PRINCETON™ RECESS BATH W/ LUXURY
LEDGE AND INTEGRAL OVERFLOW
AMERICAST® BRAND ENGINEERED MATERIAL
PRINCETON™ RECESS BATH W/ LUXURY
LEDGE AND INTEGRAL OVERFLOW
Americast® brand engineered material
❏ 2394.202 ICH (Chrome Trim) Left Hand Outlet
❏ 2394.202 ICHTC Same as above with Tub Cover
❏ 2395.202 ICH (Chrome Trim) Right Hand Outlet
❏ 2395.202 ICHTC Same as above with Tub Cover
❏ 2394.202 IPB (Polished Brass Trim)
Left Hand Outlet
❏ 2394.202 IPBTC Same as above with Tub Cover
❏ 2395.202 IPB (Polished Brass Trim)
Right Hand Outlet
❏ 2395.202 IPBTC Same as above with Tub Cover
❏ 2394.202 IBS (Brushed Satin Trim)
Left Hand Outlet
❏ 2394.202 IBSTC Same as above with Tub Cover
❏ 2395.202 IBS (Brushed Satin Trim)
Right Hand Outlet
❏ 2395.202 IBSTC Same as above with Tub Cover
• Lift and turn drain stopper assembly included
with bath
• Escutcheon included and installed on bath
• Acid resistant porcelain nish
• Recess bath with integral apron and
tiling ange
• Integral lumbar support
• Beveled headrest
• Extra wide ledge for placement of toiletries
• Full slip-resistant coverage
• End drain outlet
Nominal Dimensions:
1524 x 864 x 356mm
(60" x 34" x 14")
Bathing Well Dimensions:
1423 x 635 x 337mm
(56" x 25" x 13-1/4")
Compliance Certications -
Meets or Exceeds the Following Specications:
• ASME A112.19.4 for Americast Plumbing Fixtures
• ASTM F-462 for Slip-resistant Bathing Facilities
• ANSI Z124.1 Ignition Test
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
Revised 2/08
MEETS THE AMERICANS WITH DISABILITIES ACT GUIDELINES
AND ANSI A117.1 REQUIREMENTS FOR ACCESSIBLE AND
USEABLE BUILDING FACILITIES-CHECK LOCAL CODES.
INSTALL WITH SEAT AT HEAD END.
SEE REVERSE FOR PRODUCT DIMENSIONS
AND SPECIFICATIONS
Photograph details integral overow and drain
assembly. Drain assembly included with bath.
BARRIER FREE
Americast® brand engineered material is a composition of porcelain bonded
to enameling grade metal, bonded to a patented structural composite.
To Be Specied:
❏ Color:
❏ Bath Filler: (specify nish)
❏ Bath Drain: 1583.470 (specify nish)
To Be Specied - Optional:
❏ Pressure Test Kit†: 791363-0070A
*See faucet section for additional models available
† Pressure Test Kit is necessary to seal overow and perform
system pressure test.

H120
© 2008 AS America Inc.
PRINCETON™ RECESS BATH W/ LUXURY
LEDGE AND INTEGRAL OVERFLOW
Revised 2/08
GENERAL SPECS FOR 2394/2395ICH, IBS BATHING POOL
60 x 34 x 14 In. (1524 x 864 x 356mm)
119 Lbs. (54 Kg.)
469 Lbs. (213 Kg.)
42 Gal. (159 L)
42 x 19 In. (1067 x 483mm)
56 x 25 In. (1423 x 635mm)
9-1/2 In. (241mm)
33 Lbs./Sq.Ft. (159 Kgs./Sq.m)
6.7
20.3
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
CUBE (FT3)
NOTES:
LEFT HAND OUTLET SHOWN, RIGHT HAND REVERSE DIMENSIONS.
(2395.202.ICH).
DRAIN AND OVERFLOW ESCUTCHEON INCLUDED WITH BATH.
REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH BATH
FOR DRAIN INSTALLATION
BATH FAUCET NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH FITTING.
CONCEALED PIPING NOT FURNISHED.
PROVIDE SUITABLE REINFORCEMENT FOR ALL WALL SUPPORTS.
■ REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH BATH.
IMPORTANT: Dimensions of xtures are nominal and may vary within the range
of tolerances established by ANSI Standard A112.19.4 These measurements
are subject to change or cancellation. No responsibility is assumed for use of
superseded or voided leaet.
STUD
SHIM
DRY WALL
TILE
SEALANT
TUB
ROOFING NAIL
STEEL
STUD
SHIM
DRY WALL
WASHER
TILE
SEALANT
TUB
4" (102mm)
DRYWALL
SCREW
WOOD STUDS STEEL STUDS
Below is shown typical cross sections of the tub
rim showing typical wall constructions.
51 x 102mm (2 x 4) WOOD
STRINGER FULL LENGTH
BARRIER FREE
NN

NN

'*/*4)&%
8"--
NN

'*/*4)&%
8"--
$-0'%3"*/
NN

306()
'-003

NN

NN

NN

4&&'*55*/(41&$4
'03%*.&/4*0/
$-0'
41065
$-0'
7"-7&4
$-0'
4)08&3"3.

NN

NN


NN

015*0/"-
NN


NN

4&&
/05&
NN

$-0'
4611-*&4
NN

/14.
5)3&"%403
0%56#*/(
4-*1+0*/5
NNYNN
Y$65065
'*/*4)&%
8"--
5*-*/('-"/(&
