VIDEO TOUCH PANEL W/O BUTTONS
B
SIZE
WALLMOUNT WIDESCREEN
PICTORIAL, NXD-CV7, 7" MODERO
95-2258-03 REV.
A
RELEASED TO PRODUCTION
REV
A
ECN
5534
APPROVED
REVISIONS
DESCRIPTION DATE
10/27/03
SCALE: 1:2
SHEET 1 OF 1
R:\MECH\DEV\_Zionop Level - 95 - SP - Creation \wall\95-2258-03
7.94 [202MM]
.94 [24MM]
2.83 [72MM] 3.33 [84MM]
5.93 [151MM] 5.33 [135MM]
6.10 [155MM]
7.07 [180MM]
10/27/03
MAB
10/27/03MAB
10/27/03
AVT
JS 10/27/03
AK 10/27/03
