American Standard Champion 4 Round Front Complete Toilet... User manual

K104
Revised 2/08
© 2008 AS America Inc.
CHAMPION® 4
ROUND FRONT COMPLETE TOILET
VITREOUS CHINA
CHAMPION® 4 ROUND FRONT
COMPLETE TOILET
❑ 2585.000
• Vitreous china
• EverClean® surface inhibits the growth of stain
and odor causing bacteria, mold and mildew on
the surface
• Low-consumption (6.0 Lpf/1.6 gpf)
• Features Champion® 4 Flushing System
performance platform
• 4" non-adjustable, piston action Accelerator™
ush valve
• Siphon action jetted bowl
• 2-3/8" fully-glazed trapway
• Speed Connect® tank/bowl coupling system
• Chrome-plated trip lever
• Sweeping pier on bowl
• 100% factory ush tested
• 2 bolt caps
• Color-matched plastic toilet seat
and cover with EverClean® surface
• Wax ring gasket with closet bolts
• 10 year warranty
Nominal Dimensions:
721 x 464 x 797mm
(28-3/8" x 18-1/4" x 31-3/8")
Compliance Certications -
Meets or Exceeds the Following Specications:
• ASME A112.19.2M for Vitreous China Fixtures -
includes Flush Performance, Ball Pass Diameter,
Trap Seal Depth and all Dimensions
• Los Angeles Department of Water and Power
Supplementary Purchase Specication for
Non-Adjustability - July, 2003 revision
NOTES:
THIS TOILET IS DESIGNED TO ROUGH-IN AT A MINIMUM DIMENSION OF
305MM (12") FROM FINISHED WALL TO C/L OF OUTLET.
SUPPLY NOT INCLUDED WITH FIXTURE AND MUST BE ORDERED
SEPARATELY.
* DIMENSION SHOWN FOR LOCATION OF SUPPLY IS SUGGESTED.
IMPORTANT: Dimensions of xtures are nominal and may vary within the
range of tolerances established by ANSI Standard A112.19.2.
These measurements are subject to change or cancellation. No responsibility
is assumed for use of superseded or voided pages.
FINISHED WALL
51mm ± 6mm
(2 ± 1/4)
387mm
(15-1/4)
FINISHED
FLOOR
305mm
(12)
721mm
(28-3/8)
C/L OF OUTLET
83mm
(3-1/4)
235mm
(9-1/4)
419mm
(16-1/2)
C/L OF SEAT POST HOLES
140mm (5-1/2 CENTERS)
362mm
(14-1/4)
264mm
(10-3/8)
16mm
(5/8)
797mm
(31-3/8)
464mm
(18-1/4)
SUPPLY
AS
REQ'D
254mm
(10)
152mm
(6)
254mm
(10)
356mm
(14)
*
To Be Specied:
❏ Color: ❏ White
❏ Supply with stop:
