Antec Studio Series Take 3 3U User manual

Studio Series
Rackmount Enclosures
www.antec.com 1-800-22ANTEC (US) / [phone] (EU)
Quiet computing comes to rackmounts
Antec's Studio Series rackmount enclosures offer rock-solid, lights-out performance for professional
audio recording and anyone requiring rackmount chassis ruggedness coupled with Antec’s famous
quietness. Available in 3U and 4U sizes, these cases feature special 450-Watt, whisper-quiet power
supplies, plus 92mm and 120mm fans for cool, quiet operation. Cooling is further enhanced by a
unique segregated air-flow design. Backed by Antec's legendary 3-year warranty on all parts and
labor, our Studio Series lets you power up, tune in, and create!
Model
Chassis:
Dimension:
Weight:
Color:
Drive bays:
Motherboard:
Cooling system:
Power supply:
Expansion slots:
Front ports:
Case design:
UCC 13#:
Ta ke 3
3U
17”(W) x 20.5”(D) x 5.2”(H)
43.18(W) x 52.07(D) x 13.21(H) cm
25.7lb/11.66kg
Black
2 external 5.25” bay
1 external, 3 internal 3.5” bay
Standard ATX (9.6”x 12”)
1 x 120mm TriCool
1 x 92mm TriCool
450W ATX12V v2.0 Power Supply
(model SP2-450SXR for US version;
SP2-450SXRP for Europe Version)
7
2 x USB2.0,
1 x Firewire (IEEE1394)
Ta ke 4
4U
17”(W) x 20.5”(D) x 7”(H)
43.18(W) x 52.07(D) x 17.78(H) cm
34.6lb/15.69kg
Black
2 external 5.25” bay
2 external, 4 internal 3.5” bay
Standard ATX (9.6”x 12”)
1 x 120mm TriCool
1 x 92mm TriCool
450W ATX12V v2.0 Power Supply (model
SP-450 for US version; model SP-450P for
Europe Version)
7
2 x USB2.0,
1 x Firewire (IEEE1394)
0-761345-94004-70-761345-94003-0
Quiet studio rackmount with rubber grommets to absorb hard drive vibration. Selectable
fan speed allows choice of performance and quietness. Power supply is isolated from the
system to keep the system cooler.
