Antari F-7X User manual

F-7X
Smaze Machine
User Manual
- English
-
中文
© 2024 Antari Lighting and Effects Ltd.

1. Introduction .................................................................................................................................................. 1
2. Safety Information ........................................................................................................................................ 1
3. Package Contents & Inspection .................................................................................................................... 2
4. Machine Details ............................................................................................................................................ 3
5. Technical Label Information ........................................................................................................................ 3
6. Fog Fluid ...................................................................................................................................................... 3
7. Setting and Manual Operation ...................................................................................................................... 4
8. Control Settings ............................................................................................................................................ 4
9. Machine Status Description .......................................................................................................................... 5
10. DMX Connection ......................................................................................................................................... 6
11. RDM Function .............................................................................................................................................. 6
12. ES-W-DMX Wireless DMX Receiver (Optional) ........................................................................................ 7
13. WTR-110 Wireless Remote (Optional) ........................................................................................................ 8
14. Service and Maintenance .............................................................................................................................. 9
15. Technical Specifications ............................................................................................................................... 9
16. Warranty Disclaimer ................................................................................................................................... 10
17. Machine Dimension .................................................................................................................................... 10
1. 前言 ............................................................................................................................................................ 11
2. 安全注意事項 ............................................................................................................................................ 11
3. 包裝內容與檢查 ........................................................................................................................................ 12
4. 機器訊息 .................................................................................................................................................... 13
5. 技術標籤資訊 ............................................................................................................................................ 13
6. 煙霧水 ........................................................................................................................................................ 13
7. 設定與手動操作說明 ................................................................................................................................ 14
8. 控制設定 .................................................................................................................................................... 14
9. 機器狀態 .................................................................................................................................................... 15
10. DMX 說明 .................................................................................................................................................. 16
11. RDM 功能 .................................................................................................................................................. 16
12. ES-W-DMX 無線 DMX 接收器(選配) ..................................................................................................... 17
13. WTR-110 無線控制器(選配) .................................................................................................................... 18
14. 維護和保養 ................................................................................................................................................ 19
15. 技術規格 .................................................................................................................................................... 20
16. 機器尺寸圖 ................................................................................................................................................ 20
17. 保固聲明 .................................................................................................................................................... 20
Appendix I – Grounding Instruction .................................................................................................................. 21

1
User Manual
1. Introduction
Please read all the user manual before operating the machine, and place the manual where the user can refer to it at
all time. The manual includes how to install and operate the machine under safe condition and explain all the labels
printed on the machine. If you encounter any problem, contact your local Antari dealer for assistant immediately.
2. Safety Information
DANGER
If the danger is not avoided, it will cause death or serious injury
WA R N I N G
If the warning is not heeded, it can cause death or serious injury.
CAUTION
If the precaution is not taken, it may cause minor or moderate injury.
DANGER
l Must connect the machine to the correct rated voltage or it might lead to an electrical shock or a burn and may
cause serious consequences.
l Must connect the machine to a protected circuit and ensure it is properly grounded to avoid the risk of
electrocution. For grounding instruction, please refer to Appendix I on page 21.
l Do not operate the machine with a bundled power cord, it could lead to a fire hazard.
l When operating the machine, do not point at people, animals, or fire.
WA R N I N G
l Machine’s nozzle is extremely hot, please keep at least 50cm distance from the nozzle when the machine is
running.
l Please operate the machine on a flat, level hard and well ventilated surface area, reserve at least 50cm space
around the machine and make sure there is no flammable gas or material nearby.
l Do not disassemble, repair or modify the machine, it may cause damages, malfunction, risk of electrical shock
or result in fire.
l The machine can only be operated by adults or professionals, is not intended for use by person with reduced
physical sensory, mental capabilities, or lack of experience and knowledge including children.
l Do not leave the machine running unattended, make sure all powers are off when leaving.
l Children should be supervised to ensure that they do not play with the machine.
l Do not use the machine upside down or tilt it, it might cause damages or malfunction.
l Please store the fluid inside in a well ventilated area without direct sunlight and keep out of reach of children.
In case of eye contact or accidentally swallow the fluid, please seek medical attention immediately.
CAUTION
l Keep the machine dry at all time. The machine is not waterproof, do not expose the machine to water, rain, or
moisture environment.
l Please make sure the power outlet is not damaged or loose before plug in the power cord.
l If the power cord is damaged, it must be replaced by Antari or its local dealers, otherwise the warranty will be

2
void.
l Before operating the machine, please make sure the fluid is filled in the fluid tank to avoid the pump in idling
state which could lead to overheat or malfunction.
l Before transporting the machine, please make sure the fluid is drained and tank is empty. (Recommend using
original package)
l The machine is for indoor use only.
l Do not operate the machine in any area with unstable voltage.
l If you experience strange sound or malfunction, turn off the power and unplug the power cord immediately
and contact your local Antari dealer for assistant.
l Do not contact any moving part.
l Only use accessories recommended or sold by Antari.
l Please make sure the power is off when not using the machine and unplug the power cord if not intend to use
for a long period of time.
l To disconnect, turn all controls to the off position, then remove plug from outlet.
l Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
l Unplug from outlet before servicing or cleaning.
l Do not operate the machine with a damaged cord or plug, or after the machine malfunctions or is dropped or
damaged in any manner. Return machine to the nearest authorized service facility for examination, repair, or
electrical or mechanical adjustment.
l To ensure the lifespan of the machine, please only use the fluid manufactured by Antari, do not use other fluid
or additive, otherwise it may clog the heater and cause malfunction.
Before operating the machine, please read all warning labels on the machine, description as below;
CAUTION!
ONLY USE MANUFACTUREER DESIGNATED FLUID
NEVER ADD FLAMMABLE SUBSTANCES.
WA R N I N G !
DISCONNECT POWER BEFORE CHANGING FUSE.
USE ONLY WITH ADULT SUPERVISION.
DO NOT OPERATE WITHOUT LIQUID.
FOR INDOOR USE ONLY. KEEP DRY.
NO USER SERVICEABLE PARTS INSIDE.
3. Package Contents & Inspection
Immediately upon receiving the machine, carefully unpack the carton, check the content to ensure it is the correct
model and all parts are included. If any part appears to be damaged or missing during transportation, please contact
your local dealer and return in original package for inspection.
3.1 Package Contents
1 x F-7X Smaze Machine
2 x 5 Liter Fluid Tank
2 x Neutrik powerCON Power Cable
1 x User Manual or Scan QR Code on the Machine
3.2 Optional Accessories
Item Code
Description
ES-W-DMX
W-DMX Receiver
WTR-110
Wireless Remote (W-2 Wireless Transmitter/ Wireless Receiver)

3
4. Machine Details
01. Fan
06. Fuse
02. Nozzle
07. Neutrik powerCON Connector (Power)
03. Flight Case
08. TFT-LCD Touch Panel
04. Wireless/W-DMX Receiver (Optional)
09. Two in One Power & Breaker Switch
05. XLR 3-Pin/5-Pin Connector (DMX)
10. 5 Liter Fluid Tank
5. Technical Label Information
Please read the technical label information on the back of the machine before operating it.
1. Model Name
5. Breaker/Fuse
2. Input Vo l t a g e
6. QR CODE for User Manual
3. Frequency
7. Serial No.
4. Rated Power
6. Fog Fluid
CAUTION
Always turn off the power before filling the fluid tank. Do not add flammable
liquid to the fluid tank. If fluid gets inside the machine, please contact your local
Antari dealer for assistant.
l Only the fog fluid manufactured by Antari can be used, do not mix or dilute the fog fluid. Due to improper
storage or using other fluid might clog the heater and cause malfunction.
l The machine is tested and calibrated with the specific fog fluid to get the best performance.
l Please empty the fluid in the tank before switching to another fluid to avoid mixing.
l Only the essence manufactured by Antari can be used, and add according to the ratio recommended by Antari

4
(Recommended ratio is 1:1000), if using other essence or different ratio might clog the heater and cause
malfunction.
l The warranty on your fog machine will be void if you use fog fluid not manufacture by Antari.
7. Setting and Manual Operation
WA R N I N G
Machine falling off might cause serious injury, please make sure it is secure
and firm on the overhead.
Step 1. Place the machine on a flat, level hard and well ventilated surface area and reserve at least 50cm open
space around the machine, and make sure there is no flammable gas or material nearby;
Step 2. Fill the fluid tank with Antari approved fog liquid, and make sure the tube is not twisted;
Step 3. Connect the machine to the power outlet. Please read the technical label on the back of the machine and
make sure the power outlet is the correspond to the rated voltage for the machine;
Step 4. Turn on the machine, heating process takes approximately 8 minutes. Once the machine has reached
operating temperature “100%” (Top Left Hand Corner), the machine is ready for operation;
Step 5. To activate fogging in manual mode, please press “Manual” and adjust output and fan speed according to
your need then press start and press again to stop fogging;
Step 6. Or to activate fogging in Timer mode, please press “Timer” and adjust “Interval”; “Duration”; “Output”
and “Fan Speed” according to your need, then press start and press again to stop fogging;
Step 7. Press “DMX” and adjust according to your need;
Step 8. Press “MENU” and adjust according to your need;
Step 9. To turn off the machine, please make sure the machine is not operating then turn of the power. If you will
not use the machine a long period of time, please remove the power cord.
8. Control Settings
F-7X Smaze Machine can be operated in the following modes. The machine can only accept 1 type of signal at a
time.
l Manual
l Timer
l DMX512
l W-DMX
l Wireless
8.1 Control Panel Description
F-7X Smaze Machine can be operated with the onboard TFT-LCD Touch Screen.
Icon
Operating Method
Action
Press
Confirmed Selection

5
Icon
Operating Method
Action
Press
Adjust Values
Press
Back to Last Page
Press
Active
Press
De-Active
Press
Enter Configuration
(Green Background Color)
N/A
Selected Mode in Action
8.2 Control Menu
Main Menu
Item
Description
Timer
Interval
1 – 300 sec
Duration
1 – 300 sec
Fog Output Level
20 – 100%
Faze Output Level
1 – 100%
Fan Level
20 – 100% or Off
Manual
Fog Output Level
20 – 100% or Continuous Output
Faze Output Level
1 – 100%
Fan Level
20 – 100% or Off
DMX
Address
001-510
Channel Mode
3 Channels
W-DMX Power
On/Off
W-DMX Reset
Unpair
Menu
Information
Software Version
Setting
Operation Mode
Fog/Faze
Fan Level
20 – 100% or Off
Fluid Selection
FLG/FLH/FLZ
Fluid Sensor
On/Off
WRC Pairing
Pair/Unpair
Quick Start
On/Off
Language
English/中文/日本語
LCD Backlight
High/Normal/Low/Auto Off
Self Clean Mode
Count 180 sec
9. Machine Status Description
9.1 Machine Status with TFT-LCD Touch Screen Display
Screen
Description
Antari F-7X Smaze
Ready To Fog
Machine is ready to Operate (Top Left Corner show 100% On The Screen)
W-DMX Status (Top Right Hand Corner On the Display, please see
12.3 for more details)
Wireless Signal
Fog Output 100%
Fog Output level 20 – 100%
Faze Output 100%
Faze Output Level 1 – 100%
Fan Speed
Fan Speed 20 – 100% or Off
Interval 1 - 300 sec
Duration 1 - 300 sec
Running at Timer mode, Interval time
Running at Timer mode, Duration time
DMX-512 Add: XXX
Current DMX 512 channel
Self-Cleaning Mode
Count Down 180 sec and Machine in Sleep Mode (When DMX Disconnect)

6
Screen
Description
Warming Up
Heating up 0-100% (Upper Left Corner)
Heater Overheat!
Heater is Overheat
Heater Fault
Heater Malfunction
Thermal Line Off
Thermal Line Break Off
Line Reverse
Thermal Line Reverse Connection
Voltage Error
Incorrect Voltage
**If LCD control panel display “Warning”, please stop operating and turn off the machine immediately. Please
contact your local Antari dealer for assistance.
10. DMX Connection
10.1 DMX Connector Pin Assignment
The machine provides a XLR 3-Pin/5-Pin connector for DMX connection. The diagram below indicates pin
assignment information;
Pin
Function
1
Ground
2
Data-
3
Data+
4
N/A
5
N/A
** There is a protection cap on DMX IN, please
remove it with your finger before operation.
10.2 DMX Channel Function
This machine provides 3 channel DMX, please see chart below.
Channel Mode
DMX Value Range
Function
Channel 1
0 - 127
Faze Mode
128 - 255
Fog Mode
Channel 2
0 - 5
Output Off
6 - 255
Fog Output 20 – 100%
Faze Output 1 – 100%
Channel 3
0 - 5
Fan Off
6 - 255
Fan Speed 20 - 100%
11. RDM Function
The F-7X Smaze Machine is RDM enabled, allowing control system to configure, monitor and manage. See below
table for supported RDM parameters.
GET
Allowed
SET
Allowed
Category
RDM Parameter ID’s(Slot 21-22)
Val u e
Required
NetworkManagement
網路管理
DISC_UNIQUE_BRANCH
0x0001
O
0x0002
O
0x0003
O
O
RDM Information
RDM 資訊
QUEUED_MESSAGE
0x0020
O
STATUS_MESSAGES
0x0030
O
SUPPORTED_PARAMETERS
0x0050
O
O
PAPAMETER_DESCRIPTI ON
0x0051
O
O
Product Information
DEVICE_INFO
0x0060
O

7
GET
Allowed
SET
Allowed
Category
RDM Parameter ID’s(Slot 21-22)
Val u e
Required
O
產品資訊
PRODUCT_DETAIL_ID_LIST
0x0070
O
DEVICE_MODE_DESCRIPTION
0x0080
O
MANUFACTURER_LABEL
0x0081
O
O
DEVICE_LABEL
0x0082
O
SOFTWARE_VERSION_LABEL
0x00C0
O
O
O
DMX512 Setup
DMX512 設定
DMX_PERSONALITY
0x00E0
O
DMX_PERSONALITY_DESCRIPTION
0x00E1
O
O
DMX_START_ADDRESS
0x00F0
O
O
SLOT_INFO
(0x0120)
O
SLOT_DESCRIPTION
(0x0121)
O
DEFAULT_SLOT_VALUE
(0x0122)
O
Sensors
感應器
SENSOR_DEFINITION
0x020
O
O
SENSOR_VALUE
0x0201
O
Control
控制
DEVICE_HOURS
0x0400
O
O
IDENTIFY_DEVICE
0x1000
O
O
O
POWER_STATE
0x1010
12. ES-W-DMX Wireless DMX Receiver (Optional)
ES-W-DMX is an optional accessory for F-7X Smaze Machines. If you already purchased the W-DMX model, it’s
ready to use. If you purchase it afterwards, please follow the instruction below. If you encounter any problem,
please contact your local Antari dealer for assistant. The W-DMX Control supports both CRMX and W-DMX
protocols
12.1 ES-W-DMX
It includes a Wireless DMX Receiver.
12.2 ES-W-DMX Receiver Installation Steps
If you purchased the W-DMX Receiver afterward, please follow the instruction below to install the receiver. If you
encounter any problem, please contact your local Antari dealer for assistant.
Graph 1
Graph 2
Graph 3
1. Please see graph 1, remove the cover from the pointed place;
2. You w ill see a w h ite cab l e l i ke g rap h 2, pul l it out and con n ect to r ece i ver ;

8
3. Screw it back to the machine like graph 3, then it’s ready to use.
12.3 Status of W-DMX Signal
To Activate the function, please follow the instruction below,
1. Enter DMX Setting Menu
2. Find [W-DMX Power] and activate it, then you will see on the screen.
Signal on LCD display
W-DMX Status
○
(Green)
W-DMX present
◎
No DMX present
☉
Link to TX lost
● (Red)
Not assigned
13. WTR-110 Wireless Remote (Optional)
WTR-110 Wireless Remote is an optional accessory for F-7X Smaze Machines, it included a W-2 wireless
transmitter and a wireless receiver. If you already purchased the wireless model, it’s ready to use. If you purchase
the module afterward, please follow the instruction below. If you encounter any problem, please contact your local
Antari dealer for assistant.
13.1 Wireless Transmitter & Receiver
l Battery：27A 12V
l Effective Range：The effective range is approximately 50 meter,
depends on actual condition, it may vary.
l W-2 wireless transmitter has 4 buttons, each function as follow:
W-2 Wireless Transmitter
Button
Function
[A]
Start Fogging
[B]
Stop Fogging
[C]
Increase fog output
[D]
Decrease fog output
Wireless Receiver
13.2 Wireless Receiver Installation
If you purchased the WTR-110 Wireless Remote afterward, please follow the instructions below to install the
receiver. If you encounter any problem, please contact your local Antari dealer for assistant.
Graph 1
Graph 2
Graph 3
1. Please see graph 1, remove the cover from the pointed place;
2. You w ill see a w h ite cab l e l i ke g rap h 2, pul l it out and con n ect to t he W-2 receiver;
3. Screw it back to the machine like graph 3 and follow the instruction on 13.3 for pairing.

9
13.3 Pair & Unpair
Each wireless receiver can pair up to 5 transmitters, please follow the steps below to pair or unpair the module;
Step 1. Machine need to be in READY status in order to pair with transmitter;
Step 2. Press [MENU] to enter options;
Step 3. Press arrow and find [WRC Pairing];
Step 4. Press [Pair] then press [A] button on the transmitter to pair;
Step 5. Press [Unpair] to unpair and the machine will restart when it’s successful.
14. Service and Maintenance
DANGER
Disconnect the power cord before starting maintenance operation!
l Always keep the machine clean.
l Can use air compressor, vacuum or a soft brush to remove the dust on the machine.
l Can use a slightly damp cloth to clean the casing.
l Before store the machine, please make sure the machine is completely cool down to avoid moisture inside
causing malfunction.
l It is recommended to run the machine at least once a month in order to maintain the machine’s best
performance and output condition.
l Excessive dust and build up liquid residue will reduce the performance and cause overheat.
14.1 Breaker Reset (2 in 1 Power Switch)
The 2 in 1 power switch combines power and breaker function.
Please follow below steps to reset the breaker;
Step 1: Please switch to the OFF position;
Step 2: Wait 60 seconds;
Step 3: Flip switch to ON position.
**If the breaker (switch) still jumps off after reset, please contact
your local Antari dealer for assistance.
Breaker Specification
100-120V = 15A 250V
220-240V = 9A 250V
15. Technical Specifications
F-7X
Rated Voltage
US Model : AC 100-120V, 50/60Hz 15.8A
EU Model : AC 220-240V, 50/60Hz 12.9A
Rated Power
100V 1400W / 120V 1900W / 240V 3100W
Warming-up Time
8 minutes (Approx.)
Fluid Consumption
Fog Mode: 140 ml/min (100% Output)
Faze Mode: 28 ml/min (100% Output)
Operating Time
Faze Mode: 2.8 hrs at Max. Output
Fluid Tank Capacity
5 Liters (1.32 gallon) x 2
Compatible Fluid
Antari FLG、Antari FLH、Antari FLZ
Ambient Temp. Range
0°C – 40°C (32°F – 104°F)
Control Methods
Manual、Timer、DMX 512、W-DMX (Optional)、Wireless (Optional)
Interface
XLR 3-Pin/5-Pin Connector (DMX)、Neutrik powerCON Connector (Power)
DMX Channels
3 Channels
Included Accessories
N/A

10
F-7X
Optional Accessories
ES-W-DMX Wireless DMX Receiver、WTR-110 Wireless Remote
Dimension
L 728 W 428 H 719 mm (L 28.66 W 16.85 H 28.31 inch)
Weight
53.0 kg (117.85 lbs.)
16. Warranty Disclaimer
We guarantee the merchandise manufactured by us to be free from defect in material and workmanship for a period
of one year. Our obligation and liability under this warranty shall be restricted to repair or replacement at our
factory or local authorized dealer. We assume no liability of the products that are improperly used or used for any
purpose other than that for which they are specially designed. This warranty shall not apply to any merchandise
which has been repaired, altered or assembled outside our factory in any way so as in our judgment to affect its
performance, nor which has been subjected to misuse, negligence, or accident nor to any merchandise operated
contrary to our printed instructions. We will not allow or be liable of any loss or any damages of any kind in
connection with the use, sale, or repair of any merchandise purchased from us.
17. Machine Dimension

11
1.
前言
在操作本機器之前，請務必仔細詳閱本說明書然後請將本說明書放置在機器使用者可隨時查閱之處存放。
此說明書包含如何安全的安裝及操作本機器以及說明所有在機器上的標示。如果您有任何操作上的問題，
請立即聯繫當地的 Antari 經銷商尋求協助。
2.
安全注意事項
危險
若不確實避免這些指示，可能導致嚴重人身傷害甚至死亡。
警告
若不確實遵循這些指示，可能導致嚴重人身傷害甚至死亡。
注意
若不確實注意這些指示，可能導致人身傷害甚至死亡，嚴重程度視情況而定。
危險
l 請務必使用正確電壓。如果使用錯誤電壓，可能會遭受危險的電擊燒傷或更嚴重的後果。
l 請務必將機器連結到有保護的電路，並確保有正確的接地，以避免觸電的危險。關於接地方式請參考
第21 附錄 I。
l 請勿在捆綁電源線的情況下使用，可能會發熱導致火災。
l 操作機器時請 勿 將 機 器 對 著 人 體 、動物或火 焰使用。
警告
l 機器的噴嘴非常燙。當機器工作時，請遠離噴嘴 50 公分以上。
l 請於堅固、平坦、穩定且通風良好的表面上使用機器。請勿遮蓋機器散熱部份，機器周邊至少應保留
50 公分的空間並確認附近沒有易燃性物質或可揮發性氣體。
l 請勿隨意拆卸、修理或改造機器，這可能會導致機器故障、損壞、觸電危險或造成火災。
l 本機器僅限有行為能力之成人或專業人員操作，不預期提供生理、感知、心智能力、經驗或知識不足
者之使用者(包含孩童)使用本機器。
l 請勿在無人看管時讓機器運作，並 於 外 出 離 去 時 確 實關閉 電 源 。
l 孩童應受監督，以確保孩童不能操作或嬉戲玩本機器。
l 請勿將機器倒放或傾斜使用，可能導致機器動作不正常或損壞。
l 請將液體存放在室內孩童無法取得之處，保持通風及避免陽光直射。如果有觸碰眼睛或誤食機器，請
立即尋求醫生的協助。
注意
l 本機器無防水設計，請隨時保持機器乾燥，嚴禁將其潑水、浸水、淋雨或放在潮溼的環境。
l 在插 入 電 源 插 座前 ，請確認電 源 插 座無損壞或鬆動。
l 若電源線損壞，必須使用原廠電源線或組件進行更換，否則將導致保固無效。
l 請在使用機器之前，先填裝好煙霧水，避免機器幫浦空轉過熱造成損害。機器在搬運前或使用完畢
後，請清空油桶。
l 在運輸本機器前，請確認機器的油箱已清空並且包裝完整。(建議使用原廠包裝)
l 本產品僅限室內使用。

12
l 請勿在電壓不穩定的地區使用本機器。
l 如果機器出現異常聲音或有任何不正常現象時，請立即停止工作，將電源關閉及拔下機器電源線，並
請聯繫當地的 Antari 經銷商尋求協助。
l 請勿觸碰機器內部運轉零件。
l 只能使用原廠建議或販售之配件。
l 請確認機器不在使用的狀態下電源已關。如果長時間不使用機器，請拔掉電源線。
l 關閉機器時，將控制開關轉到關閉的位置，然後再將插頭從插座拔除。
l 拔除電源線時，請抓住插頭不是電線。
l 在保養及清潔前，請把電源線從插座拔除。
l 在電線或插座有損毀、機器故障或有掉落或損壞的情形發生時，請勿操作機器。請將機器送回最近的
維修站，做檢查、維修及電源或機械的調整。
l 為確保機器的使用壽命，請使用 Antari 原廠製造之煙霧水，勿使用其它非Antari 原廠製造煙霧水或添
加劑，否則可能會導致電熱管阻塞和故障。
在使用本機之前，請詳細閱讀機器上的警語標示，說明如下：
CAUTION! 注意!
ONLY USE MANUFACTUREER DESIGNATED FLUID 只能使用製造商指定油品
NEVER ADD FLAMMABLE SUBSTANCES. 切勿添加易燃物質。
WA R N I N G ! 警告!
DISCONNECT POWER BEFORE CHANGING FUSE. 更換保險絲前請務必斷開電源
USE ONLY WITH ADULT SUPERVISION. 僅在成人監督下使用
DO NOT OPERATE WITHOUT LIQUID. 請勿在沒有液體的情況操作本機台
FOR INDOOR USE ONLY. KEEP DRY. 僅限室內使用。請保持乾燥
NO USER SERVICEABLE PARTS INSIDE. 內部無使用者需維修之零配件
3.
包裝內容與檢查
在收到機器後，請立即小心地打開包裝紙箱，檢查所有內容，確認您所購買的機型及配件。如果有任何部
件因運輸過程出現損壞或缺少，請立即連絡經銷商，並以原包裝退回檢查。
3.1
包裝內容
1 x F-7X Smaze 煙霧機
2 x 5 公升油桶
2 x Neutrik powerCON 電源線
1 x 說明書或掃描機身 QR CODE
3.2
選配說明
品項
描述
ES-W-DMX
無線 DMX 接收器
WTR-110
無線控制器組(W-2 無線發射器/無線接收器)

13
4.
機器訊息
01. 風扇
06. 保險絲
02. 出煙口
07. Neutrik powerCON 連接頭(電源)
03. 飛行箱
08. 液晶觸控螢幕
04. 無線/無線 DMX 接收器(選配)
09. 二合一電源&斷路器開關
05. XLR 3-Pin/5-Pin 連接頭(DMX)
10. 5 公升油桶
5.
技術標籤資訊
使用本機器前，請詳閱技術標籤上的訊息
1. 機器型號
5. 斷路器/保險絲
2. 工作電壓
6. 說明書 QR CODE
3. 頻率
7. 機器流水序號
4. 瓦特數
6.
煙霧水
危險
將液體加入機器之前，請務必先拔除電源線。請勿添加易燃液體。如果發現液體
流入機器內部，請洽Antari 原廠或其經銷商尋求協助。
l 僅能使用 Antari 原廠製造之煙霧水，不可混用或稀釋。若因保存不當而變質或使用非原廠煙霧水，將
可能造成電熱管堵塞而導致機器故障。
l 本機器是使用專屬的煙霧水做測試與校正來取得最佳的效能

14
l 如需更換另一種液體，請在使用前，先將油桶中的液體清空，以避免混合。
l 僅能使用 Antari 原廠製造之香精，並依照原廠建議比例添加(原廠建議比例為1:1000)，如果使用非原
廠的香精或比例添加有誤，將可能造成電熱管阻塞而導致機器故障。
l 如果使用非原廠製造之煙霧水或香精而導致煙霧機損壞將不在保固範圍內。
7.
設定與手動操作說明
警告
機台掉落可能會造成嚴重傷害，請確保本機台安裝牢固且不會掉落。
步驟
1. 將機器平放在堅固、平坦、穩定且通風良好的表面上，機器周圍至少應保留50 公分的空間並確
認附近沒有易燃性物質或可揮發性氣體。
步驟
2. 使用 ANTARI 原廠專用煙霧水注入機器所附的油桶，並注意不要折到油管。
步驟
3. 將機器連接電源，連接之前，確認機器背後技術標籤上所標示要求功率，是否與電源插座相
符。
步驟
4. 啟動機器電源後，使機器開始加溫。機器加溫到可工作溫度大約需要8分鐘。當機器達到工作
溫度時”100%” (螢幕左上角)，表示機器已經準備好可進行操作。
步驟
5. 欲手動模式啟動噴煙，按下面板上的”手動”；調整需要的輸出量及風扇速度按下”開始”然後再按
一次停止噴煙
步驟
6. 定時模式啟動噴煙，按下面板上的”定時”; 調整需要的[間隔時間]、[噴煙時間]、[輸出量]及[風
扇速度]按下開始，然後再按一次停止噴煙
步驟
7. 按下”DMX”，然後根據需求設定
步驟
8. 按下”Menu”，然後根據需求設定
步驟
9. 需關閉本機時，請確認機器已停止運轉，再將電源開關關閉即可，長時間不使用時請移除電源
線。
8.
控制設定
F-7X Smaze 煙霧機可以使用下列操作模式，機器每次接受一種訊號。
l 手動控制
l 定時控制
l DMX512
l 無線 DMX
l 無線控制
8.1
控制面板說明

15
圖標
操作方式
動作
按
確認選擇
按
調整數值
按
回到上一頁
按
啟動
按
停止
按
進入設定
(綠色背景)
N/A
正在運作的模式
8.2
選單說明
主選單
選項
設定值
定時
間隔時間
1 – 300 秒
啓動時間
1 – 300 秒
噴煙模式輸出量
20 – 100%
噴霧模式輸出量
1 -100%
風扇速度
20 – 100%或關閉
手動
噴煙模式輸出量
20 – 100%或連續噴煙
噴霧模式輸出量
1 -100%
風扇速度
20 – 100%或關閉
DMX
地址
001-510
通道模式
3種通道
W-DMX 電源
開啓/關閉
W-DMX 重置
解除配對
選單
資訊
軟體版本
設定
控制模式
噴煙/噴霧
風扇速度
20 – 100%或關閉
油品選擇
FLG/FLH/FLZ
油量偵測
開啓/關閉
無線遙控器配對
配對/取消配對
快速啟動
開啓/關閉
語言選項
English /中文/日本語
LCD 背光
高/中/低/自動關閉
自我清潔模式
倒數 180 秒
9.
機器狀態
9.1
機器狀態說明
面板畫面
說明
Antari F-7X Smaze
噴煙就緒
噴煙就緒 (螢幕左上角顯示 100%)W-DMX 連接狀態
(螢幕右上角圖示，詳細說明請參考 12.3)Wireless 顯示
噴煙輸出量100 %
噴煙輸出量20 – 100%
噴霧輸出量100%
噴霧輸出量1 – 100%

16
面板畫面
說明
風扇速度100%
風扇速度20 – 100%或關閉
間隔時間 1 - 300 秒
啟動時間1 - 00 秒
定時噴煙/噴霧執行
DMX512
地址 xxx
DMX 執行中
自我清潔模式
倒數 180 秒後進入休眠 (DMX 移除時)
機器加熱中
加熱中 0 – 100% (螢幕左上角)
機器過熱
電熱管過熱
加熱器故障
電熱管溫度異常
溫度線斷開
溫度線斷開
溫度線反接
溫度線反接
電壓錯誤
電壓錯誤
**控制面版出現警告的訊息，請立即停止操作機器並關閉電源之後，請與當地的Antari 經銷商尋求協助。
10. DMX
說明
10.1 DMX
說明
本機提供一個XLR 3-PIN/5-PIN 的DMX 連接頭。下為PIN 的接點說明：
Pin
Function
1
Ground
2
Data-
3
Data+
4
NA
5
NA
** DMX IN 連接頭上有一個保護蓋，操作前，請用
手指撥開即可將其取下。
10.2 DMX
通道功能
本機提供三種 DMX 通道可供選擇，請參考下方表單。
通道模式
DMX
數值範圍
功能
通道1
0 - 127
噴霧模式
128 - 255
噴煙模式
通道2
0 - 5
輸出關閉
6 - 255
噴煙輸出量20 - 100%
噴霧輸出量1 – 100%
通道3
0 - 5
風扇關閉
6 - 255
風扇速度20 - 100%
11. RDM
功能
F-7X Smaze 煙霧機配有 RDM 功能，讓使用者可以經由DMX 網路使用 RDM 功能進行機台的設定、監
控、管理。請參考下表相關RDM 支援參數;
GET
Allowed
SET
Allowed
Category
RDM Parameter ID’s (Slot 21-22)
Val u e
Required
NetworkManagement
網路管理
DISC_UNIQUE_BRANCH
0x0001
O
0x0002
O
0x0003
O

17
GET
Allowed
SET
Allowed
Category
RDM Parameter ID’s (Slot 21-22)
Val u e
Required
O
RDM Information
RDM 資訊
QUEUED_MESSAGE
0x0020
O
STATUS_MESSAGES
0x0030
O
SUPPORTED_PARAMETERS
0x0050
O
O
PAPAMETER_DESCRIPTI ON
0x0051
O
O
Product Information
產品資訊
DEVICE_INFO
0x0060
O
O
PRODUCT_DETAIL_ID_LIST
0x0070
O
DEVICE_MODE_DESCRIPTION
0x0080
O
MANUFACTURER_LABEL
0x0081
O
O
DEVICE_LABEL
0x0082
O
SOFTWARE_VERSION_LABEL
0x00C0
O
O
O
DMX512 Setup
DMX512 設定
DMX_PERSONALITY
0x00E0
O
DMX_PERSONALITY_DESCRIPTI
ON
0x00E1
O
O
DMX_START_ADDRESS
0x00F0
O
O
SLOT_INFO
(0x0120)
O
SLOT_DESCRIPTION
(0x0121)
O
DEFAULT_SLOT_VALUE
(0x0122)
O
Sensors
感應器
SENSOR_DEFINITION
0x020
O
O
SENSOR_VALUE
0x0201
O
Control
控制
DEVICE_HOURS
0x0400
O
O
IDENTIFY_DEVICE
0x1000
O
O
O
POWER_STATE
0x1010
12. ES-W-DMX
無線
DMX
接收器
(
選配
)
ES-W-DMX 無線 DMX 接收器是F-7X Smaze 煙霧機的選購配件。若您採購的版本已含無線 DMX 功能即
已安裝至機器上，可直接使用。若是後續採購ES-W-DMX 無線 DMX 接收器，請按照下方說明進行安
裝。如果遇到任何困難與問題，請與當地的Antari 經銷商尋求協助。本機選購的無線 DMX 接收器可同時
支援 CRMX 以及 W-DMX 協議
12.1 ES-W-DMX
這是一個無線 DMX 接收器
12.2
無線
DMX
接收器安裝說明
如果是後續採購無線 DMX 接收器，請按照下方說明進行安裝與配對。如果遇到任何困難與問題，請與當
地的 Antari 經銷商尋求協助。

18
圖
1
圖
2
圖
3
1. 請看圖一, 取下蓋子。
2. 請看圖二, 取下後，你會看到一條白色的線，請拉出來接在 W-DMX 接收器上。
3. 請看圖三, 將接收器鎖回去原本的地方即可使用。
12.3
無線
DMX
連接狀態說明
請按照下列步驟，啟用此功能;
1. 進入 DMX 設定選單;
2. 按上下箭頭，找到[W-DMX 電源]，開啟W-DMX 電源，然後就可在螢幕上看到目前狀態。
LCD
螢幕上所顯示的符號
無線
DMX
連結狀態
○
(綠色)
無線 DMX 發射器已對頻，接收到 DMX 訊號
◎
無線 DMX 發射器已對頻，但沒有DMX 訊號
☉
無線 DMX 發射器連接遺失 / 正在與發射器連接
● (紅色)
沒有對頻任何無線 DMX 發射器
13. WTR-110
無線控制器
(
選配
)
WTR-110 無線控制器包含一個W-2 無線發射器及無線接收器，此為F-7X Smaze 煙霧機的選購配件。若您
採購的版本已含無線功能即已安裝至機器上，可直接使用。若是後續採購WTR-110 無線控制器，請按照下
方說明進行安裝與配對。如果遇到任何困難與問題，請與當地的Antari 經銷商尋求協助。
13.1 W-2
無線發射器說明
l 發射器：使用 27A 12V 電池
l 收發距離：有效距離為50 公尺，實際收訊狀況根據現場環境因
素而有所不同。
l W-2 無線發射器配有 4個按鈕，控制功能為：
W-2 無線發射器
按鈕
功能
[A] 鍵
啓動噴煙
[B] 鍵
關閉噴煙
[C] 鍵
增加煙霧輸出量
[D] 鍵
減少煙霧輸出量
無線接收器
13.2 WTR-110
接收器安裝說明
如果是後續採購WTR-110 無線控制器，請按照下方說明進行安裝與配對。如果遇到任何困難與問題，請
與當地的Antari 經銷商尋求協助。
