AMG Systems AMG5414R User manual

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 1 of 8
AMG5414R Instruction Sheet D17398-
00.doc
AMG5414R
Instruction Manual
Receive Unit with one Bi-directional Data Channel and one
Bi-directional Alarm for a Multimode Fibre Link
The AMG5414R is rackmount receive unit designed to transmit and receive 1 data signal plus 1 Bi-
directional alarm over one Multimode optical fibre.
The AMG5414R is designed to plug into an AMG2009 or AMG2015 subrack, which in turn fits into a
19" rack system.
The AMG5414R is designed to operate with an AMG5413 / AMG5413R single channel or AMG5423 /
AMG5423R dual channel transmit unit in a point to point configuration. The R suffix in the partno.
indicates a rackmount configuration.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 2 of 8
AMG5414R Instruction Sheet D17398-
00.doc
Contents
Introduction 3
Unit Functional Schematic.................................................................................................................. 3
Optical Connection ............................................................................................................................. 3
Connections 4
Optical Connections Multimode.......................................................................................................... 4
Power Connection .............................................................................................................................. 4
Data and Alarm Channel Connections............................................................................................... 4
Front Panel Indicators 5
Power / Opto LED............................................................................................................................... 5
Low Speed Data LEDs ....................................................................................................................... 5
Alarm LEDs......................................................................................................................................... 5
Data and Alarm Channel Configuration Error! Bookmark not defined.
Data Channel Configuration...............................................................Error! Bookmark not defined.
Data Interface Connections................................................................Error! Bookmark not defined.
Alarm Channel Configuration Error! Bookmark not defined.
Bi-directional Alarm Interface Connections ........................................Error! Bookmark not defined.
Physical Information Error! Bookmark not defined.
Dimensions.........................................................................................Error! Bookmark not defined.
Mounting Details.................................................................................Error! Bookmark not defined.
Safety 8
Maintenance and Repair 8

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 3 of 8
AMG5414R Instruction Sheet D17398-
00.doc
Introduction
Unit Functional Schematic
The AMG5414R transmits 1 data channel
and 1 uni-directional alarm signal to the
AMG5413R transmit unit.
It also receives 1 data channel and 1 Bi-
directional alarm transmitted from the
AMG5413R.
Optical Connection
The AMG5414R connections are illustrated in the following example which shows an AMG5413R
transmit unit together with an AMG5414R receive unit configured as a single channel point to point
system.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 4 of 8
AMG5414R Instruction Sheet D17398-
00.doc
Connections
Optical Connections Multimode
No. of Optical Connections..................1
Optical Fibre ........................................Multimode 50/125 or 62.5/125**
Connector ............................................SC/PC
Minimum Optical Launch Power..........-10dBm
Transmit Wavelength...........................1310nm
Minimum Optical Sensitivity.................-30dBm
Receive Wavelength............................1510nm
Minimum Optical Dynamic Range .......20dB.
**Note: the transmission distance is limited by the bandwidth of the Multimode optical fibre. The optical
data rate is 155Mbits/s, which may restrict operation to a maximum fibre length of 7km, although in
most cases the units will operate successfully over longer fibre lengths. It is advisable however for
distances greater than 7km, to have the optical fibre tested.
Power Connection
Connector Type ...................................Removable 2-pin, 3.81mm, Screw Terminal
Connector Partno.................................Phoenix 1803578
Supply Voltage.....................................+12 to +15Vdc
Maximum Power..................................1.5 Watts
Data and Alarm Channel Connections
No. of Data Channels ..........................1
No. of Alarm Channels.........................1
Connector ............................................Removable 8-pin, 3.81mm, Screw Terminal
Connector Partno.................................Phoenix 1803633
Data Interface ......................................RS-232, RS-422 or R-S485. Selected by slide switch above the
BNC connector.
RS-232 –Switch Position - Left
RS-422 –Switch Position - Centre
RS-485 –Switch Position - Right
Alarm Input ..........................................Contact Closure pull-up is 330R to +3V3
Alarm Output........................................Solid-state Relay, maximum 150mA at 125Vac/dc, Ron < 6.5Ω

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 5 of 8
AMG5414R Instruction Sheet D17398-
00.doc
Front Panel Indicators
Power / Opto LED
Power / Opto........................................Green - Unit powered, Opto sync.
Red - Unit powered, no Opto sync.
Off - No power applied to unit
Low Speed Data LEDs
Data Present IN (RS485 or RS422)....Green - logic zero (+V, -V) present on IN+, IN-
Red - logic one (-V,V+) present on IN+, IN-
Off - tri-state off or no connection on IN+, IN-
Data Present IN (RS232) ....................Green - logic zero (+V) present on input IN+
Red - logic transitions present on input IN+
Off - logic one (-V) present on input IN+
IN corresponds to the data signals being transmitted onto the optical fibre.
Data Present OUT (RS485 or RS422) Green - logic zero (+V,-V) present on OUT+, OUT-
Red - logic one (-V,+V) present on OUT+, OUT-
Off - tri-state off or no connection on OUT+, OUT-
Data Present OUT (RS232) ................Green - logic zero (+V) present on OUT+
Red - logic transitions present on OUT+
Off - logic one (-V) present on OUT+
OUT corresponds to the data signals being received from the optical fibre.
Alarm LEDs
ALARM IN............................................Green - Alarm ON / Contacts closed.
Off - Alarm OFF / Contacts open.
ALARM OUT........................................Green - Alarm ON / Contacts closed.
Off - Alarm OFF / Contacts open.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 6 of 8
AMG5414R Instruction Sheet D17398-
00.doc
Data and Alarm Channel Configuration
The AMG5413R sends and receives data to/from a AMG5414 transmit unit. The physical data
interface RS-485, RS-422 or RS-232 is individually selectable by the user with the corresponding slide
switch mounted on the main PCB inside the enclosure.
One Bi-directional alarm is also provided. The alarm input is typically connected to a contact closure
switch. The alarm output can receive an on/off signal from an AMG5414 and is typically used to
convey contact closure status.
Data Channel Configuration
Each low speed data channel provides an RS-232, RS-422 (full duplex, four wire) or RS-485 (half
duplex, two wire) interface defined by the corresponding mode switch inside the enclosure. Every data
channel as shipped from the factory is set up for RS-485 operation unless otherwise requested.
The data input for both the RS-485 and the RS-422 modes detects a tri-state input condition by
monitoring the differential voltage level across the input. A differential level below 600mV positive or
negative will be detected as a tri-state condition. A level above 600mV positive or negative will be
detected as a logic 1 or logic 0 respectively. It is important therefore to terminate the RS-485 bus or
the RS-422 input bus using 120Ω if a pre-bias is present on the RS-485 or RS-422 bus.
A large number of third party equipment manufacturers apply a pre-bias on their RS-485 bus. This pre-
bias is applied by pulling one arm of the RS-485 bus high (+5 volts) and the other arm low (0 volts)
using high value resistors within the third party equipment. In order to ensure that the AMG equipment
detects a tri-state condition, then these resistors should have a value above 5kΩ. If the third party
bias resistors are less the 750Ω the bus can be multiple terminated as required to ensure that a tri-
state level is detected.
The system detects a tri-state input condition on the data channel bus when in RS-485 or RS-422
mode.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 7 of 8
AMG5414R Instruction Sheet D17398-
00.doc
Data Interface Connections
Connector
Pin No.
Data Channel
RS-485
[switch top]
RS-422
[switch middle]
RS-232
[switch bottom]
1
IN + (A)
IN
2
IN - (B)
3
GND
GND
GND
4
5
6
7
IN/OUT + (A)
OUT + (A)
8
IN/OUT - (B)
OUT - (B)
OUT
Note: (A) or (B) in brackets in the above table refers to RS-485 / RS-422 data specification.
Alarm Channel Configuration
The AMG5413R provides one bi-directional alarm output / contact closure input.
The alarm input is typically connected to a contact closure switch. An ALARM IN+ input incorporates a
330R pull-up resistor to the internal +3V3 supply.
The alarm output can receive an on/off signal from an AMG5414 and is typically used to convey
contact closure status. An alarm output uses a solid-state relay, with a maximum load current of
150mA at 125Vac/dc and Ron < 6.5Ω.
Alarm Interface Connections
Connector
Pin No.
Alarm Interface
Alarm IN
Alarm OUT
1
2
3
GND
4
ALARM IN +
5
ALARM OUT -
6
ALARM OUT +
7
8

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 8 of 8
AMG5414R Instruction Sheet D17398-
00.doc
Physical Information
Dimensions
Height...................................................3U Plug-in
Width....................................................7HP
Depth ...................................................170mm excluding connectors
Weight..................................................200grams
Mounting Details
The unit is designed to be mounted within an AMG2009 or AMG2015 Subrack on standard card
guides.
Safety
AMG Optical Fibre Products use Class 1 laser systems in accordance with EN 60825-2:2000.
It is always advisable to follow good practice when working with optical fibre systems. This includes:
▪Do not stare with unprotected eyes or with any unapproved collimating device at fibre
ends or connector faces, or point them at other people.
▪Use only approved filtered or attenuating viewing aids
For other safety issues and advice on good practice associated with optical fibre systems, please see
EN 60825-2:2000 or your local safety officer.
Maintenance and Repair
There are no user serviceable parts within AMG products. See unit data sheet for full specification.
In case of problem or failure, please call your local support centre or contact: AMG Systems Ltd. at
3 The Omega Centre, Stratton Business Park, Biggleswade, Beds., SG18 8QB, UK.
Phone [phone]
Technical Support [phone]
Email [e-mail]
