OWNERS MANUAL
AquaWash® Ambient SpaLet®
Bidet Seat and Edgemere®
Chair Height Elongated Toilet Combo
INSTALLATION INSTRUCTIONS
Thank you for selecting American Standard – the benchmark of fine quality for
over 150 years. To ensure this product is installed properly, please read these
instructions carefully before you begin. Certain installations may require
professional help.
INSTALLATION PREPARATION
• Please unpack carefully and identify all parts needed for installation by using the Box Contents
page as a reference. Inspect the product and report any damages or missing parts immediately
to customer care by calling 855-815-0004. Follow the prompts for consumer/bathing. Local
building codes vary by location. Observe all local plumbing and building codes.
NOTE: Take extra care in handling the front surfaces of the walls. Use only non-abrasive cloths
avoid scratching.
• Wear protective equipment during installation to avoid injury.
• Please keep these instructions for after care and customer service details.
7302240-100 Rev. C (6/23)
Image shown may vary from product purchased.

INSIDE THE BOX
SOLD SEPARATELY
Water Supply Line
BEFORE INSTALLING YOUR TOILET
please see your product spec page to verify the dimensions and water supply
connections. Visit our website where you can search by Model number for the
product spec page at: http://www.americanstandard-us.com
Image shown may vary from product purchased.
7302240-100 Rev. C (6/23)
T-Shaped
Adapter
Connection Hose
with Filter
Insert (2)
(Apply to
Top Mount)
Nuts (2)
(Apply to
Bottom Mount)
Sliding Plates (2) Base Plate (1)
SpaLet® Seat
Bolts (2)
Wax Ring
T-Bolts with
Retainer (2)
Bolt
Caps (2)
Bowl-to-
Floor Knobs
(2)
Tank
Bolts (2)
Tank
Grommets
(2)
Tank to Bowl
Gasket
Plastic
Washers (2)
Attachment
Handle

IF REMOVING AN EXISTING TOILET
INSTALLATION INSTRUCTIONS
Turn o water
supply
BACK-TO-BACK INSTALLATION
Depending upon your plumbing and venting conditions, the flow from this toilet
in a back-to-back installation may create a vacuum on the system and draw water
from the opposing bowl. The National Standards Plumbing Code prohibits the
use of a cross fitting for drainage as throw over is possible. The code does
approve a directional “Y” style fitting with proper venting to direct the water
downward and away from the other toilet.
Clean flangeFlush to remove water from
tank; sponge remaining
water from bowl before
removing toilet
Recommended fitting type for
back-to-back installations.
CAUTION
If leaving floor flange
open for more than 1-2
hours, cover flange to
prevent escaping sewer
gasses.
1 2 3
7302240-100 Rev. C (6/23)

7302240-100 Rev. C (6/23)
1
3
2
4
Apply weight evenly. Do not move
after placement. Water tight seal
may break.
Hand tighten only.
Do not over-tighten.
Wax
ring
Press Firmly
SECURE FLANGE
PLACE TOILET ON FLANGE
ATTACH WAX RING
ATTACH BOWL TO FLOOR KNOBS

7302240-100 Rev. C (6/23)
56
7
AConnect
water supply
line. (Sold
separately)
Hand
tighten nut.
BTurn on
water supply.
WARNING: Over-tightening of water
supply line nuts could result in breakage
and potential flooding.
If the connection leaks after hand tightening,
replace the supply line. If the connection continues
to leak with the new supply line, replace the
fill valve. Do not use plumber’s putty, pipe dope
or any other sealant on the water supply
connection. Use of plumber’s putty, pipe dope, or
any other type of sealant will void the warranty.
WARNING: Do not use plumber’s putty, pipe
dope, or any other sealant on the water supply
connection to this tank. If the connection leaks
after hand tightening, replace the supply line.
If the connection continues to leak with the
new supply line, replace the fill valve.
Warranty is void if any type of sealant is used on
the water supply connection.
ATTACH TANK TO BOWL GASKET CONNECT TANK AND BOWL
CONNECT WATER SUPPLY
Tighten handles
alternately until
the tank con-
tacts the front
and back of the
bowl achieving
china-to-china
contact.
NOTE: To ease
installation,
push down on
the top of the
tank while
tightening
handles.
Place the tank
gasket over the
tank nut ensur-
ing there are no
gaps between
the gasket and
the chinaware.
Install tank
grommets and
tank bolts in
bottom of tank
as shown.
Tank
to Bowl
Gasket

8
ADJUST
7302240-100 Rev. C (6/23)
ADJUSTMENTS
Adjust water level to level indicated on tank by turning water level adjustment knob to move
float cup up or down.
Water Level Adjustment Knob
Trip Lever Rod
Flush
Valve
Flapper
Water Supply Line
Tank to Bowl Gasket
Approximate
Water Level
Flush Valve
Chain
Float Cup
Refill Tube
Overflow
Tube
Flapper Seal
Fill Valve
Or Water
Control
CARE AND CLEANING
When cleaning your toilet, wash it with mild, soapy water, rinse thoroughly with clear
water and dry with a soft cloth. WARNING: Do not use in-tank cleaners. These products
can seriously corrode fittings in the tank. This damage can cause leakage and property
damage. American Standard shall not be responsible or liable for any damage caused by
the use of in-tank cleaners.

7302240-100 Rev. C (6/23)
TROUBLESHOOTING GUIDE
See Step 9 For Diagram
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Does not flush a. Water supply valve
closed
b. Supply line blocked
c. Flush valve chain too
loose or disconnected
d. Sand or debris lodged in
water control
a. Open valve and allow water to fill tank
b. Shut o water supply, disconnect supply
line and inspect all gaskets and washers.
Reassemble
c. Readjust chain length as required
d. Shut o water supply. Remove cap and
clean as per Fluidmaster maintenance
instructions at:
www.americanstandard-us.com/enews
/fluidmasterguide.pdf
Poor or sluggish
flush
a. Bowl water level too low
b. Supply valve partly
closed
c. Partially clogged trap-
way and/or drain pipe
and/ or vent
d. Supply pressure too low
a. Check that refill tube is connected to water
control and inserted into overflow tube
without being kinked or damaged
b. Open supply valve fully. Be sure that proper
supply tube size is used
c. Remove obstruction. Consult a plumber
if necessary
d. Normal supply pressure must be at least
20 psi
Toilet leaks a. Poor supply line
connection
b. Poor bowl to tank/floor
connection
a. Review Step 8 of installation procedure
b. Review Step 1 through 6 of installation
procedure
Toilet does not
shut o
a. Flapper seal leaking or
deformed
b. Sand or debris lodged in
water control
c. Flush valve chain too
tight, holding flapper
open
a. Clean debris from seal surface. Replace
flapper seal as needed
b. Shut o water supply. Remove cap and
clean
as per Fluidmaster maintenance instruc-
tions at: www.americanstandard-us.com/
enews/fluidmasterguide.pdf
c. Readjust chain length as needed
Toilet bowl rocks
after installation
a. Wax ring not fully
compressed
b. Floor not level
a. Retighten bowl-to-floor knobs
b. Use toilet shims and /or place a bead of
caulk around the base of the toilet

PARTS
7302240-100 Rev. C (6/23)
BOWL
WATER INLET HOSE
SHUT OFF VALVE
T-SHAPED ADAPTER
LEVER
WATER TANK
WATER SUPPLY HOSE
SEAT COVER
SEAT
WASH NOZZLE
BIDET NOZZLE
RELEASE BUTTON
WARNING
Please read the instructions carefully before installing and using.
The product requires a flexible supply hose.
The watter shuto valve should be near the installed product for ease of installation.
Do not use in hot water line. Temperature above 104°F / 40°C will damage the
product and void your warranty.

7302240-100 Rev. C (6/23)
1
2b
2a
3
Place the base plate in the slotted area of
the template and then place the hardware
onto the base plate as shown. Screw in the
nuts from the underside of the ceramic
until the base plate is fixed.
Remove the template from the bowl.
Press the inserts into the toilet bowl holes.
Align the base plate to the slotted area of
the template and then place the hardware
onto the base plate as shown. Using a
medium size Phillips screwdriver, start
screwing down the bolts into the inserts
until the base plate is fixed.
If the insert does not fit the bowl, proceed
to Step 2B, otherwise, skip Step 2B
and continue with Step 3.
Wipe the bowl surface clean. Lay the
template over the top of the toilet bowl.
Position the template to how you want the
bidet seat to pair up with the bowl once
installed.
BOLT
BASE
PLATE
SLIDING
PLATE
INSERT
BOLT
SLIDING
PLATE
BASE
PLATE
NUT

7302240-100 Rev. C (6/23)
4
6
5
7
While sitting on the seat, rotate the control
knob forward or backward for functional
testing. Also, check the connections to
make sure there are no leaks. If you find
leaks retighten the connections.
Plug power cord into designated AC power
outlet.
Make sure the control knob on the SpaLet
seat is at the 90˚ o position. Turn the
water shuto valve back on.
Install T-shaped adapter to the fill valve and
supply hose as shown. Connect the included
connection hose with filter on to the T-shaped
adapter and the SpaLet® seat inlet.
WARNING: Make sure the filter and seal
on the connection hose are installed
along with the hose.
DO NOT OVERTIGHTEN THE
THREADED CONNECTIONS.
The connections
may be broken or
the threads may
be damaged if
vover torqued.
90˚
OFF POSITION
Slide the SpaLet® seat across the base
plate until you hear a click. The SpaLet
seat is now assembled to the bowl.
Turn o the water supply by turning o the
water shuto valve, then disconnect the
supply hose.
If you are using a rigid supply line you will
need to purchase a flexible supply hose to
install the SpaLet seat.
CLICK
E
AD
C
B
GASKET
FILTER

OPERATION
7302240-100 Rev. C (6/23)
OFF AND SELF-CLEANING
Keep the knob at the 90˚ position when not in use. The wand cleans itself after each use.
For additional cleaning of the wand, position the knob at 85˚ or 95˚ for a few seconds and
then reposition back to 90˚.
WASH FUNCTION LOW FLOW
HIGH FLOW
LOW FLOW
HIGH FLOW
BIDET FUNCTION

CLEANING AND MAINTENANCE
1
3
6
5
2
4
7
DO NOT USE AGGRESSIVE CHEMICALS:
For example: hydrogen chloride, paint
thinner, benzene, abrasive cloth or paper,
polishing agent,
fragrance,
insecticide, etc.
If you start to notice
that the flow of water
is low when using the
SpaLet® seat it may be
time for the filter to be
cleaned out. Especially
with new home con-
struction or newly ren-
ovated plumbing there
are a lot of sediments in
the water. You will need
to remove the connec-
tion hose and clean out
the filter as needed.
The incoming water pressure is regulated
by a regulator insert. This can be removed
and replaced. First turn o the water sup-
ply and disconnect the connection hose.
Rotate the lever to the on position, pull
out the regulator from the inlet tube with
needle-nose pliers. Press the new regu-
lator into the inlet tube. Then rotate the
lever back to non-working position.
The nozzles can be removed if needed
for cleaning.
First turn o the water supply to the SpaLet seat.
As per figure A, pull out the tube and remove the
old nozzle by pulling out straight, as shown.
As per figure B, insert the new nozzle into the
tube along the corresponding slot.
You will need to clean the wands when
they get build up of residue and calcium.
You can pull the wands out with your
finger and then with a soft bristle
toothbrush, brush the nozzle head.
You can remove the SpaLet seat by
pressing the release button on the right
side of the
SpaLet seat
and sliding the
seat forward
as shown. This
enables you to
be able to clean
more thoroughly
around the toilet.
Make sure to
disconnect
the connection
hose before
you do this.
If anything shall leak, retighten the
connection and use teflon tape if needed.
If water leaks from the two ends of the
water hose, retighten the nuts to avoid
water leaking
Insecticide
Abrasive
paper
Painting thinner
Filter
Connection
hose
A
B
AB
WARNING:
DO NOT
OVERTIGHTEN AS
IT WILL DAMAGE
THE CONNECTION.
HAND TIGHTENING
IS RECOMMENDED.
Regulator

TROUBLESHOOTING GUIDE
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Water is too low
during WASH/
BIDET
a. Low water pressure of the unit
b. Low water pressure of water
supply
a. During WASH/BIDET, turn the knob to a higher
setting
b. When water supply pressure is lower than 0.07
MPa (10 psi)
No water comes
out during
WASH/BIDET
a. Water shut-o valve is turned o
b. Filter of T-shaped connector is
stuck
c. Filter of water inlet hose is stuck
d. Nozzle head is stuck
e. External water pressure is low
a. Turn on the water shut-o valve
b. Clean the filter of T-shaped connector
c. Clean the filter of water inlet hose
d. Take o and clean the nozzle head
e. Increase external water pressure
Water dropping
from bowl when
using the unit
External water pressure is too high The maximum water pressure of the unit is 0.8 MPa
(115 psi). If water supply pressure is higher than that,
please contact local department for water pressure
question.
7302240-100 Rev. C (6/23)

7302240-100 Rev. C (6/23)
TELL US WHAT YOU THINK!
Please leave us a product review or story
at AmericanStandard.com/reviews
Register your warranty and sign up for an idea-filled newsletter at
AmericanStandard-us.com/support/warranty
PLEASE COMPLETE AMERICAN STANDARD WARRANTY REGISTRATION PROCESS AND
SAVE THIS WARRANTY INFORMATION IMPORTANT:
Registration of the sink must be completed for this warranty to become eective. Your registration
will make it easier to contact you in the event of a product recall.*
INSTRUCTIONS: Register your sink at www.americanstandard.com. Please save your proof of purchase
(sale receipt). If you need assistance or do not have access to our website, please contact American Standard
Customer Care at: [phone]. An American Standard representative will assist in completing
the warranty registration.
*In California, your warranty rights remain intact even if you do not complete the registration process.
Find installation videos at
youtube.com/americanstandard
WANT MORE INFO?
For questions or help call us at 855-815-0004,
or visit AmericanStandard.com
UNITED STATES
American Standard Brands
865 Centennial Ave.
Piscataway, New Jersey 08854
Attention: Director of Customer Care
For residents of the United States,
warrantyinformation may also be
obtained by calling the following
toll free number: [phone]
www.AmericanStandard.com
CANADA
LIXIL Canada, Inc.
5900 Avebury Rd.
Mississauga, Ontario
Canada L5R 3M3
Toll Free: [phone]
www.AmericanStandard.ca
MEXICO
American Standard B&K Mexico
S. de R.L. de C.V.
Via Morelos #330
Col. Santa Clara
Ecatepec 55540 Edo. Mexico
Toll Free: 800-839-1200
www.AmericanStandard.com.mx
SHARE YOUR NEW PRODUCT!
Tag us @american_standard on Instagram
and show us how your new product looks.

7302240-100 FR Rev. C (6/23)765AA701/5900A05G/5900A05GT
American Standard se consacre à rendre la vie
au cœur de votre maison meilleure chaque jour...
Merci de nous avoir invités! Avec les meilleurs produits de
cuisine et de salle de bains, nous sommes là pour vous aider à
rendre votre vie plus heureuse, plus saine et plus simple. Notre
engagement en faveur de la qualité, de l’innovation et du
rendement nous a permis de faire partie de votre quotidien
depuis près de 150ans, et nous nous réjouissons de continuer
pendant de nombreuses années à venir.
Apprenez-en plus au www.AmericanStandard.ca
ENREGISTREZ VOTRE GARANTIE
Essayez le code QR facile à balayer pour saisir
rapidement vos informations ou trouvez
la garantie détaillée de votre produit ici:
www.AmericanStandard.ca/support/warranty
L’enregistrement vous permet de conserver vos informations
sur les produits en toute sécurité et nous donne la possibilité
de vous contacter en cas de rappel de produits ou de nouvelles
concernant votre achat.
Avez-vous des questions ou besoin d’assistance?
Appelez-nous au 1-855-815-0004
7302240-100C

7302240-100 FR Rev. C (6/23)
CONSIGNES D’INSTALLATION
Merci d’avoir choisi American Standard, la référence en matière de qualité
supérieure depuis plus de 150 ans. Pour vous assurer de l’installation adéquate
de ce produit, veuillez lire ces consignes avant de commencer. Certaines installations
peuvent nécessiter l’aide d’un professionnel. Assurez-vous que votre installation respecte
les codes locaux.
PRÉPARATION DE L’INSTALLATION
• Veuillez déballer le produit avec précaution et identifier toutes les pièces requises pour
l’installation en utilisant la page Contenu de la boîte. Inspectez le produit et signalez
immédiatement tout dommage ou toute pièce manquante au service à la clientèle en appelant
au 855-836-9615. Suivez les options pour les clients/baignoires. Les codes locaux du bâtiment
varient selon l’endroit où vous vous trouvez. Respectez tous les codes locaux de plomberie et
du bâtiment.
REMARQUE : Soyez particulièrement vigilant en manipulant les surfaces avant des parois.
Utilisez seulement des chions non abrasifs pour éviter les égratignures.
• Utilisez de l’équipement de protection durant l’installation pour éviter les blessures.
• Veuillez conserver ces consignes pour les détails sur l’entretien et le service à la clientèle.
L’image présentée peut varier du produit acheté.
MANUEL DU PROPRIÉTAIRE
Siège de bidet AquaWashMD 2.0 SpaLetMD et
combinaison de toilette allongée à hauteur
de chaise EdgemereMD

Image shown may vary from product purchased.
7302240-100 FR Rev. C (6/23)
Anneau de Cire
Boulons en T Avec
Rondelles de Retenue
(2)
Cache
Boulons (2)
Boutons
Cuvette Sol
(2)
Joint Réservoir
Cuvette
Rondelles en
Plastique (2)
Poignée de
Fixation (1)
Boulons du
réservoir (2)
Œillets du
réservoir (2)
Adaptateur en
forme de T
Tuyau de
raccordement
aver filtre
Pièces de
fixation (2)
(se fixent sur
la surface)
Écrous (2)
(se fixent sous
la surface)
Plaques
coulissantes (2) Plaque de base (1)
Siège SpatLetMD
Boulons (2)
AVANT DE COMMENCER
Inspectez attentivement votre produit avant de commencer. Soyez
particulièrement vigilant en manipulant les surfaces de la douche et utilisez
seulement des chions non abrasifs pour éviter les égratignures. Respectez
tous les codes locaux de plomberie et du bâtiment.
CONTENU DE LA BOÎTE
VENDU SÉPARÉMENT
Ligne d’alimentation
en eau

7302240-100 FR Rev. C (6/23)
SI VOUS ENLEVEZ UNE CUVETTE DE TOILETTE DÉJÀ EN PLACE
CONSIGNES D’INSTALLATION
Coupez
l’alimentation d’eau.
INSTALLATION DOS-À-DOS
En fonction de l’état de votre plomberie et de votre évacuation, le débit
provenant d’une installation de la toilette dos à dos peut former une dépression
dans le système et aspirer l’eau de la cuvette opposée. Le code national des
normes de plomberie interdit l’utilisation d’un raccord en croix pour l’évacuation
pour éviter un éventuel débordement. Le code approuve un raccord directionnel
de type « Y » avec une évacuation adéquate afin de diriger l’eau vers le bas et de
l’éloigner de l’autre toilette.
Nettoyez la bride.Actionnez la chasse d’eau
pour vider le réservoir d’eau;
épongez le restant d’eau de
la cuvette avant d’enlever la
toilette.
Type de raccord recommandé pour
les installations dos-à-dos.
! PRÉCAUTION
Si la bride de sol est
restée ouverte plus d’une
heure ou deux, recou-
vrez la bride pour éviter
que les gaz d’égout ne
s’échappent.
1 2 3

7302240-100 FR Rev. C (6/23)
1
3 4
Appliquez une pression uniforme.
Ne déplacez pas la toilette après
l’avoir placée, au risque de briser
le joint d’étanchéité.
Serrez à la main uniquement.
Ne serrez pas excessivement.
BRIDE DE FIXATION
PLACER LES TOILETTES SUR LA BRIDE
FIXER LA CUVETTE AUX BOUTONS DE SOL
2
Anneau de
Cire
Appuyez Fermement
FIXER L’ANNEAU DE CIRE
