AMX AXC-REL14 User manual

Quick Start Guide
AXC-REL14 Universal Fourteen Relay Card
Product Information
Devices that require a simple momentary or latching contact closure can be
controlled with the AXC-REL14 Universal Fourteen Relay Card. This card
operates up to 14 relay-controlled functions in a dual 7 relay configuration.
Each section of seven relays on the AXC-REL14 are commoned and both
sections may be commoned together.
Specifications
The following table lists the AXC-REL14 specifications.
Connections
The following table lists the pinouts for the AXC-REL14.
Specifications
Power Requirements 150 mA @ 12 VDC
Relay Contact Rating 1/2 A @ 24 VAC / 28 VDC.
Jumpers CO1 - 8: On common Relays 1 - 7 with Relays 8 - 14
Contact Closures 14 per card; normally open contacts
LEDs Two rows of 7 LEDs (CR1 - CR14)
Commons 7 and 8 can be connected together via a jumper on the
card, thereby commoning all relays.
Connector Pinouts
Pinout Description
1 Common 1 - 7
2 Contact #1
3 Contact #2
4 Contact #3
5 Contact #4
6 Contact #5
7 Contact #6
8 Contact #7
9 Contact #8
10 Contact #9
11 Contact #10
12 Contact #11
13 Contact #12
14 Contact #13
15 Contact #14
16 Common 8 - 14
