AMGO Hydraulics BP-12 Manual

TWO POST LIFT
Model: BP-12

CONTENTS
Product Features and Specifications .........................................................1
Installation Requirement ........................................................................3
Steps of Installation ………………………………………………………..…………....................4
Exploded View .....................................................................................20
Test Run .............................................................................................27
Operation Instruction ...........................................................................29
Maintenance .......................................................................................29
Trouble Shooting .................................................................................31
Lift Disposal ........................................................................................31

1
I. PRODUCT FEATURES AND SPECIFICATIONS
FLOORPLATE CHAIN-DRIVED MODEL FEATURES
MODEL BP-12 (See Fig.1)
· 12000lbs lifting capacity, compact design small footprint.
·Dual hydraulic cylinders is designed and manufactured according to standard, utilizing
imported seals
·Adjustable column width, two optional column width installation 118 1/8” or 123 1/2”
·Stackable adapters 1.5”, 2.5”, 5” can be adjusted the minimum pad height in a short time.
. Lifting arm lock automatic release device, high strength moon gear for making the lift
more reliable and safety.
· Self-lubricating UHMW Polyethylene sliders and bronze bush.
· Single-point safety release, and dual safety design.
·￠9.5 mm cable using for the lift make it more safety and more reliable.
MODEL BP-12 SPECIFICATIONS
Model
Style
Lifting
Capacity
Lifting
Time
Lifting Height
Overall
Height
Overall
Width
Minimum
Pad Height
Motor
BP-12
Floor-plate
Chain-driv
e
12000lbs
55S
73 1/4”~82
1/4”
122 1/2”
145 3/8”
150 3/4”
4 3/4”~13 3/4”
2.0HP

2
Arm Swings View
Fig.2
36-7/8”
71-5/8”
104-1/2”~109-7/8”
155”
85-1/4”

3
II. INSTALLATION REQUIREMENT
A. TOOLS REQUIRED
Rotary Hammer Drill (Φ19)
Hammer
Level Bar
English Spanner (12")
Ratchet Spanner With Socket (28#)

Wrench set
Carpenter’s Chalk
Screw Sets
Tape Measure (7.5m)
Pliers
Socket Head Wrench (6#)
Lock Wrench
(10#, 13#, 14#, 15#, 17#, 19#, 24#, 27#)
Fig. 3

4
B. Equipment storage and installation requirements.
The equipment should be stored or installed in a shady, normal temperature,
ventilated and dry place.
C.The equipment should be unload and transfer by forklift.
D. SPECIFICATIONS OF CONCRETE (See Fig. 5)
Specifications of concrete must be adhered to the specification as following.
Failure to do so may result in lift and/or vehicle falling.
1. Concrete must be thickness 5’’ minimum and without reinforcing steel bars，and
must be dried completely before the installation.
2. Concrete must be in good condition and must be of test strength 3,500psi
minimum.
3. Floors must be level and no cracks.
E. POWER SUPPLY
The electrical source must be 2.0HP minimum. The source cable size must be
2.5mm² and in good condition of contacting with floor.
Fig. 4
Concrete intensity must be
3500psi (245kg/cm²) minimum
44
5”
Fig. 5

5
III. STEPS OF INSTALLATION
A. Location of Installation
Check and insure the installation location (concrete, layout, space size etc.) is
suitable for lift installation.
B. Use a carpenter’s chalk line to establish installation layout of baseplate (See Fig. 6).
C. Check the parts before assembly
1．Packaged lift and hydraulic power unit (See Fig. 7)
2. Move the lift aside with a fork lift or hoist, and open the outer packing carefully, take
off the parts from upper and inside the column, take out the parts box，check the
parts according to the shipment parts list (See Fig. 8).
Shipment Parts list
Protect Cover
Parts Box
Chalk a line
Fig. 6
Fig. 8
Fig. 7

6
3.Take out the parts upper and inside the column, move them beside the installation site.
See Fig.9
4. Loose the screws of the upper package stand, take off the upper column and remove
the package stand.
5. Move aside the parts and check the parts according to the shipment parts list (See Fig.
10,11)
6. Open the parts bag and check the parts according to parts box list (See Fig. 12).
Fig. 9
Fig. 12
Parts in the shipment parts list
45
Label
Fig. 10
Fig. 11
Parts in the parts box (45)

7
D. Lay down two columns on the installation site in parallel, position the power-side
column according to the actual installation site. Usually, it is suggested to install
Power side column on the front-right side from which vehicles are driven to the lift.
Then install the top plate (See Fig. 13).
Offside column
Power-side column
Car in direction
Fig. 13
Assemble top-plate using
M12*30 hex bolt with nut
and washer.
48
47
46

8
E. Position columns and install anchor bolts (See Fig. 14)
Check the columns plumbness with level bar, and adjusting with the shims if the columns
are not vertical. Anchor bolts should not be tightened.
Note: Lifts are designed to two level width, install according to customer’s needs
F. Install anchor bolts
1. Prepare the anchor bolts (See Fig.15)
Adjust the columns
to be vertical with
shims
49
118 1/8” / 123 1/2”
Check the columns
plumbness with level
bar from front and
side column
145 3/8” / 150 3/4”
Fig. 14
Washer
Lock washer
Nut
Fig. 15

9
2. Using the prescribed rotary hammer drill, drill all the anchor holes and install the
anchor bolts. Then tighten the anchor bolts (See Fig. 16).
Note: Torque of Anchors is 150N.m. Minimum embedment of Anchors is 4-3/8”.
G. Install safety Lock (See Fig. 17&18)
Fig. 16
Drilling
4-3/8”
Tighten
Bolting
Power-side safety
lock installation
Fig. 17
53
54
55
47
6
51
50
56
52
Offside safety lock installation
Fig.18
58
59
60
61
62
64
57
63

10
H. Lift the carriages up by hand and make them be locked at the same
level (See Fig.19).
Fig.19
Safety block locked at the
same level

11
I. Connecting cables (See Fig. 20)
1. Select the width of the foundation according to step E (Fig.14) and select
the width of the foundation size 150-3/4” to install the cable (see Fig.20)
Note: Cable pass through from one carriage to another must be passed through the
hole of the bottom steel plate of carriages
Fig. 20
65
65
steel plate of
carriages
Cable pass through the two
steel plates of carriages
from bottom to the top

12
2．Select the width of the foundation according to step E (Fig.14) and select
the width of the foundation size 145-3/8” to install the cable.(Fig.21&Fig22)
2.1. Cable go through from bottom to the top, tighten the two cable nuts when it pass
through the opening of the carriage. (Fig.21)
Fig. 21
Cable go through from
the inside two cable
connecting block holes
of the carriage.
66
Cable connecting block
Nuts be locked
each other
Cable go through
direction
Cable go through direction

13
2.2 Foundation size 145 3/8” cable installation diagram.
65
Fig. 22
65

14
J. Install safety cable, see Fig.23
NOTE: 1. Assemble safety cable from offside safety assy.
2. Pay attention to the connecting direction of safety cable.
58
67
68
1.Insert safety cable
from offside safety lock
2.Insert safety cable
from offside safety lock
to power-side safety lock
according to the arrow
direction
3.Tighten the nuts after
installing the safety
cable
Fig.23

15
K. Install power unit and oil hose (See Fig. 24)
Fig.24
A
View
A View
70
69
7
71
72
11
73
74
75
76
16
76
75
69
78
77
16
Width in 118 1/8”, use L= 54 7/8”oil hose
Width in 123 1/2”, use L= 59 7/8”oil hose.

16
L. Install protect cover (see Fig.25)
Note: Install cable protect cover or cable protect cover assy with connecting protect
cover according to the foundation width of step 5
Fig. 25
7
selection
1
9
8
1
Install the cable
protect cover
with protect
cover plate,
choosing
columns width
in 118 1/8”
Install the cable
protect cover assy
with protect cover
plate, choosing
columns width in
123 1/2”

17
M. Install lifting arms
1. After Installing the lifting arms (See Fig. 26) Lowing the carriages down to the
lowest position, then use the 8# wrench to loosen the nut of the fixed gear (See Fig.
27). adjust the gear according to the arrow direction(see Fig.28), tighten the screws
until the gear and rack match in good condition (see Fig.29)
Snap Ring
Use wrench to
loosen the Socket
bolt
Fig. 26
Fig. 27
Adjust gear and
rack meshing.
Lock the screws by wrench after the gear
and rack are in good meshing condition
Fig. 28

18
2. Install lifting arm guardrails
M. Tighten all the hydraulic fittings, and fill the reservoir with hydraulic oil
Note: In consideration of Hydraulic Power Unit’s durability and keep the equipment running
in the perfect condition, please use Hydraulic Oil 46#.
O. Install Electrical System Connect the power source on the data plate of
power unit.
Note: 1. For the safety of operators, the power wiring must contact the floor well.
2. Pay attention to the direction of rotations when using three phase motors.
Single phase motor 220V (See Fig. 30).
1.1 circuit diagram
79
80
8
43
42
Fig. 29
Single phase
Switch
Fig. 30
