EN INSTRUCTION MANUAL
NL GEBRUIKERSHANDLEIDING
IO-CBI-2547 / 8513847
(01.2022 / v1)
12243.3ePaTePrDScJNkUtX / EBPX 946 700 E

2
Information about the product concerning Regulation (EU) No 65/2014 and Regulation
(EU) No 66/2014, can be found on the last pages of the user manual or in other printed
documents provided with the product.
DEAR CUSTOMER,
The oven is exceptionally easy to use and extremely ecient. After reading the instruction
manual, operating the oven will be easy.
Before being packaged and leaving the manufacturer, the oven was thoroughly checked with
regard to safety and functionality.
Before using the appliance, please read the instruction manual carefully.
By following these instructions carefully you will be able to avoid any problems in using the
appliance.
It is important to keep the instruction manual and store it in a safe place so that it can be
consulted at any time.
It is necessary to follow the instructions in the manual carefully in order to avoid possible
accidents.
Caution!
Do not use the oven until you have read this instruction manual.
The oven is intended for household use only.
The manufacturer reserves the right to introduce changes which do not aect the
operation of the appliance.

3
Safety instructions ............................................................................................................. 4
Description of the appliance ............................................................................................. 8
Installation......................................................................................................................... 10
Operation........................................................................................................................... 12
Baking in the oven – practical hints ............................................................................... 25
Cleaning and maintenance.............................................................................................. 32
Technical data................................................................................................................... 38
TABLE OF CONTENTS

4
SAFETY INSTRUCTIONS
Warning: The appliance and its accessible parts become hot
during use. Care should be taken to avoid touching heating
elements. Children less than 8 years of age shall be kept
away unless continuously supervised.
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the ha-
zards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by chil-
dren without supervision.
During use the appliance becomes hot. Care should be taken
to avoid touching heating elements inside the oven.
Accessible parts may become hot during use. Young children
should be kept away.
Warning: Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can scratch
the surface, which may result in shattering of the glass.
Warning: Ensure that the appliance is switched o󰀨 before
replacing the lamp to avoid the possibillity of electric shock.
You should not use steam cleaning devices to clean the
appliance.

5
SAFETY INSTRUCTIONS
● Ensure that small items of household equipment, including connection leads, do
not touch the hot oven as the insulation material of this equipment is usually not
resistant to high temperatures.
● Do not leave the oven unattended when frying. Oils and fats may catch re due
to overheating or boiling over.
● Do not put pans weighing over 15 kg on the opened door of the oven.
● Do not use harsh cleaning agents or sharp metal objects to clean the door as they
can scratch the surface, which could then result in the glass cracking.
● Do not use the oven in the event of a technical fault. Any faults must be xed by
an appropriately qualied and authorised person.
● In the event of any incident caused by a technical fault, disconnect the power and
report the fault to the service centre to be repaired.
● The rules and provisions contained in this instruction manual should be strictly
observed. Do not allow anybody who is not familiar with the contents of this instruc-
tion manual to operate the oven.
● The appliance has been designed only for cooking. Any other use (for example
for heating) does not comply with its operating prole and may cause danger.
Danger of burns! Hot steam may escape when you open the
oven door. Be careful when you open the oven door during
or after cooking. Do NOT lean over the door when you open
it. Please note that depending on the temperature the steam
can be invisible.

6
HOW TO SAVE ENERGY
Using energy in a respon-
sible way not only saves
money but also helps the
environment. So let’s save
energy! And this is how you
can do it:
●Do not uncover the pan too often
(a watched pot never boils!).
Do not open the oven door unnecessarily
often.
● Only use the oven when cooking larger
dishes.
Meat of up to 1 kg can be prepared more
economically in a pan on the cooker hob.
●Make use of residual heat from the
oven.
If the cooking time is greater than 40 minutes
switch o󰀨 the oven 10 minutes before the
end time.
Important! When using the timer,
set appropriately shorter cooking
times according to the dish being
prepared.
●Make sure the oven door is properly
closed.
Heat can leak through spillages on the door
seals. Clean up any spillages immediately.
●Do not install the cooker in the direct
vicinity of refrigerators/freezers.
Otherwise energy consumption increases
unnecessarily.

7
During transportation, protec-
tive packaging was used to
protect the appliance against
any damage. After unpack-
ing, please dispose of all
elements of packaging in a
way that will not cause dam-
age to the environment.
All materials used for packaging the appli-
ance are environmentally friendly; they are
100% recyclable and are marked with the
appropriate symbol.
Caution! During unpacking, the packag-
ing materials (polythene bags, polystyrene
pieces, etc.) should be kept out of reach of
children.
UNPACKING DISPOSAL OF THE APPLIANCE
Old appliances should not sim-
ply be disposed of with normal
household waste, but should
be delivered to a collection and
recycling centre for electric and
electronic equipment. A symbol
shown on the product, the
instruction manual or the packaging shows
that it is suitable for recycling.
Materials used inside the appliance are
recyclable and are labelled with information
concerning this. By recycling materials or
other parts from used devices you are making
a signicant contribution to the protection of
our environment.
Information on appropriate disposal centres
for used devices can be provided by your
local authority.

8
DESCRIPTION OF THE APPLIANCE
P Control panel
1. On/o󰀨 switch
2. Door Handle
2
P 1

*optional
9
SPECIFICATIONS OF THE APPLIANCE
Cooker ttings:
Baking tray*
Grill grate
(drying rack)
Roasting tray*
Sideracks

10
INSTALLATION
Installing the oven
● The kitchen area should be dry and aired
and equipped with e󰀩cient ventillation.
When installing the oven, easy access to
all control elements should be ensured.
● This is a Y–type design built–in oven,
which means that its back wall and one
side wall can be placed next to a high
piece of furniture or a wall. Coating or
veneer used on tted furniture must be
applied with a heat–resistant adhesive
(100°C). This prevents surface deforma-
tion or detachment of the coating.
● Hoods should be installed according to
the manufacturer’s instructions.
● Make an opening with the dimensions
given in the diagram for the oven to be
tted.
● Make sure the mains plug is disconnected
and then connect the oven to the mains
supply.
● Insert the oven completely into the open-
ing without allowing the four screws in the
places shown in the diagram to fall out.
● The oven is manufactured to work with a
one-phase alternating current (220-240V
1N~50/60 Hz) and is equipped with a 3 x
1,5 mm2connection lead of 1.5 mm length
with a plug including a protection contact.
● A connection socket for electricity supply
should be equipped with a protection
pin and may not be located above the
cooker. After the cooker is positioned, it is
necessary to make the connection socket
accessible to the user.
● Before connecting the oven to the socket,
check if:
- the fuse and electricity supply are able to
withstand the cooker load,
- the electricity supply is equipped with an
e󰀩cacious ground system which meets
the requirements of current standards
and provisions,
- the plug is within easy reach.
Electrical connection
Important!
If the xed power supply cable is damaged,
it should be replaced at the manufacturer
or at an authorized servicing outlet, or by a
qualied person to avoid danger.

11
INSTALLATION
56
523
550
429
1034
116
7
600
595
40
40
560
40
560
560
560
600
16
25
595
595
570
max50
595
578

12
OPERATION
Before rst use
• Remove all packaging elements, par-
ticularly those protecting the interior of
the oven cavity during transport.
• Remove all the accessories from inside
of the oven and wash them thoroughly
in warm water with gentle washing up
liquid.
• Remove the protective foil from the sur-
faces of the telescopic runners.
• Use warm water with the addition of
mild detergent to wash the inside of the
chamber. Do not use hard brushes or
sponges. They could damage the coat-
ing of the inside of the chamber.
Warm up the oven cavity
• Turn on the ventilation in the room or
open a window.
• Select conventional heating or fan
assisted heating (a detailed descrip-
tion of these functions can be found be-
low in this manual).
The oven should operate for a minimum of
30 minutes; while it is operating the oven
produces a smell, which is only present at
the beginning but will eventually go away as
the appliance is used. This is perfectly nor-
mal and is part of the process of warming up
the oven cavity.
Control Panel
On/o󰀨 switch is on the right side of the
display. To activate the on/o󰀨 switch, touch the
glass in the place indicated by a pictogram.
You will hear a beep. (See section: Control
panel).
Touch sensor surfaces must be kept clean.

13
OPERATION
Control panel
The control panel is equipped with an LED display and backlit touch sensors:
Sensor Description Sensor Description
Conventional heating Main switch (standby)
Pastry Clock, minute minder
Fan cooking Lighting
Great grill Pre-set programmes
Turbo grill Eco programme
Pizza Pyrolytic cleaning
Roasting Quick oven pre-heat
Soft Steam Set temperature
Plus / up [+]
Minus / down [–]
Conrm
Note: You will hear a beep each time the sensor is used. It is not possible to turn o󰀨 the acoustic
beeps.
Each of the sensors can be backlit at the following brightness levels:
- 100% full brightness (active sensor);
- 50% reduced brightness (a sensor can be activated);
- 50% night brightness (reduced brightness for 22:00 – 6:00), switched o󰀨.

14
OPERATION
Function indicator symbols on the dis-
play
Minute Minder active
Duration
Programme end
Child Lock Active
Oven pre-heat active
* availability depending on the model
Connect the power supply
When you connect the appliance to power (or
when power is restored after an outage), the
display will show 00:00 and you will need to
set the current time. You must set the current
time to use the appliance.
Note: In the event of a power outage, all
settings such as Duration, Temperature and
Heating Function will be lost. You will need
to re-enter the settings to continue cooking.
If the pyrolytic cleaning is interrupted (or the
door is locked for any other reason), the oven
will start the cooling and door opening pro-
cedure before you can set the time. A power
outage does not release the Child Lock, but it
becomes active only after setting the current
time and when the appliance is in standby.
Set the current time
When you connect the appliance to the power
supply, the hours 00: ash on the display.
(minute digits are illuminated permanently).
Use and to set the hour. Touch to
conrm the setting. . The minutes :00 ash
on the display.(the hour is illuminated perma-
nently). Use and to set the minutes.
Touch to conrm the setting. The appli-
ance enters standby mode. You will hear a
beep when the current time is stored in the
appliance. To change the current time when
the appliance is on, touch and hold . The
symbol will be shown on the display. Touch
the sensor once again and the digits will
start to ash. Now you can proceed to set
the current time.
The display brightness.
The LED display brightness varies depending
on the time of day. The display is dimmed
during 22:00 to 06:00 and its brightness is
normal during 06:00 to 22:00. Also, the dis-
play is brighter when active than when the
appliance is in Standby mode.
Standby mode
Switch the appliance to standby mode to
reset all function settings, times, tempera-
ture and automatic programmes. All heating
elements are disconnected. The display is
dimmed except for the clock. In this mode,
only the on/o󰀨 sensor is available on the
display. The sensor has reduced brightness.
The display is dimmed in this mode.
If the temperature in the chamber exceeds
80°C, the temperature and current time are
displayed alternately.
When Child Lock is on and you touch ,
the LOC message and symbols will be
displayed for 5 seconds instead of current
time/temperature.

15
OPERATION
To turn o󰀨 the appliance and put it in stand-
by.
when you touch and hold for 3 seconds
at any time (you can turn OFF the appliance
even when Child Lock is on), you will hear
a beep;
after a power outage and when you set the
current time;
when you touch and hold for 3 seconds
during a pyrolytic cleaning cycle, the ap-
pliance activates cooling fan to unlock the
door, and enters standby only after the ap-
pliance has cooled down and the door is
unlocked.
To activate the appliance:
touch and hold for 3 seconds to activate
the appliance – you will hear a beep.
Operation
In this mode you can select the desired func-
tions, programmes and adjust settings. You
can use function, programme and minute
minder sensors as well as activate Child Lock
and adjust settings which requires touching
2 sensors. Other touch sensors are enabled
when necessary.
Auto-o󰀨: When all programmes complete and
you do nothing for 30 seconds, the appliance
turns o󰀨 automatically.
When you use the appliance display back-
light brightness is normal. The current time
is shown on the display. If a meat probe is
inserted in the oven cavity, the meat probe
symbol is displayed. If a Child Lock is set, the
lock symbol is displayed.
Child Lock
Child Lock is intended to prevent changes
to the oven settings and the oven being
turned on.
When the appliance is on, simultaneously
touch and hold the and sensors for 3
seconds to activate the Child Lock. The
symbol will be shown on the display. Simulta-
neously touch and hold the same sensors for
3 seconds to deactivate the Child Lock. The
symbol will go o󰀨 on the display.
When Child Lock is active you cannot adjust
any settings but you can turn o󰀨 the appli-
ance.
Lighting
The lighting turns on each time you open the
oven door. The lighting also turns on when
the oven is in active mode. This lighting is o󰀨
in Standby mode. If the oven door remains
open for a long time, the lighting will auto-
matically turn o󰀨 after about 5 minutes.
For details on lighting in ECO heating func-
tions, please refer to the description of the
heating functions.
The Sensor sensor operates indepen-
dently and using it does not a󰀨ect other
functions and settings. Sensor is inac-
tive in a standby mode.
Touch [] to turn on oven light for 30 seconds.
Touch and hold during cooking to turn
the light on. Touch and hold again to turn
the light o󰀨. The light turns o󰀨 when cooking
programme completes.
Touch to turn o󰀨 the light at any time.

16
OPERATION
Cooling fan
Cooling fan operates independently of the
set functions and the appliance mode of op-
eration. The cooling fan activates automati-
cally when any function is activated. The
cooling fan operates as long as the oven
cavity temperature exceeds 100°C. Below
this temperature, the cooling fan turns o󰀨.
For steam and pyrolytic programs, the cool-
ing is two-speed and operates as described
in the pre-set programmes section.
Oven pre-heat (thermostat symbol)
The pictogram indicates that at least
one of the heaters in the oven operates.
This pictogram goes out when the set tem-
perature in the oven cavity is reached. Then
the pictogram will be on and o󰀨 periodically.
This indicates that the set temperature is
maintained. If you lower the set tempera-
ture, the pictogram will only light up
when the oven cavity cools below the newly
set temperature.
Oven door
Oven door must be closed during operation.
When you open the door you will interrupt
the active oven function. If the door remains
open for more than 90 seconds, you will hear
a beep to prompt you to close the oven door.
Touch any sensor or close the oven door to
mute the beeping.
If you open the door for less than 5 minutes
the active settings are una󰀨ected. For safety
reasons, after this time, the oven enters the
standby mode (all settings are cleared).
Limit the operating time
If the oven operates any heating function for a
long time, heating elements are disconnected
to ensure safety as shown on the example
below. The appliance switches to standby
when programme is completed.
Example: If oven cavity temperature is 200°C,
heating elements are turned o󰀨 after about 3
hours. At a temperature of 100°C after about
10 hours.
This prevents overheating.
Minute Minder
You can set the timer in active mode. Touch
briey to display and the current pro-
gress of the minute minder countdown.
Touch and hold to enter the Minute
Minder setting mode and the indicator
will blink.
Then touch / to adjust the setting
and to conrm. Touch and hold /
simultaneously to clear the minute minder
setting.
When the minute minder is counting down,
the indicator lights up on the display.
You can set the minute minder for a maxi-
mum of 120 minutes.
The Minute Minder operates independently of
any active oven functions. When the set time
has elapsed, you will hear beeping. Touch any
sensor to mute the beeping.

17
OPERATION
Activate a heating function
When the appliance is on touch the desired
heating function symbol on the left side of the
display. The backlight of the selected function
is at full brightness while backlight of other
functions will be reduced to half brightness.
The symbols on the right side of the display
that are not available for a given heating func-
tion go our and their sensors become inactive.
When the heating function is selected now
you need to set the temperature. The tem-
perature and the °C symbol are displayed at
full brightness. The default temperature for
the heating function is displayed. Use /
to adjust temperature in steps of 5°C in
a loop. The minimum, maximum and default
temperature is individually dened for each
heating function. The --- symbol means that
the heaters are o󰀨.
Touch to conrm the set temperature.
The temperature display brightness is
reduced to normal level, the current time
appears on the display and the oven starts
the selected heating function at the set tem-
perature.

18
OPERATION
Heating functions and additional functions
Function Description
Oven elements Temperature [°C]
Default tempera-
ture [°C]
Lighting
Top heater
Roaster
heater
Fan heater
Bottom heater
Fan
min. max
Heating functions
Conventional √ √ √ 30 280 200
Pastry √ √ √ √ 30 280 180
Fan cooking √ √ √ 30 280 180
Grill √ √ 30 280 250
Super grill √√√ 30 280 250
Turbo grill √ √ √ √ 30 280 200
Pizza √ √ √ √ 30 280 220
Roasting √ √ 30 240 200
Soft Steam √ √ √ √ 20 280 200
Additional functions
Temperature see manual for details
ECO baking see manual for details 30 280 200
Lighting √- - -
Quick oven pre-heat √ √ √ √ 30 280 -
Pre-set programmes see manual for details
Pyrolytic cleaning* √ √ √ - - 410
* availability depending on the model
Preview and modify settings during oven operation
Touch briey to display the temperature inside the oven cavity. Touch again to display the
set temperature. Touch again to displaying the current time.
To adjust the set temperature, touch and hold and the currently set temperature will be
displayed. Use and to adjust it as needed. Touch to conrm the new temperature.
The new value is not set until conrmed.

19
OPERATION
You can check the set times much the same
as temperature. Touch briey to display
the minute minder setting. Touch again to
display the Duration. Touch again to display
the End Time. Touch again to displaying the
current time.
To adjust the set time, touch and hold and
the currently set time will be displayed. Use
and to adjust it as needed. Touch
to conrm the setting. The new value is not
set until conrmed.
To change the heating function during oven
operation simply select a new function The
newly selected function indicator starts ash-
ing while the currently running function does
not change. Touch to conrm the selection
of a new function. The new function indica-
tor stops ashing and remains on while the
previous function indicator goes o󰀨. If you do
not conrm the new selection, the previous
function will continue.
When you change a function, the set tem-
perature remains the same.
End a heating function
Touch and hold to end a heating func-
tion. By default the oven functions operate
indenitely, but you can set the oven to turn o󰀨
using a timed operation function or delayed
timed operation function. The only exception
is the pyrolytic cleaning function, which can-
not be modied.
Duration (automatic o󰀨)
In this mode the oven will turn o󰀨 after a
set duration has elapsed. You can set the
duration from 1 minute to 10 hours. To set
timed operation for any oven function, touch
and hold the sensor, and the minute
minder symbol will ash on the display. Touch
again, the symbol will appear on the
display. Now touch to set the Duration and
touch to conrm.
Touch / to adjust Duration as needed.
Touch to conrm the adjusted setting.
To clear the Duration touch until you reach
0:00 and touch to conrm.
Turning o󰀨 the oven interrupts the active oven
function. When the set Duration has elapsed,
you will hear beeping. Touch any sensor ex-
cept to mute the beeping. The beeping
stops, the function settings and temperature
are cleared and lighting will turn on for 30 s.
The symbol will go out. The appliance
will turn o󰀨 after another 60 seconds.
Note: When you use the sensor to mute
the beeping, the appliance will allow you to
adjust the delayed start time.

20
OPERATION
Delayed start (automatic on and o󰀨)
You can set the oven to start at a specic time
and operate for a set Duration. You can delay
the oven start from 1 minute to 10 hours, and
set the Duration for up to 10 hours. You rst
need to set the Duration. The display will
show . Then touch and hold the sen-
sor again and the minute minder symbol
will ash on the display. Touch twice and
the symbol will ash on the display, now
use to set the start time and touch
to conrm.
Once Start Time is conrmed the and
indicators light up steadily and the Current
Time is shown again.
Use / to adjust the Start Time. Touch
to conrm the adjusted setting.
To cancel timed operation use to adjust
duration down to the lowest possible value
and touch to conrm.
When the oven is turns on automatically, the
symbol will go out.
When the Duration has elapsed, you will hear
beeping. Touch any sensor to mute the beep-
ing. The beeping stops, the function settings
and temperature are cleared and lighting
will turn on for 30 s. The symbol will go
out. The appliance will turn o󰀨 after another
60 seconds.
