Anticimex Smart Connect Mini User manual

2019.10.25
TP, rev13
Side 1af 4
Smart Connect Mini user manual
Compliance statement Smart Connect Mini and Smart Eye Mini
Smart Connect Mini
Contains FCC ID XMR201707BG96
Contains FCC ID 2AOFP-E0048
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Smart Eye Mini
Contains FCC ID 2AOFP-E0048
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
if the FCC identification number is not visible when the module is installed inside another
device, then the outside of the device into which the module is installed must also display a
label referring to the enclosed module, Contains FCC ID: 2AOFP-E0048.
Information to user
if the FCC identification number is not visible when the module is installed inside another
device, then the outside of the device into which the module is installed must also display a
label referring to the enclosed module, Contains FCC ID: 2AOFP-E0048.
Caution: any changes or modifications not expressly approved by Anticimex Innovation Center
A/S will void the user’s authority to operate the equipment.
This equipment has been tested using a shielded network cable (STP). The Smart Connect Mini
and Smart Eye Mini are only in compliance if no changes or modifications is made to the device
The Smart Connect Mini and Smart Eye Mini are in compliance with the requirement for RF
exposure in US with 20 cm separation distance between the user and/or bystander of the
device.
The latest version of the manuals and datasheets are always available on
anticimexonline.sharepoint.com
The antenna is fixed to the device and no change in antenna or fixation of the antenna is
acceptable and such modification is considered to violate the Compliance Statement

2019.10.25
TP, rev13
Side 2af 4
This device complies with Industry Canada’s license-exempt RSSs. Operation is subject to the
following two conditions:
1. This device may not cause interference; and
2. This device must accept any interference, including interference that may cause
undesired operation of the device. This device should be installed and operated with
minimum distance of 20 cm from the human body.
Le present appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes:
1. L’appareil ne doit pas produire de brouillage, et
2. L’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si
lebrouillage est susceptible d’en compromettre le fonctionnement.
The Smart Connect Mini uses the following frequency bands;
FREQUENCY BAND
MAX POWER
LTE-FDD
B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B26/B28
23dBm
GSM850/EGSM900
33dBm
DCS1800/PCS1900
30dBm
GSM850/EGSM900 (8-PSK)
27dBm
DCS1800/PCS1900 (8-PSK)
26dBm
The Smart Connect Mini and Smart Eye mini also communicates using the following free SRD
frequency bands;
EU: 868 –868.6 MHz with a maximum transmitting power of 14 dBm.
Rest of the world: 917 –926 MHz with a maximum transmitting power of 14 dBm.
If an ethernet cable is used the product shall be connected using a shielded network cable (STP)
that is properly grounded.
Simplified declaration of conformity
Hereby, Anticimex Innovation Center A/S declares that the radio equipment type Smart
Connect Mini and Smart Eye Mini is in compliance with Directive 2014/53/EU. The full text of
the EU declaration of conformity is available at the following internet address:
anticimex.com/declaration-of-conformity
Note:

2019.10.25
TP, rev13
Side 3af 4
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
Instructions
Only Anticimex service technicians are allowed to install, replace damaged units, and service
installations. Replace the Smart Connect Mini or Smart Eye Mini if the device is faulty.
To install the Smart Connect Mini system the operator must possess a mobile device such as a
smartphone or tablet with access to an internet connection. To install, the operator should have
a user in the Anticimex-owned software system “Smart Device Tool”.
1. Use Smart Device Tool to initiate an installation
2. Scan the QR-code of the Smart Connect Mini
3. Apply power to the Smart Connect Mini and await green flashes of the gateway,
indicating beacon mode is active: You can now start to set up the sensors
a. Start setting up sensors closest to the gateway
4. Push the button of the sensor and await green flashes, indicating connection
5. Continue to set up all the sensors of the installation in the same way
6. When all sensors have been installed, end the installation through Smart Device Tool
a. During this step, the installation will form its mesh and pair sensors
7. If the connection has formed without any problems, the installation is complete
8. If there are problems, investigate using Smart Device Tool which sensors did not
connect: Either relocate them or adjust the installation by adding an extra sensor to
solve the problem
9. End installation through Smart Device Tool.

2019.10.25
TP, rev13
Side 4af 4
The Smart Connect Mini must not be installed more than 2 meters above ground. Do not use
another power supply than the one provided with the Smart Connect Mini. Use of any other
power supply could damage the product or make it operate in an unforeseen manner.
Troubleshooting
•If the Smart Connect Mini shows a red light, it can’t connect to the backend system.
Check that the device has been created in Smart Device Tool or relocate to a position
with better cellular coverage.
•If there are problems installing one or more Smart Eye Mini sensors, investigate using
Smart Device Tool which sensors did not connect: Either relocate them or adjust the
installation by adding an extra sensor to solve the problem.
•If the Smart Eye Mini still does not install, try to factory reset the unit by pressing and
holding the button and await red, green and yellow flashes. Afterwards, you can try to
install the sensor again
