Amperes PM1010 User manual

Thank you for choosing another quality product from Amperes Electronics.
PM1010 and PM1030 are newly designed desktop gooseneck microphones with contemporary outlooks suitable for
general purpose paging applications. PM1010 is a basic version with simple press to talk without chime whereas its
sibling, PM1030 comes with pre announcement chime, paging contact and chime volume controls, which is designed
for commercial applications.
Both models had been tuned to perform better than its predecessors and shall be the right choice for your paging
needs.
VER 1 / 2021
PM1010 / 1030
Analogue Paging Microphone
PAGING MICROPHONE
PM1030
amperes
CHIME + TALK
PRESS TO TALK

GND
+ AUDIO OUT
- AUDIO OUT
NO COM
DRY CONTACT BALANCED OUTPUT
INPUT
DC INPUT
LINE LEVEL MIC LEVEL
RJ45 PIN CONFIGURATION
1) NO
2) COM 3) NC
4) GND
5) +24V 6) - AUDIO 7) GND 8) +AUDIO
Parts Identifications
1
2
8
4
1. GOOSENECK MICROPHONE CONNECTOR
XLR jack for gooseneck mic ; plug the cardioid condenser gooseneck mic to this jack.
2. TALK SWITCH ( for PM1030 ONLY - NOT AVAILABLE IN PM1010 )
This momentary direct talk switch activates the mic without pre-announcement chime.
3. CHIME AND TALK SWITCH (PM1030) / TALK SWITCH (PM1010)
A 4 tone chime shall be broadcasted when the switch is pressed once and a downward 4 tone chime follows when the
unit is switched off ( PM1030 only ). For PM1010, there is no chime output and once ON, the mic shall be activated
immediately.
6. AUDIO OUTPUT
Output is balanced with either line or mic level which can be selected from this switch ( item 7 )
4. CHIME & VOLUME CONTROLS (PM1030)
Individual control for chime and mic output level to suit the installation environment. For PM1010, only mic volume
control is available.
7. MIC / LINE SWITCH
Output level from the unit can be preselected with either mic or line level.
6
PAGE 2 PM1000 SERIES PAGING MICROPHONE
CHIME + TALK
PAGING MICROPHONE
PM1030
amperes
PRESS TO TALK
3
5
7
9
Top View
Side View
AMPERES ELECTRONICS
Quality Product From
Rear View
External Box
5. DRY CONTACT (PM1030 ONLY)
When mic is active, a dry contact is available and is useful for various applications, such as to trigger emergency ALL
CALL.
8. RJ45 PORT
To connect PM1030 / PM1010 to External Box. Power and audio output shall be linked with RJ45 cable through this
port.
9. EXTERNAL BOX POWER INPUT
The unit operates using 24V DC supply. A power adaptor is provided in the package.

PAGE 3PM1000 SERIES PAGING MICROPHONE
Application Schematic PM1010
MIXER
POWER AMP
Other Audio Sources
Balanced audio
2C SCREEN
PM1010
SPEAKER
External Box
with PSU
O
I
amperes
MX 2222
POWER
OFF SELECT
TUNER
CD
CASS
OFF
MASTER
MUSIC SOURCE
SIG IN
BASS
MAXMIN
EXT INPUT
MAX MAXMIN
SOURCE
MIN
SIG IN
CHIME MIXER TREBLE
MAXMIN
TONE CTRL
CH5 CH6CH4
SIG INSIGIN SIG IN
MAXMIN MAXMIN MIN
CH3CH1 CH2
SIG INSIG IN
MAXMIN MAXMIN MAXMIN MAX
AUX
SIG IN
PUBLIC ADDRESS POWER AMPLIFIER
SIGNAL -40 dB
SIGNAL -10 dB
POWER
PROTECT
CLIP
PA 2480
amperes
PAGINGMICROPHONE
PM1030
amperes
CHIME+ TALK
Select the correct PM1010 output level when
connecting it to the Mixer input.
Application Schematic PM1030
ZONE SELECTOR
MIXER
EP1200
POWER AMP
2 Core (Dry Contact)
2C Screen ( Audio )
PM1030
EXTERNAL BOX
ALL CALL connection from PM1030 to Zone Selector is optional.
O
I
amperes
MX 2222
POWER
OFF SELECT
TUNER
CD
CASS
OFF
MASTER
MUSIC SOURCE
SIG IN
BASS
MAXMIN
EXT INPUT
MAX MAXMIN
SOURCE
MIN
SIG IN
CHIME MIXER TREBLE
MAXMIN
TONE CTRL
CH5 CH6CH4
SIG INSIGIN SIG IN
MAXMIN MAXMIN MIN
CH3CH1 CH2
SIG INSIG IN
MAXMIN MAXMIN MAXMIN MAX
AUX
SIG IN
ZS 5121
PUBLIC ADDRESS POWER AMPLIFIER
SIGNAL -40 dB
SIGNAL -10 dB
POWER
PROTECT
CLIP
PA 2480 amperes
EP 1200 amperes
EMERGENCY PAGING PANEL
MIC
SIREN SWITCH
SIREN
FIRE
EMERGENCY / SIREN ACTIVE
PAGINGMICROPHONE
PM1030
amperes
CHIME+ TALK
PRESSTO TALK
Select the correct PM1030 output level when
connecting it to the Mixer input.
Other Audio
Sources
Above illustrations shows connectivity of PM1030 to system with ALL CALL
activation. Refer Page 4 on how to connect to Zone Selector.

PAGE 4 PM1000 SERIES PAGING MICROPHONE
Connecting External Box to Zone Selector
Connecting to MX2322 Mixer Pre-Amplifier
PAGINGMICROPHONE
PM1030
amperes
CHIME+ TALK
PRESSTO TALK
L
R
L
R
CH9CH10
LINE LINEMIC
( PM1010 / PM1030 )
REMOTE MIC
12
PHANTOM
POWER
CHANNEL
34
PHANTOM
POWER
CHANNEL
56
PHANTOM
POWER
CHANNEL
78
PHANTOM
POWER
CHANNEL
INPUT
+IN GND -IN
INPUT
+IN GND -IN
INPUT
+IN GND -IN
INPUT
+IN GND -IN
INPUT
+IN GND -IN
INPUT
+IN GND -IN
INPUT
+IN GND -IN
INPUT
+IN GND -IN
CH1CH2CH3CH6 CH5 CH4CH7CH8
+
DC 24V
CH-B
+OUT GND -OUT
CH-A
+OUT GND -OUT
OUTPUT
+OUT GND +OUT GND +IN GND +IN GND
CH-B
REC OUT
CH-A
WARNING !
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK DO NOT EXPOSE THIS
EQUIPMENT TO RAIN OR MOISTURE.
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
CAUTION
CH12
PRIORITY
CH11
4) GND
3) NC
2) COM
1) NO
8) +AUDIO
7) GND
6) -AUDIO
5) +24V
LINEMICLINEMICLINEMICLINEMICLINEMICLINEMICLINEMIC
500mA
RJ45 PIN CONFIGURATION: AMPERES ELECTRONICS
amperes
R
MODEL : MX2322
PRE AMPLIFIER MIXER
MADE IN MALAYSIA
SER.
AC220-240V 50/60Hz 12W
AC220-240V 50/60Hz
FUSE: 500mA
PUBLIC ADDRESS POWER AMPLIFIER
SIGNAL -40 dB
SIGNAL -10 dB
POWER
PROTECT
CLIP
PA 2480
amperes
PM1030 can be connected to MX2322 mixer amplifier Remote Mic port without the External Box. With this connection, PM1030 shall has the
highest priority over other sources. Take note that with above connection, MX2322 volume control does not amplify / attenuate the mic audio. The
mic volume level is fully controlled by the mic volume knob.
cat5
POWER AMP
(Direct connecting PM1030 / PM1010 to
MX2322 without External Box)
PM1030
Balanced Audio
MX2322
24V DC via
power adaptor or
from Main Equipment rack
Optional connection for
triggering ALL CALL
24V DC to VC / Patch
overriding
Relay Trigger at ZS Zone Selector shall
activate ALL CALL as well as a dry contact.
ZS5122
PM1030 / PM1010 External Box
To Pre-amplifier mixer / mixing amplifier or directly to
amplifiers with line level output
Switch to select the required output level
GND
+ AUDIO OUT
- AUDIO OUT
NO COM
DRY CONTACT BALANCED OUTPUT
INPUT
DC INPUT
LINE LEVEL MIC LEVEL
RJ45 PIN CONFIGURATION
1) NO
2) COM 3) NC
4) GND
5) +24V 6) - AUDIO 7) GND 8) +AUDIO
ZONE SELECTOR
ZS 5122
DC 24V
+ - CONT
RELAYRELAY
TRIG PR
ZREMOTE SELECT
A B
RS485
1-Z1
2-Z2
3-Z3
4-Z4
5-Z5
6-Z6
7-24V
8-COM
UNIT ADD
ON
8
421
ZONE 1 TO 6
Quality Product From
AMPERES ELECTRONICS
Diagram above shows connection of PM1030 and ZS Zone Selectors ie. External Connector dry contact terminals to Zone Selector’s
Relay Trigger terminals. Activation of PM1030 shall trigger All Call at zone selector as well as providing 24V DC output to override
external volume controllers.

Connecting To MA2000 Series Mixer Amplifier
PAGE 5PM1000 SERIES PAGING MICROPHONE
Select the correct PM1030 output level when
connecting it to the Mixer input.
Dry Contact
EP1200
MIXER AMP
Other audio sources
2 Core ( Contact )
2C Screen ( audio )
PM1030
EP 1200 amperes
EMERGENCY PAGING PANEL
MIC
SIREN SWITCH
SIREN
FIRE
EMERGENCY / SIREN ACTIVE
PAGINGMICROPHONE
PM1030
amperes
CHIME+ TALK
PRESSTO TALK
Balance Audio Output
BASS
CH2 CH3 CH4 CH6CH5
TREBLE
MASTER
O
I
CH1
SPEAKER
WARNING !
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK DO NOT EXPOSE THIS
EQUIPMENT TO RAIN OR MOISTURE.
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
CAUTION
PM1030 Dry Contact to connect to MA2000 AC & PR for ALL CALL.
EP1200
MIXER AMP
GND
+ AUDIO OUT - AUDIO OUT
NO COM
DRY CONTACT BALANCED OUTPUT
INPUT
DC INPUT
LINE LEVEL MIC LEVEL
RJ45 PIN CONFIGURATION
1) NO
2) COM 3) NC
4) GND
5) +24V 6) - AUDIO 7) GND 8) +AUDIO
External Box PM1030
When there are more than one dry contact, a pair of diodes (e.g. 1N4001) are to be used as shown in order to make ALL CALL at mixing
amplifier ( MA Series ). In this case, PM1030 and EP1200 are the triggering sources, connecting to MA2000 AC (All Call) and PR (Priority)
terminals.

Connecting to IP Based System
PAGE 6 PM1000 SERIES PAGING MICROPHONE
PM1030
iPX5151 / iPX5155
(Input Mode)
cat5e
iPX 5101
amper e s
ACT STATUS POWERREM
MP3 / TUNER / CD
MEDIA PLAYER
iPX5101
IP PAGING CONTROLLER
iPX5200 MUSIC
SERVER
NETWORK SWITCH WITH FIBER LINK
iPX 5300
ETHERNETMUSIC CLIENT
ETHERNETADDRESS
ETHERNET
RESET
BALANCEDLINE
OUTPUT
amperes
iPX5155
iPX5300
paging audio & data
LOCAL PA EQUIPMENT INCL.
PRE-AMPLIFIER MIXER ZONE
DECODER POWER AMPLIFIERS ETC.
music
audio
Note:
By working with iPX5151 / iPX5155 Paging Client, PM1030 can broadcast paging via Ethernet to a remote location.
When activate paging, PM1030 utilises its Dry Contact port to trigger iPX5151 / iPX5155 Trigger port to allow the paging
client accept the mic audio and have the paging broadcasted to remote PA system.
PAGINGMICROPHONE
PM1030
amperes
CHIME+TALK
PRESSTOTALK
GND
+ AUDIO OUT - AUDIO OUT
NO COM
DRY CONTACT BALANCED OUTPUT
INPUT
DC INPUT
LINE LEVEL MIC LEVEL
RJ45 PIN CONFIGURATION
1) NO
2) COM 3) NC
4) GND
5) +24V 6) - AUDIO 7) GND 8) +AUDIO
iPX5151 / iPX5155 (Input Mode)
PM1010 / PM1030 External Box
Set to Line Level
External Box

PAGE 7PM1000 SERIES PAGING MICROPHONE
Technical Specification
PM1010 PM1030
Operating voltage
Power consumption
Indicators
Microphone
Dry contact
Audio
Mic sensitivity
Output impedance
Frequency response
S/N ratio
Output controls
Audio output (max)
Communication
Cable
Output connection
Gooseneck mic length
Dimensions (W x H x D)
Weight
24V DC
Cardioid condenser microphone
-72 dB Omni directional
Line level: 300 ohm
Mic level: 50 ohm
200Hz - 11kHz (± 3 dB)
80 dB ± 3 dB
Line output; 1.2V rms balanced
Mic output: 70mV rms balanced
2m RJ45 connector to external box
5 way mini connector at external box
370 mm
160 x 50 x 120 mm (excluding mic)
0.8W
Talk, Mic ring
-
Mic
380 g
1.3W
Press to Talk
Chime + Talk, Mic ring
3A max
Chime, Mic
400 g
Note:
The above specifications are correct at time of printing but subjected to changes without prior notice due to product
improvements.

Warranty Conditions
Disclaimer
AMPERES ELECTRONICS SDN BHD
MADE IN MALAYSIA
PUBLISHED : MAY 2021
ISO 9001: 2015
Design & Manufacture of Public Address Equipment and Systems
Certicate No. 16895 / A / 0001 / UK / En
Information contained in this manual is subject to change without prior notice and does not represent a
commitment on the part of the vendor. AMPERES ELECTRONICS SDN BHD shall not be liable for any
loss or damages whatsoever arising from the use of information or any error contained in this manual.
It is recommended that all services and repairs on this product be carried out by AMPERES ELECTRONICS
SDN BHD or its authorized service agents.
AMPERES series must only be used for the purpose they were intended by the manufacturer and in
conjunction with this operating manual.
AMPERES ELECTRONICS SDN BHD cannot accept any liability whatsoever for any loss or damages
caused by service, maintenance or repair by unauthorized personnel, or by use other than that intended by
the manufacturer.
Only Amperes Electronics Service Centres are allowed to make warranty repairs : a list of Amperes
Electronics Service Centres may be asked for by the purchaser or send directly to Amperes Electronics Sdn
Bhd at 70 Jalan Industri PBP 3, Tmn Perindustrian Pusat Bandar Puchong, 47100, Puchong, Selangor,
Malaysia or its authorized dealers. This warranty is not valid if repairs are performed by unauthorized
personnel or service centres.
This warranty covers only repairs and replacement of defective parts ; cost and risks of transportation as
well as removal and installation of the product from the main system are for the account of the purchaser.
This warranty shall not extend to the replacement of the unit.
This warranty does not cover damages caused by misuse, neglect, accident of the product as well as using
the product with power supply voltage other than shown on the product, or any other power supply source /
adaptor not recommended by the manufacturer.
This warranty does not cover damages caused by fire, earthquakes, floods, lightning and every cause not
directly related to the unit.
This warranty does not include any indemnity in favor of the purchaser or the dealer for the period out of
use of the unit; moreover the warranty does not cover any damages which may be caused to people and
things when using the product.
This warranty certificate is valid only for the described product, and is not valid if modifications are made on
this certificate or on the identification label applied on the product.
This warranty covers all the material and manufacturing defects and is valid for a period of 36 months from
the date of purchase or for a specified period in countries where this is stated by a national law. In this case,
the extension is valid only in the country where the product is purchased.
Amperes Electronics Sdn Bhd is not obliged to modify previously manufactured products under warranty if
the design changes or improvements are made.
