Owner’s Manual
Model
RC1011
Questions?
in U.S. : 1-877-227-5832
TEAM PRODUCTS INTERNATIONAL INC. Limited Warranty
WHAT IS COVERED: Any defect in materials and workmanship.
FOR HOW LONG: Ninety (90) days from the date of original purchase.
WHAT WE ASK YOU TO DO: Team Products International, Inc. (“TPI”) will replace the
defective product within the ninety (90) days from the date of original purchase. The product
must first be returned with your sales receipt to the retailer. If the retailer’s return policy has
expired, TPI will replace the defective product. The customer is responsible for the shipping
charges to TPI, but TPI will incur the shipping charges on the replacement. When sending
your product include your name, address, phone number, copy of proof of date of purchase
(receipt), and a description of the operating problem. After receiving your product, we will ship
a replacement to your home or office within four weeks. Please return the defective product to
the following address:
Alco Industries, Inc
c/o TEAM PRODUCTS INTERNATIONAL, Returns
111A Melrich Road
Cranbury, NJ 08512
WHAT WE WILL DO: If your product is defective and was not able to be returned within the
in store return policy date, but within ninety (90) days of the original purchase date we will
replace it at no charge to you. We suggest that you retain your original packing material in
the event you need to ship your product. When we replace your product, we may replace it
with a new or reconditioned one of the same or similar product. The replacement will only be
warranted ninety (90) days from the original date of receipt.
WHAT THIS WARRANTY DOES NOT COVER: AMONG OTHER THINGS THIS WARRANTY
DOES NOT COVER DEFECTS RESULTING FROM ACCIDENTS, DAMAGE WHILE IN
TRANSIT TO OUR SERVICE LOCATION, ALTERATIONS, UNAUTHORIZED REPAIR, FAILURE
TO FOLLOW INSTRUCTIONS, MISUSE, FIRE, FLOOD, WAR, AND ACTS OF GOD. IF YOUR
PRODUCT IS NOT COVERED BY OUR WARRANTY, CALL OUR CUSTOMER SERVICE
DEPARTMENT AT [phone] TO DISCUSS FURTHER OPTIONS. THIS LIMITED
WARRANTY IS THE ONLY ONE WE GIVE ON YOUR PRODUCT, AND IT SETS FORTH ALL
OUR RESPONSIBILITIES REGARDING YOUR PRODUCT. THERE ARE NO WARRANTIES
WHICH EXTEND BEYOND THE DESCRIPTION SET FORTH ABOVE.
LIMITATIONS: IMPLIED WARRANTIES, INCLUDING THOSE OF FITNESS FOR A
PARTICULAR PURPOSE AND MERCHANTABILITY (AN UNWRITTEN WARRANTY THAT
THE PRODUCT IS FIT FOR ORDINARY USE), ARE LIMITED TO NINETY (90) DAYS
FROM ORIGINAL DATE OF PURCHASE. WE WILL NOT PAY FOR LOSS OF TIME,
INCONVENIENCE, LOSS OF USE OF YOUR PRODUCT OR PROPERTY DAMAGE
CAUSED BY YOUR PRODUCT OR ITS FAILURE TO WORK, OR ANY OTHER INCIDENTAL
OR CONSEQUENTIAL DAMAGES INCLUDING PERSONAL INJURY. SOME STATES DO
NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE
ABOVE EXCLUSIONS OR LIMITATIONS MAY NOT APPLY TO YOU.
STATE LAW RIGHTS: This warranty gives you specific legal rights and you may also have
other rights which may vary from state to state.
QUESTIONS? If you have any questions about this product, please contact Team Products
International Customer Service Department at [phone], 9 am to 5 pm Eastern Time,
Monday – Friday or visit our website at: www.teamproducts.com.
Rechargeable Battery Charger
© 2007 Team Products International, Inc. All Rights Reserved.
Made in China.
The American Red Cross logo is a registered trademark owned by the American Red Cross, used under license.

Model
RC1011
Owner’s Manual
1
2
Welcome
This American Red Cross product has been carefully designed to give you
peace of mind while on the road. Please read this manual thoroughly before
operating your new American Red Cross product, as it contains the information
you need to become familiar with its features and obtain the performance that
you need during a roadside incident.
Please keep this manual on file for future reference.
OPERATING INSTRUCTIONS:
Charging the Unit Battery
The Rechargeable Battery Charger has a built-in nickel-cadmium battery.
Although the unit may arrive partially charged from the factory, we recommend
that you fully charge it before the first use. Once your vehicle is running,
simply plug the Rechargeable Battery Charger into the 12V power port. Push
the ON/OFF switch to turn the unit OFF. The LED light marked “VL” will
illuminate and the LED marked “CH” will illuminate green and start flashing.
Several hours of driving time is required to fully recharge the unit. Once the unit
is fully recharged, the LED marked “CH” will stop flashing. The unit will hold the
charge for several months. However, you should check the status of the charge
periodically. To do this, simply press the ON/OFF button. The LED light marked
“VL” should illuminate GREEN. If it does not, recharge the unit as explained
above. To avoid wasting the charge, immediately press the ON/OFF button
again to turn the unit OFF.
Charge Time Guidelines
Time / Minutes Engine Trouble
10 Engine turns slowly when starting
20 Engine makes clicking sound when starting
30 Engine does not turn or make and sounds
40 Headlights do not turn on
Note: Some vehicle’s 12-volt power ports do not operate unless the ignition
switch is in the “accessory” or “on” position. If the charging indicator does not
illuminate, check to see if your ignition switch is in the proper position.
Note: Do not continuously charge the unit for more than 36 hours.
Recharging a Vehicle
If your battery is too weak to start your vehicle, you can use the Rechargeable
Battery Charger System. Make sure that the vehicle’s accessories are all
turned off (lights, AC, heater, radio, etc.) prior to using the Rechargeable
Battery Charger System. For maximum power, make sure there are no 12-volt
accessories connected to the unit.
On/Off Switch Charge Indicator Light
12 Volt Plug
About your Rechargeable Battery Charger
Warnings
When recharging your vehicle, make sure that the Rechargeable Battery
Charger is securely connected to your vehicle’s 12-volt power port. Failure
to do so may result in the improper functioning of the unit.
Do not expose unit to moisture.
Always turn unit off when not in use.
Do not open unit. There are no user-serviceable parts in this unit. Doing so
will void the warranty.
Do not dispose of this product in fire, batteries inside product may explode
or leak.
•
•
•
•
•

Model
RC1011
Owner’s Manual
3
4
Turn the dome light of your vehicle ON, even if your battery does not have
enough “juice” left to actually make it illuminate. Plug the Rechargeable Battery
Charger into your vehicle’s 12-volt power port. Turn the ignition key to the
“accessory” position. Push the ON/OFF switch on the charger to turn it ON.
The LED light marked “VL” will illuminate AMBER/GREEN. Your dome light
should begin to brighten, showing that the unit is charging your battery. If the
dome light was not lit before, it should begin to light up. At this point, turn your
dome light off for maximum charging. Keep the Rechargeable Battery Charger
plugged in for about 40 minutes. After this time you can try to start your vehicle.
If it does not start, DO NOT TRY TO START IT AGAIN. Wait another 20
minutes before you try to start your vehicle again. Your vehicle should start.
After recharging your vehicle, recharge the Rechargeable Battery Charger.
Please be sure to reference your vehicle’s owner’s manual. Check to be
sure if there are any other requirements for your vehicle when recharging it.
You may need to have it checked at a repair shop or dealership.
Powering Your 12-Volt Accessories
The 12-volt power ports will operate most 12-volt accessories with a draw
of 8 amps or less. (Check the accessory for the rated amperage.) Note: If
you connect a DC/AC power inverter to the 12-volt power port in order to
operate an AC-powered accessory, run time may be reduced due to the design
parameters of the inverter. Typically, power inverters will shut off when input
voltage is below 10 - 10.5 volts. So even though there is reserve capacity in the
Rechargeable Battery Charger, the inverter may shut down as voltage drops
below approximately 10.5 volts. You do not need to plug the unit into your
vehicle’s 12-volt power port to operate a 12-volt accessory. Simply plug the 12-
volt item you wish to operate into the power port on the Rechargeable Battery
Charger. This will provide a Rechargeable Battery Charger that you can take
with you anywhere. If the LED light marked “VL” changes from GREEN/AMBER
to RED, discontinue use IMMEDIATELY. It is time to recharge the unit.
Using a Rechargeable Battery Charger System
Rechargeable Battery Charger systems, in general, are designed to provide
emergency battery power to jumpstart a vehicle with a low battery. They are
not designed to provide long-term battery backup nor are they designed to
operate high amperage equipment or components for extended periods of
time. Depending on your vehicle’s condition and power requirements, any
Rechargeable Battery Charger may or may not provide adequate voltage to
successfully start your vehicle. Just as your vehicle’s battery provides a certain
amount of reserve capacity, a Rechargeable Battery Charger system has similar
limitations. It is possible that a jumpstart’s internal battery may be depleted
before you can start your engine. The ambient temperature can affect the
performance of the Rechargeable Battery Charger system. A battery at zero
degrees has less reserve capacity than a battery at sixty degrees. This condition
applies to both a Rechargeable Battery Charger system and your vehicle’s
battery. In the event that your vehicle fails to start after repeated attempts,
additional servicing or tune up may be required. Consult your dealership or local
servicing professional for advice.
Specifications:
Battery: Ni-Cad
12 volts DC (nominal)
Power Port: 12 Volt DC
Fuse: 8A
Questions?
If you have any questions about this product, please contact Team Products
International Customer Service Department at [phone], Monday through
Friday, 9 AM to 5 PM Eastern Time or visit us at www.teamproducts.com.
