amiad MEGA ABF 40,000 User manual

AMIAD Water Systems Ltd.
MEGA ABF 40,000
ON-LINE FILTER
Serial number:
Order number:
Catalog number:
Filtration degree:
Tested by:
Installation and Operation
Instructions
Ref: 910101-001027 /08.2019
Original Instructions

Mega ABF 40000 IL 910101-001027 / 08.2019 Page 2 of 22
AMIAD Water Systems Ltd.
MEGA ABF-40,000 ON-LINE FILTER
Amiad’s MEGA-ABF-40,000 FILTER is an automatic self-cleaning filter designed for use with non-hazardous liquids only
and within the pressure and temperature framework described in the specifications table. For other applications please
contact Amiad’s marketing department.
This manual is the operation manual of the MEGA ABF-40,000 FILTER; it describes the installation and the commissioning
processes for a single filter installation and specifies the end-user operation and regular maintenance procedures.
The Mega ABF filters are available in 16", 18", 20", 24" and 28” inlet/outlet diameters.
Disclaimer:
Copyright © 2018 Amiad Water Systems Ltd. All rights reserved.
The contents of this document, including without limitation all information and materials, images, illustrations, data, drawings, names and any other
such materials that appear in this document are the sole property of Amiad Water Systems Ltd., including any intellectual property rights, whether
registered or not, and all know-how contained or embodied therein. Amiad may alter, remove or change the Content without any further notice. You
may not reproduce, copy, modify, create derivative works from, sell or participate in any sale of, or exploit in any way, in whole or in part, any of this
document or its content.
The confidential nature of and/or privilege in the file enclosed is not waived or lost as a result of a mistake or error in this file.If you received this file
in error, please notify Amiad immediately at [e-mail].
This document does not replace any certified drawing, procedure or information provided by Amiad in reference to a specific customer, site or
project.
Amiad assumes that all users understand risks involved within this file and/or its attached materials.This document is given in good faith and is not
intended to impose any obligation to Amiad. While every effort has been made to ensure the information in this manual is accurate and complete, we
would appreciate if you can bring any errors or omissions to the knowledge of Amiad or consult Amiad experts or its authorized representatives if you
have any questions.
Amiad Water Systems Ltd. D.N. Galil Elyon 1, 1233500, Israel Tel: [phone] | Fax: [phone] Email: inf[email protected]

Mega ABF 40000 IL 910101-001027 / 08.2019 Page 3 of 22
Table of Contents
Technical Specifications............................................................................................................................4
Safety Instructions....................................................................................................................................5
General Safety Instructions...................................................................................................................5
Installation.............................................................................................................................................5
Commissioning ......................................................................................................................................6
Operation and Control ..........................................................................................................................6
Maintenance..........................................................................................................................................7
Dimensional Drawing................................................................................................................................8
Description of Filter Operation.................................................................................................................9
Description of Filter Operation.................................................................................................................9
Installation ..............................................................................................................................................11
Commissioning, Start-Up and First Operation........................................................................................12
Electrical Control System Description ....................................................................................................13
Flushing by PDS: ..................................................................................................................................13
Manual Operation: ..............................................................................................................................13
Flushing according to Time: ................................................................................................................13
Fault Mode: .........................................................................................................................................13
Maintenance...........................................................................................................................................14
Parts schedule mega ABF........................................................................................................................16
Parts Drawing #1.....................................................................................................................................17
Parts Drawing #2.....................................................................................................................................19
Parts Drawing #2.....................................................................................................................................19
Parts Drawing #3.....................................................................................................................................20
Amiad Limited Warranty ...........................................................................Error! Bookmark not defined.
With any inquiry please quote Filter Serial Number, located on the filter housing.

Mega ABF 40000 IL 910101-001027 / 08.2019 Page 4 of 22
Technical Specifications
General
Maximum flow rate
2500 m3/h
Consult manufacturer for optimum flow
depending on filtration degree& water
quality.
Min. working pressure
2 bar
28 psi
Or lower if pressure is increased for
flushing.
Max. working pressure
10 bar
150 psi
16 bar = 240 psi upon request.
Filter area
40,000 cm2
Inlet/Outlet diameter
400, 450, 500, 600,
700 mm
16", 18, 20", 24",28"
Flange standards as per request.
Filter housing
1400 mm
55.1"
Epoxy-coated steel or other on request.
Max. working temperature
600C
1400F
Weight (empty)
3120 kg
Weight (with water)
5850 kg
Flushing data
Exhaust valve
4 X 80 mm
4 X 3"
Flushing cycle time
50 - 140 seconds
50 - 140 seconds
Rejected water per cycle
1,200 liter
530 gallon
at 2 bar = 30 psi
Minimum flow for flushing
50 - 200 m3/h
220 - 880 US gpm
at 2 bar = 30 psi
Control and electricity
Control voltage
24V AC / DC
Electric motor
4 X 1.5 HP
50 Hz, 14 Gear output R.P.M.
Rated operation Voltage
3 phase
380/ 440 V, 50 / 60 Hz
Single phase
110 / 220 V, 50 / 60 Hz
Current consumption
4X3 Amp.
(With 3 phase 380 / 440 V)
Construction materials
Filter Housing and Lid
carbon steel 37-2, Epoxy-coated
Screens
Stainless Steel 316
Cleaning mechanism
Stainless Steel 316, POM
Exhaust valve
Epoxy-coated cast iron, Natural Rubber
Seals
Synthetic Rubber, Teflon
Control
Aluminum, Brass, Stainless Steel, PVC
Standard filtration degrees
Perforated Screens
Wedge-wire Screens
Micron
3500
2500
1500
800
800
500
300
200
mm
3.5
2.5
1.5
0.8
0.8
0.5
0.3
0.2

Mega ABF 40000 IL 910101-001027 / 08.2019 Page 5 of 22
Safety Instructions
General Safety Instructions
➢Amiad filtration products always operate as components in a larger system. It is essential for the system designers, installers and
operators to comply with all the relevant safety standards.
➢Prior to installation, operation, maintenance or any other type of action carried out on the filter, read carefully the safety,
installation and operation instructions.
➢During installation, operation or maintenance of the filter all conventional safety instructions should be observed in order to
avoid danger to the workers, the public or to property in the vicinity.
➢Please note: The filter enters into a flushing mode automatically, without prior warning.
➢No change or modification to the equipment is permitted without a written notification given in advance by the manufacturer or
by its representative, on the manufacturer’s behalf.
➢Always observe standard safety instructions and good engineering practices whilst working in the filter’s vicinity.
➢Use the filter only for its intended use as designed by Amiad, any misuse of the filter may lead to undesired damage and may
affect your warranty coverage. Please consult with Amiad prior to any non-regular use of this equipment.
Installation
General
➢Install the filter according to the detailed Installation Instructions provided with the filter by the manufacturer and according to
the description given in this manual.
➢Make sure to leave enough clearance so as to enable easy access for future treatments and safe maintenance operations.
➢The user should arrange suitable lighting at the area of the filter to enable good visibility and safe maintenance.
➢The user should arrange suitable platforms, ladders and safety barriers to enable easy and safe access to the filter without
climbing on pipes and other equipment. The user should verify that any platform, barrier, ladder or other such equipment is built,
installed and used in accordance with the relevant local authorized standards.
➢Check and re-tighten all bolts during commissioning and after the first week of operation.
➢Use only appropriate standard tools and equipment operated by qualified operators when installing, operating and maintaining
the filter.
➢When installation is required in hazardous environment sites, underground or high above ground, make sure that the site design
and the auxiliary equipment are appropriate and that installation procedures are carried out in accordance with the relevant
standards and regulations.
➢Ensure walking areas about the installation are slip free when wet.
Shipment and transporting
➢Shipping and transporting the filter must be done in a safe and stable manner and in accordance with the relevant standards and
regulations.
➢For shipping, lifting and positioning the filter, use only approved lifting equipment and authorized employees and contractors.
Electricity
➢Electric wiring should be performed by an authorized electrician only, using standardized and approved components.
➢Install a lockable main power cut-off switch close to the control panel.
➢If due to site constraints, the control panel is installed without a clear line-of sight of the filter, an additional lockable power
disconnect cut-off switch should be installed near each filter unit.
➢Installation of the filter should be performed so as to avoid direct water splashing on the electrical components or on the control
panel.

Mega ABF 40000 IL 910101-001027 / 08.2019 Page 6 of 22
Pneumatics
➢Install a lockable main cut-off switch, featured with a pressure release mechanism, on the compressed air supply line close to
the control panel.
➢If the control panel is installed far away and there is no eye contact with the filter, a lockable compressed air cut-off switch,
featured with a pressure release mechanism, should be installed near each filter unit.
➢The user should make sure that the compressed air supplied to the filter never exceeds the maximum designated pressure for
this filter. An air-pressure reduction valve should be installed on the compressed air supply line upstream of the filter’s pneumatic
inlet port.
Hydraulics
➢Extra safety devices should be installed on hot water applications to avoid skin burn danger.
➢The user should install a manual Water Cut-off Valve next to the filter’s inlet port.
➢In cases where the downstream piping network downstream of the filter is pressurized an additional manual Water Cut-off Valve
should be installed next to the filter outlet port.
➢The user should make sure that the system includes a Pressure Release / Drainage Valve to enable release of residual pressure
prior to any maintenance procedure performed on the filter.
➢The user should make sure that the filter is never exposed to water pressure exceeding the maximum designated pressure for this
filter, if needed a Pressure Reduction Valve should be installed upstream of the filter’s water inlet port.
➢Please note that the maximum working pressure indicated at the filter’s specifications table includes the pressure caused by fluid
hammer and pressure surge effects.
Civil Engineering
➢Make sure that the filter installation is done by Amiad qualified technicians.
➢Make sure that any civil engineering work at the installation site such as construction, lifting, welding, etc. is done by qualified
workers / technicians / contractors and in accordance with the relevant local standards.
➢While using lifting equipment, make sure that the filter or the lifted part is chained securely and in
a safe manner.
➢Do not leave lifted equipment if there is no necessity. Avoid working below lifted equipment.
➢Wear a safety helmet while using lifting equipment.
➢Make sure that the flooring is sloped for drainage and to avoid accumulation of liquids.
Commissioning
➢Read carefully the Commissioning and the First Start-up Operation instructions prior to any attempt to operate the filter.
➢In order to achieve maximum performance and smooth operation of the filter it is crucial to perform the Startup and First
Operation procedures exactly as described in this manual.
➢Commissioning the filter should be done by an authorized Amiad technician, do not attempt to commission the filter
unaccompanied since this may lead to undesired damage and may affect your warranty coverage.
Operation and Control
➢Do not operate the filter before reading carefully and being familiar with its operation instructions.
➢Observe the safety stickers on the filter and never perform any operation contradicting the instructions given.
➢Never operate or use the filter for purposes other than its original design and operational envelope.

Mega ABF 40000 IL 910101-001027 / 08.2019 Page 7 of 22
Maintenance
Before any maintenance or non-regular operation please read the following:
➢Servicing the filter should be done only by technicians authorized by Amiad.
➢Disconnect the filter from the power supply and lock the Main Power Switch.
➢Disconnect the compressed air supply, release the residual pressure and lock the Pneumatics Main Valve.
➢Disconnect the filter from the water system by closing and securing the Manual Inlet Valve. In cases where the downstream
piping network is pressurized, close and secure the Manual Outlet Valve also.
➢Release the residual water pressure by opening the Pressure Release / Drainage Valve.
➢Empty the filter by opening the Drainage Valve.
➢In hot water systems wait till the filter components cool off to a safe temperature.
➢Place warning signs around the work area as required by the local standards and procedures.
➢Inspect the filter’s safety stickers and replace any damaged or faded sticker.
Mechanical
➢When working on the filter use only appropriate standard tools.
➢Always open and close valves slowly and gradually.
➢Remove grease and fat material residues in order to avoid slipping.
➢Before disconnecting the filter from the water supply, electricity and pneumatics and before releasing the filter’s residual
pressure do NOT:
oloosen or unscrew bolts
oremove any protection cover
oopen any service port flange
➢Avoid splashing and water leakage so as to minimize slippage, electrification or damage to the equipment, caused by moisture.
➢While using lifting equipment, make sure that the filter or the lifted part is chained securely and in
a safe manner.
➢Do not leave lifted equipment if there is no necessity. Avoid working below lifted equipment.
➢Wear a safety helmet, goggles, gloves, and any other personal safety equipment required by the local standards and regulations.
➢Human entry into a filter must be done in accordance with the relevant local safety instructions, standards and regulations for
working in hazardous environment.
➢Manual cleaning of filter media using high water pressure or steam should be performed in accordance with the cleaning system
instructions, the local standards and regulations and without endangering the operator or the vicinity
➢Manual cleaning of filter element using acid or other chemical agents should be performed in accordance with the relevant
material safety instructions, the local standards and regulations and without endangering the operator or his vicinity.
Before returning to regular operation
➢Re-assemble any protection covers or protection mechanisms removed during service or maintenance operations.
➢Make sure that all the tools, ladders, lifting devices, etc. used during the maintenance procedures are taken away from the filter
area and stored
➢In order to return the filter to regular operation, follow the First Start-up Operation instructions as detailed in your user manual.
➢For filters used in potable water systems it is required to disinfect the filter according to the local water authority standards and
regulations before putting it back to service.

Mega ABF 40000 IL 910101-001027 / 08.2019 Page 8 of 22
Dimensional Drawing

Mega ABF 40000 IL 910101-001027 / 08.2019 Page 9 of 22
Description of Filter Operation
Filtering process:
The MEGA ABF-40,000 FILTER is a sophisticated yet easy-to-operate automatic filter, with a self-cleaning mechanism driven by
electric motors. The MEGA ABF consists of four filter unit and is designed to work with various types of screens in filtration degrees
from 200 to 3500 micron, and is available in 16", 18", 20", 24" and 28”inlet/outlet diameters.
The water enters through the inlet pipe into the fine screens from the inside out. The "filtration cake" accumulates on the fine
screen surface and causes head loss to develop.
Self-cleaning process:
The MEGA ABF-40,000 FILTER starts the self-cleaning process when the pressure differential across the screens reaches a pre-set
value or a predetermined lapse of time.
Cleaning of the filter element is carried out by opening a flushing valve located on the housing lid and starting the electric motor,
which revolves 2 stainless steel brushes on the inside of the filtration cylinder.
The particles trapped on the cylinder are dislodged by the revolving brushes and flushed out through the open flushing valve.
The cleaning operation duration is approximately 15 seconds per screen.
The service flow of the filtered water is continuous during the cleaning cycle.
The electric control board which is supplied with the filter controls the automatic operation of the filter.
Different modes of filtration:
The filtration system may be found in one of the following modes:
1. Filtering mode: This is the normal function condition. Flushing doesn’t occur & the power light on the control board is lit.
2. Flushing mode: A mode in which the flushing process is in progress. The motors and the exhaust valves open according to the
program.
3. Malfunction mode: During malfunction mode the self-cleaning operation is stopped, the malfunction light on the control board
is turned on and an external dry contact output is activated.
The filtration system may enter a malfunction mode in the following cases:
1st. When there is a continuous signal from the pressure differential switch for duration of more than 5 minutes. This means that
the self-cleaning process is not successful (Could be set differently by changing the settings of the fault timer TAL, inside
control board).
2nd. When one of the motor-protectors is activated, manually, or due to overload (in such case the remaining filter elements
continue to operate).

Mega ABF 40000 IL 910101-001027 / 08.2019 Page 10 of 22
Initiation of self-cleaning:
The filter enters the self-cleaning process as a result of any of the following causes:
1. A signal from the Pressure Differential Switch (PDS) - The PDS mounted on the filter body, sends a dry contact when the pressure
differential across the screen reaches the pre-set value (usually 0.5 bar / 7 psi). The control board registers the signal and
operates the flushing process according to its program. (Closing the manometer valve connected to the low pressure of the PDS
for 5 seconds also causes the filter to start flushing.)
2. Manually pressing the "TEST" push button at the control board.
3. The TIMER feature of the control board allows operation of self-cleaning process at pre-set time intervals, independent off the
head loss factor. The timer resets after every flushing cycle.
Cleaning cycle stages of single filtration unit:
1) The exhaust valve opens to the atmosphere.
2) The motor starts rotating the shaft with the brushes, for approximately 15 seconds.
3) The exhaust valve closes.
4) The motor stops.
Cleaning cycle of the MEGA ABF unit:
The four filter units are flushing in sequence; one unit at a time.
A common PD Switch provides the signal for flushing the entire system.
1) Unit #1 flushes as described above.
2) The exhaust valve of unit #2 opens as soon as the cleaning cycle of unit #1 ends.
3) The cycle ends when unit #4 has ended its cycle
During the self-cleaning process there is no interruption of the service flow and the PDS constantly monitors the pressure differential
between the inlet and the outlet of the filter.

Mega ABF 40000 IL 910101-001027 / 08.2019 Page 11 of 22
Installation
Design recommendations
1. If flow increases and pressure drops dramatically for a long period of time during network filling-up, it is recommended that a
pressure sustaining valve is installed downstream of the filter. The pressure sustaining valve will ensure a controlled filling-up
of the line.
2. If continual water flow is essential even during maintenance period, it is recommended that a manual or automatic by-pass is
installed, and the isolating valves will be used to isolate each filter.
3. In places where there is an expected temporary worsening of water quality, it is possible to operate an emergency flushing
program. In order to do so, a hydraulic controlled valve has to be installed downstream of the filter. For details, please
consult the manufacturer.
Installation instructions
1. Before beginning the installation process, carefully read the safety instructions chapter of this document and make sure that
all the workers at the installation site are fully aware of and comply with, these and any other local safety instructions.
2. Select a convenient location for the installation of the filter where operation and maintenance will be optimal. It is
recommended that a standard and safe lifting auxiliary is available for maintenance.
3. Install the filter horizontally. Please note the minimum clearance (Not including a crane) required in order to allow
disassembly of the unit.
4. Ensure that the direction of flow is aligned with the arrows marked on the filter housing.
5. Installation of a mechanical non-return valve downstream of the filter is required.
6. If possible, prior to installing the filter, thoroughly flush the main line at the connection point in order to remove large objects
that may damage the filter’s internal mechanism.
7. Install a drainage pipe to the exhaust valve. Minimum 2" diameter for a maximum pipe length of 20 meters (60 feet), for
longer drainage, 3" pipe diameter must be used for a maximum length of 40 meters (120 feet). Please note that no restriction
is allowed on the drainage pipe for a flow of 7.5 m3/h (33 US-gpm). For special applications, please consult the manufacturer.
8. If the system is designed to operate with working pressure higher than 6 bar (85 psi), it is recommended that a manual
valve is installed on the exhaust pipe, in order to enable regulation of the flushing flow rate & pressure.
9. The user should arrange suitable lighting in the vicinity of the filter to enable good visibility and safe maintenance.
10. The user should arrange suitable platforms and safety barriers to enable easy access to the filter without climbing on pipes
and other equipment. All such equipment should comply with the safety clauses of the relevant local standards.
IMPORTANT!!
•Prevent static back pressure or reverse flow through the filter.
•Install a non-return valve at the outlet of the filter.
•Install a manual or a hydraulic valve downstream of the filter.
Electric wiring
1. All electrical works at the installation site must be done by a qualified and authorized electrician only. Make sure that this
electrician is fully aware of all the relevant safety instructions.
2. Install the control board in a dry and protected place (In out-door installation sites make sure to use a special control board
for out-door installation).
3. Power connection to the control board:
a. Connect a three-phase voltage source through a semi-automatic switch, or 16 Amp. fuse to the L1 L2 L3 inlet at the
terminal strip in the control board.
b. Earth the control board.
4. Power connection to the motor:
Connect the drive units to the control panel by means of a cable of 4 x 1.5mm2 for a distance of up to 5m. For distance of up
to 10m a cable of 4 x 2.5mm2 should be used.

Mega ABF 40000 IL 910101-001027 / 08.2019 Page 12 of 22
Use a long enough cable to allow the drive units to be removed and placed near the filter for maintenance, without having to
disconnect them from the cable. (It is recommended that this installation meets or exceeds local or national electrical codes,
this is a "high" voltage connection).
5. Control wiring:
The connection between the control junction box and the control board should be by 6 x 1.5 mm 2 (16 AWG) wire in flex-
conduct. The numbers on the terminals in the board and in the junction box are identical.
Commissioning, Start-Up and First Operation
1. Before starting-up the filter read the safety instruction as appear at chapter 2 of this document and pay special attention to the
commissioning safety instructions.
2. Inspect the filter’s installation and make sure that it is installed in accordance with the official installation drawings.
3. Verify (by authorized electrician only) that the electric wiring is correct and complies with the enclosed drawings. Make sure
that the electrical start-up operation is done by an authorized electrician only.
4. Switch "OFF" motor protectors E1 - E4
5. Switch "ON" all circuit breakers.
6. Set selector ITSW to the off position (PD only).
7. Switch on E1 and watch the rotation direction of the motor of filter unit #1. If the motor rotates counterclockwise, stop it
immediately by turning E1 to the off position. Change the motor direction by switching between two phases.
8. Repeat the above with filter elements #2, 3 and 4.
9. Press the "TEST" push button and verify that the filters are functioning according to the sequence described in this document.
10. Open the water supply and pressurize the filter. It is highly recommended that first "wet" operation is done with static
pressure and no flow i.e. the outlet valve is open and the by-pass of the system is open.
11. Operate and simulate the different events by closing the 1/4" Manometer Valves of the PD switch for 5 seconds.
12. If everything is functioning as described, open the outlet valves of the filter and gradually, close the by-pass valve.
13. Set it to 4 - 8 hours and turn selector ITSW to the on position (PD & Time). Follow and monitor the functioning of the filtration
system, change its setting if required.

Mega ABF 40000 IL 910101-001027 / 08.2019 Page 13 of 22
Electrical Control System Description
The Mega ABF control board monitors and operates the filter self-cleaning process. The self-cleaning process includes simultaneous
operation of the motor and opening of the exhaust valve. The control board will cause the initiation of a flushing cycle as a result of
each of the following reasons:
1. Signal from the PDS.
2. Manual initiation by TEST / RESET push-button.
3. Internal timer, up to 30 hours.
During operation the Main switch, the Motor Protector and the F2 Circuit Breaker must be "ON". In this condition the power pilot
light is lit.
Flushing by PDS:
The signal duration from the PDS should be longer than the preset time in timer T0. It is recommended to set it to 3-5 seconds.
This delay will prevent the filter from entering into flushing mode as a result of a momentary signal from the PDS.
Manual Operation:
Quick pressing on the TEST / RESET push button will cause operation of self-cleaning.
Flushing according to Time:
The timer is located inside the control board and is marked "T2".It is possible to set it for intervals from a few minutes up to 30
hours.
To cancel the option of flushing by timer, turn off the SW-1 switch.
Timer T1 determines the minimum flushing duration. It is recommended that flushing duration be set to 15 seconds.
Fault Mode:
The control board is equipped with a protection circuit. It will cause the filter to enter a "fault" mode if continuous signal from the
PDS is received for duration longer than the preset time in TAL. This means that in case that the filter does not manage to clean
itself; the PDS will continue to send a signal. When the TAL time elapses, flushing stops, "fault" pilot light is lit and fault relay is
activated. It is possible to use this relay also for an alarm, automatic by-pass, etc.
To come out of fault mode, press the TEST / RESET push-button.
The recommended preset time for TAL is 5 minutes.
It is possible to order control boards with additional features such as sequential operation of a few filters in a battery, flushing
counter, etc.
Follow the drawing in this manual for proper wiring of the control board to the filter.

Mega ABF 40000 IL 910101-001027 / 08.2019 Page 14 of 22
Maintenance
Before beginning any maintenance procedure, carefully read the safety instructions chapter of this document and make sure that all
the workers at the filtration site are fully aware of and comply with, these and any other local safety instructions.
A. General inspection of the filter operation
This is the visual basic general inspection procedure of the filter for proper operation. It should be done regularly and prior to any
scheduled maintenance procedure.
Press the test button or close the 1/4" valve at the low pressure sensing port of the pressure differential switch for 5 seconds, this
will initiate the self-cleaning cycle; Check that the exhaust valve opens, that the scanner moves outwards, and when it reaches the
outer limit switch - verify that the exhaust valve closes.
B. Weekly maintenance
Visual Check:
1. Check that the filter operates properly by following the General Inspection of the Filter Operation as described above.
2. Visually check that there is grease on the brush assembly shaft.
3. Visually check the filter’s brush assembly shaft for any leakage.
4. Visually check the filter housing, the valves and the check-valves for leakage.
5. Check the filter for loosen-bolts.
If Necessary:
1. Disconnect and lock the filter’s power supply.
2. Disconnect and lock the filter’s compressed air supply.
3. Disconnect the filter from the water supply and drain the filter housing.
4. If it is necessary add grease to the filter’s brush assembly shaft.
5. Take care of any leakage from the brush assembly shaft. If necessary, replace the Sealing flange Internal O-Ring.
6. Reconnect the filter carefully and safely to its water, air and power supply.
7. Perform a General Inspection of the Filter Operation as described above.
C. Maintenance prior to long term cessation of filter operation
The following must be done if the filter will not be operated for more than a month.
1. Operate flushing cycle (If possible, with a closed downstream valve).
2. Disconnect the control board from the power and lock the main switch before the limit switch disc reaches the switch.
3. Release pressure from the filter.
4. Disconnect the compressed air supply and lock the main switch.
5. Grease the filter’s brush assembly shaft.
6. Clean the 3/4" control filter.
D. Maintenance prior to re-operation
1. Make sure that the filter is disconnected from power, compressed air and water supply.
2. Grease the drive shaft and the drive bushing.
3. Connect the control board to the mains.
4. Connect the compressed air supply.
5. Connect the filter to its water supply.
6. Perform a General Inspection of the Filter Operation as described above.
7. If necessary change the tightening nut’s internal seal as described above.

Mega ABF 40000 IL 910101-001027 / 08.2019 Page 15 of 22
E. Every Six Months
Before beginning this maintenance procedure, carefully read the safety instructions chapter of this document and make sure that all
the workers at the filtration site are fully aware of and comply with, these and any other local safety instructions.
1. Perform a General Inspection of the filter Operation as described above and carefully inspect the filter visually for:
a. Proper operation
b. Any leakage from the filter housing or accessories
c. Abnormal or unusual noises
d. Loosen bolts
e. Non smooth turning of the suction scanner
f. Unusual load on the filter electrical motor
g. Any sign of corrosion on the filter housing or accessories
h. Unusual vibrations
i. Non smooth operation of the filter valves, air release valves and check-valves
2. Close the inlet and the outlet valves of the filter. Drain the filter housing and release any residual pressure.
3. Disconnect and lock the filter's power supply.
4. Disconnect and lock the filter's compressed air supply and release any residual pressure.
5. Disassemble the filter as described in the next chapter of this document.
6. Inspect the filter screens and components for any wear and tear.
7. Check the brush assemblies.
8. Check the filter bearings.
9. Check the filter housing and lid for any sign of corrosion.
10. Check the filter internal and external coating and pain for damage
11. Replace any damaged component
12. Make sure that your maintenance engineers are aware of even the slightest sign of corrosion in the filter housing, lid or
accessories. In such case consider performing a standard pressure vessel tests as required by your local applicable standards.
13. Re-assemble the filter as described in the next section of this document.
14. Perform a complete COMMISSIONING, START-UP AND FIRST OPERATION as described earlier in this document.
IMPORTANT !
THE DRIVE SHAFT MUST BE LUBRICATED WITH HEAVY-DUTY, WATER RESISTANT GREASE THAT WILL NOT OXIDIZE. (SHELL,
DARINA EP-2 OR SIMILAR)

Mega ABF 40000 IL 910101-001027 / 08.2019 Page 16 of 22
Parts schedule Standard Mega ABF 40K
No.
Description
Qty.
1
HOUSING ABF-40K C/ST BSTDO.L. AMRLK 400 IDEB-3002
1
2
ABF-40K SCR.SUPPORT C/ST RB. LINE AMERLOCK 400
4
3
HEX BOLT FULL TH M10X30 S/ST316 DIN933
8
4
LOWER BEARING ABF/EBS10000 POM
4
5
SHAPED SEAL HYD.AM-04NR EBS10000 SCR.NBR
8
6
SCREEN S/ST316L 10000SQ.CM XXXMIC ABF-10K
4
7
ABF-10,000 BRUSH ASSY.FOR COUPLING UNIT
4
8
KEY 55MM ABF-10000 SAE 1040 SHORT F/BRUSH SIDE
4
9
MEGA-ABF SCREEN STOPPER ASSY
1
10
NIPPLE 2" PKPK 3002 C/ST POLYESTER
1
11
2-WAY BALL VALVE 2" BSP
1
12
PARKER O-RING 2-463 NBR 70 SHORE
4
13
LID FOR ABF-40K IDEB 3002 BSTD
4
14
HEX BOLT FULL THRD M22 60MM C/ST DIN933 Z.PLATED
48
15
FLAT WASHER M22 DIN125 ZINC PLATED C/ST
48
16
O-RING 38X4 NBR 70 SHORE NO FLASH
4
17
FLANGE SEALING ABF/EBS DELRIN
4
18
O-RING 30X4 NBR 70 SHORE NO FLASH
4
19
SOCKET SET SCREW M10X60 S/ST304 DIN916
8
20
HEX NUT M10 S/ST316 DIN934
8
21
FLAT WASHER M10 DIN125 S/ST316
8
22
COUPLING ABF ASSY
4
23
KEY ABF-10000 BRASS BRUSH
4
24
HEX BOLT FULL THRD M10X50 Z.PLT C/ST
16
25
FLAT WASHER M10 DIN125 ZINC PLATED C/ST
32
26
SPRING WASHER M10 DIN127 ZINC PL. C/ST
16
27
HEX NUT M10 ZINC PLATED C/ST DIN934
16
28
DR.UNIT ABF10K 380/480AC 50/60HZ RAL5010
4
29
ABF10K DRIVE SHAFT COVER S/ST304 S.BLAST
4
30
HEX BOLT FULL TH M8X45 S/ST316 DIN933
8
31
FLAT WASHER M8 DIN125 S/ST316
8
32
FLANGE GASKET 3" 124X92 NBR
4
33
HYDRAULIC VALVE 3" RAM BSTD RED
4
34
FLAT WASHER M16 DIN125 ZINC PLATED C/ST
32
35
HEX BOLT PARTIAL THR M16X65 Z.PLT C/ST
16
36
HEX NUT M16 ZINC PLATED C/ST DIN934
16
37
PRESS CH POINT CONNECTOR 1/4"X1/4" BRASS
4
38
SOLENOID VALVE 24VAC,50HZ,NO (GEM-SOL)
4
39
L-CONNECTOR 1/4"M X5/16" BSPT BRASS AIGNEP
9
40
ADAPTOR5/16"X5/16" 63PT F/AIR BRAKE TUBE
24
41
CONNECTOR 5/16" X1/4" BRASS HAM-LET
5
42
L-CONNECTOR 1/8"M X5/16" BSPT BRASS AIGNEP
6
43
Ball Valve 3/4" M/F (BRASS)
4
44
L-CONNECTOR 3/4" F/M GALVANIZED
4
45
HOUSING 3/4" (AC,BLACK) BSPT ASSY
4
46
MOLDED WEAVEWIRE SCREEN 140SQ.CM 200MIC AMIAD 3/4"
4
47
3/4" COVER CLOSED ACETAL BLACK
4
48
O-RING 2-112 NBR 70 SHORE NO FLASH
4
49
NIPPLE 1/4" ABF/EBS/SAF POM PLASTIC FILTER
4
50
RACCORD NUT 3/4" FOR 3/4" FILTER
4

Mega ABF 40000 IL 910101-001027 / 08.2019 Page 17 of 22
No.
Description
Qty.
51
EBS -40K PLATE ST.37-2
1
52
HEX BOLT FULL TH M8X25 S/ST316 DIN933
4
53
Aluminum Amiad Nameplate, CE, EN
1
54
RIVET BLIND 3X6 DIN 7337 S/ST316
4
55
PRESSURE GAUGE 0-16 BAR/PSI 1/4" BSP
2
56
BACK SIDE CLAMP FOR C/ST FOR 1/4'' PRESSURE GAUGE
2
57
ADAPTOR 1/8"FX1/4"F NICKEL PLATED
2
58
PRESSOSTAT SUB-AS. MIDWEST W/O FTNG EL.CABLE ASSY
1
59
MANOMETER VALVE 1/4" W/ DRAIN ASSY
1
60
L-CON. 1/4"F X1/4"M BSPT NIC.PLT AIGNEP
1
61
T-CONNECTOR 1/8"X5/16"X5/16" BRASS
2
62
C.BOARD MEGA EBS/ABF X4 VALVES TYPE-D IP66
1
63
CONTROL TUBE 5/16'' BLACK BACCARA
4.2 [M]

Mega ABF 40000 IL 910101-001027 / 08.2019 Page 18 of 22
Parts Drawing Standard Mega ABF 40K #1

Mega ABF 40000 IL 910101-001027 / 08.2019 Page 19 of 22
Parts Drawing Standard Mega ABF 40K #2

Mega ABF 40000 IL 910101-001027 / 08.2019 Page 20 of 22
Parts Drawing Standard Mega ABF 40K #3
