MVP-5100 DATA SHEET
Modero®Touch Panels
5.2” Modero
V i e w P o i n t ®IR
Widescreen
Touch Panel
The MVP-5100 brings a new level of simplicity to the 5.2” MVP family. The MVP-5100 is a 5.2” Touch
Panel built on the same lightning fast processor as the MVP-5200i and offers the same eye-popping, crisp,
clean, high-resolution graphics in an ultra-light compact design that is easy to carry around the home or
office. The MVP-5100 offers cost-effective, one-way IR communication, perfect for controlling third party
IR devices from the bedroom to the conference room.
ULTRA BRIGHT WIDESCREEN DISPLAY
With 800x480 pixel resolution, the MVP-5100 is our brightest touch panel display. Colors are displayed crisply, clearly and
accurately. Its 16x9 screen size provides plenty of widescreen multimedia display options.
INCREASED INFRARED CAPABILITY
The MVP-5100 offers a total of ten IR ports: (1) 38kHz AMX port, (1) 455kHz AMX port, and (8) user-defined IR ports for
direct communication with third party IR-enabled equipment.
• Ultra-light,compactandthinformfactor
• Fasterprocessingandenergyefcient
• High-glossblackstyling
• Chargingoptionsincludetablechargingstation(MVP-TCS52)andwallchargingstation(MVP-WCS52)
(kickstand not available)
• Justtherightfeaturesandjusttherightprice
• (10)IRports:(1)38kHzAMX,(1)455kHzAMX,(8)userIR

MVP-5100 DATA SHEET
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 • 800.222.0193 • 469.624.8000 • +1.469.624.7400 • 469.624.7153 fax • www.amx.com
MVP-5100 (FG5966-08)
DIMENSIONS (HWD)
4 5/8” x 7 1/2” x 3/4” (11.7 cm x 19.1 cm x 2.0 cm)
POWER
110-240VAC +/- 10%, 50/60Hz
MINIMUM POWER SUPPLY REQUIRED
PS3.0 Power Supply (FG423-30):
All MVP-5100 models are shipped with this power supply
POWER MODES
•ON: All necessary modules are powered up and device remains online with
the Netlinx Master.
•STANDBY: LCD/backlight shutdown. Panel resumes the ON mode
instantly upon screen touch.
•FULL-OFF: Power to all peripherals and components is turned off.
Reboot required to wake.
CERTIFICATIONS
•FCC Part 15 Class B and CE
•IEC60950
BATTERY DURATION
•Three hours of continuous use
•2.5 days of normal use (25% On, 25% Standby, 50% Off)
MEMORY
•128 MB NAND FLASH
•256 MB Mobile DDRAM
WEIGHT
1.2 lbs (0.6 kg)
SCREEN PROPERTIES
•Contrast Ratio: 400:1
•Screen Resolution: 800 x 480 pixels WVGA
•Aspect Ratio: 16 x 9
•Brightness (Luminance): 300 cd/m2
•Display Colors: 262,144 colors (18-bit color depth)
•Dot/Pixel Pitch: 180 dpi
•Panel Type: TFT Color Active-Matrix
VIEWING ANGLE
+/- 60° (horizontal) and + 80°/- 40° (vertical)
OPERATING/STORAGE ENVIRONMENTS
•Operating Temperature: 0° C (32° F) to 40° C (104° F)
•Operating Humidity: 20% - 85% RH
•Storage Temperature: -20° C (-4° F) to 60° C (140° F)
•Storage Humidity: 5% - 85% RH
INCLUDED ACCESSORIES
•PS3.0 Power Supply (FG423-30)
•Stylus (pre-installed onto the left side of the unit)
•Integrated battery
MVP-5100
(Front View)
MVP-5100
(Right View)
MVP-5100
(Isometric View)
5.00
[127 mm]
7 1/2”
(19.1 cm)
4 5/8”
(11.7 cm)
3/4”
(2.0 cm)
