Anywhere Cart AC-SLIM-PW45 User manual

USER GUIDE
AC-SLIM-PW45
Specifications subject to change without notice.
36 BAY PRE-WIRED USB-C SECURE CHARGING CART
DIMENSIONS
Height: 44”
Width: 26”
Depth: 26”
© 2020 Anywhere Cart | 42035 Zevo Drive, Temecula CA 92590, USA | 888-650-4488 | www.AnywhereCart.com
4/2/20
CART CAPACITY
Divider Spacing: 1.18”
Shelf Depth: 14.375”
Shelf Height: 10.50”
WEIGHT
Product Weight: 203 lbs.
Shipping Weight: 225 lbs.
The AC-SLIM-PW45 is designed to charge & store 36 USB-C Chromebooks.
Please review this guide before installing devices and to learn how to safely use your cart.
AC input: 120V AC 60 Hz |Max amps: 14A
Front of Cart (closed)
Push Handle (Installation required)
Keyed Door Lock Latch
Power Cord
5” Swivel / Lock Casters (Black tab)
5” Swivel / Directional Casters (Orange tab)









11
Front of Cart (open)
Pre-wired Device Cords
External Power Button
External Power Outlets
Removable Dividers
Back of Cart (open)
Pre-Wired AC Adapter Baskets
Pre-Wired Power Outlet Strips
INTELLI-SENSE Smart Charger
11
12
12

• THIS IS NOT A TOY. CHILDREN SHOULD NEVER
MOVE OR CLIMB THE CART!
• ONLY ADULTS should move the cart.
• NEVER climb, sit on or tilt the cart.
• ALWAYS move the cart slowly and be aware
of your surroundings.
• ALWAYS latch doors before moving the cart.
• DO NOT use the power cord to pull the cart.
• DO NOT roll the cart over the power cord.
• DO NOT touch any part of the electrical system
while plugged in.
• DO NOT place liquids on or near the cart.
• DO NOT use an extension cord with this unit.
• DO NOT plug in the cart if the switch, receptacles,
or power cord are broken, cracked, torn or
inadequately repaired.
• Repairs should always be performed by a qualified
electrician.
• Set the power switch to the OFF position before you
unplug the unit from the wall, plug the unit into the
wall, or plug in devices.
• If external devices are set on top of the cart,
remove them before rolling cart around.
WARNING
ALWAYS FOLLOW SAFETY PRECAUTIONS.
DO NOT REMOVE THIS DECAL.
WARNING
THIS IS NOT A TOY. ALWAYS FOLLOW SAFETY PRECAUTIONS. DO NOT REMOVE THIS DECAL.
ONLY ADULTS should move the cart. DO NOT allow children to move or climb. DO NOT ride or run with the cart. DO NOT attempt to move downstairs. DO NOT place liquids on or near the cart.
For warranty claims, please have the
following information ready, then visit
www.anywherecart.com/support
to create a help ticket.
Serial Number:
________________________________
Charging System Type:
________________________________
Date Of Purchase:
________________________________
Reseller Name:
________________________________
PO Number:
________________________________
1. Before initial setup, IDENTIFY the wattage of your
device’s power adapter. Multiply this number by the
number of devices being charged.
2. Determine which EXTERNAL devices, if any, will
be used and IDENTIFY the wattage.
3. Add device power adapter wattage total and the
external device total. If the combined total wattage is
under 1875 Watts, any mode can be selected.
If over 1875 Watts, DO NOT USE YOUR TIMER IN
“C” - ALL ON MODE. Divide device wattage by 2,
then add EXTERNAL devices. If under 1875 Watts,
use “A” Mode or “B” Mode. If the total device wattage
divided by 2, plus the external devices is over 1875
Watts, remove devices as needed.
NOTE: If wattage exceeds 1875W at one time, charging
system will not operate correctly. Remove devices until the
total wattage is under 1875W.
IMPORTANT
THE ELECTRICAL SYSTEM IS DESIGNED
TO HANDLE A MAXIMUM OF 1875 WATTS.
THE ELECTRICAL SYSTEM IS DESIGNED TO HANDLE A
MAXIMUM OF 1400 WATTS per side. If wattage exceeds 1400W
at one time, charging system may not operate correctly. Remove
devices until the total wattage is under 1400W.
• THIS IS NOT A TOY. CHILDREN SHOULD NEVER
MOVE OR CLIMB THE CART!
• ONLY ADULTS should move the cart.
• NEVER climb, sit on or tilt the cart.
• ALWAYS move the cart slowly and be aware
of your surroundings.
• ALWAYS latch doors before moving the cart.
• DO NOT use the power cord to pull the cart.
• DO NOT roll the cart over the power cord.
• DO NOT touch any part of the electrical system
while plugged in.
• DO NOT place liquids on or near the cart.
• DO NOT use an extension cord with this unit.
• DO NOT plug in the cart if the switch, receptacles,
or power cord are broken, cracked, torn or
inadequately repaired.
• Repairs should always be performed by a qualified
electrician.
• Set the power switch to the OFF position before you
unplug the unit from the wall, plug the unit into the
wall, or plug in devices.
• If external devices are set on top of the cart,
remove them before rolling cart around.
WARNING
ALWAYS FOLLOW SAFETY PRECAUTIONS.
DO NOT REMOVE THIS DECAL.

USER GUIDE
© 2020 Anywhere Cart | 42035 Zevo Drive, Temecula CA 92590, USA | 888-650-4488 | www.AnywhereCart.com
INSTALLING THE HANDLE




x4
6
6
x2 x2 x1
Locate the narrow cardboard box
containing the handle rod, handle
bolts, mounting brackets & hex
wrenches.
Locate the threaded holes for the
handle on the left side of the cart.
Using the larger hex wrench, attach
and tighten both the left and right
side handle mounting bracket to
the cart using 4 large bolts.
Fit the handle rod between the
bracket and tighten using the
smaller hex wrench and handle
bolts.

© 2020 Anywhere Cart | 42035 Zevo Drive, Temecula CA 92590, USA | 888-650-4488 | www.AnywhereCart.com © 2020 Anywhere Cart | 42035 Zevo Drive, Temecula CA 92590, USA | 888-650-4488 | www.AnywhereCart.com
USER GUIDE INTELLI-SENSE SMART CHARGER
Within 5 seconds of plugging in your cart’s power cord, your
INTELLI-SENSE Smart Charging System will initiate an test of
your devices charging level requirements.
Devices which are plugged into power strips that draw the
most power will take priority and can take up to 2 hours before
switching to the next set of outlets. Once devices are fully
charged, the system will remain in a trickle charging state,
maintaining your devices battery levels.
Power Input
Internal Power Button





THE ELECTRICAL SYSTEM IS DESIGNED TO HANDLE A MAXIMUM OF 14 AMPS.
NOTE: If wattage exceeds 14 Amps or about 1400 Watts at one time, the charging system may
not operate correctly. Review your device’s AC Adapter wattage, multiplying it by 18.
65 Watts
X
18 Devices
1170 Watts
85 Watts
X
18 Devices
1530 Watts
75 Watts
X
18 Devices
1350 Watts
With Mode Selection Switch set to SMART:
Group Outlets “A” and Group Outlets “B” power on for
8 seconds in sequence then enter the following modes
depending on current draw.
If the total current draw is greater than 9A:
The group outlets with the highest current draw will
power on, while the group with less current draw remains
OFF. Once the current draw dierence is within 0.5A, the
system will switch to the other group. When the total
current is less than 9A, all outlets will power on at the
same time.
If the total current draw is less than 9A:
Group “A” and Group “B” power on at the same time.
The total output is continuously monitored in case a new
device is added.
Group Outlets “A” Group Outlets “B”
7 Amp load 5.5 Amp load
ON OFF
5 Amp load 5.5 Amp load
OFF ON
5 Amp load 4.5 Amp load
ON OFF
4.5 Amp load 4.5 Amp load
ON ON
The AC-PLUS-T, AC-SLIM, AC-MAX, AC-45, AC-PRO-II and AC-MANAGE are
equipped with the INTELLI-SENSE Smart Charging System. This system will initiate an
test of your devices charging level requirements. Devices which are plugged into power
strips that draw the most power will take priority. Once devices are fully charged, the
system will remain in a trickle charging state, maintaining your devices battery levels.
1. Power Cord Inlet
2. Internal Power Button
3. Mode Selection Switch
1
2
3
4
5
6
78
How It Works
888.650.4488
www.AnywhereCart.com
Subject to change without notice
42035 Zevo Drive, Temecula, CA 92590
Intelli-Sense System Overview
1. Plug in device adapters so there are an
equal number of devices in Group A
and Group B.
2. Make sure the Mode Selection Switch is
set to “SMART” mode.
3. Plug in cart.
The Intelli-Sense timer will automatically
sense the charging needs of the cart and
start charging in the most effcient and
quickest method.
Quick Start Guide
With the Mode Selection Switch set to SMART:
Group Outlets “A” and Group Outlets “B” power on for 8 seconds in sequence then enter the
following modes depending on current draw.
If the total current draw is greater than 9A:
The group outlets with the highest current draw will power on, while the group with less
current draw remains OFF. Once the current draw difference is within 0.5A, the system
will switch to the other group. When the total current is less than 9A, all outlets will
power on at the same time.
If the total current draw is less than 9A:
Group “A” and Group “B” power on at the same time.
The total output is continuously monitored in case a new device is added.
4. External Switch Cable
5. LED Indicators
6.Auxiliary Outlets (Always ON)
7. Group Outlets “A”
8. Group Outlets “B”
À
À
À
For units shipped June 1, 2018 forward
Group Outlets “A” Group Outlets “B”
7 Amp load 5.5 Amp load
ON OFF
5 Amp load 5.5 Amp load
OFF ON
5 Amp load 4.5 Amp load
ON OFF
4.5 Amp load 4.5 Amp load
ON ON
The AC-PLUS-T, AC-SLIM, AC-MAX, AC-45, AC-PRO-II and AC-MANAGE are
equipped with the INTELLI-SENSE Smart Charging System. This system will initiate an
test of your devices charging level requirements. Devices which are plugged into power
strips that draw the most power will take priority. Once devices are fully charged, the
system will remain in a trickle charging state, maintaining your devices battery levels.
1. Power Cord Inlet
2. Internal Power Button
3. Mode Selection Switch
1
2
3
4
5
6
78
How It Works
888.650.4488
www.AnywhereCart.com
Subject to change without notice
42035 Zevo Drive, Temecula, CA 92590
Intelli-Sense System Overview
1. Plug in device adapters so there are an
equal number of devices in Group A
and Group B.
2. Make sure the Mode Selection Switch is
set to “SMART” mode.
3. Plug in cart.
The Intelli-Sense timer will automatically
sense the charging needs of the cart and
start charging in the most effcient and
quickest method.
Quick Start Guide
With the Mode Selection Switch set to SMART:
Group Outlets “A” and Group Outlets “B” power on for 8 seconds in sequence then enter the
following modes depending on current draw.
If the total current draw is greater than 9A:
The group outlets with the highest current draw will power on, while the group with less
current draw remains OFF. Once the current draw difference is within 0.5A, the system
will switch to the other group. When the total current is less than 9A, all outlets will
power on at the same time.
If the total current draw is less than 9A:
Group “A” and Group “B” power on at the same time.
The total output is continuously monitored in case a new device is added.
4. External Switch Cable
5. LED Indicators
6.Auxiliary Outlets (Always ON)
7. Group Outlets “A”
8. Group Outlets “B”
À
À
À
For units shipped June 1, 2018 forward
Mode Selection Switch
External Cable Port
Cycle Outlets “A”
Cycle Outlets “B”
Auxiliary Outlets
(Always ON)
QUICK START TIPS

© 2020 Anywhere Cart | 42035 Zevo Drive, Temecula CA 92590, USA | 888-650-4488 | www.AnywhereCart.com
USER GUIDE
© 2020 Anywhere Cart | 42035 Zevo Drive, Temecula CA 92590, USA | 888-650-4488 | www.AnywhereCart.com
THICK DEVICES SETUP (FRONT)
If device is thicker than 1”, locate
& remove thumbscrews on shelf.
Remove Retaining Strip. Pull forward, then up to
remove the Divider.
Adjust spacing as needed. Place Strip in position
& replace thumbscrews.
Using a ruler, measure the
width of your device.

© 2020 Anywhere Cart | 42035 Zevo Drive, Temecula CA 92590, USA | 888-650-4488 | www.AnywhereCart.com
USER GUIDE
© 2020 Anywhere Cart | 42035 Zevo Drive, Temecula CA 92590, USA | 888-650-4488 | www.AnywhereCart.com
RECONFIGURE DEVICES (BACK)
To reconfigure your cart, remove basket by pulling forward first, then pull upward.
If your device power adapters are “brick”
style, feed power cables through holes
and place no more than 6 into a basket.
Feed device cables into
pass-thru slots to front of cart. Working up front, weave device
cables into divider tabs.

Hook basket(s) in place &
distribute power cords so that all
power strips have an equal
number of devices plugged in.
3
Ê
Ê
Use the supplied Cable Clips to fasten each
cable to the divider by pressing down firmly,
securing the cable in place.

© 2020 Anywhere Cart | 42035 Zevo Drive, Temecula CA 92590, USA | 888-650-4488 | www.AnywhereCart.com
USER GUIDE
© 2020 Anywhere Cart | 42035 Zevo Drive, Temecula CA 92590, USA | 888-650-4488 | www.AnywhereCart.com
Your cart is equipped with Casters that have an “Orange” color foot pedal.
Engage the Directional Locking Casters by pressing the orange foot
pedal down. Your cart will now easily track in a straight line.
  Release the Direction Lock by lifting up on the foot pedal.
The cart will have its full swivel motion restored.
CASTER POSITIONS

© 2020 Anywhere Cart | 42035 Zevo Drive, Temecula CA 92590, USA | 888-650-4488 | www.AnywhereCart.com
USER GUIDE
With your cart plugged in, open the rear panel door and press the internal
Power Button labeled PWR on the charging system.
If your cart powers on, unplug the External Cable from Charging System.
Using a small flat head screwdriver, ensure all individual wires are secure.
Plug the External Cable back in and press the External Power Button.
If the External Power Button does not light up or power on, replace it.





Testing the External Power Button External Power Button - Part # 1321375
Charging
System
Power
Button
External
Cable
Power
Input
Open the rear panel door and locate the 4 vertically mounted Power Strips.
Verify each switch is in the “RESET” position, not the “OFF” position.
Using an extension cord, test each Power Strip by unplugging each cord
from the charging system and plugging them into the extension cord.
If one or more Power Strips no longer works, replace as needed.




Testing the Power Strips 9 Outlet Power Strip - Part #1320953
Check the main Power Cord into the Power Input port located on the
left side of the Charging System to verify it is secure.
Plug the cart into a wall outlet and press the internal Power Button labeled
PWR directly on the Charging System.
If the system does not power on, test your Power Cord by removing it and
plugging in a PC monitor style IEC Power Cord.



Testing the Power Cord Power Cord - Part # 1320399
Overload Protection Mode has been activated.
Verify devices don’t exceed 1400 watts at one time by multiplying
your device’s AC adapter wattage by 18.
Reduce the number of devices if necessary and resume charging.



External LED Button is flashing green and devices are not charging
100 Watts
X
18 Devices
1800 Watts 100W
TROUBLESHOOTING

© 2020 Anywhere Cart | 42035 Zevo Drive, Temecula CA 92590, USA | 888-650-4488 | www.AnywhereCart.com
1. The terms below shall have the following definitions for purposes of this Warranty:
“Client” means the original party purchasing the Products from Anywhere Cart or from an authorized dealer to sell Anywhere Cart
branded products.
“Components” mean the mechanical components of a Product including the wheels, locks, drawer slides and hinges.
“Electronics” mean the electronic timer, Sync station and power strips. Cords and switches are not warrantied.
“Frame” means the main frame or chassis of a Product.
“Products” means any goods and any related services to be supplied by Anywhere Cart to the Client pursuant to the Acceptance of an
Order and any other goods or services which Anywhere Cart supplies to the Client from time to time.
Anywhere Cart warrants that the Products to be supplied to Client are free from defects in material and workmanship under normal
use and service for which they were intended if, but only if, the Products have been properly installed and operated. Anywhere Cart’s
obligation under this Warranty is limited to only supplying replacement part(s) for any part(s) which are returned and found to be
defective, provided that such part(s) are returned to Anywhere Cart within the following Warranty Period:
a. With regard to the Frame, the Warranty Period shall be for the life of the Product to Client.
b. With regard to Components, the Warranty Period shall be for a period of two (2) years from the date of delivery of the Product to
Client.
c. With regard to Electronics, the Warranty Period shall be for a period of two (2) years from the date of delivery of the Product to Client.
Except as prohibited or limited by applicable law, Anywhere Cart does not warrant that the Products meet the requirements of any
safety code of any country, state, municipality, or other jurisdiction, and Client assumes all risk and liability whatsoever resulting from the
use thereof, whether used singly or in combination with other machines or apparatus. This Warranty shall not apply to any of Anywhere
Cart’s Products, or parts thereof, which have been repaired or altered, without Anywhere Cart’s written consent, outside Anywhere Cart’s
facility or altered in any way so as, in the sole judgment of Anywhere Cart, to adversely aect the stability or reliability of the Products,
or if such Products have been subject to misuse, negligence, or accident, or have been operated in a manner not in accordance with
Anywhere Cart’s printed instructions or have been operated under conditions more severe than, or otherwise exceeding, those set forth
in the specifications for such Products.
EXCEPT AS PROHIBITED OR LIMITED BY APPLICABLE LAW, THIS WARRANTY AND THE OBLIGATIONS AND LIABILITIES OF Anywhere
Cart ARE EXCLUSIVE AND IN LIEU OF WARRANTIES, GUARANTIES OR LIABILITIES, EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED
WARRANTY FOR MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, ARISING BY LAW OR OTHERWISE OR WHETHER OR
NOT OCCASIONED BY Anywhere Cart’s NEGLIGENCE AND CLIENT HEREBY WAIVES ALL REMEDIES NOT EXPRESSLY PROVIDED
IN THIS WARRANTY. THIS WARRANTY SHALL NOT BE EXTENDED, ALTERED OR VARIED EXCEPT BY A WRITTEN INSTRUMENT
SIGNED BY Anywhere Cart AND CLIENT. REGARDLESS OF THE FAILURE OF THE SOLE AND EXCLUSIVE REMEDIES PROVIDED IN
THIS WARRANTY, Anywhere Cart WILL NOT BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT OR CONSEQUENTIAL DAMAGES
WHATSOEVER (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF REVENUE, BUSINESS OR PROFITS, LOSS RESULTING
FROM BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, LOSS RESULTING FROM ANY CLAIM BY ANY THIRD PARTY,
ANY LOSS DUE TO DAMAGE TO PROPERTY, AND INJURY TO OR DEATH OF ANY PERSONS RESULTING, DIRECTLY OR INDIRECTLY,
FROM THE USE OR LOSS OF THE PRODUCTS OR ANY OTHER PECUNIARY LOSS) OF ANY KIND OR NATURE. Anywhere Cart
NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN CONNECTION WITH THE
SALE OR USE OF THE PRODUCTS, AND THERE ARE NO ORAL AGREEMENTS OR WARRANTIES COLLATERAL TO OR AFFECTING
THIS WARRANTY. THE EXCLUSION OF SPECIAL, INCIDENTAL, INDIRECT OR CONSEQUENTIAL DAMAGES IS AN INDEPENDENT
AGREEMENT OF Anywhere Cart AND CLIENT APART FROM THE SOLE AND EXCLUSIVE REMEDIES PROVIDED IN THIS WARRANTY.
Client shall notify Anywhere Cart by registered or certified mail, return receipt requested, of a breach of this Warranty within thirty (30)
days after discovery thereof, but not later than the expiration of the applicable Warranty Period, otherwise such claims shall be deemed
waived.
2. Limitations of Warranty.
Anywhere Cart makes no warranties to any third party. You are responsible for all claims, damages, settlements, expenses, and attorneys’
fees with respect to claims made against You as a result of Your use or misuse of the Product. This warranty applies only if the Product
is installed, operated, maintained, and used in accordance with Anywhere Cart specifications. Specifically, the warranties do not extend
to any failure caused by (i) accident, unusual physical, electrical, or electromagnetic stress, neglect or misuse, (ii) fluctuations in electrical
power beyond Anywhere Cart specifications, (iii) use of the Product with any accessories or options not furnished by Anywhere Cart
or its authorized agents, or (iv) installation, alteration, or repair of the Product by anyone other than Anywhere Cart or its authorized
agents.
3. Disclaimer of Warranty.
Except As Expressly Provided Otherwise Herein And To The Maximum Extent Permitted By Applicable Law, Anywhere Cart Disclaims
All Other Warranties With Respect To The Product, Whether Express, Implied, Statutory Or Otherwise, Including Without Limitation,
Satisfactory Quality, Course Of Dealing, Trade Usage Or Practice Or The Implied Warranties Of Merchantability, Fitness For A Particular
Purpose Or Noninfringement Of Third Party Rights.
4. Limitation of Liability.
In no event shall Anywhere Cart be liable for indirect, incidental, special, exemplary, punitive, or consequential damages of any nature
including, but not limited to, loss of profits, data, revenue, production, or use, business interruption, or procurement of substitute goods
or services arising out of or in connection with this limited warranty, or the use or performance of any product, whether based on
contract or tort, including negligence, or any other legal theory, even if Anywhere Cart has advised of the possibility of such damages.
Anywhere Cart’s total, aggregate liability for damages of any nature, regardless of form of action, shall in no event exceed the amount
paid by you to Anywhere Cart for the specific product upon which liability is based.
5. Governing Law and Your Rights.
This warranty gives You specific legal rights; You may also have other rights granted under state law. These rights vary from state to
state.
6. Warranty Period for Anywhere Cart Product Purchased:
AC-SLIM-PW45 Lifetime Frame, 2 Years Components, 2 Year Electronics
Limited Warranty
