American Eagle 13P User manual

Model 13P
Single-Stage Piston
Compressor Manual
American Eagle
740 North State Street
PO Box 169
Garner, IA 50438
800-392-3015
www.americaneagleacc.com
Subject to Change without Notification.
© 2019 American Eagle
Rev 1
PN 92580
Specifications • Installation • Assembly
®

Page ii | American Eagle®13P Compressor Manual
Model 13P Manual Revisions
Date of Revision Section Revised Description of Revision
Serial Tag
DATE
HYDRAULIC FLOW (GPM) HYDRAULIC PRESSURE (PSI)COMPRESSOR SPEED (RPM)
HYDRAULIC MOTOR SERIAL
COMPRESSOR MODEL
MADE IN THE U.S.A. BY AMERICAN EAGLE.
COMPRESSOR SERIAL
PATENT INFORMATION
http://www.americaneagleacc.com/ip
PN 54490

American Eagle®13P Compressor Manual | Page iii
Table of Contents
For Technical Questions, Information, Parts, or Warranty, Call Toll-Free at
800-321-3741
Hours: Monday - Friday, 8:00 a.m. - 5:00 p.m. CST
Or email at the following addresses:
Technical Questions, and Information: [email protected]
Order Parts: [email protected]
Warranty Information: [email protected]
Introduction ............................................................................................................................................iv
Chapter 1 - Specifications......................................................................................................................... 1
Chapter 2 - Installation .............................................................................................................................. 3
Component Installation......................................................................................................................... 3
Component Installation, continued..................................................................................................... 4
13P Electrical Schematic....................................................................................................................... 5
Hydraulic System .................................................................................................................................... 6
Air System ................................................................................................................................................ 6
Compressor Pressure Switch.................................................................................................................. 7
Typical Hydraulic Circuit for Single-Section Pump.............................................................................. 8
Typical Hydraulic Circuit for Tandem (Two Part) Pump .................................................................... 9
Typical Hydraulic Circuit for Compressor with Auxiliary Cooler ...................................................... 10
Chapter 3 - Assembly Drawings ............................................................................................................. 11
13P Assembly - PN D1829 .................................................................................................................... 11
Crankcase Group (Straight Shaft)...................................................................................................... 12
Cylinder Group..................................................................................................................................... 13
Head Group.......................................................................................................................................... 14
Chapter 4 - Replacement Parts .............................................................................................................. 15

Page iv | American Eagle®13P Compressor Manual
Introduction
American Eagle®Air Compressors are designed to provide safe and dependable service
for a variety of operations. With proper use and maintenance, these air compressors will
operate at peak performance for many years.
To promote this longevity, carefully study the information contained in this manual before
putting the equipment into service. Though it is not intended to be a training manual for
beginners, this manual should provide solid guidelines for the safe and proper usage of the
air compressor.
Once you feel comfortable with the material contained in this manual, strive to exercise
your knowledge as you safely operate and maintain the air compressor. This process is vital
to the proper use of the unit.
A few notes on this manual:
A copy of this manual is provided with every air compressor and can be found in the hard
plastic manual case that is installed on the chassis. A copy of this manual shall remain with
the air compressor at all times.
Throughout the manual, three signal words will be used to bring attention to important
items:
A NOTICE signal word indicates a practice not related to physical injury.
A WARNING signal word indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
A DANGER signal word indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
Information contained within this manual does not cover all maintenance, operating, or
repair instructions pertinent to all possible situations. Please be aware that some sections
of this manual contain information pertaining to American Eagle®manufactured air
compressors in general and may or may not apply to your specific model.
This manual is not binding. American Eagle reserves the right to change, at any time, any
or all of the items, components, and parts deemed necessary for product improvement or
commercial/production purposes. This right is kept with no requirement or obligation for
immediate mandatory updating of this manual.
In closing:
If more information is required or technical assistance is needed, or if you feel that any
part of this manual is unclear or incorrect, please contact the American Eagle Customer
Service Department by phone at 800-392-3015 or email at service@americaneagleacc.
com.
WARNING
NOTICE
DANGER

American Eagle®13P Compressor Manual | Page 1
Chapter 1 - Specifications
25.09
16.69
14.13
5.46
13.00
6.63
SLOT
.44X0.63
TYP 4
1.38
11.38
1.38
SPECIFICATIONS 13P
Hydraulic System 7 GPM @ 1800 PSI
Max Compressor Speed 1300 RPM
Hydraulic Operating Pressure 1800 PSI
Hydraulic Relief Pressure 2500 PSI
Max Air Pressure 150 PSI
Air Delivery (At Max Speed) 13 CFM @ 100 PSI
Max Working Pressure 150 PSI
Weight (Hydraulic Driven Asm) 135 lbs.
Weight (Air Pump Only) 60 lbs.
Dimensions (Length) 25.09"
Dimensions (Width) 14.13"
Dimensions (Height) 16.69"
Electrical 12V DC
Crankcase Oil Capacity 24 Ounces
Cooler Fan 350 CFM, 12 Volt (Pull)
Drive Type Direct Driven
Duty cycle on Piston Compressors is 50:50 over 10 minutes.
NOTICE

Page 2 | American Eagle®13P Compressor Manual
This page intentionally left blank.

American Eagle®13P Compressor Manual | Page 3
Chapter 2 - Installation
Component Installation
This section pertains to the installation of the air compressor, PTO, pump and other related
items. The instructions are intended as a guide to assist you with particular installation.
These instructions will provide only general information.
Compressor Torque Procedure
Head Assembly:
Torque Value: 34 ft-lbs
Procedure: Assemble head on the cylinder with head bolts
started only, not tight. Working in the pattern shown, torque
three times, increasing the torque each time as follows:
First Torque: 10 ft-lbs
Second Torque: 20 ft-lbs
Third Torque: 34 ft-lbs
After five hours of use re-torque bolts to 34 ft-lbs.
Cylinder Assembly:
Torque Value: 20 ft-lbs
Procedure: After assembling cylinder over pistons and setting into place, tighten (6) cap
screws finger tight. In a criss-cross pattern, tighten bolts evenly so all bolts are hand snug.
Again in a criss-cross pattern torque each bolt to 20 ft-lbs, checking each bolt twice. After
five hours of use, re-torque bolts to 20 ft-lbs.
Connecting Rod Control:
Torque Value: 18 ft-lbs
Procedure: Assemble rod onto the crankshaft taking care to align the machined surfaces
together and tighten cap screws finger tight. Tighten bolts until hand tight and torque to 18
ft-lbs. Check twice the torque reading before final assembly of the cylinders.
12
43
56

Page 4 | American Eagle®13P Compressor Manual
Pump Assembly:
The pump assembly may either be installed directly on the PTO or as an optional
method, may be driven by a driveline from the PTO. Pump manufacturers provide specific
installation information for their products and should be consulted if questions arise.
Note: A dual or tandem hydraulic pump is recommended when additional hydraulically
operated equipment are added to the hydraulic system.
PTO Assembly:
Check with the PTO manufacturer’s representative for specific instructions regarding your
particular make, model, and year of vehicle. As some trucks may require modification of
the transmission cross member and the exhaust system, the manufacturer’s instructions
should be followed to ensure proper installation of the PTO.
Compressor Assembly:
Prepare the mounting location of the compressor by locating and drilling four (4) holes,
1/2” diameter as per the mounting pattern of the air compressor base. Using four (4) 3/8” x
1.25 GR-5 cap screws, 3/8” flat washer, and 3/8” nyloc nut, secure the compressor in place.
The compressor is air cooled, and must have a clean supply of cooling air to the fan with
minimum restrictions. Adequate space must be provided for proper circulation of air.
Electric Speed Control:
An optional electric or electronic speed control must be used to maintain proper
operating speed of the air compressor. The engine speed control will automatically
increase from idle to preset speed when engaged and decrease when disengaged.
POWER SUPPLY
(12V BATTERY HOT)
GROUND
CPRSR RELAY
(12V CONTROL INPUT)
SPEED CTRL
(12V CONTROL OUTPUT)
RED 12GA
GRN 14GA
YEL 14GA
BLK 12GA
CIRCUIT BREAKER
(STELLAR SUPPLIED)
BATTERY +
* CUSTOMER ADDED WIRING MUST MATCH OR
EXCEED PIGTAIL WIRE SIZE FOR POWER
SUPPLY AND GROUND CIRCUIT
ELECTRICAL PIGTAIL
(STELLAR SUPPLIED)
Component Installation, continued

American Eagle®13P Compressor Manual | Page 5
13P Electrical Schematic
Electrical Connections:
Supplied with the compressor is a wire harness pigtail which has 4 leads coming off of it.
Connect the black wire to the vehicle frame or other suitable ground. Connect the red
lead to a fused power source. Mount a single throw toggle switch in a convenient location
and connect the green wire from the compressor to this switch. Connect the other switch
terminal to a fuse holder and then to a 12V power supply. The yellow wire is required from
the compressor when connecting the speed control into the system.
6Class 1 Compressor Owner’s Manual
Return Line
Pressure
Line
GND
CPRSR
SPD CTRL
PRESSURE
SWITCH
LINE
MOTOR
HYDRAULIC
MANIFOLD
C
OMPRESSOR (12V INPUT)
GROUND
SPEED CONTROL
C
B
A
C
B
A
SHD-21/8P Installation
Pump Assembly:
The pump assembly may either be installed directly
on the PTO or as an optional method, may be
driven by a driveline from the PTO. Pump
manufacturers provide specific installation
information for their products and should be
consulted if questions arise.
PTO Assembly:
Check with the PTO manufactures representative
for specific instructions regarding your particular
make, model, and year of vehicle. As some trucks
may require modification of the transmission cross
member and the exhaust system, the
manufacturer’s instructions should be followed to
insure proper installation of the PTO.
Compressor Assembly:
Prepare the mounting location of the compressor
by locating and drilling four (4) holes, 7/16”
diameter as per the mounting pattern of the air
compressor base. Using four (4) 3/8” x 1.25 GR-5
cap screws, 3/8” flat washers, and 3/8” nyloc nuts,
secure the compressor in place. The compressor is
air cooled, and must have a clean supply of
cooling air to the fan with minimum restrictions.
Adequate space must be provided for proper
circulation of air.
FAN
Electric speed control:
An optional electric or electronic speed control
must be used to maintain proper operating speed
of the air compressor. The engine speed control will
automatically increase from idle to preset speed
when engaged and decrease when disengaged.
The electric cable pull speed control (American
Eagle P/N 25740) is used on most gasoline engines.
The electronic speed controls are used only on Ford
7.3 and 6.0L diesel engines. Proper installation
instructions are provided with each system.
Hydraulic System:
The hydraulic system consists of the pump, oil
reservoir, filters and hoses. Installed on the
compressor is a valve block assembly that controls
the flow to the hydraulic motor. To this block, a 1/2”
high-pressure hose must be attached. This hose
comes from the hydraulic pumps pressure side. A
3/4” minimum low-pressure return line is connected
to the oil cooler outlet and is routed to the oil
reservoir. American Eagle recommends a sufficient
sized reservoir be provided which includes the
proper suction and return filters. The cooler on the
compressor is designed and sized to cool the air
compressor efficiently. An auxiliary oil cooler is
required when additional hydraulically operated
equipment are added to the hydraulic system.
Pressure on the return line exceeding 200 PSI can
and will cause damage to the filter, cooler, and
components of the compressor hydraulic system.

Page 6 | American Eagle®13P Compressor Manual
HYDRAULIC PRESSURE
-8 SAE PORT
HYDRAULIC RETURN
-12 MALE JIC
AIR DISCHARGE
-12 FEMALE NPT
The hydraulic system consists of the oil reservoir, pump, manifold, motor, filters, and
hoses. A ½” 3000psi pressure line should be connected to the pressure line fitting on the
bulkhead. This line is plumbed though an internal manifold block, and then to the motor.
After the motor there is an internal cooler which the oil passes through before going to
the return line bulkhead fitting. A ¾” minimum low-pressure return line is to connect to
the return bulkhead fitting and filter before being returned to the oil reservoir. American
Eagle recommends a sufficiently-sized reservoir be provided that includes the proper
suction and return filters. The cooler on the compressor is designed and sized to cool the
air compressor efficiently. An auxiliary oil cooler is required when additional hydraulically
operated equipment is added to the hydraulic system. Pressure on the return line
exceeding 200PSI can and will cause damage to the filter, cooler, and components of the
compressor’s hydraulic system.
The airline is routed using a ¾” 200 psi air/steam hose. This delivery line should be free from
all obstructions. Note: There should be no check valve installed between the compressor
and the air tank (One is already included in the compressor package). American Eagle
recommends the installation of a ten-gallon air tank (minimum) to maintain proper
operation of the air compressor.
Hydraulic System
Air System

American Eagle®13P Compressor Manual | Page 7
Pressure Setting Instructions:
1. Always set the kick out pressure setting first. Adjust the kick out screw setting to 145 psi
minimum/150 psi maximum.
2. After kick out pressure is set, adjust the kick on screw setting to 115 psi minimum/120 psi
maximum.
3. Cycle compressor to verify correct settings.
4. For questions about this procedure, please contact American Eagle Customer Service at
800-321-3741.
Compressor Pressure Switch
Kick Out (Step 1)
Pressure Setting
Adjustment Screw
(145-150 psi)
Kick On (Step 2)
Pressure Setting
Adjustment Screw
(115-120 psi)
Note: Turning adjustment screws clockwise increases psi settings.
Turning adjustment screws counterclockwise decreased psi settings.
Pressure
Switch

Page 8 | American Eagle®13P Compressor Manual
Typical Hydraulic Circuit for Single-Section Pump
PN 30533

American Eagle®13P Compressor Manual | Page 9
Typical Hydraulic Circuit for Tandem (Two Part) Pump
PN 30532

Page 10 | American Eagle®13P Compressor Manual
Typical Hydraulic Circuit for Compressor with Auxiliary Cooler
COMPRESSOR
RETURN
PRESSURE
AUXILIARY
COOLER
SINGLE
HYDRAULIC
PUMP
SUCTION PORT
FILTER
FILTER SCREEN
HYDRAULIC
RESERVOIR

American Eagle®13P Compressor Manual | Page 11
Chapter 3 - Assembly Drawings
13P Assembly - PN D1829
9
4
53
52
10
11
13
12
14
23
28
22
17
3
3
4
6
31
16
33
15
8
58
47
19
20
21
39
42
41
43
44
46
45
1
27
4
3
2
3
7
21
21
40
6
50
7
49
56
55
26
5
6
30
29
32
34
25
20
59
38
29
48
6
3
7
56
ITEM PART DESCRIPTION
QTY.
1 4156 BASE WLDMT SHD30 L BASE 1
2 12809
BRKT COOLER MNT SHD 30/21 1
3
C6353 WASHER 0.38 FLAT GR8 14
4 0522
WASHER 0.31 LOCK 10
5 5472
COOLER OIL SHD30 & SHD21 1
6
C0922 CAP SCR 0.31-18X1.00 HHGR5 14
7 0342
NUT 0.31-18 HH NYLOC 10
8
B0800 BRACKET MOTOR MOUNT 1
9 5661
SPACER SHD30 CPRSR 2
10
C3480 COUPG HYD CPRSR TAPER 1
11
D1465 WASHER 0.31-0.178 THICK 1
12
C4570 CAP SCR 0.31-24X0.75 HH NF 1
13
C4779 COUPG SPIDER SUL 99 BLUE URETHANE 1
14
C4781 COUPLING LOVEJOY 5/8 1
15 4568
MOTOR HYD 21306 DSE 1
16 0345
CAP SCR 0.38-16X1.50 HHGR5 2
17 0347
NUT 0.38-16 HH NYLOC 2
19 0340
WASHER 0.25 FLAT 2
20 0521
WASHER 0.25 LOCK 4
ITEM PART DESCRIPTION
QTY.
21 0479 CAP SCR 0.25-20X0.75 HHGR5 6
22 16605
HOSE STEAM 0.75(200PSI)-12MP RIGID-12M 1
23 5425
FTG 12-12X2.50 MP-MP NIPPLE STRAIGHT B 1
25 0483
CAP SCR 0.25-20 X 3.50 HHGR5 2
26 12808
FTG 12-8 MJ-MORB STRAIGHT 2
27 0420
CAP SCR 0.31-18X0.75 HHGR5 2
28
C6175 FTG 12-12 FP-FP 90 1
29
C4498 FTG 12-12 MJ-MORB STRAIGHT 2
30
C4954 TUBE ASM 0.50 MANIF TO MOTOR SHD60 YZ 1
31
C6145 FTG 12-12 MJ-MAORB 90 1
32
C4501 FTG 8-8 MJ-MAORB 90 1
33
C4671 FTG 8-12 MJ-MAORB 90 1
34
C2297 TUBE ASM 0.50 MANIF TO MOTOR SHD60 YZ 1
38
C2322 FTG 8 MORB PLUG 1
39
C2261 DRAIN COCK 1
40 4586
FAN 7.50" PULL 12 VOLT SPL 301003 1
41
D1264 FTG 0.75-CLOSE RED BRASS NIPPLE 1
42 5480
VALVE CHECK 0.75 STANDARD 1
43
C6101 FTG 4-2 MP-MP HEX NIPPLE 1
ITEM PART DESCRIPTION QTY.
44 C0863 SWITCH PRES COMPRESSOR 1
45
C5616 CLAMP ROMEX 0.50
1
46 16641
TUBE COPPER 0.25X9.00 1
47
D0240 FTG 4-2 CPRSN-MP 90 1
48 5590
TUBE ASM MANIF TO CLR 0.75 SHD30/21 ZC 1
49 5139
HOOD F/G SHD30 1
50 0343
WASHER 0.31 USS FLAT ZINC 4
52 3860
CPRSR 200CI6NP 1
53 0485
CAP SCR 0.31-18X1.25 HHGR5 4
54 29589
PANEL SHROUD FAN SHD21 1
55 29590
CAP SHROUD FAN SHD21 1
56 0333
NUT 0.25-20 HHGR5 NYLOC 4
58 11284
PULSATION TANK SHD30 1
59 44645
MANIFOLD ASM SHD60 1

Page 12 | American Eagle®13P Compressor Manual
Crankcase Group (Straight Shaft)
01
71 51
41
61
11
8 21
2
5
4
6
33
72
42
32
22
02
12
91
81
52
23
13
31
3
62
9
1
7
82
03
92
43
.YTQNOITPIRCSEDTRAPMETI
1S/O002ESACKNARC19751
1002-RETLIFEKATNILIOGULP88752
5)510.(002-REIRRACGNIRAEBTEKSAG11853
100.3X52.EKATNILIOEBUT58754
1002-RETLIFEKATNILIOGNIR'O78755
1002-RETLIFEKATNILIONEERCS48756
1084VLAESGNIRAEB8626C7
1S002VTFAHSKNARC638228
1)01076ML(PUCGNIRAEB3611C9
1)01644L(PUCGNIRAEB
4611C01
1ENOCGNIRAEB5580C11
184076MLENOCGNIRAEB6580C21
1002REIRRACGNIRAEB538631
1002/063V/084VEVEELSEVIRDPMUPLIO028541
1PMUPLIOGNIRPS0600C51
105.X91.0NIPLLOR718561
1GNIHSUBREFSNARTPMUPLIO9500C71
1PMUPLIO0500C81
1TEKSAGETALPTROP5726C91
1DENIHCAMETALPTROP2500C02
136.X91.0NIPLLOR9022212
1)LLAMS(TEKSAGREVOCETALPTROP4500C22
1REVOCETALPTROP6262232
45RGHH52
.1X81-13.0RCSPAC584042
4CHS00.1X81-13.0WERCS430652
100283BTPN83.RSRPCREHTAERB3860262
1DHQSTPN52.0GULP097572
1)002(DORKCITSPID9403282
1)002(YDOBKCITSPID0503292
1211-GNIR'O1400C03
1084VKCEHCLIOKCITSPIDELDNAH6862213
15.1ISPLIOEGUAG918523
126-0005NNIPNOTSIPGNIRPANS3726C33
14/1LEEHWYLFYEK7403243
CRANKCASE GROUP

American Eagle®13P Compressor Manual | Page 13
Cylinder Group
6
5
4
2
3
5
12
9
8
7
10
11
1
12
.YTQNOITPIRCSEDTRAPMETI
2TEKSAGREDNILYC7400C1
2 C6364 CONNECTING ROD 200/V480 O/S2
2084V/002NOTSIP76753
2084V/002NIPNOTSIP7636C4
5 C6273 SNAP RING PISTON PIN N5000-62 4
6 C6360 CYLINDER V480 FINISHED O/S1
6KCOL13.0REHSAW22507
8 C0922 CAP SCR 0.31-18X1.00 HHGR5 6
9 5827 RING OIL V480/200 FLEX DIVIDER2
10 32931 RING SCRAPER V480/200 H#48638 2
11 32930 RING CPRSN V480/200 BARREL H#383472
12 36368 RING OIL V480/200 RING RAIL4
CYLINDER GROUP

Page 14 | American Eagle®13P Compressor Manual
Head Group
5
3
4
2
1
31
21
11
01
8
7
9
6
41
.YTQNOITPIRCSEDTRAPMETI
1S/O002C/ADAEH83751
4TLOBDAEHHS57.1X61-83.0RCSPAC6851C2
1LTSTLOBDHREHSAW0400C3
1)SSARB(TLOBDHGNOLREHSAW82854
2TLOBDAEHHS00.3X61-83.0RCSPAC2851C5
1NEERCSRETLIF7920C6
1MAOFRETLIF6920C7
1RENIATERRETLIF4920C8
1MAOFRETLIF5170C9
3FN88.0X23-01#WERCS0030C01
1084/002ETALPEVLAVTEKSAG7880D11
1S/OMSABUSETALPEVLAV3
014221
1084/063/032/341DAEHTEKSAG0130C31
3RSRPCRATS01#REHSAW5783241
HEAD GROUP

American Eagle®13P Compressor Manual | Page 15
Chapter 4 - Replacement Parts
Assembly Items
Part Number Description Kit Contents (If Applicable)
4468 Overhaul Kit Gasket Set (Qty 1), Ring Set (Qty 1), Valve Plate (Qty 1),
Bearing Oil Seal (Qty 1), Oil (1 Quart), Inner Filter (Qty
1), Outer Filter (Qty 1)
5773 Gasket Set Complete
23366 Ring Set Complete
D1489 Valve Plate Assembly Valve Plate (Qty 1), Top Head Gasket (Qty 1), Bottom
Head Gasket (Qty 1)
5783 Crankshaft with Bearings -
Straight Shaft
23198 Crankshaft with Bearings -
Tapered Shaft
Maintenance Items
Part Number Description Kit Contents (If Applicable)
4562 Canister Filter Element Only
22867 Canister Filter Assembly
C0297 Embedded Filter Screen
C0296 Embedded Filter Foam -
Outer
C0715 Embedded Filter Foam -
Inner
C0294 Embedded Filter Retainer
C0087 Synthetic Compressor Oil
(Quart)
7259 Synthetic Compressor Oil
(Case of 12 Quarts)

®
Subject to Change without Notification.
© 2019 American Eagle
