Analog Devices ADSP-21161N User manual

ADSP-21161N EZ-KIT Lite®
Evaluation System Manual
Revision 4.0, October 2006
Part Number
82-000530-01
Analog Devices, Inc.
One Technology Way
Norwood, Mass. 02062-9106 a
www.BDTIC.com/ADI

Copyright Information
©2006 Analog Devices, Inc., ALL RIGHTS RESERVED. This document
may not be reproduced in any form without prior, express written consent
from Analog Devices, Inc.
Printed in the USA.
Limited Warranty
The EZ-KIT Lite evaluation system is warranted against defects in materi-
als and workmanship for a period of one year from the date of purchase
from Analog Devices or from an authorized dealer.
Disclaimer
Analog Devices, Inc. reserves the right to change this product without
prior notice. Information furnished by Analog Devices is believed to be
accurate and reliable. However, no responsibility is assumed by Analog
Devices for its use; nor for any infringement of patents or other rights of
third parties which may result from its use. No license is granted by impli-
cation or otherwise under the patent rights of Analog Devices, Inc.
Trademark and Service Mark Notice
The Analog Devices icon bar and logo, VisualDSP++, the VisualDSP++
logo, SHARC, CROSSCORE, the CROSSCORE logo, and EZ-KIT Lite
are registered trademarks of Analog Devices, Inc.
All other brand and product names are trademarks or service marks of
their respective owners.
www.BDTIC.com/ADI

Regulatory Compliance
The ADSP-21161N EZ-KIT Lite evaluation system has been certified to
comply with the essential requirements of the European EMC directive
89/336/EEC (inclusive 93/68/EEC) and, therefore, carries the “CE”
mark.
The ADSP-21161N EZ-KIT Lite evaluation system had been appended to
Analog Devices Development Tools Technical Construction File refer-
enced “DSPTOOLS1” dated December 21, 1997 and was awarded CE
Certification by an appointed European Competent Body and is on file.
The EZ-KIT Lite evaluation system contains ESD
(electrostatic discharge) sensitive devices. Electro-
static charges readily accumulate on the human
body and equipment and can discharge without
detection. Permanent damage may occur on devices
subjected to high-energy discharges. Proper ESD
precautions are recommended to avoid performance
degradation or loss of functionality. Store unused
EZ-KIT Lite boards in the protective shipping
package.
www.BDTIC.com/ADI

www.BDTIC.com/ADI

ADSP-21161N EZ-KIT Lite Evaluation System Manual v
CONTENTS
PREFACE
Purpose of This Manual ................................................................. xiv
Intended Audience ......................................................................... xiv
Manual Contents ............................................................................ xv
What’s New in This Manual ............................................................ xv
Technical or Customer Support ...................................................... xvi
Supported Processors ...................................................................... xvi
Product Information ..................................................................... xvii
MyAnalog.com ........................................................................ xvii
Processor Product Information ................................................. xvii
Related Documents ................................................................ xviii
Online Technical Documentation ............................................. xix
Accessing Documentation From VisualDSP++ ....................... xx
Accessing Documentation From Windows ............................. xx
Accessing Documentation From Web ................................... xxi
Printed Manuals ....................................................................... xxi
VisualDSP++ Documentation Set ......................................... xxi
Hardware Tools Manuals ..................................................... xxii
Processor Manuals ............................................................... xxii
www.BDTIC.com/ADI

CONTENTS
vi ADSP-21161N EZ-KIT Lite Evaluation System Manual
Data Sheets ........................................................................ xxii
Notation Conventions .................................................................. xxii
USING ADSP-21161N EZ-KIT LITE
Package Contents ......................................................................... 1-2
Default Configuration .................................................................. 1-3
Installation and Session Startup ..................................................... 1-5
Evaluation License Restrictions ..................................................... 1-7
Memory Map ............................................................................... 1-8
SDRAM Memory ......................................................................... 1-9
Flag Pins ...................................................................................... 1-9
Interrupt Pins ............................................................................. 1-10
Audio Interface ........................................................................... 1-11
Example Programs ...................................................................... 1-13
Flash Programmer Utility ............................................................ 1-13
ADSP-21161N EZ-KIT LITE HARDWARE REFERENCE
System Architecture ...................................................................... 2-2
External Port ........................................................................... 2-3
Host Processor Interface (HPI) ................................................ 2-4
SPORT Audio Interface .......................................................... 2-4
SPI Audio Interface ................................................................. 2-4
JTAG Emulation Port ............................................................. 2-5
Switch and Jumper Settings ........................................................... 2-5
Clock Mode Selection Switch (SW10) ..................................... 2-5
www.BDTIC.com/ADI

ADSP-21161N EZ-KIT Lite Evaluation System Manual vii
CONTENTS
Boot Mode Selection Switch (SW11) ....................................... 2-7
~BMS Enable Jumper (JP22) ................................................... 2-7
SDRAM Disable Jumper (P17) ................................................ 2-8
S/PDIF Selection Jumper (P2) ................................................. 2-8
MCLK Selection Jumper (JP3) ................................................ 2-8
FLAG0 Enable Jumper (JP1 and JP4) ...................................... 2-9
FLAG1 Enable Jumper (JP5) ................................................... 2-9
Sample Frequency Jumper (JP6) ............................................... 2-9
ADC2 Input Mode Selection Jumpers (JP7 and JP8) .............. 2-10
MIC Gain Selection Jumpers (JP9 and JP10) ......................... 2-10
ADC2 Input Selection Jumper (JP11) .................................... 2-10
AD1836 Control Selection Jumper (JP23) ............................. 2-11
SW1 Enable Jumper (JP26) ................................................... 2-11
SW2 Enable Jumper (JP27) ................................................... 2-12
Processor ID Settings .................................................................. 2-12
LEDs and Push Buttons .............................................................. 2-13
Reset LED (LED1) ................................................................ 2-13
FLAG LEDs (LED2–7) ......................................................... 2-14
VERF LED (LED12) ............................................................ 2-14
Power LED (LED11) ............................................................. 2-14
USB Monitor LED (ZLED3) ................................................. 2-15
Programmable Flag Push Buttons (SW1–4) ............................ 2-15
Interrupt Push Buttons (SW5–7) ........................................... 2-15
Board Reset Push Button (SW12) .......................................... 2-16
www.BDTIC.com/ADI

CONTENTS
viii ADSP-21161N EZ-KIT Lite Evaluation System Manual
Connectors ................................................................................. 2-17
USB Connector (ZJ1) ........................................................... 2-17
Audio Connectors (J2–6, P4) ................................................ 2-18
External Port Connector (P9) ................................................ 2-18
Host Processor Interface Connector (P10) ............................. 2-19
Voltage Connector (P11) ....................................................... 2-19
SPORT1 and SPORT3 Connector (P12) ............................... 2-19
Link Port Connectors (P13 and P14) ..................................... 2-20
Power Input Connector (P16) ............................................... 2-20
SPI Connector (P18) ............................................................. 2-21
JTAG Connector (ZP4) ......................................................... 2-21
Specifications ............................................................................. 2-22
Power Supply ........................................................................ 2-22
Board Current Measurements ................................................ 2-22
ADSP-21161N EZ-KIT LITE BILL OF MATERIALS
ADSP-21161N EZ-KIT LITE SCHEMATIC
Title Page ..................................................................................... B-1
ADSP-21161N Processor .............................................................. B-2
Memory ....................................................................................... B-3
S/PDIF Receiver ........................................................................... B-4
Audio Codec ................................................................................ B-5
Audio In 1 .................................................................................... B-6
Audio In 2 .................................................................................... B-7
www.BDTIC.com/ADI

ADSP-21161N EZ-KIT Lite Evaluation System Manual ix
CONTENTS
Audio In MIC/LINE, Headphone Out ......................................... B-8
Audio Out 1 ................................................................................ B-9
Audio Out 2 .............................................................................. B-10
Audio Out 3 .............................................................................. B-11
Audio Out 4 .............................................................................. B-12
Push Buttons ............................................................................. B-13
LEDs, RESET, and Oscillators ................................................... B-14
Connectors ................................................................................ B-15
Power ........................................................................................ B-16
INDEX
www.BDTIC.com/ADI

CONTENTS
x ADSP-21161N EZ-KIT Lite Evaluation System Manual
www.BDTIC.com/ADI

ADSP-21161N EZ-KIT Lite Evaluation System Manual xi
PREFACE
Thank you for purchasing the ADSP-21161N EZ-KIT Lite®, Analog
Devices, Inc. evaluation system for SHARC®digital signal processors
(DSPs).
SHARC processors are based on a 32-bit super Harvard architecture that
includes a unique memory architecture comprised of two large on-chip,
dual-ported SRAM blocks coupled with a sophisticated IO processor,
which gives a SHARC processor the bandwidth for sustained high-speed
computations. SHARC processors represent today’s de facto standard for
floating-point processor targeted for premium audio applications.
The evaluation system is designed to be used in conjunction with the
VisualDSP++®development environment to test the capabilities of
ADSP-21161N SHARC processors. The VisualDSP++ development envi-
ronment gives you the ability to perform advanced application code
development and debug, such as:
• Create, compile, assemble, and link application programs written
in C++, C, and ADSP-21161N assembly
• Load, run, step, halt, and set breakpoints in application programs
• Read and write data and program memory
• Read and write core and peripheral registers
• Plot memory
www.BDTIC.com/ADI

xii ADSP-21161N EZ-KIT Lite Evaluation System Manual
Access to the ADSP-21161N processor from a personal computer (PC) is
achieved through a USB port or an optional JTAG emulator. The USB
interface provides unrestricted access to the ADSP-21161N processor and
the evaluation board peripherals. Analog Devices JTAG emulators offer
faster communication between the host PC and target hardware. Analog
Devices carries a wide range of in-circuit emulation products. To learn
more about Analog Devices emulators and processor development tools,
go to http://www.analog.com/dsp/tools/.
The ADSP-21161N EZ-KIT Lite provides example programs to demon-
strate the capabilities of the evaluation board.
LThe ADSP-21161N EZ-KIT Lite installation is part of the Visu-
alDSP++ installation. The EZ-KIT Lite is a licensed product that
offers an unrestricted evaluation license for the first 90 days. For
details about evaluation license restrictions after the 90 days, refer
to “Evaluation License Restrictions” on page 1-7.
The board features:
• Analog Devices ADSP-21161N SHARC processor
D100 MHz core clock speed
DConfigurable core clock switch
• Analog Devices AD1836 96 kHz audio codec
DJumper selectable line-in or mic-in 3.5 mm stereo jack
DLine-out 3.5 mm stereo jack
DFour RCA jacks for audio input
DEight RCA jacks for audio output
• Analog Devices AD1852 192 kHz auxiliary digital-to-analog con-
verter (DAC)
www.BDTIC.com/ADI

ADSP-21161N EZ-KIT Lite Evaluation System Manual xiii
Preface
• Crystal Semiconductor CS8416 192 kHz Sony/Philips Digital
Interface Format (SPDIF) receiver
DOptical and coaxial connectors for SPDIF input
• Flash memory
D512K x 8-bits
• Synchronous dynamic random access memory (SDRAM)
D48 MB (8M x 48 bit)
• Interface connectors
D14-pin emulator connector for JTAG interface
DSPORT connectors
DLink port 0 and link port 1
DExternal port connectors (not populated)
• General-purpose IO
DFour push button flags
DThree push button interrupts
DSix LED outputs
• Analog Devices ADP1864, ADP3338 and ADP3339 voltage
regulators
The EZ-KIT Lite board has a flash memory device that can be used to
store user-specific boot code. By configuring the switch for EPROM boot,
the board can run as a stand-alone unit. The ADSP-21161N EZ-KIT Lite
package contains a flash programmer utility, which allows you to program
the flash memory. The “Flash Programmer Utility” is described
on page 1-13.
www.BDTIC.com/ADI

Purpose of This Manual
xiv ADSP-21161N EZ-KIT Lite Evaluation System Manual
SPORT0 and SPORT2 connect to the audio codec, facilitating creation of
audio-signal processing applications. SPORT1 and SPORT3 connect to
off-board connectors of other serial devices.
Additionally, the EZ-KIT Lite board provides un-installed expansion con-
nector footprints to connect to the processor’s external port (EP) and host
processor interface (HPI).
Purpose of This Manual
The ADSP-21161N EZ-KIT Lite Evaluation System Manual provides
instructions for installing the product hardware (board) and describes the
operation and configuration of the board components. The product soft-
ware component is detailed in the VisualDSP++ Installation Quick
Reference Card. The manual provides guidelines for running your own
code on the ADSP-21161N EZ-KIT Lite. Finally, a schematic and a bill
of materials are provided as a reference for future designs.
Intended Audience
The primary audience for this manual is a programmer who is familiar
with Analog Devices processors. This manual assumes that the audience
has a working knowledge of the appropriate processor architecture and
instruction set. Programmers who are unfamiliar with Analog Devices
processors can use this manual but should supplement it with other texts
(such as the ADSP-21161 SHARC Processor Hardware Reference and
ADSP-21160 SHARC Processor Instruction Set Reference) that describe your
target architecture.
Programmers who are unfamiliar with VisualDSP++ should refer to the
VisualDSP++ online Help and the VisualDSP++ user’s or getting started
guides. For the locations of these documents, see “Related Documents” on
page -xviii.
www.BDTIC.com/ADI

ADSP-21161N EZ-KIT Lite Evaluation System Manual xv
Preface
Manual Contents
The manual consists of:
• Chapter 1, “Using ADSP-21161N EZ-KIT Lite” on page 1-1
Provides information on the EZ-KIT Lite from a programmer’s
perspective and provides a simplified memory map.
• Chapter 2, “ADSP-21161N EZ-KIT Lite Hardware Reference” on
page 2-1
Provides information on the hardware aspects of the evaluation
system.
• Appendix A, “ADSP-21161N EZ-KIT Lite Bill Of Materials” on
page A-1
Provides a list of components used to manufacture the EZ-KIT
Lite board.
• Appendix B, “ADSP-21161N EZ-KIT Lite Schematic” on
page B-1
Provides the resources to allow EZ-KIT Lite board-level debugging
or to use as a reference design.
LAppendix B now is part of the online Help. The PDF version of
the ADSP-21161N EZ-KIT Lite Evaluation System Manual is
located in the Docs\EZ-KIT Lite Manuals folder on the installation
CD. Alternatively, the book can be found on the Analog Devices
Web site, www.analog.com/processors.
What’s New in This Manual
This edition of the ADSP-21161N EZ-KIT Lite Evaluation System Manual
documents the ADSP-21161N EZ-KIT Lite compliance with the RoHS
and WEEE directives.
www.BDTIC.com/ADI

Technical or Customer Support
xvi ADSP-21161N EZ-KIT Lite Evaluation System Manual
Technical or Customer Support
You can reach Analog Devices, Inc. Customer Support in the following
ways:
• Visit the Embedded Processing and DSP products Web site at
http://www.analog.com/processors/technicalSupport
• E-mail tools questions to
[e-mail]
• E-mail processor questions to
[email protected]m (World wide support)
[email protected] (Europe support)
[email protected] (China support)
• Phone questions to 1-800-ANALOGD
• Contact your Analog Devices, Inc. local sales office or authorized
distributor
• Send questions by mail to:
Analog Devices, Inc.
One Technology Way
P.O. Box 9106
Norwood, MA 02062-9106
USA
Supported Processors
This EZ-KIT Lite evaluation system supports Analog Devices
ADSP-21161N SHARC processors.
www.BDTIC.com/ADI

ADSP-21161N EZ-KIT Lite Evaluation System Manual xvii
Preface
Product Information
You can obtain product information from the Analog Devices Web site,
from the product CD-ROM, or from printed publications (manuals).
Analog Devices is online at www.analog.com. Our website provides infor-
mation about a broad range of products—analog integrated circuits,
amplifiers, converters, and digital signal processors.
MyAnalog.com
MyAnalog.com is a free feature of the Analog Devices Web site that allows
customization of a Web page to display only the latest information on
products you are interested in. You can also choose to receive weekly
e-mail notifications containing updates to the Web pages that meet your
interests. MyAnalog.com provides access to books, application notes, data
sheets, code examples, and more.
Registration:
Visit www.analog.com to sign up. Click Register to use MyAnalog.com.
Registration takes about five minutes and serves as means for you to select
the information you want to receive.
If you are already a registered user, just log on. Your user name is your
e-mail address.
Processor Product Information
For information on embedded processors and DSPs, visit our Web site at
www.analog.com/processors, which provides access to technical publica-
tions, data sheets, application notes, product overviews, and product
announcements.
www.BDTIC.com/ADI

Product Information
xviii ADSP-21161N EZ-KIT Lite Evaluation System Manual
You may also obtain additional information about Analog Devices and its
products in any of the following ways.
• E-mail questions or requests for information to
[email protected]m (World wide support)
[email protected] (Europe support)
[email protected] (China support)
• Fax questions or requests for information to
1-781-461-3010 (North America)
[phone] (Europe)
Related Documents
For information on product related development software, see the follow-
ing publications.
Table 1. Related Processor Publications
Title Description
ADSP-21161N DSP Data Sheet General functional description, pinout, and
timing
ADSP-21161 SHARC Processor Hardware Refer-
ence
Description of internal processor architecture,
registers, and all peripheral functions
ADSP-21160 SHARC Processor Instruction Set
Reference
Description of all allowed processor assembly
instructions
Table 2. Related VisualDSP++ Publications
Title Description
VisualDSP++ User’s Guide Description of VisualDSP++ features and usage
VisualDSP++ Assembler and Preprocessor Man-
ual
Description of the assembler function and
commands
VisualDSP++ C/C++ Complier and Library
Manual for SHARC Processors
Description of the complier function and com-
mands for SHARC processors
www.BDTIC.com/ADI

ADSP-21161N EZ-KIT Lite Evaluation System Manual xix
Preface
The listed documents can be found through online Help or in the Docs
folder of your VisualDSP++ installation. Most documents are available in
printed form.
LIf you plan to use the EZ-KIT Lite board in conjunction with a
JTAG emulator, also refer to the documentation that accompanies
the emulator.
All documentation is available online. Most documentation is available in
printed form.
Visit the Technical Library Web site to access all processor and tools man-
uals and data sheets:
http://www.analog.com/processors/technicalSupport/technicalLi-
brary/.
Online Technical Documentation
Online documentation comprises the VisualDSP++ Help system, software
tools manuals, hardware tools manuals, processor manuals, the Dinkum
Abridged C++ library, and Flexible License Manager (FlexLM) network
license manager software documentation. You can easily search across the
entire VisualDSP++ documentation set for any topic of interest. For easy
printing, supplementary .pdf files of most manuals are provided in the
Docs folder on the VisualDSP++ installation CD.
VisualDSP++ Linker and Utilities Manual Description of the linker function and com-
mands
VisualDSP++ Loader and Utilities Manual Description of the loader function and com-
mands
Table 2. Related VisualDSP++ Publications (Cont’d)
Title Description
www.BDTIC.com/ADI

Product Information
xx ADSP-21161N EZ-KIT Lite Evaluation System Manual
Each documentation file type is described as follows.
If documentation is not installed on your system as part of the software
installation, you can add it from the VisualDSP++ CD at any time by run-
ning the Tools installation. Access the online documentation from the
VisualDSP++ environment, Windows®Explorer, or the Analog Devices
Web site.
Accessing Documentation From VisualDSP++
To view VisualDSP++ Help, click on the Help menu item or go to the
Windows task bar and navigate to the VisualDSP++ documentation via
the Start menu.
To view ADSP-21161N EZ-KIT Lite Help, which is part of the Visu-
alDSP++ Help system, use the Contents or Search tab of the Help
window.
Accessing Documentation From Windows
In addition to any shortcuts you may have constructed, there are many
ways to open VisualDSP++ online Help or the supplementary documenta-
tion from Windows.
File Description
.chm Help system files and manuals in Help format
.htm or
.html
Dinkum Abridged C++ library and FlexLM network license manager software doc-
umentation. Viewing and printing the .html files requires a browser, such as
Internet Explorer 5.01 (or higher).
.pdf VisualDSP++ and processor manuals in Portable Documentation Format (PDF).
Viewing and printing the .pdf files requires a PDF reader, such as Adobe Acrobat
Reader (4.0 or higher).
www.BDTIC.com/ADI
