Antunes 9210875 User manual

P/N 1011190 Rev. G 01/17
GST-3V
owner’s manual
Gold Standard Toaster
Manufacturing Numbers:
9210875
www.antunes.com

2P/N 1011190 Rev. G 01/17
SERVICE/TECHNICAL
ASSISTANCE
If you experience any problems with the
installation or operation of your unit, con-
tact Antunes Technical Service.
Fill in the information below and have it
handy when calling for assistance. The
serial number is on the specication plate
located on the rear of the unit.
Use only genuine Antunes replacement
parts in this unit. Use of replacement parts
other than those supplied by the manu-
facturer will void the warranty.
WARRANTY
INFORMATION
Please read the full text of the Limited
Warranty in this manual.
If the unit arrives damaged, contact
the carrier immediately and le a dam-
age claim with them. Save all packing
materials when ling a claim. Freight
damage claims are the responsibility of
the purchaser and are not covered under
warranty.
The warranty does not extend to:
yDamages caused in shipment or
damage as result of improper use.
yInstallation of electrical service.
yNormal maintenance as out-
lined in this manual.
yMalfunction resulting from im-
proper
maintenance.
yDamage caused by abuse or care-
less
handling.
yDamage from moisture into electri-
cal
components.
yDamage from tampering with,
removal of, or changing any
preset control or safety device.
TABLE OF CONTENTS
Purchased From
Date of Purchase
Model Number
Serial Number
Manufacturing Number
IMPORTANT
A.J. Antunes & Co. reserves the right to
change specifications and product de-
sign without notice. Such revisions do
not entitle the buyer to corresponding
changes, improvements, additions or
replacements for previously purchased
equipment.
IMPORTANT
Keep these instructions for future refer-
ence. If the unit changes ownership,
be sure this manual accompanies the
equipment.
Table of Contents 2
Warranty
Information 2
Service/Technical
Assistance 2
Important Safety
Information 3
Warnings 3
Specications 4
Shipping Weight 4
Installation 5
Operation 5
Light/Dark Adjustments 5
User Mode 6
Manager Mode 6
Safety Features 6
Hi-Limit Control 6
Purging buns from Toaster 6
Fault Messages 6
Error Codes 6
Daily Cleaning 7
Replacing Belts (Quarterly) 7
Removing Belts 7
Installing Belts 7
Cleaning the Top Cooling Fan and Elec-
trical Housing (Annually) 8
Troubleshooting 9
Replacement Parts 11
Replacement Part Kits 15
Wiring Diagram 16
Notes 17
Limited Warranty 20

3
P/N 1011190 Rev. G 01/17
IMPORTANT SAFETY
INFORMATION
Use the following guidelines for safe op-
eration of the unit.
yRead all instructions be-
fore using equipment.
yFor your safety, the equipment is
furnished with a properly grounded
cord connector. Do not attempt to
defeat the grounded connector.
yInstall or locate the equipment only
for its intended use as described in
this manual. Do not use corrosive
chemicals in this equipment.
yDo not operate this equipment if
it has a damaged cord or plug, if
it is not working properly, or if it
has been damaged or dropped.
yThis equipment should be serviced
by qualied personnel only. Contact
your nearest Authorized Service
Agency for adjustment or repair.
yDo not block or cover any
openings on the unit.
yDo not immerse cord
or plug in water.
yKeep cord away from
heated surfaces.
yDo not allow cord to hang over
edge of table or counter.
yTurn the power o, unplug the
power cord, and allow unit to
cool down before performing any
service or maintenance on the unit.
NOTE: Turning o the power switch
does NOT turn o all power to
the unit.
yThe procedures in this manual may
include the use of chemical prod-
ucts. These chemical products will
be highlighted with bold face letters
followed by the abbreviated HCS
(Hazard Communication Standard).
See Hazard Communication Stan-
dard manual for the appropriated
Material Safety Data Sheets (MSDS).
yThe equipment should be grounded
according to local electrical codes to
prevent the possibility of electri-
cal shock. It requires a grounded
receptacle with separate electrical
lines, protected by fuses or circuit
breaker of the proper rating.
yAll electrical connections must
be in accordance with lo-
cal electrical codes and any
other applicable codes.
yDo not clean this appli-
ance with a water jet.
WARNINGS
Be advised of the following warnings
when operating and performing mainte-
nance on this unit.
yIf the supply cord is damaged, it
must be replaced by the manu-
facturer or its service agent or
a similarly qualied person
in order to avoid a hazard.
yDo not modify the power sup-
ply cord plug. If it does not t
the outlet, have a proper outlet
installed by a qualied electrician.
yDo not use an extension
cord with this appliance.
yElectrical ground is re-
quired on this appliance.
yCheck with a qualied electrician if
you are in doubt as to whether the
appliance is properly grounded.
yWhen using a chemical cleaner,
be sure it is safe to use on cast
aluminum. Observe all precautions
and warnings on product label.
yInspection, testing, and repair
of electrical equipment should
only be performed by quali-
ed service personnel.
yDo not use a sanitizing solution or
abrasive materials. These may cause
damage to the stainless steel nish.
yChlorides or phosphates in clean-
ing agents (e.g. bleach, sanitizers,
degreasers or detergents) could
cause permanent damage to
stainless steel equipment. The
damage is usually in the form of
discoloration, dulling of metal
surface nish, pits, voids, holes, or
cracks. This damage is permanent
and not covered by warranty.
yThe following tips will help
in the maintenance of stain-
less steel equipment:
• Always use soft, damp cloth for
cleaning, rinse with clear water
and wipe dry. When required,
always rub in direction of metal
polish lines.
• Routine cleaning should be
done daily with soap, ammonia
detergent, and water.
• Stains and spots should be
sponged using a vinegar solu-
tion.
• Finger marks and smears should
be rubbed o using soap and
water.
• Hard water spots should be re-
moved using a vinegar solution.

4P/N 1011190 Rev. G 01/17
SPECIFICATIONS
Model &
Mfg. No. Volts Watts Hertz Plug Description
GST-3V
9210875 208/240 3300- 3840 50/60
NEMA 6-20P
20 Amp, 250 Volt
Non-Locking
Model &
Mfg. No.
Width
(A)
Depth
(B)
Height
(C)
Height
(D)
GST-3V
9210875 25" (635 mm) 16 1/2" (419 mm) 22 1/2" (572 mm) (without Bun Feeder)
30” (762 mm)
(with Bun Feeder)
SHIPPING WEIGHT
GST-3V Series 127 lbs (58 kg)
AB
CD

5
P/N 1011190 Rev. G 01/17
INSTALLATION
1. Remove unit and all packing mate-
rials from shipping carton.
2. The unit is shipped with the follow-
ing items:
• Butter Wheel Assy. (including
Butter Wheel and Butter Pan)
• Bun Feeder
• Owner’s Manual
NOTE: If any parts are missing or dam-
aged, contact Antunes Techni-
cal Service IMMEDIATELY at
1-877-392-7854 or 1-630-784-
1000.
3. Remove all packing materials and
protective coverings from the unit.
4. Wipe the entire exterior of the
toaster and the accessories men-
tioned above with a hot damp
cloth. Allow to air dry
NOTE: Do NOT use a dripping wet
cloth. Wring out before use.
5. Attach the Bun Chute, Bun Feeder,
and Butter Wheel assembly.
When placing the toaster into service,
pay attention to the following guidelines.
yMake sure the power switch is o
and the unit is at room temperature
before plugging in the power cord.
yDo not block or cover any
openings on the unit.
yDo not immerse the power
cord or plug in water.
yKeep the power cord away
from heated surfaces.
yDo not allow the power cord to
hang over edge of table or counter.
yPlace the unit on a sturdy, level
table or other work surface.
yTurn the power switch to
o (if it is set to on).
yEnsure the line voltage cor-
responds to the stated voltage
on the specication label and
power cord warning tag.
6. Plug the power cord into the ap-
propriate power outlet. Refer to the
specication plate for the proper
voltage.
Figure 1.
OPERATION
1. Turn the unit on and allow it to
warm up until USE appears in the
display
2. Drop product into the appropriate
lane on the Bun Feeder according
to Bun Feeder labels. Insert buns
with the cut side facing away from
the front of the toaster
3. Finished product drops into the bun
landing zone.
Light/Dark Adjustments
The light/dark value can be adjusted when
the unit is displaying “USE”. To adjust the
light/dark value, press the LIGHTER or
DARKER button. The display will change to
show the current light/dark value.
NOTE: The default light/dark value is
d0.
Press the LIGHTER or DARKER buttons to
change the light/dark value. The adjust-
ment range is L1-L9 and d0-d9. L9 is the
lightest, d0 is the middle, and d9 is the
darkest setting.
To save the light/dark value, press the PRO-
GRAM button or wait 5 seconds until the
screen displays “USE”.
NOTE: Adjusting the light/dark value
does NOT change the tempera-
ture. It changes the speed of the
conveyors. The light/dark value
will reset to the default value of
d0 when the unit is turned o.
