Apogee GiO User manual

QuickStart Guide
support.apogeedigital.com

GiO Quickstart Guide 1
Contents
1 Introduction
2 PackageContents
3 IntroducingGiO
4 SystemRequirements
4-12 GettingStarted
4 InstallApogeeSoftware
5 ConnectUSB
6 ChooseGiOforMacSoundI/O
6 ConnectHeadphonesorSpeakers
7 ConnectYourGuitar
8-12 SetupGarageBand
11 UsingGiO’sStompboxButtons
12 Record!
Introduction
GiOisaUSBGuitarInterfaceandControllerfortheMac.
ThisQuickStartguidedescribeshowtosetupGiOwithyourMac,connectspeakers,
headphonesandinstrumentstoGiO,andgetstartedquicklywithGarageBand.
ForacompletedescriptionofGiO,includinginformationonhowtouseGiOwith
awidearrayofhardwareandsoftware,pleaseconsultthecompleteUser’sGuide,
foundontheincludedsoftwareCD.Youcanalsondthemostup-to-dateinfor-
mationatourwebsite:
http://support.apogeedigital.com

GiO Quickstart Guide
2
Package Contents
GiO
1/4”toRCACable
USBCable
QuickStartGuide

GiO Quickstart Guide 3
Introducing GiO
InstrumentInput Headphone/SpeakerOutput
USBPort
Stompboxbuttonsandindicators
ExpressionPedalInput
Previousbutton Nextbutton
Transportcontrolbuttons

GiO Quickstart Guide
4
System Requirements
YourMacshouldmeetthefollowingrequirements:
 IntelorPPCG5processor,OSX10.5.7orgreater
 1GBminimumofinstalledRAM,2GBrecommended
 GarageBand‘09version5.1and/orLogicStudio9.
(Pleaseconsultourwebsiteforthemostup-to-datecompatibility
information:http://support.apogeedigital.com.)
Getting Started
Install Apogee Software
DownloadthelatestGiOsoftwareinstallerhere:
http://www.apogeedigital.com/downloads.php

GiO Quickstart Guide 5
Connect the USB Cable
ConnectGiO’sUSBport
toaUSBportonyour
Macusingtheprovided
cable.GiOispowered
throughtheUSBcon-
nection.
OncetheUSBconnectionismade,theTransportbuttonslightinsequenceandall
Stompboxindicatorslightgreen,indicatingthatGiOisreadyforuse.

Choose GiO for Mac Sound I/O
AfterconnectingGiOtoyourMac,a
dialogboxpromptsyoutochoose
GiOforMacsoundoutputand
input.ClickYes.

Connect Headphones or Speakers
ConnectheadphonestoGiO’sbackpanel
Outputjack.
Toconnectapairofpoweredspeakers
usingtheincluded1/4”TRStodualRCA
cable,connectthe1/4”TRSplugtoGiO’s
Output jack.Next,connectthewhite-
bandedRCAplugtotheleftspeakerand
thered-bandedRCAplugtotheright
speaker
GiO Quickstart Guide
6

GiO Quickstart Guide 7
Connect Your Guitar
ConnectyourguitartotheInstrumentinputusingastandard1/4”guitarcable.
ShownbelowisatypicalGiOsetupshownwithoptionalexpressionpedal.

GiO Quickstart Guide
8
Set up GarageBand ‘09
OpenGarageBand,foundinyourMac’s
Applicationsfolder.IntheProjectWindow
thatappearsduringlaunch,clickElectric
Guitar thenclickChoosetocreateanaudio
track.
InGarageBand,double-clicktheTrack
headertoshowtheTrackInfopane.Atthe
topofthepane,clickGuitar Track.
Chooseaguitarpresetfromthepop-up
menuatthetopoftheTrackInfopane.You
canscrollthroughthepresetlistbytapping
GiO’sPreviousorNextbutton.

GiO Quickstart Guide 9
Set up GarageBand ‘09 (continued)
ClickEdit(atthetopoftheTrackInfo
pane)andclickontheguitarampto
highlightit.
Atthebottomofthepane,selectMono1
(GiO)intheInputSourcemenuandselect
OnintheMonitormenu.IfGiOcan’tbe
selectedintheInputSourcemenu,please
seethenextpage.
Clickthefadersbuttontotherightofthe
InputSourcemenutoopentheApogeeGiO
controlpanel.

GiO Quickstart Guide
10
GarageBand Preferences
IfGiOcan’tbeselectedintheInputSource
menu,openGarageBandPreferences
(GarageBand>Preferences),clickAudio/
MIDI,andselectGiOintheAudioOutput
andAudioInputmenus.
Important!Toexperiencethefullaudio
resolutionofGiO,openGarageBand
Preferences,clickAdvanced,andselect
BestintheAudioResolutionmenu.

GiO Quickstart Guide 11
Using GiO’s Stompbox Buttons
WhenyouloadaGarageBandguitarpreset
thatincludesstompboxes,eachofGiO’s
Stompboxindicatorslighttoacolorthat
correspondstothestompboxesselected
inthepreset.PressGiO’sstompboxswitch
toturntheeecton-theindicatorglows
brightly.Pressagaintoturntheeect
o-theindicatorglowsdimly.
Set the Input Level
ClicktheGarageBandtrack’sRecord
enablebuttontoseetheinputsignallevel
onthetrackmetersandhearitinyour
headphones.

GiO Quickstart Guide
12
IntheApogeeGiOcontrolpanel,adjustthe
RecordingLevelslideruntilanadequate
signallevelisdisplayedinthetrackmeters.
SeetheGiOUser’sGuideforamore
detaileddescriptionofhowtosetrecording
levels.
Record!
Onceyou’vesetalevel,taptheRecord
Transportbutton.Thenewlycreatedregion
appearsinGarageBand’stimeline.Once
you’vecompletedrecording,tapthePlay
buttontostoprecording,tapeithertheGo
ToBeginningorRewindbutton,andtap
Playtolistenbacktoyourrecording.

ForFAQsandmoreGiOsupportinformation,
pleasevisittheApogeeWebsite:
http://support.apogeedigital.com
ApogeeElectronicsCorporation
1715BerkeleySt.
SantaMonica,CA90404U.S.A.
+1(310)584-9394
email:[email protected]
GiO QuickStart Guide - Version 1.1 • Apogee Part #: 7010-2346-0000
