Aosom 370-218V80 User manual

1
ASSEMBLY INSTRUCTION
INfad004_US_CA
370-218V80
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
* Suitable for ages 3-6 years.
* Maximum load: 40kg.
● 2.4G remote control
● Light control switch
● Power display
● Music
● High and low speed
● Forward and backward
● Volume adjustment
● Wireless connection ! WARNING: This product must be
assembled by an adult. When unassembled, there
are small and sharp parts, which could be choked on
if swallowed. Keep out the reach of small children.
Warning: Do not use in traffic.
EN
Assembly video please scan the QR code.
Vidéo d'assemblage, veuillez scanner le code QR.

2
L1
K1
J2
I1
E2
D2
C1
B1 A1
H1 G1 F4
Exhaust pipe Seat plate
Motor
Iron handlebar
Windshield Steering wheel
Handlebar
decoration
M1N2
Small plastic
cover Spanner
O1P2
Rear axle Big washer
Car body Front wheel
Wheel cover Seat
Rear wheel Steering plate
Rear fender
T8 S4 R6
Q1
Nut
M4x14 flat
screw
M4×30 flat screw M6×12 screw and
M6 nut R/C Charger
Trunk fixing plate Manual Small washer Cotter pin
Z1 Y1
X1 W1 V2
U6
Z1 1Z2 1

3
Battery
Suitable age
Loading capacity
Product size
Speed
Charge/Use time
Charger
Remote control
12V7AH*1
37-95 months
40kg
120*78*69cm
3-5 km/h
Charge 8-12h, use 1-2h
Input: 100-240V
Output: 12V 1000mA
AAA1.5V
Product Specifications:

4
⑥ ⑦
⑧
⑨
⑩
②
③
④
⑤

①
Function
Button function
1.Light control switch
2.Mode switch
3.Music switch/Volume -
4.Play/pause
5.Music switch/volume +
6. Power display
7.Power switch
8.High/low speed switch
9.Forward
10.Backward
11.Wireless connection
Features
- Supply voltage : 2 ×1.5V
- Frequency : 2.4GHz
2.4G remote control instructions
Button description
- Forward: Moves the car forward.
- Backward: Moves the car backward.
- Pairing: Connect the car to the remote control.
- Left: Turns the car left.
- Right: Turns the car right.
- Speed: Choose between low, medium and high.
- Brake: Bring the car to an immediate stop.

5
1
2
Pairing instructions
1. Turn the car on, then hold the pairing button until the speed indicator stays lit.
2. Stop holding the pairing button – the speed indicator will turn off.
3. If the speed indicator turns on again, the pairing is successful; if not, please repeat
steps 1 and 2.
4.Once pairing is successful, you do not to pair again in the future.
Remote control battery installation
Open the back cover of the remote control, then insert two AAA batteries. Pay attention
to the polarity. Close the back cover and tighten the screws when the LED is on,
indicating the battery is installed properly.
When the LED light dims or blinks, the batteries need replacing.
1. Iron handlebar assembly
Installation
1.Insert iron handlebar into its position on the car body, following the arrow.
2.Use two M4X30 flat screws to tighten. Do the same for the other side.
3.Flip the car and use one M4X30 flat screw to tighten. Do the same for the other side.
1
23
Bottom
2. Steering plate assembly
1. Insert the direction lever
into the steering plate hole,
then add one small washer
to the lever. Insert one
cotter pin into the lever hole
to tighten.
2. Tighten the steering plate,
using two M6X12 screws
and two M6 nuts.

6
3.Motor assembly
Insert the rear axle into the body, then install the motor correctly, following the left
and right labels on the motor and car body.
123
4. Rear wheel assembly
Add the rear wheel and one washer, then use the spanner to tighten the nut. Insert
wheel cover into the rear wheel. Repeat for the other side.
5. Front wheel assembly
Add one washer, the front wheel, then another washer – use a spanner to tighten the
nut. Insert wheel cover into the rear wheel. Repeat for the other side.

7
6. Steering wheel, Handlebar decoration,
windshield assembly
7.Motor line and battery line connection
1. Unscrew the steering wheel and insert it into the direction lever, then use the screw
and nut to tighten.
2. Insert the handlebar decoration into the reserved hole on the platform.
3. Insert the windshield into the reserved hole on the car.
12
3
1. Connect the motor line connector (no need to distinguish between left and right).
2. Connect the red battery line to the red terminal.

8
8.Small plastic cover, trunk fixing plate and rear
fender assembly
1. Insert the plastic cover into the reserved place on the car.
2. Remove the fixing plate from the trunk, then insert it into the right place on the car.
Use two M4X14 flat screws to tighten.
3. Insert the rear fender into its position on the car, then use four M4X14 flat screws to
tighten.
9.Seat plate, exhaust pipe and seat assembly.
1.Insert the seat plate and exhaust pipe (distinguish between left and right) into the
hole on the car.
2.Insert the seat into its position in the car, then use two M4X14 flat screws to tighten.
R1
L
2
WARNING
- For children's safety, please follow these instructions carefully.
- Adult assembly and adjustment are required, keep children away.
- Small parts are present when assembling, keep small children away to prevent
choking.
- Children must wear the safety belt when riding.
- Adult supervision is always required when riding. Teach children how to ride before
using.
- Never stand or play when the product is moving.
- Battery to be charged by adults only. Fully charge the product before first use.
- Keep children away from plastic packaging to prevent suffocation.
- Only use spare parts that are provided by the manufacturer.

9
Safety use
- Do not use in the street, on the road or near slopes and ditches.
- Do not change the wire or add electrical devices to the car.
- Use in a dry area, keeping away from wet conditions. Keep away from open flames.
- Suitable for 1-2 children. Do not overload.
- Maximum capacity is 40kg.
- When not in use, switch off the power. If not in use for a long period, unplug the
battery.
- Check battery, charger and other parts regularly. If damages are found, ensure they
are fixed before using.
- Before the first use, charge for 8-12 hours.
- Place the charger into the hole under the seat, then plug the charger into the socket.
- The car cannot be used when charging.
- Do not charge for more than 20 hours.
- When charging, it is normal for the battery and charger to be warm.
- Do not charge if the plug is wet to avoid electrical hazards or a short circuit.
- Only use the charger provided by the manufacturer. Any other charger can damage
the battery or cause a short circuit.
- If not in use for a long period, ensure it gets charged once a month.
Charging notification
Charging steps are as follows:
Step 1: The charging hole is under the seat.
Step 2: Put the charger plug into the hole.
Step 3: Connect the charger to a power socket.
Warning: Car must be charged by an adult. This product cannot be used when
charging.
- The charger is not a toy and shouldn't be played with.
- Maximum load: 40kg. Do not overload.
- Suitable age: 3-6 years.

10
Maintenance and Service
● Check battery, charger and other parts regularly. If there are any damages, ensure it
is fixed before using.
● Use lubricating oil for parts. Keep this product away from open flames and out of
direct sunlight.
● Store indoors and use a water-resistant cover.
● Keep away from flammable materials to avoid fire hazards.
● Charge the product after each use.
● Clean with a dry cloth. Do not use chemical solvents to wipe plastic parts. Do not
wash with water. Do not use when raining or snowing – water can damage the motor,
electric system or battery.
● Switch off the power after each use.
● Only use the charger provided by the manufacturer.
● Do not modify this car or its electric wire in any way.
