Table des matières
SÉCURITÉ DE LA SÉCHEUSE ................................................ 24
INSTRUCTIONS D’INSTALLATION......................................... 26
UTILISATION DE LA SÉCHEUSE............................................ 39
ENTRETIEN DE LA SÉCHEUSE.............................................. 41
DÉPANNAGE ............................................................................ 42
GARANTIE................................................................................ 45
ASSISTANCE OU SERVICE............... COUVERTURE ARRIÈRE
Sécheuse Électrique
compacte 240 volts
Guide d’utilisation et
d’entretien
Para una versión de estas instrucciones en español, visite www.amana.com

2
Dryer Safety

3

4
Installation Instructions
Tools and Parts
Tools needed
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools
listed here.
Flat-blade screwdriver #2 Phillips screwdriver
¼” nut driver or socket
wrench (recommended) Tin snips (new vent installations)
Tape measure Vent clamps
Level Pliers
Adjustable wrench that
opens to 1” (25 mm) or
hex-head socket wrench
Caulking gun and
compound (for installing
new exhaust vent)
Wire Stripper (direct wire
installations) Wood block
Parts supplied
Remove parts package from the dryer drum. Check that all parts
listed are included.
Cycle control knob Start button
Leveling legs (4)
Parts needed
Check local codes, existing electrical supply and venting, and
see “Venting Requirements” and “Electrical Requirements” before
purchasing parts.
■Mobile home installations require metal exhaust
system hardware.
Location Requirements
You will need
■A location that allows for proper exhaust installation. See
“Venting Requirements.”
■A separate 30-amp circuit.
■A grounded electrical outlet located within 2 ft (610 mm) of
either side of the dryer. See “Electrical Requirements.”
■A sturdy floor to support the dryer weight (dryer and load)
of 115 lbs (52 kg). The combined weight of a companion
appliance should also be considered.
■A level floor with a maximum slope of 1" (25 mm) under
entire dryer.
Do not operate your dryer at temperatures below 45°F (7°C). At
lower temperatures, the dryer might not shut off at the end of an
automatic cycle. Drying times can be extended.
The dryer must not be installed or stored in an area where it will
be exposed to water and/or weather.
Check code requirements. Some codes limit, or do not permit,
installation of the dryer in garages, closets, mobile homes, or
sleeping quarters. Contact your local building inspector.

5
Installation Clearances
The location must be large enough to allow the dryer door to
open fully.
Dryer Dimensions Front View
237/8"
(606 mm)
1"
(25 mm)
*203/4"
(527 mm)
31"
(787 mm)
Side View
1"
(25 mm)
36"
(914 mm)
203/4"
(527 mm)
Back View
1"
(25 mm)
235/8"
(600 mm)
81/4"
(210 mm)
31/4"
(83 mm)
117/8"
(303 mm)
Minimum spacing for recessed area and
closet installation
The following dimensions shown are for the minimum spacing
allowed when the dryer is to be operated with, or without, the
Stack Stand Kit. To purchase a Stack Stand Kit, see “Assistance
or Service.”
■Additional spacing should be considered for ease of
installation and servicing.
■Additional clearances might be required for wall, door, and
floor moldings.
■For closet installation with a door, minimum ventilation
openings in the top and bottom of the door are required.
Louvered doors with equivalent ventilation openings
are acceptable.
■Companion appliance spacing should also be considered.
Recessed or closet installation - Dryer only
AB
14"*
(356 mm)
18"* (457 mm)
1"
(25 mm)
1"
(25 mm)
51/2"*
(140 mm)
A. Side view - closet or confined area
B. Recessed area
*Most installations require a minimum 5½"(140 mm) clearance
behind the dryer for the exhaust vent with elbows. See “Venting
Requirements.”
Recessed or closet installation - Stacked
DRYER
WASHER
51/2"
(76 mm)
(305 mm)
12"*
(305 mm)
12"*
1"
(25 mm)
1"
(25 mm)
A B
C
1"*
(25 mm)
3"*
(76 mm)
48 in. *
2
(309.7 cm )
2
24 in. *
2
(154.8 cm )
2
3"*
(76 mm)
A. Recessed area
B. Side view - closet or confined area
C. Closet door with vents
Mobile Home - Additional Location Requirements
This dryer is suitable for mobile home installations. The
installation must conform to the Manufactured Home
Construction and Safety Standard, Title 24 CFR, Part 3280
(formerly the Federal Standard for Mobile Home Construction
and Safety, Title 245, HUD Part 280) or Standard CAN/CSA-
Z240 MH.
Mobile home installations require:
Metal exhaust system hardware, which is available for purchase
from your dealer.
Special provisions must be made in mobile homes to introduce
outside air into the dryer. The opening (such as a nearby window)
should be at least twice as large as the dryer exhaust opening.

6
Electrical Requirements
It is your responsibility
■To contact a qualified electrical installer.
■To be sure that the electrical connection is adequate and in
conformance with the National Electrical Code, ANSI/NFPA
70-latest edition and all local codes and ordinances.
The National Electrical Code requires a 4-wire supply
connection for homes built after 1996, dryer circuits involved
in remodeling after 1996, and all mobile home installations.
A copy of the above code standards can be obtained from:
National Fire Protection Association, One Batterymarch Park,
Quincy, MA 02269.
■To supply the required 3 or 4 wire, single phase, 120/240 volt,
60 Hz., AC only electrical supply (or 3 or 4 wire, 120/208 volt
electrical supply, if specified on the serial/rating plate) on a
separate 30-amp circuit, fused on both sides of the line. A
time-delay fuse or circuit breaker is recommended. Connect
to an individual branch circuit. Do not have a fuse in the
neutral or grounding circuit.
■Do not use an extension cord.
■If codes permit and a separate ground wire is used, it is
recommended that a qualified electrician determine that the
ground path is adequate.
Electrical Connection
To properly install your dryer, you must determine the type of
electrical connection you will be using and follow the instructions
provided for it here.
■If local codes do not permit the connection of a neutral ground
wire to the neutral wire, see “Optional 3-wire connection” in
the “Electrical Connection” section.
■This dryer is manufactured ready to install with a 3-wire
electrical supply connection. The neutral ground wire is
permanently connected to the neutral conductor (white wire)
within the dryer. If the dryer is installed with a 4-wire electrical
supply connection, the neutral ground wire must be removed
from the external ground conductor screw (green screw), and
secured under the neutral terminal (center or white wire) of the
terminal block. When the neutral ground wire is secured under
the neutral terminal (center or white wire) of the terminal block,
the dryer cabinet is isolated from the neutral conductor.
■A 4-wire power supply connection must be used when the
appliance is installed in a location where grounding through
the neutral conductor is prohibited. Grounding through the
neutral is prohibited for (1) new branch-circuit installations, (2)
mobile homes, (3) recreational vehicles, and (4) areas where
local codes prohibit grounding through the
neutral conductors.
If using a power supply cord:
Use a UL listed power supply cord kit marked for use with
clothes dryers. The kit should contain:
■A UL listed 30-amp power supply cord, rated 120/240 volt
minimum. The cord should be type SRD or SRDT and be
at least 4 ft (1.22 m) long. The wires that connect to the
dryer must end in ring terminals or spade terminals with
upturned ends.
■A UL listed strain relief.
If your outlet looks like this:
4-wire receptacle (14-30R)
Then choose a 4-wire power supply cord with ring or spade
terminals and UL listed strain relief. The 4-wire power supply
cord, at least 4 ft (1.22 m) long, must have four 10-gauge copper
wires and match a 4-wire receptacle of NEMA Type 14-30R. The
ground wire (ground conductor) may be either green or bare. The
neutral conductor must be identified by a white cover.
If your outlet looks like this:
3-wire receptacle (10-30R)
Then choose a 3-wire power supply cord with ring or spade
terminals and UL listed strain relief. The 3-wire power supply
cord, at least 4 ft (1.22 m) long, must have three 10-gauge copper
wires and match a 3-wire receptacle of NEMA Type 10-30R.
If connecting by direct wire:
Power supply cable must match power supply (4-wire or 3-wire)
and be:
■Flexible armored cable or nonmetallic sheathed copper cable
(with ground wire), protected with flexible metallic conduit. All
current-carrying wires must be insulated.
■10-gauge solid copper wire (do not use aluminum).
■At least 5 ft (1.52 m) long.

7
1. Disconnect power.
2. Remove the hold-down screw and terminal block cover.
A. Terminal block cover
B. External ground conductor screw
C. Center terminal block screw
D. Hold-down screw location
E. Neutral ground wire
F. Hole below terminal block opening
3. Install strain relief.
Electrical Connection
Direct Wire
Power Supply Cord
Style 1: Power supply cord strain relief
■Remove the screws from a ¾" (19 mm) UL listed strain relief
(UL marking on strain relief). Put the tabs of the two clamp
sections into the hole below the terminal block opening so
that one tab is pointing up and the other is pointing down, and
hold in place. Tighten strain relief screws just enough to hold
the two clamp sections together.
A
B
C
D
A. Strain relief tab pointing up
B. Hole below terminal block opening
C. Clamp section
D. Strain relief tab pointing down
A
B
C
D
E
F

8
■Put power supply cord through the strain relief. Be sure that
the wire insulation on the power supply cord is inside the
strain relief. The strain relief should have a tight fit with the
dryer cabinet and be in a horizontal position. Do not further
tighten strain relief screws at this point.
Style 2: Direct wire strain relief
■Unscrew the removable conduit connector and any screws
from a ¾" (19 mm) UL listed strain relief (UL marking on strain
relief). Put the threaded section of the strain relief through
the hole below the terminal block opening. Reaching inside
the terminal block opening, screw the removable conduit
connector onto the strain relief threads.
A
B
C
A. Removable conduit connector
B. Hole below terminal block opening
C. Strain relief threads
■Put direct wire cable through the strain relief. The strain
relief should have a tight fit with the dryer cabinet and be in
a horizontal position. Tighten strain relief screw against the
direct wire cable.
4. Now complete installation following instructions for your type
of electrical connection:
4-wire (recommended)
3-wire (if 4-wire is not available)
Electrical Connection Options
If your home has: And you will be
connecting to: Go to Section
4-wire receptacle
(NEMA Type 14-30R) A UL listed, 120/240-volt
minimum,
30-amp, dryer
power supply
cord*
4-wire connection:
Power supply cord
4-wire direct
(127 mm)
5"
A fused
disconnect or
circuit breaker
box*
4-wire connection:
Direct Wire
3-wire receptacle
(NEMA type 10-30R)
A UL listed,
120/240-volt
minimum,
30-amp, dryer
power supply
cord*
3-wire connection:
Power supply cord
3-wire direct
3¹₂"
(89 mm)
A fused
disconnect or
circuit breaker
box*
3-wire connection:
Direct Wire
*If local codes do not permit the connection of a cabinet-ground
conductor to the neutral wire, go to “Optional 3-wire
connection” section.
4-wire connection: Power Supply Cord
IMPORTANT: A 4-wire connection is required for mobile
homes and where local codes do not permit the use of
3-wire connections.
A
BF
EG
D
C
A. 4-wire receptacle (NEMA type 14-30R)
B. 4-prong plug
C. Ground prong
D. Neutral prong
E. Spade terminals with upturned ends
F. ¾" (19 mm) UL listed strain relief
G. Ring terminals
1. Remove center terminal block screw.

9
2. Remove neutral ground wire from external ground conductor
screw. Connect neutral ground wire and the neutral wire (white
or center wire) of power supply cord under center terminal
block screw. Tighten screw.
D
E
ABC
A. External ground conductor screw - Dotted line
shows position of NEUTRAL ground wire before
being moved to center terminal block screw
B. Center terminal block screw
C. Neutral wire (white or center wire)
D. ¾" (19 mm) UL listed strain relief
E. Neutral ground wire
3. Connect ground wire (green or bare) of power supply cord to
external ground conductor screw. Tighten screw.
D
ABC
E
F
A. External ground conductor screw
B. Center terminal block screw
C. Neutral wire (white or center wire)
D. ¾" (19 mm) UL listed strain relief
E. Neutral ground wire
F. Ground wire (green or bare) of power supply cord
4. Connect the other wires to outer terminal block screws.
Tighten screws.
5. Tighten strain relief screws.
6. Insert tab of terminal block cover into slot of dryer rear panel.
Secure cover with hold-down screw.
7. You have completed your electrical connections. Now go to
“Venting Requirements.”
4-wire connection: Direct Wire
IMPORTANT: A 4-wire connection is required for mobile
homes and where local codes do not permit the use of 3-wire
connections.
Direct wire cable must have 5 ft (1.52 m) of extra length so dryer
can be moved if needed.
Strip 5" (127 mm) of outer covering from end of cable, leaving
bare ground wire at 5" (127 mm). Cut 1½" (38 mm) from 3
remaining wires. Strip insulation back 1" (25 mm). Shape ends of
wires into a hook shape.
1"
(25 mm)
5"
(127 mm)
When connecting to the terminal block, place the hooked end of
the wire under the screw of the terminal block (hook facing right),
squeeze hooked end together and tighten screw, as shown.
1. Remove center terminal block screw.
2. Remove neutral ground wire from external ground conductor
screw. Connect neutral ground wire and place the hooked end
(hook facing right) of the neutral wire (white or center wire) of
direct wire cable under the center screw of the terminal block.
Squeeze hooked ends together. Tighten screw.
E
D
ABC
A. External ground conductor screw - Dotted line
shows position of NEUTRAL ground wire before
being moved to center terminal block screw
B. Center terminal block screw
C. Neutral wire (white or center wire)
D. ¾" (19 mm) UL listed strain relief
E. Neutral ground wire

10
3. Connect ground wire (green or bare) of power supply cable to
external ground conductor screw. Tighten screw.
E
D
ABC
F
A. External ground conductor screw
B. Center terminal block screw
C. Neutral wire (white or center wire)
D. ¾" (19 mm) UL listed strain relief
E. Neutral ground wire
F. Ground wire (green or bare) of power supply cable
4. Place the hooked ends of the other power supply cable wires
under the outer terminal block screws (hooks facing right).
Squeeze hooked ends together. Tighten screws.
5. Tighten strain relief screws.
6. Insert tab of terminal block cover into slot of dryer rear panel.
Secure cover with hold-down screw.
7. You have completed your electrical connections. Now go to
“Venting Requirements.”
3-wire connection: Power Supply Cord
Use where local codes permit connecting cabinet-ground
conductor to neutral wire:
A
BD
C
E
F
G
A. 3-wire receptacle (NEMA type 10-30R)
B. 3-wire plug
C. Neutral prong
D. Spade terminals with up turned ends
E. ¾" (19 mm) UL listed strain relief
F. Ring terminals
G. Neutral (white or center wire)
1. Loosen or remove center terminal block screw.
2. Connect neutral wire (white or center wire) of power supply
cord to the center terminal screw of the terminal block.
Tighten screw.
A
BC
D
E
A. Neutral ground wire
B. External ground conductor screw
C. Center terminal block screw
D. Neutral wire (white or center wire)
E. ¾" (19 mm) UL listed strain relief
3. Connect the other wires to outer terminal block screws.
Tighten screws.
4. Tighten strain relief screws.
5. Insert tab of terminal block cover into slot of dryer rear panel.
Secure cover with hold-down screw.
6. You have completed your electrical connections. Now go to
“Venting Requirements.”
3-wire connection: Direct Wire
Use where local codes permit connecting cabinet-ground
conductor to neutral wire.
Direct wire cable must have 5 ft (1.52 m) of extra length so dryer
can be moved if needed.
Strip 3½" (89 mm) of outer covering from end of cable. Strip
insulation back 1" (25 mm). If using 3-wire cable with ground
wire, cut bare wire even with outer covering. Bend ends of wires
into a hook shape.
1"
(25 mm)
3½"
(89 mm)
When connecting to the terminal block, place the hooked end of
the wire under the screw of the terminal block (hook facing right),
squeeze hooked end together and tighten screw, as shown.

11
1. Loosen or remove center terminal block screw.
2. Place the hooked end of the neutral wire (white or center wire)
of power supply cable under the center screw of terminal
block (hook facing right). Squeeze hooked end together.
Tighten screw.
BC
D
E
A
A. Neutral ground wire
B. External ground conductor screw
C. Center terminal block screw
D. Neutral wire (white or center wire)
E. ¾" (19 mm) UL listed strain relief
3. Place the hooked ends of the other power supply cable wires
under the outer terminal block screws (hooks facing right).
Squeeze hooked ends together. Tighten screws.
4. Tighten strain relief screw.
5. Insert tab of terminal block cover into slot of dryer rear panel.
Secure cover with hold-down screw.
6. You have completed your electrical connections. Now go to
“Venting Requirements.”
Optional 3-wire connection
Use for direct wire or power supply cord where local codes do
not permit connecting cabinet-ground conductor to neutral wire.
1. Remove center terminal block screw.
2. Remove neutral ground wire from external ground conductor
screw. Connect neutral ground wire and the neutral wire
(white or center wire) of power supply cord/cable under center
terminal block screw. Tighten screw.
ABC
D
E
F
A. External ground conductor screw
B. Neutral ground wire
C. Center terminal block screw
D. Neutral wire (white or center wire)
E. ¾" (19 mm) UL listed strain relief
F. Grounding path determined by a qualified electrician
3. Connect the other wires to outer terminal block screws.
Tighten screws.
4. Tighten strain relief screws.
5. Insert tab of terminal block cover into slot of dryer rear panel.
Secure cover with hold-down screw.
6. Connect a separate copper ground wire from the external
ground conductor screw to an adequate ground.

12
Venting Requirements
WARNING: To reduce the risk of fire, this dryer MUST BE
EXHAUSTED OUTDOORS.
IMPORTANT: Observe all governing codes and ordinances.
Dryer exhaust must not be connected into any gas vent,
chimney, wall, ceiling, attic, crawlspace, or a concealed space
of a building. Only rigid or flexible metal vent shall be used for
exhausting.
4" (102 mm) heavy metal exhaust vent
■Only a 4"(102 mm) heavy metal exhaust vent and clamps
may be used.
■Do not use plastic or metal foil vent.
Rigid metal vent:
■Recommended for best drying performance and to avoid
crushing and kinking.
Flexible metal vent: (Acceptable only if accessible to clean)
■Must be fully extended and supported in final dryer location.
■Remove excess to avoid sagging and kinking that may result
in reduced airflow and poor performance.
■Do not install in enclosed walls, ceilings, or floors.
■The total length should not exceed 7¾ ft. (2.4 m).
NOTE: If using an existing vent system, clean lint from entire
length of the system and make sure exhaust hood is not
plugged with lint. Replace plastic or metal foil vents with rigid
metal or flexible metal vents. Review “Vent System Chart” and,
if necessary, modify existing vent system to achieve best
drying performance.
Exhaust hoods:
■Must be at least 12"(305 mm) from ground or any object
that may obstruct exhaust (such as flowers, rocks, bushes,
or snow).
Recommended Style:
Louvered hood Box hood
Acceptable Style:
Angled hood
Elbows
45° elbows provide better airflow than 90° elbows.
Good Better
Clamps
■Use clamps to seal all joints.
■Exhaust vent must not be connected or secured with screws
or other fastening devices that extend into the interior of the
duct, because they can catch lint. Do not use duct tape.
Improper venting can cause moisture and lint to collect
indoors, which may result in:
Moisture damage to woodwork, furniture, paint, wallpaper,
carpets, etc.
Housecleaning problems and health problems.
Venting

13
Plan Vent System
Choose your exhaust installation type
Recommended exhaust installations:
Typical installations vent the dryer from the rear of the dryer.
Other installations are possible.
A
B
C
A. Exhaust hood
B. Flexible metal or rigid metal vent
C. Elbow
Alternate installations for close clearances:
Venting systems come in many varieties. Select the type best
for your installation. Two close-clearance installations are shown.
Refer to the manufacturer’s instructions.
A B
A. Over-the-top installation
(also available with one offset elbow)
B. Periscope installation
NOTE: The following kits for close clearance alternate
installations are available for purchase. For information on
ordering, see “Assistance or Service.”
■Over-the-Top Installation:
Part Number 4396028
■Periscope Installation (for use with dryer vent to wall
vent mismatch):
Part Number 4396037 - for mismatch of 0" (0 mm) to
18" (457 mm)
Part Number 4396011 - for mismatch of 18" (457 mm) to
29" (737 mm)
Part Number 4396014 - for mismatch of 29" (737 mm) to
50" (1.27 m)
Special provisions for mobile home installations
The exhaust vent must be securely fastened to a noncombustible
portion of the mobile home structure and must not terminate
beneath the mobile home. Terminate the exhaust vent outside.
Determine vent path
■Select the route that will provide the straightest and most
direct path outdoors.
■Plan the installation to use the fewest number of elbows
and turns.
■When using elbows or making turns, allow as much room
as possible.
■Bend vent gradually to avoid kinking.
■Use the fewest 90° turns possible.
Determine vent length and elbows needed for
best drying performance
■Use the “Vent System Chart” below to determine type of vent
material and hood combinations acceptable to use.
NOTE: Do not use vent runs longer than those specified in
the Vent system chart. Exhaust systems longer than those
specified will:
■Shorten the life of the dryer.
■Reduce performance, resulting in longer drying times and
increased energy usage.
The “Vent System Chart” provides venting requirements that will
help to achieve the best drying performance.
Vent System Chart
Number of
90° turns or
elbows
Type of vent Box or
louvered
hoods
Angled
hoods
0Rigid metal 36 ft (11 m) 26 ft (7.9 m)
1Rigid metal 26 ft (7.9 m) 16 ft (4.9 m)
2Rigid metal 16 ft (4.9 m) 6 ft (1.8 m)

14
Install Vent System
1. Install exhaust hood.
12" min.
(305 mm)
12" min.
(305 mm)
Install exhaust hood and use caulking compound to seal
exterior wall opening around exhaust hood.
2. Connect vent to exhaust hood.
Vent must fit inside exhaust hood. Secure vent to exhaust
hood with 4" (102 mm) clamp. Run vent to dryer location.
Use the straightest path possible. See “Determine vent path”
in “Plan Vent System.” Avoid 90° turns. Use clamps to seal
all joints. Do not use duct tape, screws, or other fastening
devices that extend into the interior of the vent to secure vent,
because they can catch lint.
Install Leveling Legs
1. To avoid damaging floor, use a large flat piece of cardboard
from dryer carton. Place cardboard under entire back edge of
the dryer.
2. Firmly grasp dryer body and gently lay dryer on cardboard.
See illustration.
3. Start to screw legs into holes by hand. Use a wrench to finish
turning legs. They should stick out about 1" (25 mm).
4. Place a carton corner post from dryer packaging under each
of the 2 dryer back corners. Stand the dryer up. Slide the
dryer on the corner posts until it is close to its final location.
Leave enough room to connect the exhaust vent.
Connect Vent
1. Connect vent to exhaust outlet.
Using a 4" (102 mm) clamp, connect vent to exhaust outlet
in dryer. If connecting to existing vent, make sure the vent is
clean. Dryer vent must fit over dryer exhaust outlet and inside
exhaust hood. Check that vent is secured to exhaust hood
with a 4" (102 mm) clamp.
2. Move dryer into its final location. Avoid crushing or kinking
the vent.
3. Once exhaust vent connection is made, remove corner posts
and cardboard.

15
Level Dryer
1. Check levelness of dryer. Check levelness first side to side,
then front to back.
Not Level LEVEL Not Level
2. Tighten and adjust leveling legs.
If dryer is not level, prop the dryer up using a wood block.
Use a wrench to adjust the legs up or down and check again
for levelness. Once legs are level, make sure all four legs are
snug against the floor before tightening them.
Complete Installation
1. Check that all parts are now installed. If there is an extra part,
go back through the steps to see what was skipped.
2. Check that you have all of your tools.
3. Dispose of/recycle all packaging materials.
4. Check dryer’s final location. Be sure vent is not crushed
or kinked.
5. Check that dryer is on a level surface.
6. For power supply cord installation, plug into an outlet. For
direct wire installation, turn on power.
7. Remove film on the console and any tape remaining on dryer.
Remove tape from lint screen (located on inside back wall
of dryer).
8. Read “Dryer Use.”
9. Wipe dryer drum interior thoroughly with a damp cloth to
remove any dust.
10. To test the dryer, set the dryer on a full heat cycle (not an air
cycle) for 20 minutes and start the dryer.
If the dryer will not start, check the following:
■Controls are set in a running or “On” position.
■START button has been firmly pressed.
■Dryer is plugged into an outlet and/or electrical supply
is on.
■Household fuse is intact and tight, or circuit breaker has
not tripped.
■Dryer door is closed.
11. When the dryer has been running for 5 minutes, open the
dryer door and feel for heat. If you feel heat, cancel cycle and
close the door.
If you do not feel heat, check the following:
■Controls are set on a heated cycle, not an air cycle.
NOTE: You may notice an odor when dryer is first heated. This
odor is common when the heating element is first used. The odor
will go away.

16
WARNING: To reduce the risk of fire, electric shock, or injury to
persons, read the IMPORTANT SAFETY INSTRUCTIONS before
operating this appliance.
Before using your dryer, wipe the dryer drum with a damp cloth to
remove dust from storing and shipping.
1. Clean the lint screen before each load. See “Cleaning the Lint
Screen.”
2. Load clothes loosely into the dryer and close the door. Do not
pack the dryer. Allow space for clothes to tumble freely.
UsingYour Dryer
Starting Your Dryer
3. Turn the Cycle Control knob to the recommended cycle for the
type of load being dried. Use the Energy Preferred setting to
dry most heavyweight and medium weight loads. See “Drying,
Cycle, and Temperature Tips.”
4. Press START.
Stopping and Restarting
You can stop your dryer anytime during a cycle.
To stop your dryer
Open dryer door or turn Cycle Control knob to OFF.
NOTE: The Cycle Control knob should point to an Off
area when dryer is not in use.
To restart your dryer
1. Close the door.
2. Select a new cycle and temperature (if desired).
3. Press START button.

17
Loading
Load clothes loosely into the dryer. Do not overload the dryer.
Allow space for clothes to tumble freely. The following chart
shows the maximum load you can place in your compact dryer.
Expect longer drying times.
Heavy work clothes 2 pair of pants, 3 work shirts
Delicates 1 camisole, 2 slips, 4 undergarments,
1 set of sleepwear, 1 half slip
Towels 9 bath towels; or 6 bath towels,
3 hand towels, 6 washcloths
Mixed load 2 pillowcases, 1 T-shirt, 2 shirts,
1 pair slacks
Knits 2 slacks, 2 shirts; or 3 dresses
Perm Press 6 shirts; or 2 double sheets &
2 pillowcases; or 2 singles sheets &
2 pillowcases
Drying, Cycle, and Temperature Tips
Select the correct cycle and temperature for your load.
Your dryer tumbles the load without heat during the last few
minutes of all cycles to make the load easier to handle.
Drying tips
■Follow care label directions when they are available.
■If desired, add a fabric softener sheet. Follow package
instructions.
■Remove load from the dryer as soon as tumbling stops to
reduce wrinkling. This is especially important for permanent
press, knits, and synthetic fabrics.
Cycle and temperature tips
■Dry most loads using the Energy Preferred setting.
■Use a no heat (air) setting for rubber, plastic, or heat-
sensitive fabrics.
■Line-dry bonded or laminated fabrics.
NOTE: If you have questions about drying temperatures for
various loads, refer to the care label directions.
Cycles
Auto Dry
Senses exhaust air temperature and shuts off when the load
reaches the selected dryness level. The Cycle Control knob does
not move until the load is almost dry. After the cool down, the
knob automatically turns to an Off area and tumbling stops.
Dry most loads using the Energy Preferred setting. Drying time
with an Auto Dry cycle varies according to the type of fabric, size
of load, and temperature setting.
■If the load is drier than you like, select a setting closer to Less
Dry the next time you dry a similar load.
■If the load is not as dry as you like, complete drying using the
Time Dry cycle. The next time you dry a similar load, select a
setting closer to Very Dry.
Air Dry
Use this cycle for items that require drying without heat, such
as rubber, plastic and heat-sensitive fabrics. See the chart for
examples of items that can be dried using an air cycle.
Type of Load Time*
Foam rubber - pillows,
padded bras, stuffed toys 20 - 30
Plastic - shower curtains,
tablecloths 20 - 30
Rubber-backed rugs 40 - 50
Olefin, polypropylene, sheer
nylon 10 - 20
*(Minutes). Reset cycle to complete drying, if needed.
When using an air cycle
■Check that coverings are securely stitched.
■Shake and fluff pillows by hand periodically during cycle.
■Dry item completely. Foam rubber pillows are slow to dry.
Time Dry Cycle
Use this cycle to complete drying if items are still damp after
the automatic cycle.
Time Dry is also useful for:
Heavyweight items and work clothes that require a long
drying time.
Lightweight items, such as lingerie, blouses and knits that
require a short drying time.
For damp dry, turn the Cycle Control knob to 30 minutes
or less.
End of Cycle Signal
The dryer sounds a signal to let you know when the cycle is
finished. The signal is not adjustable and cannot be turned off.
The signal is helpful when you are drying permanent press,
synthetics and other items that should be taken out as soon as
the dryer stops.
Cleaning the Dryer Location
Keep dryer area clear and free from items that would obstruct the
flow of combustion and ventilation air.

18
Cleaning the Lint Screen
Every load cleaning
The lint screen is located inside the dryer drum, on the back wall.
Clean it before each load. A screen blocked by lint can increase
drying time.
To clean:
1. Open the door and pull the lint screen straight out.
2. Squeeze body of lint screen lightly while pulling off the cover.
3. Roll lint off the screen with your fingers. Do not rinse or wash
screen to remove lint. Wet lint is hard to remove.
4. Replace cover on lint screen body. Push the lint screen firmly
back into place and close the door.
IMPORTANT:
■Do not run the dryer with the lint screen loose, damaged,
blocked, or missing. Doing so can cause overheating and
damage to both the dryer and fabrics.
As needed cleaning
Laundry detergent and fabric softener residue can build up on the
lint screen. This buildup can cause longer drying times for your
clothes, or cause the dryer to stop before your load is completely
dry. The screen is probably clogged if lint falls off the screen.
Clean the lint screen with a nylon brush every 6 months, or more
frequently if it becomes clogged due to a residue buildup.
Dryer Care To wash:
1. Roll lint off the screen with your fingers.
2. Wet both the lint screen cover and body with hot water.
3. Wet a nylon brush with hot water and liquid detergent.
Scrub lint screen cover and body with the brush to remove
residue buildup.
4. Rinse with hot water.
5. Thoroughly dry lint screen body and cover with a clean towel.
Replace in dryer.
Cleaning the Dryer Interior
To clean dryer drum:
1. Make a paste with powdered laundry detergent and very
warm water.
2. Apply paste to a soft cloth.
OR
Apply a liquid, nonflammable household cleaner to the stained
area and rub with a soft cloth until all excess dye is removed.
3. Wipe drum thoroughly with a damp cloth.
4. Tumble a load of clean cloths or towels to dry drum.
NOTE: Garments that contain unstable dyes, such as denim blue
jeans or brightly colored cotton items, may discolor the dryer
interior. These stains are not harmful to your dryer and will not
stain future loads of clothes. Dry unstable dye items inside-out to
avoid transfer of dye.
Removing Accumulated Lint
From Inside the Dryer Cabinet
Lint should be removed every 2 years, or more often, depending
on dryer usage. Cleaning should be done by a qualified person.
From the Exhaust Vent
Lint should be removed every 2 years, or more often, depending
on dryer usage.

19
Troubleshooting
If you experience Possible Causes Solution
Dryer Operation
Dryer will not run Door not closed completely. Make sure the dryer door is closed completely.
Press and hold the START button
2–5 seconds. Press and hold the START button 2–5 seconds.
Household fuse is blown or circuit
breaker has tripped. There may be 2 household fuses or circuit breakers for the dryer. Check that both fuses are intact and tight, or that both circuit
breakers have not tripped. Replace the fuses or reset the circuit
breaker. If the problem continues, call an electrician.
Incorrect power supply. Electric dryers require 240 volt power supply.
Check with a qualified electrician.
Wrong type of fuse. Use a time-delay fuse.
Dryer will not heat Household fuse is blown or circuit
breaker has tripped. The drum may be turning, but you may not have heat. Electric dryers use 2 household fuses or circuit breakers. Replace the
fuses or reset the circuit breaker. If the problem continues, call
an electrician.
Incorrect power supply. Electric dryers require 240 volt power supply.
Check with a qualified electrician.
Timer does not
noticeably advance Dryer set to Timed or Air Dry The timer moves slowly and continuously for the time setting.
Dryer set to Auto Dry The timer moves only when the clothing is mostly dry. See
“Auto Dry” in “Cycles” section.
Unusual Noise
Thumping noise Dryer hasn’t been used in a while. This is normal. The thumping sound should diminish after a few
minutes of use.
Rattling or vibrating noise A small object caught between the
edges of dryer drum. Check the front and rear edges of the drum for small objects. Clean out pockets before laundering.
Dryer isn’t properly leveled. The dryer may vibrate if not properly installed. See “Level Dryer.”
All four leveling legs should be in firm contact with the floor.
Clothing is balled up in dryer. When balled up, the load will bounce, causing the dryer to
vibrate. Separate the load items and restart the dryer.
First try the solutions suggested here or visit our website at www.amana.custhelp.com -
In Canada www.amanacanada.ca for assistance and to possibly avoid a service call.
Vacation and Moving Care
Vacation Care
Operate your dryer only when you are at home. If you will be on
vacation or not using your dryer for an extended period of time,
you should:
1. Unplug dryer or disconnect power.
2. Clean lint screen. See “Cleaning the Lint Screen.”
Moving Care
For power supply cord-connected dryers:
1. Unplug the power supply cord.
2. Make sure leveling legs are secure in dryer base.
3. Use tape to secure dryer door.
For direct-wired dryers:
1. Disconnect power.
2. Disconnect wiring.
3. Make sure leveling legs are secure in dryer base.
4. Use tape to secure dryer door.

20
Troubleshooting
If you experience Possible Causes Solution
Dryer Results
NOTE: The compact dryer operates at a lower wattage. Expect longer drying times.
Clothes are not drying
satisfactorily or drying
times are too long
Lint screen is clogged with lint. Clean lint screen before each load.
The exhaust vent or outside exhaust
hood is clogged with lint, restricting
air movement.
Run the dryer for 5–10 minutes. Hold your hand under
the outside exhaust hood to check air movement. If you
do not feel air movement, clean exhaust system of lint
or replace exhaust vent with heavy metal or flexible metal vent.
See “Venting.”
The exhaust vent is not the correct
length. Check that the exhaust vent is not too long or has too many turns. Long venting will increase drying times.
See “Venting.”
The exhaust vent diameter is not the
correct size. Use 4"(102 mm) diameter vent material.
The Air Dry cycle has been selected. Select the correct temperature for the types of garments being
dried. See “Cycles.”
The load is too large and heavy
to dry quickly. Separate the load to tumble freely.
Fabric softener sheets are blocking
the lint screen cover. Use only one fabric softener sheet, and use it only once.
The dryer is located in a room with
temperature below 45°F (7°C). Proper operation of dryer cycles requires temperatures above 45°F (7°C).
The dryer is located in a closet. Closet doors must have ventilation openings at the top
and bottom of the door. The front of the dryer requires a
minimum of 1"(25 mm) of airspace, and, for most
installations, the rear of the dryer requires 5½"(140 mm).
See “Location Requirements.”
First try the solutions suggested here or visit our website at www.amana.custhelp.com -
In Canada www.amanacanada.ca for assistance and to possibly avoid a service call.
