Antari AF-6 User manual

AF-6/AF-6R
Special Effects Fan
User Manual
- English
-中文
© 2023 Antari Lighting and Effects Ltd.

1. Introduction ................................................................................................................................................. 1
2. Safety Information....................................................................................................................................... 1
3. Package Contents & Inspection................................................................................................................... 2
4. Machine Details........................................................................................................................................... 3
5. Technical Label Information........................................................................................................................ 3
6. Setting and Manual Operation..................................................................................................................... 3
7. Control Settings ........................................................................................................................................... 3
8. Machine Status ............................................................................................................................................ 5
9. DMX Connection ........................................................................................................................................ 5
10. RDM Function............................................................................................................................................. 6
11. SC-2 Cable Remote (Optional).................................................................................................................... 7
12. WTR-20 Wireless Remote (Optional) ......................................................................................................... 7
13. Service and Maintenance............................................................................................................................. 8
14. Technical Specifications .............................................................................................................................. 9
15. Warranty Disclaimer.................................................................................................................................... 9
16. Machine Dimension..................................................................................................................................... 9
1. 前言........................................................................................................................................................... 10
2. 安全注意事項........................................................................................................................................... 10
3. 包裝內容與檢查........................................................................................................................................11
4. 機器訊息................................................................................................................................................... 12
5. 技術標籤資訊........................................................................................................................................... 12
6. 設定與手動操作說明............................................................................................................................... 12
7. 控制設定................................................................................................................................................... 12
8. 機器狀態說明........................................................................................................................................... 14
9. DMX 說明................................................................................................................................................. 14
10. RDM 說明................................................................................................................................................. 15
11. SC-2 有線控制器(選配)........................................................................................................................... 16
12. WTR-20 無線控制器(選配)..................................................................................................................... 16
13. 維護和保養............................................................................................................................................... 17
14. 技術規格................................................................................................................................................... 17
15. 保固聲明................................................................................................................................................... 18
16. 機器尺寸圖............................................................................................................................................... 18
Appendix I - Grounding Instruction .................................................................................................................. 19

1
User Manual
1. Introduction
Please read all the user manual before operating the machine, and place the manual where the user can refer to it at
all time. The manual includes how to install and operate the machine under safe condition and explain all the labels
printed on the machine. If you encounter any problem, contact your local Antari dealer for assistant immediately.
2. Safety Information
DANGER
If the danger is not avoided, it will cause death or serious injury
WARNING
If the warning is not heeded, it can cause death or serious injury.
CAUTION
If the precaution is not taken, it may cause minor or moderate injury.
DANGER
Must connect the machine to the correct rated voltage or it might lead to an electrical shock or a burn and may
cause serious consequences.
Must connect the machine to a protected circuit and ensure it is properly grounded to avoid the risk of
electrocution. For grounding instruction, please refer to Appendix I on page 19.
Do not operate the machine with a bundled power cord, it could lead to a fire hazard.
Do not use the fan in an environment full of flammable gas, susceptible to water or powder. Keep away from
any fire and heat sources.
When operating the machine, do not point at people, animals, or fire.
WARNING
Please operate the machine on a flat, level hard and well ventilated surface area, reserve at least 50cm space
around the machine and make sure there is no flammable gas or material nearby.
Do not disassemble, repair or modify the machine, it may cause damages, malfunction, risk of electrical shock
or result in fire.
The machine can only be operated by adults or professionals, is not intended for use by person with reduced
physical sensory, mental capabilities, or lack of experience and knowledge including children.
Do not leave the machine running unattended, make sure all powers are off when leaving.
Children should be supervised to ensure that they do not play with the machine.
Do not use the machine upside down or tilt it, it might cause damages or malfunction.
Never allow any object or part of your body to enter path of the fan blades to prevent any injury or damages
Do not spray the fan with any liquid including cleaner and insecticide to avoid injury or damages.
CAUTION
Keep the machine dry at all time. The machine is not waterproof, do not expose the machine to water, rain, or

2
moisture environment.
Please make sure the power outlet is not damaged or loose before plug in the power cord.
If the power cord is damaged, it must be replaced by Antari or its local dealers, otherwise the warranty will be
void.
The machine is for indoor use only.
Do not operate the machine in any area with unstable voltage.
If you experience strange sound or malfunction, turn off the power and unplug the power cord immediately
and contact your local Antari dealer for assistant.
Do not contact any moving part.
Only use accessories recommended or sold by Antari.
Please make sure the power is off when not using the machine and unplug the power cord if not intend to use
for a long period of time.
To disconnect, turn all controls to the off position, then remove plug from outlet.
Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
Unplug from outlet before servicing or cleaning.
Ensure that curtain, clothing, cables or other items cannot be suck into the fan.
Do not operate the machine with a damaged cord or plug, or after the machine malfunctions or is dropped or
damaged in any manner. Return machine to the nearest authorized service facility for examination, repair, or
electrical or mechanical adjustment.
After a period of operation, abnormal noise and uneven air volume may appear because of dust blocking
airflow. It will disappear after cleaning the air inlet and outlet.
Before operating the machine, please read all warning labels on the machine, description as below:
WARNING!
1. Disconnect power before changing fuse.
2. No user serviceable part inside.
3. Keep hands off. Do not put anything into the fan
4. Operate with fan only with adult supervision
3. Package Contents & Inspection
Immediately upon receiving the machine, carefully unpack the carton, check the content to ensure it is the correct
model and all parts are included. If any part appears to be damaged or missing during transportation, please contact
your local dealer and return with original package for inspection.
3.1 Package Contents
AF-6
AF-6R
1 x AF-6 Special Effects Fan
1 x AF-6R Special Effects Fan
1 x Neutrik powerCON Cable Connector
1 x WTR-20 Wireless Remote
1 x User Manual or Scan QR Code on the Machine
1 x Neutrik powerCON Cable Connector
1 x User Manual or Scan QR Code on the Machine
3.2 Optional Accessories
Item Code
Description
SC-2
Cable Remote
WTR-20
Wireless Remote (W-2 Transmitter and W-2 Receiver)

3
4. Machine Details
01. Fan Outlet
06. Wireless Connector
02. Power Switch
07. XLR 4-Pin Cable Remote Connector
03. AC Input Connector
08. Fan Inlet
04. XLR 5-Pin DMX
09. Handle
05. LCD Screen
10. Stand
5. Technical Label Information
Please read the technical label information on the back of the machine before operating it.
1. Model Name
5. Breaker/Fuse
2. Input Voltage
6. QR CODE for User Manual
3. Frequency
7. Serial No.
4. Rated Power
6. Setting and Manual Operation
Step 1. Place the machine on a flat, level hard and well ventilated surface area and reserve at least 50cm open
space around the machine, and make sure there is no flammable gas or material nearby;
Step 2. Plug the machine to the power outlet. Please read the technical label on the back of the machine and make
sure the power outlet has the correct rated voltage for the machine;
Step 3. Turn on the power, when the LCD displays “Ready”, now the machine is ready for operation;
Step 4. To start, press [VOLUME] button and you can adjust the fan speed by pressing [UP/DOWN], and to stop,
please press [STOP] button;
Step 5. To turn off the power, please make sure the machine is not operating. If you will not use the machine a
long period of time, please unplug the power cord.
7. Control Settings
AF-6/AF-6R Special Effects Fan can be operated in the following modes. The machine can only accept 1 type of
signal at a time. When using different control modes at the same time, the machine will work according to built-in
control priority:
Manual

4
Timer
DMX512
Wireless
Cable Remote
7.1 Control Panel Description
AF-6/AF-6R Special Effect Fan can be operated with the onboard digital control interface.
Button
Operating Method
Action
MENU
Press
Scroll through setting menu
TIMER
Press
Activate Timer function
VOLUME
Press
Activate Volume function
UP/DOWN
Press
Increase/Decrease Value
STOP
Press
Deactivate Timer/Volume function
& Confirm/Leave Setting Menu
7.2 Menu Options Description
Menu
Item
Description
Manual
Interval
Set 5s
Set interval time at timer mode from 5 to 999 seconds
Duration
Set 5s
Set duration time at timer mode from 5 to 999 seconds
Timer
Out XXX%
Set fan speed at timer mode from 1 to 100%
Volume
Out XXX%
Set fan speed at Volume mode from 1 to 100%
DMX
DMX512
Add: XXX
DMX-512 Address: 1-512
Setting
Wireless
On/Off
Wireless Remote: On / Off
W. Remote
Pair/Upair
Wireless Transmitter：Pair / Unpaired
Use ▲UP and ▼DOWN buttons to select Pair and Unpair
radio wireless remote
Quick
Start Off/On
Turn On or Off Quick Start mode
When it is turned on, once power up AF-6 fan, it will run last

5
setting.
Use ▲UP and ▼DOWN buttons to switch, and press
▓STOP/ENTER button to memorize settings.
KeySound
Set On/Off
Keypad Sound：On / Off
Turn On or Off the beep sound of pushing buttons
Use ▲UP and ▼DOWN buttons to switch, and press
▓STOP/ENTER button to memorize settings
Backlite
AlwaysOn/AutoOff
Screen Backlite: Always On /Auto Off
Use ▲UP and ▼DOWN buttons to switch, and press
▓STOP/ENTER button to memorize settings
Default
Proceed?
Reset to factory settings
Press ▓STOP button to reset AF-6 to Factory settings
UID 1ED8
06020001
To view RDM’s UID (Unique Identifier)
Run Time
0000000H
To view total how many minutes or hours this AF-6 has been
running
8. Machine Status
Screen
Description
AF-6 v1.0
Software Version
AC-120V 60Hz
Input Voltage
AF-6 Ready
Machine is ready to Operate
Remote Out XXX%
Cable remote operating (only shows when SC-2 is connected)
Volume Out XXX%
Running at volume mode
Interval XXX min
Running at timer mode, Interval time
Duration XXX min
Running at timer mode, Duration time
DMX-512 Add: XXX
Current DMX 512 channel
Wrong Voltage!
Wrong input voltage
AC Power Failure
AC Power Failure
9. DMX Connection
9.1 DMX Connector Pin Assignment
The machine has a XLR 5-Pin for DMX connection. The diagram below indicates pin assignment information.
Pin
Function
1
Ground
2
Data-
3
Data+
4
NA
5
NA
** There is a protection cap on DMX IN, please
remove it with your finger before operation.

6
9.2 DMX Setting
Channel
Mode
DMX Value Range
Function
1
Fan Speed
0 – 5
Off
6 – 255
Fan 1 – 100%
10. RDM Function
The AF-6/AF-6R Special Effect Fan is RDM enabled, allowing control system to configure, monitor and manage.
GET Allowed
SET Allowed
Category
類別
RDM Parameter ID’s (Slot 21-22)
Value
Required
Network
Management
網路管理
DISC_UNIQUE_BRANCH
0x0001
O
DISC_MUTE
0x0002
O
DISC_UN_MUTE
0x0003
O
O
RDM Information
RDM 資訊
QUEUED_MESSAGE
0x0020
O
SUPPORTED_PARAMETERS
0x0050
O
O
PARAMETER_DESCRIPTION
0x0051
O
O
Product Information
產品資訊
DEVICE_INFO
0x0060
O
O
PRODUCT_DETAIL_ID_LIST
0x0070
O
DEVICE_MODEL_DESCRIPTION
0x0080
O
MANUFACTURER_LABEL
0x0081
O
O
DEVICE_LABEL
0x0082
O
SOFTWARE_VERSION_LABEL
0x00C0
O
O
O
DMX512 Setup
DMX512 設定
DMX_PERSONALITY
0x00E0
O
DMX_PERSONALITY_DESCRIPTION
0x00E1
O
O
DMX_START_ADDRESS
0x00F0
O
O
SLOT_INFO
(0x0120)
O
SLOT_DESCRIPTION
(0x0121)
O
DEFAULT_SLOT_VALUE
(0x0122)
O
Sensors
感應器
SENSOR_DEFINITION
0x0200
O
O
SENSOR_VALUE
0x0201
O
DEVICE_HOURS
0x0400
O
O
O
Control
控制
IDENTIFY_DEVICE
0x1000
O

7
11. SC-2 Cable Remote (Optional)
SC-2 Cable Remote is an optional accessory for AF-6/AF-6R Special Effects Fan, please see instruction below;
1. Plug the timer cable remote to the connector on the back of the machine;
2. Press the RED switch to turn on the power of the remote (Red Indicator Light is on) and press the RED switch
again to turn off the power (Red Indicator Light is off);
3. Turn the rotary knob to active the machine and adjust output volume.
Note:
** You must turn on the power of the remote in order to use it.
** If you encounter any problem, please contact your local Antari dealer for assistant.
12. WTR-20 Wireless Remote (Optional)
WTR-20 Wireless Remote is an optional accessory for AF-6 Special Effects Fan, it included a W-2 wireless
transmitter and a W-2 wireless receiver. If you already purchased the wireless model, it’s ready to use. If you
purchase the WTR-20 Wireless Remote afterwards, please follow the instruction below. If you encounter any
problem, please contact your local Antari dealer for assistant.
12.1 W-2 Wireless Transmitter & Receiver
Battery：27A 12V
Effective Range：The effective range is approximately 50m,
depends on actual condition, it may vary.
W-2 wireless transmitter has 4 buttons, each function as follow:
W-2 Wireless Transmitter
Button
Function
[A]
Start
[B]
Stop
[C]
Increase Fan Speed
[D]
Decrease Fan Speed
W-2 Wireless Receiver
12.2 W-2 Wireless Receiver Installation
If you purchased the WTR-20 Wireless Remote afterwards, please follow the instructions below to install the
receiver. If you encounter any problem, please contact your local Antari dealer for assistant.

8
Graph 1
Graph 2
Graph 3
1. Please see graph 1, remove the cover from the pointed place;
2. You will see a white cable like graph 2, pull it out and connect to the W-2 wireless receiver;
3. Screw it back to the machine like graph 3 and follow the instruction on 12.3 for pairing.
12.3 Pair & Unpair
Each receiver can pair up to 5 transmitters, please follow the steps below to pair or unpair;
Step 1. Press [MENU] button and select [Setting], find Screw the menu until [W.Remote] shows on display;
Step 2. Press [UP] button to select [Pair] then press [STOP] button, and press any button on W-2 transmitter to
pair it;
Step 3. Please repeat Step 2 to pair multiple transmitters;
Step 4. To unpair, repeat Step 1 and press [DOWN].
13. Service and Maintenance
DANGER!
Disconnect the power cord before starting maintenance operation!
Always keep the machine clean.
Can use an air compressor, a vacuum or a soft brush to remove the dust on the machine.
Can use a slightly damp cloth to clean the casing.
Before store the machine, please make sure the machine is completely cool down to avoid moisture inside the
machine causing malfunction.
It is recommended to run the machine at least once a month in order to maintain its best performance and
output condition.
Excessive dust will reduce the performance and cause overheat.
Fuse Specification
120V=T2.0A 250V
240V=T1.0A 250V

9
14. Technical Specifications
AF-6/AF-6R
Rated Voltage
US Model : AC 100-120V, 50/60Hz 2.5A
EU Model : AC 220-240V, 50/60Hz 1.5A
Rated Power
250W
Ambient Temp. Range
0°C – 40°C (32°F – 104°F)
Air Flow
2583 CFM (AC 120V/60Hz)、2550 CFM (AC 240V/60Hz)
Fan Speed
1550 rpm (AC 120V/60Hz)、1530 rpm (AC 240V/60Hz)
Noise Level
81.5 dB (Max. Output)
Control Methods
Manual、Timer、DMX512、Wireless (Optional)、Cable Remote (Optional)
Interface
XLR 5-Pin (DMX)、Neutrik powerCon (Power)
DMX Channel
1 Channel
Included Accessories
N/A
Optional Accessories
SC-2 Cable Remote、WTR-20 Wireless Remote
Dimension
L 461 W 596 H 629 mm (L 18.20 W 23.50 H 24.80 inch)
Weight
22.30 kg (49.10 lbs.)
15. Warranty Disclaimer
We guarantee the merchandise manufactured by us to be free from defect in material and workmanship for a period
of one year. Our obligation and liability under this warranty shall be restricted to repair or replacement at our
factory or local authorized dealer. We assume no liability of the products that are improperly used or used for any
purpose other than that for which they are specially designed. This warranty shall not apply to any merchandise
which has been repaired, altered or assembled outside our factory in any way so as in our judgment to affect its
performance, nor which has been subjected to misuse, negligence, or accident nor to any merchandise operated
contrary to our printed instructions. We will not allow or be liable of any loss or any damages of any kind in
connection with the use, sale, or repair of any merchandise purchased from us.
16. Machine Dimension

10
中文使用說明書
1. 前言
在操作本機器之前，請務必仔細詳閱本說明書然後請將本說明書放置在機器使用者可隨時查閱之處存放。
此說明書包含如何安全的安裝及操作本機器以及說明所有在機器上的標示。如果您有任何操作上的問題，
請立即聯繫當地的 Antari 經銷商尋求協助。
2. 安全注意事項
危險
若不確實避免這些指示，可能導致嚴重人身傷害甚至死亡。
警告
若不確實遵循這些指示，可能導致嚴重人身傷害甚至死亡。
注意
若不確實注意這些指示，可能導致人身傷害甚至死亡，嚴重程度視情況而定。
危險
請務必使用正確電壓。如果使用錯誤電壓，可能會遭受危險的電擊燒傷或更嚴重的後果。
請務必將機器連結到有保護的電路，並確保有正確地接地，以避免觸電的危險。關於接地方式請參考
第19 頁附錄 I。
請勿在捆綁電源線的情況下使用，可能會發熱導致火災。
禁止在有易燃氣體、易被水淋、粉塵較多的地方使用風扇。請遠離火源及熱源。
操作機器時請 勿 將 機 器 對 著 人 體 、動物或火 焰使用。
警告
請於堅固、平坦、穩定且通風良好的表面上使用機器。請勿遮蓋機器散熱部份，機器周邊至少應保留
公分的空間並確認附近沒有易燃性物質或可揮發性氣體。
請勿隨意拆卸、修理或改造機器，這可能會導致機器故障、損壞、觸電危險或造成火災。
本機器僅限有行為能力之成人或專業人員操作，不預期提供生理、感知、心智能力、經驗或知識不足
者之使用者(包含孩童)使用本機器。
請勿在無人看管時讓機器運作，並 於 外 出 離 去 時 確 實關閉 電 源 。
孩童應受監督，以確保孩童不能操作或嬉戲玩本機器。
請勿將機器倒放或傾斜使用，可能導致機器動作不正常或損壞。
禁止將其他物體或身體部位插入前後網內，避免受傷或損壞。
請勿將任何液體包含清潔劑與殺蟲劑等，噴向風扇避免受傷或損壞。
注意
本機器無防水設計，請隨時保持機器乾燥、嚴禁將其潑水、浸水、淋雨或放在潮溼的環境。

11
在插 入 電 源 插 座前 ，請確認電 源 插 座無損壞或鬆動。
若電源線損壞，必須使用原廠電源線或組件進行更換，否則將導致保固無效。
本產品僅限室內使用。
請勿在電壓不穩定的地區使用本機器。
如果機器出現異常聲音或有任何不正常現象時，請立即停止工作，將電源關閉及拔下機器電源線，並
請聯繫當地的 Antari 經銷商尋求協助。
請勿觸碰機器內部運轉零件。
只能使用原廠建議或販售之配件。
請確認機器不在使用的狀態下電源已關。如果長時間不使用機器，請拔掉電源線。
關閉機器時，將所以控制開關轉到關閉的位置，然後再將插頭從插座拔除。
拔除電源線時，請抓住插頭不是電線。
應遠離窗簾、衣物、電線或其他異物，避免被風扇葉片捲入。
在保養及清潔前，請把電源線從插座拔除。
在電線或插座有損毀、機器故障或有掉落或損壞的情形發生時，請勿操作機器。請將機器送回最近的
維修站，做檢查、維修及電源或機械的調整。
使用一段時間後，因為灰塵阻擋空氣流動，有可能會產生異音或不均勻風量。在清潔過後就會恢復正
常。
在使用本機之前，請詳細閱讀機器上的警語標示，說明如下：
WARNING! 警告!
1. Disconnect power before changing fuse. 更換保險絲前請務必斷開電源
2. No user serviceable part inside. 內部無使用者需維修之零配件
3. Keep hands off. Do not put anything into the fan. 請勿觸摸風扇葉片 請勿放任何東西到風扇中
4. Operate with fan only with adult supervision 僅在成人監督下使用風扇
3. 包裝內容與檢查
在收到機器後，請立即小心地打開包裝紙箱，檢查所有內容，確認您所購買的機型及配件。如果有任何部
件因運輸過程出現損壞或缺少，請立即連絡經銷商，並以原包裝退回檢查。
3.1 包裝內容
AF-6
AF-6R
1 x AF-6 特效風扇
1 x AF-6R 特效風扇
1 x Neutrik powerCon 電源線
1 x WTR-20 無線控制器
1 x 說明書或掃描機身 QR Code
1 x Neutrik powerCon 電源線
1 x 說明書或掃描機身 QR Code
3.2 選配說明
品項
描述
SC-2
有線控制器
WTR-20
無線控制器 (W-2 無線發射器/W-2 無線接收器)

12
4. 機器訊息
01. 出風口
06. 無線控制器連接頭
02. 電源開關
07. XLR 4-Pin 有線控制器連接頭
03. 電源線連接頭
08. 入風口
04. XLR 5-Pin DMX 連接頭
09. 把手
05. 液晶螢幕
10. 底座
5. 技術標籤資訊
使用本機器前，請詳閱位於機器後方的技術標籤訊息。
1. 機器型號
5. 斷路器/保險絲
2. 工作電壓
6. 說明書 QR CODE
3. 頻率
7. 機器流水序號
4. 瓦特數
6. 設定與手動操作說明
步驟1. 將機器平放在堅固、平坦、穩定且通風良好的表面上，機器周圍至少應保留 50 公分的空間並確
認附近沒有易燃性物質或可揮發性氣體;
步驟2. 將機器連接電源插座，連接之前，確認機器背後技術標籤上所標示要求功率，是否與電源插座
相符;
步驟3. 啟動機器電源後，當液晶螢幕顯示”Ready”，代表機器可以進行操作;
步驟4. 欲啟動風扇，按下[VOLUME]鍵，然後可以按下[UP/DOWN]鍵調整風扇速度；欲停止風扇，按
下[STOP];
步驟5. 需關閉機器時，請確認機器已停止運轉，再將電源關閉即可，長時間不使用時請拔除電源線。
7. 控制設定
AF-6/AF-6R 特效風扇可以使用下列操作模式，機器每次接受一種訊號。當同時間使用多種訊號時機器將

13
根據原廠內建訊號的優先順序來進行工作;
手動控制
定時控制
DMX512
無線控制
有線控制
7.1 控制面板說明
AF-6/AF-6R 特效風扇可以使用機器上的數位控制面板來操作。
按鍵
操作方式
功能
MENU
按
瀏覽清單
TIME
按
啟動定時模式
VOLUME
按
啟動輸出量模式
UP/DOWN
按
增加/減少數值
STOP
按
關閉定時/輸出量模式，確認/離
開設定清單
7.2 選單說明
選項
功能簡述
Interval
Set 5s
定時模式下，風扇運轉的間隔時間：5 至 999 秒。
Duration
Set 5s
定時模式下，風扇運轉的啓動時間：5 至 999 秒。
Timer
Out XXX%
定時模式下，風扇輸出量：1至100%。
Volume
Out XXX%
風量調整：1至100%。
DMX512
Add: XXX
DMX-512 位址: 1-512
Wireless
On/Off
無線控制: 開啟/關閉
W. Remote
Pair/Upair
無線遙控器：Pair 配對 / Unpaired 取消配對
點選▲UP 和 ▼DOWN 按鍵來選擇，並按▓STOP 完成設定。

14
Quick Start
Off/On
記憶模式：開啟 / 關閉 (接續斷電前的動作)
點選▲UP 和 ▼DOWN 按鍵來選擇，並按▓STOP 完成設定。
KeySound
Set On/Off
按鍵音：On 開啟 / Off 關閉
點選▲UP 和 ▼DOWN 按鍵來選擇，並按▓STOP 完成設定。
Backlite
AlwaysOn/AutoOff
LCD 背光：AlwaysOn 常亮/ Auto Off 自動關閉
點選▲UP 和 ▼DOWN 按鍵來選擇，並按▓STOP 完成設定。
Default
Proceed?
恢復原廠設置
按 ▓STOP 鍵恢復原廠設置
UID 1ED8
06020001
產品 UID 碼
Run Time
0000000H
AF-6 機累計運轉時間：0 - 9999999 小時
8. 機器狀態說明
面板畫面
說明
AF-6 v1.0
程式版本
AC-120V 60Hz
使用電壓
AF-6 Ready
AF-6 機台準備就緒
Remote Out XXX%
有線控器控制中 (插上有線控器 SC-2 時才會顯示此頁面)
Volume Out XXX%
手動啓動，風扇運轉中
Interval XXX Sec
定時功能執行中_風扇停止 (間隔時間計數中)
Duration XXX Sec
定時功能執行中_風扇運轉 (持續時間計數中)
DMX-512 Add: XXX
DMX 連接中， 顯示目前通道位址
Wrong Voltage!
電源電壓輸入錯誤 (插錯電)
AC Power Failure
AC 電源異常
9. DMX 說明
9.1 DMX 說明
本機器提供一個 XRL 5-Pin 的DMX 連接頭。PIN 的接點說明如下：
Pin
功能
1
接地
2
數據-
3
數據+
4
N/A
5
N/A
**DMX IN 連接頭上有一個保護蓋，操作前，請
用手指撥開即可將其取下。

15
9.2 DMX 通道功能
通道
通道模式
DMX 數值範圍
功能
1
風量調整
0 – 5
Off
6 – 255
Fan 20 – 100%
10. RDM 說明
AF-6/AF-6R 特效風扇配有 RDM 功能，讓使用者可以經由 DMX 網路使用 RDM 功能進行機台的設定、監
控、管理。
GET Allowed
SET Allowed
Category
類別
RDM Parameter ID’s (Slot 21-22)
Value
Required
Network
Management
網路管理
DISC_UNIQUE_BRANCH
0x0001
O
DISC_MUTE
0x0002
O
DISC_UN_MUTE
0x0003
O
O
RDM Information
RDM 資訊
QUEUED_MESSAGE
0x0020
O
SUPPORTED_PARAMETERS
0x0050
O
O
PARAMETER_DESCRIPTION
0x0051
O
O
Product Information
產品資訊
DEVICE_INFO
0x0060
O
O
PRODUCT_DETAIL_ID_LIST
0x0070
O
DEVICE_MODEL_DESCRIPTION
0x0080
O
MANUFACTURER_LABEL
0x0081
O
O
DEVICE_LABEL
0x0082
O
SOFTWARE_VERSION_LABEL
0x00C0
O
O
O
DMX512 Setup
DMX512 設定
DMX_PERSONALITY
0x00E0
O
DMX_PERSONALITY_DESCRIPTION
0x00E1
O
O
DMX_START_ADDRESS
0x00F0
O
O
SLOT_INFO
(0x0120)
O
SLOT_DESCRIPTION
(0x0121)
O
DEFAULT_SLOT_VALUE
(0x0122)
O
Sensors
感應器
SENSOR_DEFINITION
0x0200
O
O
SENSOR_VALUE
0x0201
O
DEVICE_HOURS
0x0400
O

16
O
O
Control
控制
IDENTIFY_DEVICE
0x1000
O
11. SC-2 有線控制器(選配)
SC-2 有線控制器是 AF-6/AF-6R 特效風扇的選購配件，使用方法如下;
1. 將有線定時控制器插入機器後方的接頭;
2. 按下紅色按鈕開啟電源(紅色指示燈亮起); 如欲關閉控制器電源請再次按下紅色按鍵(紅色指示燈熄滅);
3. 旋轉旋鈕啟動機器並調整輸出量;
注意:
**務必開啟控制器電源才能使用。
**如果有任何問題，請聯繫當地的 Antari 經銷商尋求協助。
12. WTR-20 無線控制器(選配)
WTR-20 無線控制器組包含一個 W-2 無線發射器及 W-2 無線接收器，此為 AF-6 特效風扇的選購配件。若
您採購的版本已含無線功能即已安裝至機器上，可直接使用。若是後續採購 WTR-20 無線控制器，請按照
下方說明進行安裝與配對。如果遇到任何困難與問題，請與當地的 Antari 經銷商尋求協助。
12.1 W-2 無線發射器/接收器說明
發射器：使用 27A 12V 電池
收發距離：有效距離為 50 公尺，實際收訊狀況根據現場環
境因素而有所不同。
W-2 無線發射器配有 4個按鈕，控制功能為：
W-2 無線發射器
按鈕
功能
[A] 鍵
啓動風扇
[B] 鍵
停止風扇
[C] 鍵
增加風扇速度
[D] 鍵
減少風扇速度
W-2 無線接收器

17
12.2 W-2 接收器安裝說明
如果是後續採購 WTR-20 無線控制器，請按照下方說明進行安裝與配對。如果遇到任何困難與問題，請與
當地的 Antari 經銷商尋求協助。
圖 1
圖2
圖3
1. 請看圖一，取下蓋子;
2. 請看圖二，取下後，你會看到一條白色的線，請拉出來接在 W-2 無線接收器上;
3. 請看圖三，將接收器鎖回去原本的地方，然後按照 12.3 的步驟開始配對。
12.3 配對 & 取消配對
每個接收器可以配對最多五個發射器，請參考下列步驟進行配對與取消配對。
步驟 1：按[MENU]鍵進入選單[Setting]，選擇[W.Remote]無線控制配對設定畫面(如下);
步驟 2：按 [UP ]按鍵選擇[Pair]，按[STOP]鍵後，再按下 W-2 無線發射器上的任何按鍵來完成配對;
步驟 3：如果要配對多個無線發射器，然後重複步驟 2即可;
步驟 4：欲解除配對，重複步驟 1，按 [DOWN /箭頭向下]按鍵，選擇[Unpair]按鍵解除配對。
13. 維護和保養
危險!
維修保養之前，請務必拔除電源線！
隨時保持機器清潔。
可以使用空氣壓縮機、吸塵器或軟刷除去機器上的灰塵。
機殼可使用濕布擦拭。
建議每月至少讓機器運轉一次，以保持機器處於最佳的性能和輸出條件。
機器上過多的灰塵會降低機器工作性能，導致散熱不良。
14. 技術規格
AF-6/AF-6R
額定電壓
美規 : AC 100-120V, 50/60Hz 2.5A
歐規 : AC 220-240V, 50/60Hz 1.5A
額定功率
250 瓦
適用環境溫度
0°C – 40°C (32°F – 104°F)
風量
2583 立方英尺/分(AC 120V/60 赫茲)、2550 立方英尺/分(AC 240V/60 赫茲)
風扇速度
1550 轉(AC 120V/60 赫茲)、1530 轉(AC 240V/60 赫茲)
噪音值
81.5 分貝(最大輸出)
控制方式
手動控制、定時控制、DMX512、無線控制(選配) 、有線控制(選配)
DMX 頻道
1個頻道
連接座
XLR 5-PIN (DMX)、Neutrik powerCon (主電源)
隨附配件
無

18
選購配件
SC-2 有線控制器、WTR-20 無線控制器
尺寸
長 461 寬 596 高 629 公釐 (長 18.20 寬23.50 高 24.80 英寸)
重量
22.3 公斤 (49.10 磅)
15. 保固聲明
本公司保證我們的商品在一年內沒有材料和製作缺陷。我們在本保證下的義務和責任僅限於在原廠或當地
授權經銷商進行的維修或更換。我們對不當使用或用於非專門設計目的以外之用途不承擔任何責任。本保
固不適用於以任何方式在原廠或當地授權經銷商外修理、改動或組裝的任何商品，以便我們判斷影響其性
能，沒有受到誤用、疏忽或事故的影響，也沒有違反我們的任何商品操作印刷說明。本公司對於從我們這
邊購買的商品不會允許也不對於使用、銷售或修理任何產品有關的任何類型的任何損失或損害承擔責任。
16. 機器尺寸圖
